Product 78BD0017-1 - Web Catalogo

Product 78BD0017-1

Description: Brake disc
Axe: Rear
No. of Pieces: 1
Barcode: 8424073193162
Url: https://catalogonuevo.icerbrakes.com/Producto/Details?idProducto=78BD0017-1
Weight (gr.): 8080

Measures: Ø290x22x70.5
: Brake Disc Type: Vented; Minimum thickness [mm]: 19; Hole Arrangement/Number: 8; Bolt Hole Circle Ø [mm]: 127; Wheel Hub Diameter [mm]: 110

Reference applications

Brand	OE Reference
NISSAN	43206-MA50A
NISSAN	43207-9X100
RENAULT	50 01 871 282

Maker	Cross reference
ATE	24.0122-0264.1
BENDIX BRAKING-TMD	BDS2211
BOSCH	O 986 479V18
BREMBO	09.7263.30
FERODO	FCR340A
HELLA-PAGID	8DB 355 133-321
MINTEX	MDC2975C
ROAD HOUSE	NCA.1140.20
TEXTAR	92322303

NISSAN

ATLEON () Platform/Chassis 09/2000-

Vehicle	Engine	Fuel	Date	CC	KW	CV	Tonnage	Axels
110.35, 120.35	BD-30TI	2	09/2000-	2953	78	106	3.00	4x2
110.56, 120.56	BD-30TI	2	09/2000-	2953	78	106	5.00	4x2
140.75	BD-40TI	2	09/2000-	3990	100	136	7.00	4x2

CABSTAR / ATLAS (TL_, VL_) Platform/Chassis 07/1992-11/2006

Vehicle	Engine	Fuel	Date	CC	KW	CV	Traction
105.35, 110.35, 110.45 (TL0)	BD-30TI	2	10/1998-10/2006	2953	78	106	2
120.35, 120.45 (TL0)	BD-30TI	2	10/1998-10/2006	2953	88	120	2
125.35, 125.45 (TL0, VL0)	BD-30TI	2	10/1998-10/2006	2953	92	125	2

CABSTAR E (F24M, F24W) Platform/Chassis 09/2006-12/2013

Vehicle	Engine	Fuel	Date	CC	KW	CV	Traction
28.11 DCI, 32.11 DCI, 35.11 DCI 2.5 (F24M)	YD25DDTI	2	09/2006-12/2013	2488	81	110	2
35.13 DCI, 45.13 DCI 2.5 (F24M)	YD25DDTI	2	09/2006-12/2012	2488	96	131	2
35.14 DCI 3.0 (F24M)	ZD30DDTI	2	09/2006-12/2013	2953	101	137	2
35.14 DCI, 45.14 DCI 2.5 (F24M)	YD25DDTI YD25K3LD-5MI	2	09/2006-12/2013	2488	100	136	2
35.15 DCI, 45.15 DCI 3.0 (F24M)	ZD30 ZD30DDTI ZD30H HD-5	2	09/2006-12/2013	2953	110	150	2

NT400 CABSTAR (F24M) Platform/Chassis 08/2009-

Vehicle	Engine	Fuel	Date	CC	KW	CV	Traction
35.14, 45.14	YD25K3LD-5MI	2	01/2014-	2488	100	136	2
35.15, 45.15	YD25K3LD-5HO	2	01/2014-	2488	107	146	2
35.15, 45.15	ZD30DDTI	2	09/2016-	2953	110	150	2

RENAULT TRUCKS

Maxity () Platform/Chassis 03/2007-

Vehicle	Engine	Fuel	Date	CC	KW	CV	Tonnage	Axels
130.45	DXI 2,5 YD25DDTI	2	03/2007-	2488	96	130	4.00	4x2
130.45	DTI 3 DXI 3 ZD30DTI	2	07/2016-	2953	96	130	4.00	4x2
140.45	DXI 2,5 YD25DDTI	2	03/2010-	2488	103	140	4.00	4x2
150.45	DXI 2,5 YD25DDTI	2	03/2010-	2488	110	150	4.00	4x2
150.45	DXI 3 ZD30DTI	2	03/2007-	2953	110	150	4.00	4x2

Maxity () Dump Truck 03/2007-

Vehicle	Engine	Fuel	Date	CC	KW	CV	Tonnage	Axels
130.45	DXI 2,5 YD25DDTI	2	03/2007-	2488	96	130	4.00	4x2
140.45	DXI 2,5 YD25DDTI	2	03/2010-	2488	103	140	4.00	4x2
150.45	DXI 2,5 YD25DDTI	2	03/2010-	2488	110	150	4.00	4x2
150.45	DXI 3 ZD30DTI	2	03/2007-	2953	110	150	4.00	4x2
