Product 181781

Description
Brake pad set
Axe
Front
No. of Pieces
4
Barcode
EAN13 Code
8424073095657
QR Code
Url
https://catalogonuevo.icerbrakes.com/Producto/Details?idProducto=181781
Weight (gr.)
1655
System
Sumitomo
R90 Homologation
R90 90R-01111/1396
Measures
119.3x68.1x17
Reference applications
Brand OE Reference
TOYOTA 04465-04030
TOYOTA 04465-04050
TOYOTA 04465-04060
TOYOTA 04465-04630
TOYOTA 04465-0J140
TOYOTA 04465-0K070
TOYOTA 04465-0K140
TOYOTA 04465-0K210
Maker Cross reference
ATE 13.0460-5503.2
ATE 605503
B.M. DB1323
B.M. DB1739
BENDIX ANTIGUO 572625B
BENDIX-ROULUNDS 510774
BREMBO P 83 069
BREMBO P 83 151
DELPHI LOCKHEED LP2242
FERODO FDB1852
FMSI D799-7671
GIRLING 6134289
HELLA-PAGID 8DB 355 020-811
HELLA-PAGID T1718
MINTEX MDB1947
MINTEX MDB2203
NECTO FD7223A
ROAD HOUSE 2315.22
TEXTAR 21680 175 0 5
TEXTAR 2168003
TRW GDB3213
TRW GDB3428
VALEO 601810
WVA 21679
WVA 21680
TOYOTA
FORTUNER / SW4 (_N5_, _N6_) SUV 06/2004-09/2015
Vehicle Engine Fuel Date CC KW CV Traction
2.7 (TGN61_, TGN61R)

2TR-FE

 1 06/2004-05/2015 2694 118 160 2
2.7 (TGN61_)

2TR-FE

 1 03/2009-05/2015 2694 116 158 2
2.7 4WD (TGN51_, TGN51R)

2TR-FE

 1 06/2004-05/2015 2694 118 160 3
2.7 4WD (TGN51_)

2TR-FE

 1 08/2008-03/2015 2694 116 158 3
2.7 Flexfuel 1 01/2012-05/2015 2694 120 163 1
4.0 (GGN50_, GGN60_)

1GR-FE

 1 07/2005-05/2015 3956 175 238 2
4.0 4WD (GGN50_, RZN215, GGN60) 1 01/2005-05/2015 3956 173 235 3
2.5 D-4D 4WD (KUN50)

2KD-FTV

 2 01/2009-05/2015 2494 75 102 3
2.5 D-4D 4WD (RZN215, KUN50)

2KD-FTV

 2 07/2011-05/2015 2494 106 144 3
3.0 D 2 08/2009-05/2015 2982 120 163 2
3.0 D (KUN61_) 2 01/2005-05/2015 2982 126 171 2
3.0 D (KUN61) 2 08/2009-05/2015 2982 125 170 2
3.0 D 4WD (KUN51_)

1KD-FTV

 2 08/2009-05/2015 2982 126 171 3
3.0 D 4WD (KUN51)

1KD-FTV

 2 06/2004-05/2015 2982 120 163 3
3.0 TDI 2 12/2013- 2982 130 177 2
HiLux IV-VI (LN_, _N1_) Platform/Chassis 08/1983-08/2005
Vehicle Engine Fuel Date CC KW CV Traction
2.7 EFI (RZN154, RZN149)

3RZ-FE

 1 08/1997-08/2005 2694 107 145 2
HILUX V (_N_, KZN1_, VZN1_) Pickup 09/1988-08/2001
Vehicle Engine Fuel Date CC KW CV Traction
3.0 4WD (RN37_, RN42_, VZN130)

3VZ-E

 1 09/1988-08/1997 2959 105 143 3
HILUX VI (_N1_) Pickup 08/1994-03/2006
Vehicle Engine Fuel Date CC KW CV Traction
2.7 EFI (RZN154, RZN149)

3RZ-FE

 1 01/1998-07/2004 2694 107 145 2
2.7 EFI 4WD (RZN140, RZN169)

3RZ-FE

 1 06/1997-12/2000 2694 110 150 3
3.0 (VZN130_) 1 08/2001-07/2005 2959 105 143 2
3.4 EFI (VZN167R, VZN172R) 1 08/2001-07/2005 3378 131 178 2
3.4 EFI 4WD (VZN167, VZN172) 1 08/2001-07/2005 3378 131 178 3
2.5 D-4D 4WD (KDN165, KDN170, KDN190)

2KD-FTV

 2 11/2001-07/2005 2494 75 102 3
3.0 D (LN147, LN152) 2 01/2002-02/2005 2986 67 91 2
3.0 D 4WD (LN172, LN167)

5L

 2 08/1997-07/2005 2986 67 91 3
HiLux SUV VI / SW4 (_N1_, _N2_) SUV 01/1995-08/2005
Vehicle Engine Fuel Date CC KW CV Traction
2.7 EFI (RZN149) 1 08/2001-07/2004 2694 107 145 2
3.4 4WD (KYN195)

5VZ-FE

 1 08/2000-07/2005 3378 131 178 3
3.4 EFI 4WD (VZN185) 1 11/1995-07/2000 3378 136 185 3
3.0 D 2 08/2002-07/2004 2986 67 91 2
HiLux VII / HiLux (VIGO) (_N1_, _N2_, _N3_) Pickup 08/2004-
Vehicle Engine Fuel Date CC KW CV Traction
2.0 VVTi (KGN15_, TGN15_, TGN15R)

1TR-FE

 1 08/2005-05/2015 1998 108 147 2
2.0 VVTi (TGN10, TGN15, TGN16)

1TR-FE

 1 06/2005-05/2015 1998 100 136 2
2.7 VVTi (TGN16)

2TR-FE

 1 08/2005-05/2015 2694 118 160 2
2.7 VVTi 4WD (TGN26)

2TR-FE

 1 08/2005-05/2015 2694 118 160 3
4.0 V6 VVTi (GGN15) 1 08/2005-02/2016 3956 175 238 2
4.0 V6 VVTi 4WD (GGN25)

1GR-FE

 1 08/2005-02/2016 3956 175 238 3
2.5 D 4WD (KUN25)

2KD-FTV

 2 03/2005-05/2015 2494 75 102 3
2.5 D-4D (KUN15_, KUN15R)

2KD-FTV

 2 06/2006-05/2015 2494 88 120 2
2.5 D-4D (KUN15, KUN10)

2KD-FTV

 2 03/2005-05/2015 2494 75 102 2
2.5 D-4D 4WD (KUN25_, KUN25R)

2KD-FTV

 2 06/2006-05/2015 2494 88 120 3
2.5 D-4D 4WD (KUN25_)

2KD-FTV

 2 11/2004-12/2005 2494 94 128 3
2.5 D-4D 4WD (KUN25)

2KD-FTV

 2 12/2007-05/2015 2494 106 144 3
3.0 D-4D 4WD (KUN26)

1KD-FTV

 2 03/2005-05/2015 2982 120 163 3
3.0 D-4D 4WD (KUN26)

1KD-FTV

 2 08/2005-09/2015 2982 126 171 3
3.0 D-4D 4WD (KUN26)

1KD-FTV

 2 05/2008-12/2012 2982 145 197 3
HiLux VII (_N1_, _N2_) Platform/Chassis 02/2005-
Vehicle Engine Fuel Date CC KW CV Traction
4.0 V6 VVTi (GGN15R) 1 02/2005- 3956 175 238 2
4.0 V6 VVTi 4WD (GGN25R) 1 02/2005- 3956 175 238 3
3.0 D 4WD (KUN26)

1KD-FTV

 2 02/2005- 2982 126 171 3
3.0 D-4D (KUN16R) 2 02/2005- 2982 126 171 2
TACOMA (_N1_) Pickup 09/1994-08/2004
Vehicle Engine Fuel Date CC KW CV Traction
2.4 16V 1 09/1994- 2395 1
2.4 16V 4WD 1 09/1994- 2395 1
2.7 16V 1 09/1994- 2695 1
2.7 16V 4WD 1 09/1994- 2695 1
3.4 16V 4WD 1 09/1994- 3395 1
3.4 24V 1 09/1994- 3395 1
TACOMA () Pickup 01/1995-
Vehicle Engine Fuel Date CC KW CV Traction
2.4 16V 1 01/1995- 2395 1
2.4 16V 4WD 1 01/1995- 2395 1
2.7 16V 1 01/1995- 2695 1
2.7 16V 4WD 1 01/1995- 2695 1
3.4 16V 4WD 1 01/1995- 3395 1
3.4 24V 1 01/1995- 3395 1
TACOMA (U.S.A.) Pickup 09/1995-12/2006
Vehicle Engine Fuel Date CC KW CV Traction
2.4 16V 1 09/1995- 2395 1
2.4 16V 4WD 1 09/1995- 2395 1
2.7 16V 1 09/1995- 2695 107 145 1
3.4 24V 1 09/1995- 3395 1
