Product 78BD0108-2

Description
Brake disc
Axe
Front
No. of Pieces
2
Barcode
EAN13 Code
8424073208521
QR Code
Url
https://catalogonuevo.icerbrakes.com/Producto/Details?idProducto=78BD0108-2
Weight (gr.)
6680
R90 Homologation
R90 90R-02C0538/0103
Measures
Ø280x25x51.15
Brake Disc Type: Vented
Minimum thickness [mm]: 22.4
Hole Arrangement/Number: 5
Bolt Hole Circle Ø [mm]: 112
Wheel Hub Diameter [mm]: 67
Reference applications
Brand OE Reference
MERCEDES-BENZ 246 421 00 12
MERCEDES-BENZ 246 421 00 12 07
MERCEDES-BENZ 246 421 11 12
MERCEDES-BENZ A24 642 10 01 2
MERCEDES-BENZ A24 642 10 01 20 7
MERCEDES-BENZ A24 642 11 11 2
Maker Cross reference
ATE 24.0125-0200.1
BOSCH 0 986 479 A00
BREMBO 09.B343.41
FERODO DF2334C-1
HELLA-PAGID 8DD 355 119-601
LETEC LBM060V
MINTEX MDC2538
TEXTAR 92257005
TRW DF6548
MERCEDES-BENZ
A-Class III (W176) Hatchback 06/2012-
Vehicle Engine Fuel Date CC KW CV Traction
A 160 (176.041)

M 270.910

 1 07/2015-05/2018 1595 75 102 1
A 180 (176.042)

M 270.910

 1 09/2012-05/2018 1595 90 122 1
A 200 (176.043)

M 270.910

 1 06/2012-05/2018 1595 115 156 1
A 200 Flex Urban Turbo (176.043)

M 270.910

 19 06/2015-05/2018 1595 115 156 1
A 160 CDI / d (176.011)

OM 607.951

 2 06/2013-05/2018 1461 66 90 1
A 180 CDI (176.000)

OM 651.901

 2 06/2012-10/2014 1796 80 109 1
A 180 CDI / d (176.012)

OM 607.951

 2 06/2012-05/2018 1461 80 109 1
B-Class II Sports Tourer (W246, W242) Hatchback 10/2011-
Vehicle Engine Fuel Date CC KW CV Traction
B 160 (246.241)

M 270.910

 1 07/2015-12/2018 1595 75 102 1
B 180 (246.242)

M 270.910

 1 11/2011-12/2018 1595 90 122 1
B 160 CDI / d (246.211)

OM 607.951

 2 05/2013-12/2018 1461 66 90 1
B 180 CDI (246.200)

OM 651.901

 2 11/2011-08/2014 1796 80 109 1
B 180 CDI / d (246.212)

OM 607.951

 2 02/2013-12/2018 1461 80 109 1
CLA-Class (C117) Coupe 01/2013-
Vehicle Engine Fuel Date CC KW CV Traction
CLA 180 (117.342)

M 270.910

 1 01/2013-03/2019 1595 90 122 1
CLA 180 CDI / d (117.312)

OM 607.951

 2 10/2013-05/2018 1461 80 109 1
