Product 78BD0102-1

Description
Brake disc
Axe
Front
No. of Pieces
1
Barcode
EAN13 Code
8424073291578
QR Code
Url
https://catalogonuevo.icerbrakes.com/Producto/Details?idProducto=78BD0102-1
Weight (gr.)
9700
Measures
Ø330x15x48
Brake Disc Type: Vented
Minimum thickness [mm]: 28
Hole Arrangement/Number: 5
Bolt Hole Circle Ø [mm]: 108
Wheel Hub Diameter [mm]: 71.1
Reference applications
Brand OE Reference
PEUGEOT 1642761480
PEUGEOT 9804605780
Maker Cross reference
ATE 24.0130-0241.1
BOSCH 0 986 479 D70
BREMBO 09.B929.11
DELPHI LOCKHEED BG4716C
FERODO DDF2817C-1
HELLA-PAGID 8DD 355 125-331
MINTEX MDC2774
ROAD HOUSE 61627.10
TEXTAR 92283403
CITROËN
C5 AIRCROSS (AC_, AJ_, AR_, A4_) SUV 11/2018-
Vehicle Engine Fuel Date CC KW CV Traction
1.2 PureTech 130 (ARHNSJ)

HNS (EB2ADTS)

 1 11/2018- 1199 96 131 1
1.6 PureTech 180 (A45GFR)

5GF (EP6FADTXD)

 1 11/2018- 1598 133 181 1
1.6 THP 150 (A45GXJ)

5GX (EP6FDTMD)

 1 09/2019- 1598 110 150 1
1.6 THP 165 (A45GYJ)

5GY (EP6FDTM)

 1 05/2019- 1598 121 165 1
1.2 Hybrid 136 (ARHPYJ) 13 05/2023- 1199 100 136 1
1.6 Hybrid 180 (A4DGXR) 13 11/2022- 1598 133 181 1
1.6 Hybrid 225 (A45GFR) 13 04/2020- 1598 165 224 1
1.5 BlueHDi 130 (ACYHZJ, ACYHZR)

YHZ (DV5RC)

 2 11/2018- 1499 96 131 1
2.0 BlueHDi 180 (AJEHZR)

EHZ (DW10FC)

 2 11/2018- 1997 130 177 1
C5 III X (ND_, NC_) Estate 09/2021-
Vehicle Engine Fuel Date CC KW CV Traction
PureTech 130 (NCHNSP) 1 09/2021- 1199 96 131 1
PureTech 180 (ND5GFP) 1 09/2021- 1598 133 181 1
Hybrid 180 (NDDGYP) 13 02/2023- 1598 133 181 1
Hybrid 225 (NDDGYP) 13 09/2021- 1598 165 224 1
DS
DS 4 II (FR_, FB_, F3_, FP_, F4_) Hatchback 10/2021-
Vehicle Engine Fuel Date CC KW CV Traction
PureTech 225 (FP5GGT) 1 10/2021-08/2022 1598 165 224 1
DS 7 Crossback (J4_, JR_, JC_) SUV 09/2017-
Vehicle Engine Fuel Date CC KW CV Traction
E-TENSE 225 (J4DGZU, J45GQU) 13 09/2020- 1598 165 224 1
E-TENSE 4x4 (J45GBU)

5GB (EP6FADTXHP)

 13 05/2019- 1598 221 300 3
DS 7 (J4_, JC_) SUV 09/2022-
Vehicle Engine Fuel Date CC KW CV Traction
1.6

EP6FADTXM

 1 04/2023- 1598 158 215 1
PureTech 180 (J45GFU) 1 09/2022- 1598 133 180 1
PureTech 225 (J45GGU) 1 09/2022- 1598 165 224 1
E-TENSE 225 (J4DGZU) 13 09/2022- 1598 165 224 1
E-TENSE 4x4 300 (J45GBU) 13 09/2022- 1598 220 299 3
E-TENSE 4x4 360 (J45GBT) 13 09/2022- 1598 265 360 3
BlueHDi 130 (JCYHZU) 2 09/2022- 1499 96 130 1
DS 9 (X2_) Saloon 09/2020-
Vehicle Engine Fuel Date CC KW CV Traction
1.6 PureTech 225 (X25GGR) 1 09/2020-08/2022 1598 165 224 1
1.6 E-TENSE 225 (X2DGZR) 13 09/2020-06/2022 1598 165 225 1
1.6 E-TENSE 250 (X2DGYR) 13 08/2022-08/2024 1598 184 250 1
E-TENSE 360 4x4 (X25GBR) 13 06/2021-08/2024 1598 265 360 3
OPEL
ASTRA L (OV5) Hatchback 10/2021-
Vehicle Engine Fuel Date CC KW CV Traction
1.2 (FPHNSL, FPHNSR) 1 10/2021- 1199 96 131 1
1.6 Plug-In-Hybrid (F3DGZT) 13 10/2021- 1598 133 181 1
1.6 Plug-In-Hybrid (F3DGZT) 13 01/2023- 1598 165 224 1
1.5 Turbo D (FBYHZT, FBYHZJ) 2 10/2021- 1499 96 131 1
Astra-e (F3ZKWZ) 11 03/2023- 115 156 1
ASTRA L Sports Tourer (OV5) Estate 10/2021-
Vehicle Engine Fuel Date CC KW CV Traction
1.2 (FRHNSL, FRHNSR) 1 10/2021- 1199 96 131 1
1.6 Plug-In Hybrid (F4DGZT, F4DGYT) 13 10/2021- 1598 133 181 1
1.6 Plug-In Hybrid (F4DGZT, F4DGYT) 13 03/2023- 1598 165 224 1
1.5 CDTi (FCYHZT, FCYHZJ) 2 10/2021- 1499 96 131 1
Astra-e (F4ZKWZ) 11 03/2023- 115 156 1
PEUGEOT
(FP_, F3_, FM_) Hatchback 07/2022-
Vehicle Engine Fuel Date CC KW CV Traction
PureTech 130 (FPHNST) 1 07/2022- 1199 96 131 1
PureTech 215 (F3EGPP) 1 02/2023- 1598 158 215 1
Hybrid 136 (FPHPYC) 13 07/2023- 1199 100 136 1
Hybrid 180 (F3DGXT) 13 07/2022- 1598 133 181 1
Hybrid 225 (F3DGYT) 13 07/2022- 1598 165 224 1
308 II (LB_, LP_, LW_, LH_, L3_) Hatchback 09/2013-
Vehicle Engine Fuel Date CC KW CV Traction
1.6 GT 205

5GT (EP6FDTX)

 1 06/2014-06/2021 1598 151 205 1
1.6 PureTech 225

GGR (EP6FADTX)

 1 01/2018-06/2021 1598 165 225 1
1.6 Flex 19 11/2015-02/2019 1598 127 173 1
2.0 GT BlueHDi 180

EHZ (DW10FC)

 2 06/2017-06/2021 1997 130 177 1
2.0 GT BlueHDi 180

AHW (DW10FC)

 2 06/2017-06/2021 1997 132 179 1
2.0 GT BlueHDi 180

AHW (DW10FC)

 2 06/2014-06/2021 1997 133 181 1
308 II SW (LC_, LJ_, LR_, LX_, L4_) Estate 03/2014-
Vehicle Engine Fuel Date CC KW CV Traction
1.6 GT 205

5GT (EP6FDTX)

 1 02/2015-06/2021 1598 151 205 1
1.6 PureTech 225 (L45GGR)

5GG (EP6FADTX)

 1 01/2018-06/2021 1598 165 225 1
1.5 BlueHDi 100

YHY (DV5RD)

 2 04/2018-06/2021 1499 75 102 1
1.5 BlueHDi 130

YHZ (DV5RC)

 2 06/2017-06/2021 1499 96 131 1
2.0 GT BlueHDi 180

EHZ (DW10FC)

 2 06/2017-06/2021 1997 130 177 1
2.0 GT BlueHDi 180

AHW (DW10FC)

 2 06/2017-06/2021 1997 132 179 1
2.0 GT HDi 180 / BlueHDi 180

AHW (DW10FC)

 2 06/2014-06/2021 1997 133 181 1
308 II (LB_) Hatchback Van 03/2015-
Vehicle Engine Fuel Date CC KW CV Traction
1.6 BlueHDi 120 (LBBHZM)

BHX (DV6FC)

 2 03/2015-06/2021 1560 88 120 1
1.6 e-HDi 115 (LB9HCG)

9HC (DV6C)

 2 03/2015-06/2021 1560 85 116 1
508 II (FB_, FH_, F3_) Hatchback 09/2018-
Vehicle Engine Fuel Date CC KW CV Traction
1.6 PureTech 180 (F35GFR)

5GF (EP6FADTXD)

 1 10/2018- 1598 133 181 1
1.6 PureTech 225 (F35GGR)

5GG (EP6FADTX)

 1 10/2018- 1598 165 224 1
1.6 THP 150 (F35GXV)

5GX (EP6FDTMD)

 1 09/2018- 1598 110 150 1
1.6 THP 165 (F35GYV)

5GY (EP6FDTM)

 1 09/2018- 1598 121 165 1
PureTech 130 (FBHNSR)

HNS (EB2ADTS)

 1 06/2020- 1199 96 131 1
Hybrid 225 (F35GQU)

5GQ (EP6FADTXHPD)

 13 08/2019- 1598 165 224 1
PSE Hybrid4 360 (F35GBT) 13 01/2021- 1598 265 360 3
1.5 BlueHDI 130 (FBYHZJ, FBYHZR)

YHZ (DV5RC)

 2 10/2018- 1499 96 131 1
2.0 BlueHDI 160 (FHEHYR)

EHY (DW10FCC)

 2 10/2018- 1997 120 163 1
2.0 BlueHDI 180 (FHEHZR, FHEHZN)

EHZ (DW10FC)

 2 10/2018- 1997 130 177 1
508 II SW (FC_, FJ_, F4_) Estate 09/2018-
Vehicle Engine Fuel Date CC KW CV Traction
1.6 PureTech 180

GFR (EP6FADTXD)

 1 09/2018- 1598 133 181 1
1.6 PureTech 225 (F45GGR)

GCR (EP6FADTX)

 1 09/2018- 1598 165 224 1
1.6 THP 165 (F45GYV)

5GY (EP6FDTM)

 1 09/2018- 1598 121 165 1
PureTech 130

HNS (EB2ADTS)

 1 06/2020- 1199 96 131 1
Hybrid 224 (F45GQU)

5GQ (EP6FADTXHPD)

 13 08/2019- 1598 165 224 1
PSE Hybrid4 360 (F45GBT) 13 01/2021- 1598 265 360 3
1.5 BlueHDi 130

YHZ (DV5RC)

 2 09/2018- 1499 96 131 1
2.0 BlueHDi 160

EHY (DW10FCC)

 2 09/2018- 1997 120 163 1
2.0 BlueHDi 180

EHZ (DW10FC)

 2 09/2018- 1997 130 177 1
3008 II SUV (MC_, MR_, MJ_, M4_) SUV 05/2016-
Vehicle Engine Fuel Date CC KW CV Traction
hybrid

5GQ (EP6FADTXHPD)

 13 10/2019- 1598 165 224 1
Hybrid4 (M45GBU)

5GB (EP6FADTXHPA)

 13 10/2019- 1598 220 299 3
308 III (FB_, FH_, FP_, F3_, FM_) Hatchback 07/2021-
Vehicle Engine Fuel Date CC KW CV Traction
PureTech 110 (FPHNPL) 1 07/2021- 1199 81 110 1
PureTech 130 (FPHNSL, FPHNST) 1 07/2021- 1199 96 131 1
Hybrid 180 (F3DGXT, F3DGMH) 13 07/2021- 1598 133 181 1
Hybrid 225 (F3DGYT, F3DGNH) 13 07/2021- 1598 165 224 1
BlueHDi 130 (FBYHZL, FBYHZT) 2 07/2021- 1499 96 131 1
308 III SW (FC_, FJ_, FR_, F4_, FN_) Estate 07/2021-
Vehicle Engine Fuel Date CC KW CV Traction
PureTech 110 (FRHNPL) 1 07/2021- 1199 81 110 1
PureTech 130 (FRHNSL, FRHNST) 1 07/2021- 1199 96 131 1
Hybrid 180 (F4DGXT) 13 07/2021- 1598 133 181 1
Hybrid 225 (F4DGYT) 13 07/2021- 1598 165 224 1
BlueHDi 130 (FCYHZL, FCYHZT) 2 07/2021- 1499 96 131 1
VAUXHALL
ASTRA Mk VIII (L) () Hatchback 10/2021-
Vehicle Engine Fuel Date CC KW CV Traction
1.2 (FPHNSL, FPHNSR) 1 10/2021- 1199 96 131 1
1.6 Plug-In-Hybrid (F3DGZT) 13 10/2021- 1598 133 181 1
1.6 Plug-In-Hybrid (F3DGZT) 13 06/2022- 1598 165 224 1
1.5 Turbo D (FBYHZT, FBYHZJ) 2 10/2021- 1499 96 131 1
Astra-e (F3ZKWZ) 11 03/2023- 115 156 1
ASTRA Mk VIII (L) Sports Tourer () Estate 10/2021-
Vehicle Engine Fuel Date CC KW CV Traction
1.2 1 10/2021- 1199 96 131 1
1.6 Plug-In-Hybrid 13 10/2021- 1598 133 181 1
1.6 Plug-In-Hybrid (F4DGYT, F4DGZT) 13 03/2023- 1598 165 224 1
1.5 Turbo D 2 10/2021- 1499 96 131 1
Astra-e (F4ZKWZ) 11 03/2023- 115 156 1
