Product 181784 - Web Catalogo

Description: Brake pad set
Axe: Front
No. of Pieces: 4
Barcode: 8424073095701
Url: https://catalogonuevo.icerbrakes.com/Producto/Details?idProducto=181784
Weight (gr.): 1670

System: Tokico
R90 Homologation: 90R-01111/2463
Measures: 155.4x50.9x16

Reference applications

Brand	OE Reference
FIAT	6 000 609 714
FIAT	6 000 609 715
FIAT	6 000 611 054
MITSUBISHI	46 05A 198
MITSUBISHI	46 05A 284
MITSUBISHI	46 05A 623
MITSUBISHI	46 05A 631
MITSUBISHI	46 05A 632
MITSUBISHI	46 05A 633
MITSUBISHI	46 05A 930
MITSUBISHI	46 05B 158
MITSUBISHI	46 05B 233
MITSUBISHI	46 05B 290
MITSUBISHI	MQ 704 260
MITSUBISHI	MZ 690 356
MITSUBISHI	MZ 690 587

Maker	Cross reference
ATE	13.0460-5570.2
ATE	13.0460-5631.2
ATE	605570
ATE	605631
BENDIX ANTIGUO	572574B
BENDIX-ROULUNDS	510686
BENDIX-ROULUNDS	511395
BOSCH	0 986 460 069
BOSCH	0 986 494 211
BOSCH	0 986 494 268
BREMBO	P 54 038
BREMBO	P 54 055
DELPHI LOCKHEED	LP2074
DELPHI LOCKHEED	LP3313
FERODO	FDB4023
FERODO	FDB5226
FMSI	D1519-8728
GIRLING	6134359
HELLA-PAGID	8DB 355 023-401
HELLA-PAGID	T1688
MINTEX	MDB2882
NECTO	FD7363A
ROAD HOUSE	21242.00
ROAD HOUSE	21242.01
TEXTAR	24529 160 0 5
TEXTAR	2452901
TEXTAR	2452905
TEXTAR	25087 158 1 5
TEXTAR	2508703
TRW	GDB2124
TRW	GDB2511
TRW	GDB3435
VALEO	598893
WVA	24529
WVA	24530
WVA	25004

FIAT

FULLBACK (502_, 503_) Pickup 01/2016-

Vehicle	Engine	Fuel	Date	CC	KW	CV	Traction
2.4 (KT0T)	4G64	1	04/2016-	2351	97	132	2
2.4 4x4 (KT0T)	4G64	1	04/2016-	2351	97	132	3
2.4 D		2	01/2016-	2442	110	150	2
2.4 D (KT0T)	4N15	2	04/2016-	2442	113	154	2
2.4 D 4x4 (KT0T)	4N15	2	04/2016-	2442	110	150	3
2.4 D 4x4 (KT0T)	4N15	2	04/2016-	2442	113	154	3
2.4 D 4x4 (KT0T)	4N15	2	04/2016-	2442	133	181	3
2.5 D		2	01/2016-	2477	79	107	2
2.5 D		2	01/2016-	2477	81	110	2
2.5 D		2	01/2016-	2477	94	128	2
2.5 D		2	01/2016-	2477	100	136	2
2.5 D		2	01/2016-	2477	131	178	2
2.5 D 4WD (KT0T)	4D56	2	04/2016-	2477	81	110	3
2.5 D 4x4		2	01/2016-	2477	79	107	3
2.5 D 4x4 (KT0T)	4D56	2	04/2016-	2477	100	136	3

MITSUBISHI

L200 III / COLT-RODEO / STRADA / TRITON (K7_T, K6_T, K5_T) Pickup 01/1996-12/2011

Vehicle	Engine	Fuel	Date	CC	KW	CV	Traction
2.5 DI-D 4x4 (K74T)		2	01/2004-12/2007	2477	89	121	3

L200 IV / TRITON (KA_T, KB_T) Pickup 01/2004-12/2018

Vehicle	Engine	Fuel	Date	CC	KW	CV	Traction
2.4 (KA5T)		1	11/2005-12/2015	2351	94	128	2
2.4 (KA5T)	4G64 (16V)	1	05/2007-12/2015	2351	97	132	2
2.4 4WD (KB5T)	4G64 (16V)	1	09/2009-12/2012	2351	94	128	3
2.4 4WD (KB5T)	4G64 (16V)	1	08/2011-12/2015	2351	97	132	3
3.5 (KA9T)		1	07/2006-12/2011	3497	135	184	2
3.5 4WD (KB9T)	6G74 (SOHC 24V)	1	11/2005-12/2015	3497	132	180	3
3.5 4WD (KB9T)		1	07/2006-12/2010	3497	135	184	3
3.5 4WD (KB9T)		1	08/2011-12/2015	3497	137	186	3
3.5 4WD (KB9T)	6G74 (SOHC 24V)	1	05/2007-12/2015	3497	147	200	3
3.5 Flexfuel		1	12/2012-	3497	182	247	1
2.4 CNG (KA5T)		16	04/2010-12/2015	2351	94	128	2
2.4 Flex (KA5T)	4G64 (16V)	19	11/2013-04/2018	2351	104	142	2
3.5 Flex 4WD (KB9T)	6G74 (SOHC 24V)	19	09/2009-12/2015	3497	147	200	3
3.5 Flexfuel 4WD (KB9T)	6G74 (SOHC 24V)	19	08/2009-12/2017	3497	151	205	3
2.5 D		2	08/2011-12/2015	2477	55	75	2
2.5 D (KA4T)	4D56-TD	2	08/2011-12/2015	2477	66	90	2
2.5 D 4WD		2	08/2011-12/2015	2477	55	75	3
2.5 DI-D		2	04/2010-	2477	104	141	2
2.5 DI-D (KA4T)	4D56 (16V) 4D56-HP	2	04/2010-12/2015	2477	94	128	2
2.5 DI-D (KA4T)	4D56-HP	2	11/2005-12/2015	2477	100	136	2
2.5 DI-D (KA4T)		2	04/2010-12/2015	2477	103	140	2
2.5 DI-D (KA4T)	4D56-HP	2	08/2007-12/2015	2477	123	167	2
2.5 DI-D (KA4T)		2	01/2010-12/2015	2477	131	178	2
2.5 DI-D 16V 4WD	4D56 (16V)	2	04/2007-12/2015	2477	98	133	3
2.5 DI-D 4WD (KB4T)	4D56 (16V)	2	04/2010-12/2015	2477	94	128	3
2.5 DI-D 4WD (KB4T)	4D56-HP	2	11/2005-12/2015	2477	100	136	3
2.5 DI-D 4WD (KB4T)		2	04/2010-12/2015	2477	103	140	3
2.5 DI-D 4WD (KB4T)	4D56-HP	2	10/2007-12/2015	2477	123	167	3
2.5 DI-D 4WD (KB4T)	4D56-HP	2	04/2010-12/2015	2477	131	178	3
2.5 TDiC		2	11/2005-	2477	98	133	2
2.8 D 4WD (KB7T)		2	05/2005-12/2015	2835	71	97	3
3.2 DI-D 4WD (KB8T)		2	07/2006-12/2009	3200	118	160	3
3.2 DI-D 4WD (KB8T)		2	01/2007-12/2015	3200	121	165	3
3.2 DI-D 4WD (KB8T)	4M41	2	01/2012-12/2016	3200	125	170	3
3.2 DI-D 4WD (KB8T)	4M41	2	11/2013-12/2018	3200	132	180	3

L200 IV / TRITON (KA_T, KB_T) Platform/Chassis 03/2006-12/2015

Vehicle	Engine	Fuel	Date	CC	KW	CV	Traction
2.4		1	01/2009-12/2015	2351	94	128	1
2.4 CNG		1	12/2009-12/2015	2351	94	128	1
3.5 (KA9T)	6G74 (SOHC 24V)	1	09/2006-11/2009	3497	135	184	2
3.5 i 4WD (KB9T)	6G74 (SOHC 24 V)	1	03/2006-06/2009	3497	135	184	3
2.5 DI-D (KA4T)	4D56 (16V)	2	08/2007-12/2015	2477	94	128	2
2.5 DI-D (KA4T)		2	01/2008-12/2015	2477	100	136	2
2.5 DI-D 4WD (KB4T)	4D56-HP	2	09/2009-12/2015	2477	131	178	3
3.2 DI-D 4WD (KB8T)	4M41	2	07/2006-08/2009	3200	118	160	3

L200 V / TRITON (KJ_, KK_, KL_) Pickup 02/2014-

Vehicle	Engine	Fuel	Date	CC	KW	CV	Traction
2.4		1	11/2014-	2351	93	126	2
2.4	4G64 (16V)	1	11/2014-	2351	97	132	2
2.4 (KK4T)		1	11/2014-	2351	94	128	2
2.4 (KK4T)		1	11/2014-	2351	96	131	2
2.4 2WD	4G64 (16V)	1	11/2014-08/2020	2351	94	128	2
2.4 4WD	4G64 (16V)	1	11/2014-	2351	97	132	3
2.2 DI-D	4N14	2	07/2019-	2268	110	150	2
2.2 DI-D 4WD	4N14	2	07/2019-	2268	110	150	3
2.4 DI-D		2	07/2019-	2442	100	136	2
2.4 DI-D		2	08/2015-	2442	112	152	2
2.4 DI-D (KJ0T)	4N15	2	09/2015-	2442	113	154	2
2.4 DI-D (KK1T)	4N15	2	01/2015-	2442	133	181	2
2.4 DI-D 4WD		2	07/2019-	2442	100	136	3
2.4 DI-D 4WD		2	09/2015-	2442	112	152	3
2.4 DI-D 4WD (KJ0T)	4N15	2	09/2015-	2442	113	154	3
2.4 DI-D 4WD (KL1T, KL2T)	4N15	2	09/2015-	2442	140	190	3
2.4 DI-D 4WD (KL1T)	4N15	2	11/2014-	2442	133	181	3
2.5 DI-D	4D56 (16V)	2	01/2016-	2477	81	110	2
2.5 DI-D	4D56 (16V)	2	01/2015-	2477	100	136	2
2.5 DI-D (KJ3T)	4D56 (16V)	2	11/2014-	2477	94	128	2
2.5 DI-D (KK3T)	4D56 (16V)	2	11/2014-	2477	131	178	2
2.5 DI-D 4WD	4D56 (16V)	2	11/2014-	2477	81	110	3
2.5 DI-D 4WD	4D56 (16V)	2	11/2014-	2477	100	136	3
2.5 DI-D 4WD		2	11/2014-	2477	131	178	3
3.2 DI-D 4WD	4M41	2	05/2015-	3200	132	180	3

L200 V / TRITON / STRADA (MQ) Platform/Chassis 01/2015-

Vehicle	Engine	Fuel	Date	CC	KW	CV	Traction
2.4 D (KK1T)		2	01/2015-	2442	133	181	2
2.4 D 4WD (KL1T)		2	01/2015-	2442	133	181	3

PAJERO SPORT II / PAJERO DAKAR / CHALLENGER / MONTERO SPORT / NATIVA (KH_, KG_) Closed Off-Road Vehicle 01/2008-

Vehicle	Engine	Fuel	Date	CC	KW	CV	Traction
2.4		1	07/2008-	2351	94	128	1
3.0		1	09/2008-	2998	162	220	1
3.0 4WD	6B31	1	09/2008-	2998	162	220	3
3.0 Mivec (KG6W)	6B31	1	01/2012-12/2015	2998	161	219	2
3.5	6G74 (SOHC 24V)	1	01/2010-	3497	137	186	3
3.5		1	09/2009-12/2011	3497	147	200	1
3.5 Flex		1	08/2009-	3497	147	200	1
3.5 V6 24V	6G74 (SOHC 24V)	1	09/2008-	3497	153	208	3
3.5 Flex 4WD		19	06/2011-12/2018	3497	151	205	3
2.5 DI-D		2	09/2008-	2477	100	136	2
2.5 DI-D (KH4W)	4D56-HP	2	07/2008-12/2015	2477	131	178	2
2.5 DI-D 4WD (KG4W)		2	09/2008-	2477	100	136	3
2.5 DI-D 4WD (KH4W)	4D56-HP	2	07/2008-	2477	131	178	3
2.5 TD		2	09/2008-	2477	98	133	3
3.2 DI-D		2	11/2009-	3200	120	163	2
3.2 DI-D 4WD	4M41	2	07/2008-	3200	118	160	3
3.2 DI-D 4WD	4M41	2	07/2008-	3200	121	165	3

RAM

1200 (B_) Pickup 03/2017-

Vehicle	Engine	Fuel	Date	CC	KW	CV	Traction
2.4 (B20)		1	03/2017-	2351	97	132	2
2.5 D (B23)		2	03/2017-	2477	94	128	2

1200 (E_) Pickup 03/2017-

Vehicle	Fuel	Date	CC	KW	CV	Traction
2.4 (E20)	1	03/2017-	2351	97	132	2
2.4 4x4 (E80)	1	03/2017-	2351	97	132	3
2.5 D (E23)	2	03/2017-	2477	94	128	2
2.5 D 4x4 (E85)	2	03/2017-	2477	100	136	3
