Product 141027

Description
Brake pad set
Axe
Rear
No. of Pieces
4
Barcode
EAN13 Code
8424073016751
QR Code
Url
https://catalogonuevo.icerbrakes.com/Producto/Details?idProducto=141027
Weight (gr.)
1047
System
Sumitomo
R90 Homologation
R90 90R-01100/220
Measures
115.9x43.9x15.5
Reference applications
Brand OE Reference
IKARUS 04465-60010
LEXUS 04466-60060
LEXUS 04466-60090
MITSUBISHI 46 05A 389
MITSUBISHI 46 05A 458
MITSUBISHI MZ 690 577
TOYOTA 04466-60010
TOYOTA 04466-60020
TOYOTA 04466-60040
TOYOTA 04466-60050
TOYOTA 04466-60080
TOYOTA 04466-60140
TOYOTA 04466-YZZC8
TOYOTA 04492-60010
TOYOTA 04492-60020
TOYOTA 04492-60050
TOYOTA 04492-60080
Maker Cross reference
ATE 13.0460-5744.2
ATE 605744
B.M. DB1200
BENDIX ANTIGUO 572245B
BENDIX-ROULUNDS 510735
BOSCH 0 986 424 313
BREMBO P 83 024
DELPHI LOCKHEED LP963
FERODO FDB1021
FMSI D606-7487
GIRLING 6111829
GIRLING 6132809
HELLA-PAGID 8DB 355 016-831
HELLA-PAGID T3064
MINTEX MDB1696
NECTO FD6698A
ROAD HOUSE 2413.00
TEXTAR 21947 150 0 4
TEXTAR 21947 150 0 4 T4067
TEXTAR 2194701
TEXTAR 2194703
TRW GDB1182
TRW GDB3280
VALEO 598777
WVA 21947
BAIC WEIWANG
007 () SUV 05/2015-
Vehicle Engine Fuel Date CC KW CV Traction
2.0

4G20-D4

 1 05/2015- 1977 90 122 2
2.0 T

4G63-S4T

 1 05/2015- 1977 140 190 2
2.0 T 4x4

4G63-S4T

 1 05/2015- 1977 140 190 3
BAW
LUBA () Hatchback 06/2003-
Vehicle Engine Fuel Date CC KW CV Traction
2.4 1 01/2005- 2351 96 129 1
2.4 1 01/2005- 2351 96 129 1
2.4 1 01/2005- 2438 105 143 1
2.4 1 01/2005- 2438 105 143 1
2.7 1 01/2005- 2693 110 150 1
2.7 1 01/2005- 2693 110 150 1
3.0 1 01/2005- 2960 118 158 1
3.4 1 01/2005- 3378 136 182 1
YUSHENG 007 () Hatchback 01/2011-
Vehicle Engine Fuel Date CC KW CV Traction
2.0 1 01/2011- 1977 90 122 1
2.4 1 01/2011- 2438 105 143 1
2.4 1 01/2011- 2438 105 143 1
CHANGAN
CX30 () Hatchback 01/2009-12/2012
Vehicle Engine Fuel Date CC KW CV Traction
1.6 1 05/2010- 1590 78 106 1
2.0 1 05/2010- 1998 112 152 1
CX30 () Saloon 12/2010-
Vehicle Engine Fuel Date CC KW CV Traction
1.6 1 12/2010- 1590 78 106 1
2.0 1 12/2010- 1998 112 152 1
FUQI
FQ6480 () Hatchback 02/1999-
Vehicle Engine Fuel Date CC KW CV Traction
4.5 1 02/1999- 4477 151 205 1
JMC
YUHU 5 () Pickup 01/2018-
Vehicle Engine Fuel Date CC KW CV Traction
2.0

JX4D20A6L

 2 10/2019- 1998 104 141 2
2.0 4x4

JX4D20A6L

 2 10/2019- 1998 104 141 3
2.4

JX4D24A5L

 2 01/2018- 2402 103 140 2
2.4 4x4

JX4D24A5L

 2 01/2018- 2402 103 140 3
LEXUS
GX (_J12_) SUV 11/2001-11/2009
Vehicle Engine Fuel Date CC KW CV Traction
470 (UZJ120)

2UZ-FE

 1 11/2001-11/2009 4664 175 238 3
470 (UZJ120)

2UZ-FE

 1 11/2001-11/2009 4664 199 271 3
GX II (URJ15_, GRJ15_) SUV 11/2009-
Vehicle Engine Fuel Date CC KW CV Traction
460 4WD (URJ150)

1UR-FE

 1 01/2010- 4608 218 296 3
460 4WD (URJ150)

1UR-FE

 1 01/2010- 4608 225 306 3
LX I-II (U.S.A.) SUV 09/1995-12/1997
Vehicle Engine Fuel Date CC KW CV Traction
450 4WD (FZJ80_)

1FZ-FE

 1 09/1995-12/1997 4477 151 205 3
MITSUBISHI
PAJERO III / MONTERO / SHOGUN (V6_W, V7_W) Open Off-Road Vehicle 02/2000-12/2006
Vehicle Engine Fuel Date CC KW CV Traction
3.2 D 2 04/2000-12/2006 3200 121 165 2
PAJERO IV FULL / MONTERO / SHOGUN (V8_W, V9_W) SUV 10/2006-
Vehicle Engine Fuel Date CC KW CV Traction
3.2 DI-D 1 01/2009- 3200 153 208 1
3.5 4WD 1 11/2013- 3497 147 200 1
3.5 Flex 4WD 1 08/2009- 3497 151 205 1
3.8 i 4WD (V97W, V87W)

6G75

 1 01/2009- 3828 175 238 3
3.8 V6 (V87W, V97W)

6G75

 1 02/2007- 3828 184 250 3
3.8 V6 (V87W)

6G75

 1 10/2006- 3828 182 248 3
3.2 4WD (V98W)

4M41

 2 10/2016- 3200 141 192 3
3.2 DI-D (V88W, V98W)

4M41

 2 02/2007- 3200 118 160 3
3.2 DI-D (V88W, V98W)

4M41

 2 02/2007- 3200 125 170 3
3.2 DI-D 4WD

4M41

 2 11/2008- 3200 121 165 3
3.2 DI-D 4WD (V98W, V88W)

4M41

 2 02/2007- 3200 140 190 3
3.2 DI-D 4WD (V98W, V88W)

4M41

 2 01/2009- 3200 147 200 3
PAJERO IV / MONTERO / SHOGUN (V9_, V8_, V8_V) Closed Off-Road Van 11/2006-
Vehicle Engine Fuel Date CC KW CV Traction
3.2 DI-D

4M41

 2 11/2006- 3200 118 160 3
3.2 DI-D 4WD (V88W, V98W)

4M41

 2 02/2007- 3200 140 190 3
3.2 TD 4WD (V88V, V98V)

4M41

 2 01/2010- 3200 147 200 3
PAJERO SPORT II / PAJERO DAKAR / CHALLENGER / MONTERO SPORT / NATIVA (KH_, KG_) Closed Off-Road Vehicle 01/2008-
Vehicle Engine Fuel Date CC KW CV Traction
3.2 DI-D 4WD 2 11/2013-12/2018 3200 132 180 3
TOYOTA
4RUNNER IV (_N21_) SUV 08/2002-12/2009
Vehicle Engine Fuel Date CC KW CV Traction
4.0 (GRN210)

1GR-FE

 1 09/2005-09/2009 3956 174 237 2
4.0 (GRN210)

1GR-FE

 1 11/2002-07/2009 3956 183 249 2
4.0 (GRN215)

1GR-FE

 1 09/2005-09/2009 3956 174 237 3
4.0 4WD (GRN215)

1GR-FE

 1 01/2003-12/2009 3956 183 249 3
4.7 (UZN210_)

2UZ-FE

 1 08/2002-09/2006 4663 175 238 2
4.7 (UZN210)

2UZ-FE

 1 01/2005-12/2009 4663 194 264 2
4.7 4WD (UZN215_)

2UZ-FE

 1 08/2002-09/2006 4663 175 238 3
4.7 4WD (UZN215)

2UZ-FE

 1 01/2005-12/2009 4663 194 264 3
4 RUNNER V / SW4 (_N28_) SUV 03/2009-
Vehicle Engine Fuel Date CC KW CV Traction
2.7 1 03/2009- 2694 116 158 1
4.0 (GRN280_)

1GR-FE

 1 01/2010- 3956 202 275 2
FJ CRUISER (GSJ1_) SUV 06/2005-
Vehicle Engine Fuel Date CC KW CV Traction
4.0 (GSJ15)

1GR-FE

 1 06/2005-10/2009 3956 176 239 2
4.0 (GSJ15)

1GR-FE

 1 01/2006-12/2011 3956 178 242 2
4.0 (GSJ15)

1GR-FE

 1 01/2010-06/2014 3956 191 260 2
4.0 4WD (GSJ15_, GSJ15R)

1GR-FE

 1 12/2010- 3956 200 272 3
4.0 4WD (GSJ15_, GSJ15W)

1GR-FE

 1 06/2005-01/2018 3956 203 276 3
4.0 4WD (GSJ15_)

1GR-FE

 1 01/2006-01/2018 3956 178 242 3
4.0 4WD (GSJ15_)

1GR-FE

 1 01/2010-06/2014 3956 191 260 3
4.0 4WD (GSJ15)

1GR-FE

 1 06/2005-12/2009 3956 176 239 3
FORTUNER II / SW4 (_N15_, _N16_) SUV 05/2015-
Vehicle Engine Fuel Date CC KW CV Traction
2.8 D 4x4 (GUN156)

1GD-FTV

 2 05/2015- 2755 130 177 3
LAND CRUISER (_J7_, _JL7_) Closed Off-Road Vehicle 03/1984-
Vehicle Engine Fuel Date CC KW CV Traction
2.4 (RJ70_, RJ73_, RJ70RV)

22R

 1 11/1984-05/1993 2367 81 110 3
2.4 (RJ70_, RJ73_)

22R

 1 11/1984-05/1993 2367 77 105 3
2.4 (RJ70_V, RJ73_V)

22RE

 1 12/1988-12/1996 2367 84 114 3
2.4 TD (LJ70_, LJ73_, LJ70RV)

2L-T

 2 10/1985-05/1990 2446 63 86 3
2.4 TD (LJ70)

2L-T

 2 01/1990-05/1993 2446 66 90 3
2.8 D 4x4 (LJ79) 2 04/1990-03/1996 2779 61 83 3
3.0 TD (KZJ70_, KZJ73_, KZJ77_, KZJ78, KZJ71)

1KZ-T

1KZ-TE

 2 05/1993-05/1996 2982 92 125 3
3.4 D (BJ70_V, BJ73_)

3B

 2 11/1984-12/1996 3432 70 95 3
3.5 D 4x4 (PZJ75, PZJ70)

1PZ

 2 01/1990-12/1994 3470 85 116 3
4.0 TD 4x4 (RJ70_, LJ70_, BJ7_, HJ75_, FJ7_)

12HT

 2 01/1997-08/2001 3980 100 136 3
4.2 D (HZJ76, HZJ78, HZJ70, HZJ73, HZJ75, HZJ79, HZJ77,...

1H-Z

 2 01/1990- 4164 96 131 3
LAND CRUISER (_J7_) Open Off-Road Vehicle 11/1984-08/2001
Vehicle Engine Fuel Date CC KW CV Traction
2.4 TD (LJ70_, LJ70R)

2L-T

 2 07/1990-05/1996 2446 66 90 3
3.0 TD (KZJ70_, KZJ70R)

1KZ-T

 2 05/1993-05/1996 2982 92 125 3
LAND CRUISER 80 (_J8_) Closed Off-Road Vehicle 01/1990-02/2001
Vehicle Engine Fuel Date CC KW CV Traction
2.4 (FJ80) 1 01/1990-05/1993 2367 77 105 3
4.0 (FJ80_, FJ80R, FJ80G)

3F-E

 1 01/1990-10/1992 3956 115 156 3
4.5 1 08/1992-01/1998 4477 215 292 1
4.5 24V (FZJ80_)

1FZ-FE

 1 08/1992-12/1997 4477 151 205 3
4.5 4WD (FZJ80_)

1FZ-FE

 1 08/1992-01/1998 4477 215 292 3
3.0 TD 2 01/1990-09/1991 2982 92 125 3
3.4 D 2 01/1990-12/1996 3431 70 95 2
3.5 D

1PZ

 2 01/1990-08/1992 3470 85 116 3
4.2 D (HZJ80, HZJ81)

1H-Z

 2 01/1990-12/1997 4164 99 135 3
4.2 TD (HDJ80, HDJ81)

1HD-T

 2 01/1990-12/1997 4164 123 167 3
4.2 TD (HDJ80)

1HD-T

 2 08/1992-12/1997 4164 118 160 3
4.2 TD 24V (HDJ80_, HDJ80, HDJ81V)

1HD-FT

 2 01/1995-12/1997 4164 125 170 3
LAND CRUISER 90 (_J9_) Closed Off-Road Vehicle 04/1995-
Vehicle Engine Fuel Date CC KW CV Traction
2.7 (RZJ95, RZJ90)

3RZ-FE

 1 06/1995-08/2002 2694 110 150 3
3.4 i 24V (VZJ90_, VZJ95_, VZJ90R, VZJ95R, VZJ90W,...

5VZ-FE

 1 03/1996-08/2002 3378 131 178 3
4.7 1 08/2002- 4664 175 238 3
3.0 D-4D 4WD (KDJ90_, KDJ95_, KDJ90W, KDJ95W)

1KD-FTV

 2 08/2000-08/2002 2982 120 163 3
3.0 TD (KZJ90_, KZJ95_, KZJ90R, KZJ95R, KZJ90W, KZJ95W)

1KZ-TE

 2 04/1996-12/2002 2982 92 125 3
3.0 TD (KZJ90, KZJ95)

1KZ-TE

 2 04/1995-07/2000 2982 103 140 3
4.2 D

1H-Z

 2 08/1999-08/2001 4164 123 167 3
LAND CRUISER 100 (_J1_) Closed Off-Road Vehicle 01/1998-07/2008
Vehicle Engine Fuel Date CC KW CV Traction
4.2 D (HZJ105)

1H-Z

 2 03/1998-08/2007 4164 96 131 3
LAND CRUISER PRADO (_J12_) Closed Off-Road Vehicle 09/2002-12/2010
Vehicle Engine Fuel Date CC KW CV Traction
2.7 (TRJ120, TRJ125)

2TR-FE

 1 11/2003-02/2010 2694 120 163 3
3.4 (VZJ121, VZJ125, VZJ120) 1 09/2002-07/2005 3378 136 185 3
4.0 (GRJ120, GRJ125, GRJ121)

1GR-FE

 1 12/2002-12/2010 3956 183 249 3
4.0 (GRJ120)

1GR-FE

 1 09/2002-08/2010 3956 179 243 3
4.0 V6 VVT-i (GRJ125)

1GR-FE

 1 01/2003-07/2009 3956 207 282 3
3.0 D (KZJ120, KDJ125, KDJ121)

1KZ-TE

 2 09/2002-07/2009 2982 92 125 3
3.0 D (LJ120, LJ125)

5L-E

 2 09/2002-02/2010 2986 70 95 3
3.0 D-4D (KDJ120_)

1KD-FTV

 2 08/2006-07/2009 2982 150 204 3
3.0 D-4D (KDJ120, KDJ125, KDJ121)

1KD-FTV

 2 09/2002-08/2009 2982 120 163 3
3.0 D-4D (KDJ120, KDJ125, KDJ121)

1KD-FTV

 2 07/2004-08/2009 2982 122 166 3
3.0 D-4D (KDJ120, KDJ125, KDJ121)

1KD-FTV

 2 09/2002-12/2010 2982 127 173 3
4.5 D 2 02/2005-02/2010 4461 151 205 2
LAND CRUISER PRADO (_J15_) Closed Off-Road Vehicle 07/2009-
Vehicle Engine Fuel Date CC KW CV Traction
3.5 (GRJ152_)

7GR-FKS

 1 09/2015- 3456 206 280 3
4.0 V6 Dual VVTi (GRJ150_)

1GR-FE

 1 08/2009- 3956 205 279 3
4.0 V6 VVT-i (GRJ150_, GRJ125_, GRJ150)

1GR-FE

 1 08/2009- 3956 207 282 3
4.0 V6 VVTi (GRJ150_, GRJ150R, GRJ150W)

1GR-FE

 1 11/2012- 3956 183 249 3
4.0 V6 VVTi (GRJ150)

1GR-FE

 1 08/2009- 3956 202 275 3
2.8 D-4D (GDJ150_, GDJ155_, GDJ150, GDJ151)

1GD-FTV

 2 06/2015- 2755 130 177 3
2.8 D-4D (GDJ150, GDJ155)

1GD-FTV

 2 10/2018- 2755 147 200 3
2.8 D-4D (GDJ155, GDJ150)

1GD-FTV

 2 07/2020- 2755 150 204 3
3.0 D-4D (KDJ150_, KDJ150, KDJ155)

1KD-FTV

 2 08/2009- 2982 127 173 3
3.0 D-4D (KDJ155_, KDJ150_, KDJ150R, KDJ155R)

1KD-FTV

 2 08/2009- 2982 140 190 3
3.0 TDi (KDJ150_)

1KD-FTV

 2 08/2009- 2982 120 163 3
LAND CRUISER PRADO VAN (_J15_) Closed Off-Road Van 01/2011-
Vehicle Engine Fuel Date CC KW CV Traction
3.0 D4d 4WD (KDJ155, KDJ150)

1KD-FTV

 2 01/2011- 2982 140 190 3
SEQUOIA (_K3_, _K4_) SUV 05/2000-10/2007
Vehicle Engine Fuel Date CC KW CV Traction
4.7 (UCK35_, UCK35L)

2UZ-FE

 1 09/2000-10/2007 4664 175 238 2
4.7 (UCK35)

2UZ-FE

 1 05/2004-10/2007 4664 201 273 2
4.7 32V 1 05/2000- 4695 201 273 1
4.7 32V 4WD 1 05/2000- 4695 201 273 1
4.7 4WD (UCK35)

2UZ-FE

 1 05/2004-10/2007 4664 201 273 3
4.7 4WD (UCK45_, UCK45L)

2UZ-FE

 1 09/2000-10/2007 4664 175 238 3
TOYOTA (FAW)
PRADO (_J12_) Closed Off-Road Vehicle 01/2003-06/2010
Vehicle Engine Fuel Date CC KW CV Traction
4.0 A las 4 ruedas (GRJ120, GRJ121, GRJ125)

1GR-FE

 1 10/2003-06/2010 3956 179 243 3
Return
