Product 78BD0037-2 - Web Catalogo

Product 78BD0037-2

Description: Brake disc
Axe: Front
No. of Pieces: 2
Barcode: 8424073208507
Url: https://catalogonuevo.icerbrakes.com/Producto/Details?idProducto=78BD0037-2
Weight (gr.): 5350

R90 Homologation: 90R-02C0452/0119
Measures: Ø265.8x22x48
: Brake Disc Type: Vented; Minimum thickness [mm]: 20; Hole Arrangement/Number: 5; Bolt Hole Circle Ø [mm]: 108; Wheel Hub Diameter [mm]: 71

Reference applications

Brand	OE Reference
PEUGEOT	1610704680
PEUGEOT	1642761280

Maker	Cross reference
ATE	24.0122-0291.1
BOSCH	0 986 479 C34
BREMBO	09.C657.11
FERODO	DDF2413C
HELLA-PAGID	8DD 355 120-541
LETEC	LBP033V
MINTEX	MDC2613
TEXTAR	92269003
TRW	DF6785

PEUGEOT

308 II (LB_, LP_, LW_, LH_, L3_) Hatchback 09/2013-

Vehicle	Engine	Fuel	Date	CC	KW	CV	Traction
1.2 THP 110	HNP (EB2ADT) HNV (EB2DTM) HNZ (EB2DT)	1	11/2013-06/2021	1199	81	110	1
1.2 THP 130	HNY (EB2DTS)	1	11/2013-06/2021	1199	96	131	1
1.2 VTi 72	HMZ (EB2F)	1	09/2013-06/2021	1199	60	82	1
1.6 PureTech 225	GGR (EP6FADTX)	1	01/2018-06/2021	1598	165	225	1
1.6 THP	5GX (EP6FDTMD)	1	09/2013-06/2021	1598	112	152	1
1.6 THP	5FV (EP6CDT)	1	09/2013-06/2021	1598	115	156	1
1.6 THP 125	5FA (EP6CDT)	1	09/2013-06/2021	1598	92	125	1
1.6 THP 150	5GX (EP6FDTMD)	1	03/2014-06/2021	1598	110	150	1
1.6 THP 163	5FM (EP6CDTM)	1	06/2014-06/2021	1598	120	163	1
1.6 VTi 115	NFP (EC5)	1	05/2015-06/2021	1587	85	115	1
1.6 Flex		19	11/2015-02/2019	1598	127	173	1
1.5 BlueHDi 100	YHY (DV5RD)	2	05/2018-06/2021	1499	75	102	1
1.5 BlueHDi 130	YHZ (DV5RC)	2	06/2017-06/2021	1499	96	131	1
1.6 BlueHDi 120	BHZ (DV6FC)	2	11/2013-06/2021	1560	88	120	1
1.6 HDi	9HP (DV6DTED)	2	09/2013-06/2021	1560	68	92	1
1.6 HDi / BlueHDi 115	9HC (DV6C) BHZ (DV6FC)	2	09/2013-06/2021	1560	85	115	1
1.6 HDi 100	BHY (DV6FD)	2	04/2014-06/2021	1560	73	99	1
2.0 BlueHDi 150	AHX (DW10FCD) AHX (DW10FD)	2	11/2013-06/2021	1997	110	150	1

308 II SW (LC_, LJ_, LR_, LX_, L4_) Estate 03/2014-

Vehicle	Engine	Fuel	Date	CC	KW	CV	Traction
1.2 THP 110	HNP (EB2ADT) HNV (EB2DTM) HNZ (EB2DT)	1	03/2014-06/2021	1199	81	110	1
1.2 THP 130	HNY (EB2DTS)	1	03/2014-06/2021	1199	96	131	1
1.6 PureTech 225 (L45GGR)	5GG (EP6FADTX)	1	01/2018-06/2021	1598	165	225	1
1.6 THP 125	5FA (EP6CDT)	1	03/2014-06/2021	1598	92	125	1
1.6 THP 150 (L45GXA)	5GX (EP6FDTMD)	1	03/2014-06/2021	1598	110	150	1
1.6 THP 155	5FV (EP6CDT)	1	03/2014-06/2021	1598	115	156	1
1.6 VTi (LWNFPA)	NFP (EC5)	1	03/2014-06/2021	1587	85	115	1
1.5 BlueHDi 100	YHY (DV5RD)	2	04/2018-06/2021	1499	75	102	1
1.5 BlueHDi 130	YHZ (DV5RC)	2	06/2017-06/2021	1499	96	131	1
1.6 BlueHDi 100	BHY (DV6FD)	2	04/2014-06/2021	1560	73	99	1
1.6 BlueHDi 120	BHZ (DV6FC)	2	03/2014-06/2021	1560	88	120	1
1.6 HDi / BlueHDi 115 (LCBHXM, LCBHXT)	9HC (DV6C) BHZ (DV6FC)	2	03/2014-06/2021	1560	85	115	1
1.6 HDI 92	9HP (DV6DTED)	2	03/2014-06/2021	1560	68	92	1
2.0 BlueHDi 150	AHX (DW10FCD)	2	03/2014-06/2021	1997	110	150	1

308 II SW (LC_) Estate Van 04/2014-

Vehicle	Engine	Fuel	Date	CC	KW	CV	Traction
1.5 BlueHDi 130 (LCYHZP)	YHZ (DV5RC)	2	06/2017-06/2021	1499	96	131	1
1.6 BlueHDi	BHY (DV6FD)	2	04/2014-06/2021	1560	73	99	1

308 II (LB_) Hatchback Van 03/2015-

Vehicle	Engine	Fuel	Date	CC	KW	CV	Traction
1.5 BlueHDi 130 (LBYHZP)	YHZ (DV5RC)	2	06/2017-06/2021	1499	96	131	1
1.6 BlueHDi 120 (LBBHZM)	BHX (DV6FC)	2	03/2015-06/2021	1560	88	120	1
1.6 e-HDi 115 (LB9HCG)	9HC (DV6C)	2	03/2015-06/2021	1560	85	116	1
