Product 78BD0042-1
- Description
- Brake disc
- Axe
- Rear
- No. of Pieces
- 1
- Barcode
-
8424073288790
- Url
- https://catalogonuevo.icerbrakes.com/Producto/Details?idProducto=78BD0042-1
- Weight (gr.)
- 8010
- R90 Homologation
-
90R-02C0559/0110
- Measures
- Ø300x11x81.5
-
Brake Disc Type:
solid -
Minimum thickness [mm]:
9.5 -
Hole Arrangement/Number:
5 -
Bolt Hole Circle Ø [mm]:
114,3 -
Wheel Hub Diameter [mm]:
52.3
| Brand | OE Reference |
|---|---|
| RENAULT | 40 20 200 03R |
| RENAULT | 40 20 222 91R |
| RENAULT | 43 20 000 15R |
| RENAULT | 43 20 224 34R |
| RENAULT | 43 20 271 12R |
| SAMSUNG | 432000015R |
| Maker | Cross reference |
|---|---|
| BOSCH | 0 986 479 445 |
| BREMBO | 08.A826-47 |
| DELPHI LOCKHEED | BG9138RS |
| FERODO | DDF1725 |
| GIRLING | 6060446 |
| HELLA-PAGID | 8DD 355 123-401 |
| LETEC | LBR747S* |
| MINTEX | MDC2513 |
| TEXTAR | 92233103 |
| TRW | DF6044BS |
| Vehicle | Engine | Fuel | Date | CC | KW | CV | Traction |
|---|---|---|---|---|---|---|---|
| 1.6 16V (BT04, BT0D, BT0U) |
K4M 824 |
1 | 10/2007-12/2015 | 1598 | 81 | 110 | 1 |
| 2.0 16V (BT05, BT0F, BT0W) |
M4R 704 |
1 | 10/2007-12/2012 | 1998 | 103 | 140 | 1 |
| 2.0 16V Turbo |
F4R 811 |
1 | 10/2007-12/2015 | 1998 | 125 | 170 | 1 |
| 2.0 GT |
F4R 800 |
1 | 03/2008-12/2015 | 1998 | 150 | 204 | 1 |
| 3.5 V6 (BT0C, BT0P) |
V4Y 713 |
1 | 04/2008-12/2015 | 3498 | 175 | 238 | 1 |
| 2.0 16V Hi-Flex (BT1H, BT1G, BT1K) |
M4R 726 |
19 | 10/2007-12/2015 | 1997 | 103 | 140 | 1 |
| 1.5 dCi (BT00, BT0A, BT0T, BT1J) |
K9K 780 K9K 782 |
2 | 10/2007-12/2015 | 1461 | 81 | 110 | 1 |
| 2.0 dCi (BT01, BT08, BT09, BT0E, BT0K, BT12, BT1C, BT1D,... |
M9R 742 M9R 744 M9R 746 M9R 748 M9R 754 M9R 802 M9R 805 M9R 808 M9R 814 M9R 845 M9R 854 M9R 858 |
2 | 10/2007-12/2015 | 1995 | 110 | 150 | 1 |
| 2.0 dCi (BT07, BT0J, BT14, BT1A, BT1S) |
M9R 742 M9R 744 M9R 802 M9R 814 M9R 854 M9R 858 |
2 | 10/2007-12/2015 | 1995 | 96 | 131 | 1 |
| 2.0 dCi (BT0M, BT0N, BT0S, BT19, BT1F) |
M9R 800 M9R 806 M9R 809 M9R 815 M9R 854 M9R 857 M9R 858 |
2 | 01/2008-12/2015 | 1995 | 127 | 173 | 1 |
| 2.0 dCi GT (BT11, BT1E, BT1N) |
M9R 816 M9R 820 M9R 828 |
2 | 03/2008-12/2015 | 1995 | 131 | 178 | 1 |
| 3.0 dCi (BT03, BT13) |
V9X 791 V9X 891 |
2 | 09/2008-12/2015 | 2998 | 173 | 235 | 1 |
| Vehicle | Engine | Fuel | Date | CC | KW | CV | Traction |
|---|---|---|---|---|---|---|---|
| 1.6 16V (KT0D) |
K4M 824 |
1 | 10/2007-12/2015 | 1598 | 81 | 110 | 1 |
| 2.0 16V (KT0F, KT0W) |
M4R 704 |
1 | 10/2007-12/2015 | 1998 | 103 | 140 | 1 |
| 2.0 16V Turbo |
F4R 811 |
1 | 10/2007-12/2015 | 1998 | 125 | 170 | 1 |
| 2.0 GT |
F4R 800 |
1 | 03/2008-12/2015 | 1998 | 150 | 204 | 1 |
| 3.5 V6 (KT0C, KT0P) |
V4Y 713 |
1 | 04/2008-12/2015 | 3498 | 175 | 238 | 1 |
| 2.0 16V Hi-Flex (KT1H, KT1G, KT1K) |
M4R 704 M4R 726 |
19 | 10/2007-12/2015 | 1997 | 103 | 140 | 1 |
| 1.5 dCi (KT0A, KT0R, KT02) |
K9K 780 K9K 782 K9K 846 |
2 | 10/2007-12/2015 | 1461 | 81 | 110 | 1 |
| 2.0 dCi (KT01, KT08, KT09, KT0K, KT12, KT1D, KT1W) |
M9R 742 M9R 744 M9R 802 M9R 805 M9R 808 M9R 814 M9R 845 M9R 854 M9R 858 |
2 | 10/2007-12/2015 | 1995 | 110 | 150 | 1 |
| 2.0 dCi (KT07, KT0J, KT14, KT1A, KT1S) |
M9R 742 M9R 744 M9R 802 M9R 814 M9R 854 M9R 858 |
2 | 10/2007-12/2015 | 1995 | 96 | 131 | 1 |
| 2.0 dCi (KT0M, KT0N, KT0S, KT19, KT1F) |
M9R 800 M9R 806 M9R 809 M9R 815 M9R 849 M9R 854 M9R 857 M9R 858 |
2 | 01/2008-12/2015 | 1995 | 127 | 173 | 1 |
| 2.0 dCi GT (KT11, KT1E, KT1N) |
M9R 816 M9R 820 M9R 828 |
2 | 03/2008-12/2015 | 1995 | 131 | 178 | 1 |
| 3.0 dCi (KT03, KT13) |
V9X 791 V9X 891 |
2 | 09/2008-12/2015 | 2998 | 173 | 235 | 1 |
| Vehicle | Engine | Fuel | Date | CC | KW | CV | Traction |
|---|---|---|---|---|---|---|---|
| 1.5 dCi |
K9K 846 |
2 | 03/2012-12/2015 | 1461 | 81 | 110 | 1 |
| Vehicle | Engine | Fuel | Date | CC | KW | CV | Traction |
|---|---|---|---|---|---|---|---|
| 2.0 16V |
M4R 746 |
1 | 02/2011- | 1997 | 102 | 139 | 1 |
| 2.0 16V | 1 | 01/2011- | 1997 | 105 | 143 | 1 | |
| 2.0 16V (L70B) |
M4R 746 |
1 | 02/2011- | 1997 | 103 | 140 | 1 |
| 2.5 V6 (L702, L703, L704, L707) |
2ZV 604 |
1 | 05/2011- | 2495 | 130 | 177 | 1 |
| 3.5 V6 |
5ZV604 |
1 | 08/2013- | 3498 | 174 | 237 | 1 |
| 3.5 V6 |
5ZV604 |
1 | 01/2011- | 3498 | 176 | 240 | 1 |
| 3.5 V6 (L700, L701, L706, L708) | 1 | 01/2011- | 3498 | 169 | 230 | 1 | |
| 2.0 16V eco2 Flexfuel (L70B) |
M4R 746 |
19 | 02/2011- | 1997 | 103 | 140 | 1 |
| 1.5 dCi (L70R, L731) |
K9K 782 K9K 849 |
2 | 07/2010- | 1461 | 81 | 110 | 1 |
| 2.0 dCi 130 |
M9R 756 |
2 | 12/2013- | 1995 | 96 | 131 | 1 |
| 2.0 dCi 150 (L70H) |
M9R 824 M9R 846 |
2 | 02/2011- | 1995 | 110 | 150 | 1 |
| 2.0 dCi 175 (L70Y, L734) |
M9R 804 M9R 817 M9R 844 |
2 | 05/2011- | 1995 | 127 | 173 | 1 |
| 2.5 dCi | 2 | 05/2011- | 2496 | 133 | 181 | 2 | |
| 3.0 dCi 240 (L70G) |
V9X 891 |
2 | 02/2011- | 2998 | 177 | 241 | 1 |
