Product 78BD0356-2

Description
Brake disc
Axe
Front
No. of Pieces
2
Barcode
EAN13 Code
8424073142337
QR Code
Url
https://catalogonuevo.icerbrakes.com/Producto/Details?idProducto=78BD0356-2
Weight (gr.)
12524
R90 Homologation
R90 90R-02C0538/0081
Measures
Ø284x22x43.4
Brake Disc Type: Vented
Minimum thickness [mm]: 20.2
Hole Arrangement/Number: 4
Bolt Hole Circle Ø [mm]: 98
Wheel Hub Diameter [mm]: 59.05
Reference applications
Brand OE Reference
ALFA ROMEO 6 081 040 4
FIAT 4 640 395 9
FIAT 4 644 500 4
FIAT 4 644 589 2
FIAT 4 644 816 8
FIAT 4 644 846 8
FIAT 4 645 580 4
FIAT 6 080 613 5
FIAT 6 081 216 4
FIAT 7 173 956 9
FIAT 9 081 303 8
LANCIA 4 640 308 8
LANCIA 4 645 589 2
LANCIA 4 675 871 4
LANCIA 6 081 242 2
LANCIA 6 081 303 8
LANCIA 8 243 391 8
LANCIA 8 244 035 6
LANCIA 8 245 065 7
LANCIA 8 245 174 6
Maker Cross reference
ATE 24.0122-0147.1
ATE 422147
BENDIX ANTIGUO 561387B
BOSCH 0 986 478 810
BREMBO 09.4939.10
BREMBO 09.4939.14
BREMBO 09.9624.14
DELPHI LOCKHEED BG2407
FERODO DDF220
GIRLING 6025661
HELLA-PAGID 51808
LETEC LBY005V
MINTEX MDC616
NECTO WN477
ROAD HOUSE 6316.11
SANLI SL34429
TEXTAR 92053500
TRW DF2566
VALEO 186266
ABARTH
500 / 595 / 695 () Hatchback 01/2008-
Vehicle Engine Fuel Date CC KW CV Traction
1.4 (312.AXD1A)

312 A1.000

 1 08/2008- 1368 99 135 1
1.4 (312.AXF1A, 312.AXF11, 312.AXD1A)

312 A3.000

 1 05/2010- 1368 103 140 1
1.4 (312.AXT1A) 1 08/2008- 1368 140 190 1
ALFA ROMEO
155 (167_) Saloon 01/1992-12/1997
Vehicle Engine Fuel Date CC KW CV Traction
2.0 16V Turbo Q4 (167.A2B, 167.A2C, 167.A2E)

AR 67203

 1 01/1992-12/1997 1995 137 186 3
2.0 16V Turbo Q4 (167.A2B, 167.A2C, 167.A2E)

AR 67203

 1 03/1992-12/1997 1995 140 190 3
2.5 V6 (167.A1C, 167.A1E)

AR 67302

AR 67303

 1 09/1992-12/1997 2492 120 163 1
2.5 V6 (167.A1C, 167.A1E)

AR 67301

 1 03/1992-05/1995 2492 121 165 1
2.5 TD (167.A1A, 167.A1G)

VM 07 B

VM 31 B

 2 04/1993-12/1997 2499 92 125 1
CHRYSLER
DELTA () Hatchback 08/2011-
Vehicle Engine Fuel Date CC KW CV Traction
1.4

198 A4.000

 1 08/2011- 1368 88 120 1
1.6 D Multijet

198 A2.000

 2 08/2011- 1598 88 120 1
FIAT
BRAVO (182_) Hatchback 10/1995-10/2001
Vehicle Engine Fuel Date CC KW CV Traction
2.0 HGT 20V (182.AD)

182 A1.000

 1 10/1995-07/1998 1998 108 147 1
2.0 HGT 20V (182AQ)

182 B7.000

 1 07/1998-10/2001 1998 113 154 1
BRAVO II / RITMO III (198_) Hatchback 11/2006-
Vehicle Engine Fuel Date CC KW CV Traction
1.9 D Multijet (198AXB1A)

192 A8.000

 2 04/2007-12/2014 1910 88 120 1
COUPE (175_) Coupe 11/1993-08/2000
Vehicle Engine Fuel Date CC KW CV Traction
2.0 16V Turbo

175 A1.000

 1 11/1993-08/1996 1995 140 190 1
2.0 20V Turbo

175 A3.000

 1 08/1996-08/2000 1998 162 220 1
CROMA (154_) Hatchback 12/1985-12/1996
Vehicle Engine Fuel Date CC KW CV Traction
2500 V6

834 G.000

 1 06/1993-08/1996 2492 119 162 1
DOBLO (119_, 223_) MPV 03/2001-
Vehicle Engine Fuel Date CC KW CV Traction
1.6 1 09/2002- 1596 68 92 1
1.6 Natural Power (223AXD1A)

182 B6.000

 16 11/2005-07/2009 1596 68 92 1
IDEA (350_) MPV 12/2003-
Vehicle Engine Fuel Date CC KW CV Traction
1.8

93313090-7U

 1 01/2008-07/2010 1796 81 110 1
1.3 D Multijet

199 A3.000

 2 10/2005- 1248 66 90 1
1.6 D Multijet

350 A2.000

 2 05/2008- 1598 88 120 1
1.9 JTD

188 B2.000

 2 01/2004- 1910 74 101 1
IDEA (350_) Box Body/MPV 12/2003-
Vehicle Engine Fuel Date CC KW CV Traction
JTD Multijet (350BXG1A) 2 04/2005-12/2010 1248 66 90 1
MJTD (350BXD1A) 2 10/2004-12/2010 1910 74 101 1
LINEA (323_, 110_) Saloon 10/2006-
Vehicle Engine Fuel Date CC KW CV Traction
1.4 T-Jet 1 09/2007-03/2013 1368 84 114 1
1.4 T-Jet (323AXC1A)

198 A4.000

 1 05/2007- 1368 88 120 1
1.6 (323.AXF1A)

310 A5.011

 1 10/2011- 1598 81 110 1
1.6 D Multijet

198 A3.000

 2 06/2009- 1598 77 105 1
MAREA (185_) Saloon 05/1996-12/2007
Vehicle Engine Fuel Date CC KW CV Traction
2.0 150 20V

182 A1.000

 1 09/1996-04/1999 1998 108 147 1
2.0 150 20V

185 A8.000

 1 01/2001-05/2002 1998 110 150 1
2.0 155 20V

182 B7.000

 1 04/1999-01/2001 1998 113 154 1
2.4 JTD 130

185 A6.000

839 A5.000

 2 04/1999-05/2002 2387 96 130 1
2.4 TD 125

185 A2.000

 2 09/1996-04/1999 2387 91 125 1
MAREA Weekend (185_) Estate 09/1996-12/2007
Vehicle Engine Fuel Date CC KW CV Traction
2.0 150 20V

182 A1.000

 1 09/1996-04/1999 1998 108 147 1
2.0 150 20V

185 A8.000

 1 01/2001-05/2002 1998 110 150 1
2.0 155 20V

182 B7.000

 1 04/1999-02/2003 1998 113 154 1
2.4 JTD 130

185 A6.000

839 A5.000

 2 04/1999-05/2002 2387 96 130 1
2.4 TD 125

185 A2.000

 2 09/1996-04/1999 2387 91 125 1
STILO (192_) Hatchback 10/2001-11/2010
Vehicle Engine Fuel Date CC KW CV Traction
1.8 16V 1 06/2002-12/2007 1747 90 122 1
1.8 16V (192AXC1A, 192BXC1A)

192 A4.000

 1 10/2001-04/2007 1747 98 133 1
1.9 D Multijet

192 A9.000

 2 09/2005-11/2006 1910 74 100 1
1.9 D Multijet

192 A8.000

 2 09/2005-11/2006 1910 88 120 1
1.9 D Multijet

937 A5.000

 2 09/2005-11/2006 1910 110 150 1
1.9 JTD

937 A4.000

 2 09/2003-11/2006 1910 93 126 1
1.9 JTD

192 B1.000

 2 04/2004-11/2006 1910 100 136 1
1.9 JTD

192 A5.000

 2 01/2004-11/2006 1910 103 140 1
1.9 JTD (192_XE1A)

192 A1.000

937 A7.000

 2 10/2001-11/2006 1910 85 115 1
1.9 JTD (192_XF1A)

192 A3.000

 2 02/2002-11/2006 1910 59 80 1
1.9 JTD (192AXS1B, 192BXS1B)

192 B5.000

 2 09/2004-11/2006 1910 66 90 1
STILO (192_) Estate Van 10/2001-08/2008
Vehicle Engine Fuel Date CC KW CV Traction
1.6 (192DXR1A)

192 B3.000

 1 04/2005-08/2008 1598 77 105 1
1.9 JTD (192DXE1A)

192 A1.000

 2 10/2001-08/2005 1910 85 116 1
1.9 JTD (192DXF1A)

192 A3.000

 2 10/2001-08/2005 1910 59 80 1
1.9 JTD (192DXG1B)

937 A4.000

 2 09/2003-08/2005 1910 93 126 1
1.9 JTD (192DXG1B)

192 B1.000

 2 02/2004-08/2008 1910 100 136 1
1.9 JTD (192DXG1B)

192 A5.000

 2 09/2003-08/2005 1910 103 140 1
1.9 JTD (192DXS1A)

192 A8.000

 2 09/2005-08/2008 1910 88 120 1
1.9 JTD (192DXT1B)

937 A5.000

 2 09/2005-08/2008 1910 110 150 1
STILO Multi Wagon (192_) Estate 01/2003-08/2008
Vehicle Engine Fuel Date CC KW CV Traction
1.6 16V

192 B3.000

 1 03/2005-12/2007 1598 77 105 1
1.8 16V

192 A4.000

 1 01/2003-08/2008 1747 98 133 1
1.9 D

192 B5.000

 2 09/2004-08/2008 1910 66 90 1
1.9 D Multijet

192 A9.000

 2 09/2005-08/2008 1910 74 100 1
1.9 D Multijet

192 A8.000

 2 09/2005-08/2008 1910 88 120 1
1.9 D Multijet (192DXT1B)

937 A5.000

 2 09/2005-08/2008 1910 110 150 1
1.9 JTD

192 A3.000

 2 01/2003-08/2008 1910 59 80 1
1.9 JTD

192 A1.000

937 A7.000

 2 01/2003-08/2008 1910 85 115 1
1.9 JTD

937 A4.000

 2 09/2003-08/2008 1910 93 126 1
1.9 JTD

192 B1.000

 2 04/2004-08/2008 1910 100 136 1
1.9 JTD

192 A5.000

 2 01/2004-08/2008 1910 103 140 1
LANCIA
DELTA (831_) Hatchback 09/1979-01/1994
Vehicle Engine Fuel Date CC KW CV Traction
2.0 16V HF Integrale (831AB.026)

831 D5.000

 1 03/1989-09/1991 1995 144 196 3
2.0 HF Integrale (831AB.024S, 831AB.028)

831 B5.000

 1 11/1986-08/1988 1995 122 166 3
2.0 HF Integrale (831AB.024S, 831AB.028)

831 C5.046

 1 12/1986-12/1992 1995 130 177 3
2.0 HF Integrale (831AB.024S, 831AB.028)

831 C5.000

 1 10/1987-12/1991 1995 133 181 3
DELTA II (836_) Hatchback 06/1993-09/1999
Vehicle Engine Fuel Date CC KW CV Traction
2.0 16V Turbo (836AB)

836 A2.000

 1 06/1993-08/1999 1995 137 186 1
2.0 16V Turbo (836AS)

175 A4.000

 1 07/1996-08/1999 1995 142 193 1
DELTA III (844_) Hatchback 08/2008-08/2014
Vehicle Engine Fuel Date CC KW CV Traction
1.4 (844.AXA1A)

198 A4.000

 1 09/2008-08/2014 1368 88 120 1
1.4 Bifuel (844.AXA1A)

198 A4.000

 18 07/2011-08/2014 1368 88 120 1
1.6 D Multijet (844.AXC11, 844.AXC1A)

198 A2.000

 2 09/2008-08/2014 1598 88 120 1
1.6 D Multijet (844.AXF11, 844.AXF1A)

955 A4.000

 2 08/2008-08/2014 1598 85 116 1
LYBRA (839_) Saloon 07/1999-10/2005
Vehicle Engine Fuel Date CC KW CV Traction
1.8 16V (839AXB1A, 839AXG1A)

839 A4.000

839 A7.000

839 A9.000

 1 07/1999-10/2005 1747 96 131 1
2.0 20V (839AXC11, 839AXC1A)

182 B7.000

 1 07/1999-09/2000 1998 113 154 1
2.0 20V (839AXH1A)

185 A8.000

 1 09/2000-10/2005 1998 110 150 1
2.4 20V (839.CXM1A)

192 A2.000

 1 10/2001-10/2005 2446 125 170 1
1.9 JTD (839.AXI1A, 839.AXN1A, 839.CXL1A)

937 A2.000

 2 05/2001-10/2005 1910 85 116 1
1.9 JTD (839AXD1A)

AR 32302

 2 07/1999-09/2000 1910 77 105 1
1.9 JTD (839AXI1A)

AR 37101

 2 09/2000-05/2001 1910 81 110 1
2.4 JTD (839.AXE1A)

841 C.000

 2 05/2002-10/2005 2387 110 150 1
2.4 JTD (839AXE1A)

839 A5.000

AR 32501

 2 07/1999-02/2001 2387 99 135 1
2.4 JTD (839AXL1A)

839 A6.000

 2 09/2000-05/2002 2387 103 140 1
LYBRA SW (839_) Estate 07/1999-10/2005
Vehicle Engine Fuel Date CC KW CV Traction
1.8 16V (839BXB1A, 839BXG1A)

839 A4.000

839 A7.000

 1 07/1999-10/2005 1747 96 131 1
2.0 20V (839BXC11, 839BXC1A)

182 B7.000

 1 07/1999-09/2000 1998 113 154 1
2.0 20V (839BXH1A)

185 A8.000

 1 09/2000-10/2005 1998 110 150 1
1.9 JTD (839.BXI1A, 839.BXN1A, 839.CXL1A)

937 A2.000

 2 05/2001-10/2005 1910 85 116 1
1.9 JTD (839BXD1A)

AR 32302

 2 07/1999-09/2001 1910 77 105 1
1.9 JTD (839BXI1A)

AR 37101

 2 09/2000-05/2001 1910 81 110 1
2.4 JTD (839.BXE1A)

841 C.000

 2 05/2002-10/2005 2387 110 150 1
2.4 JTD (839BXE1A)

839 A5.000

AR 32501

 2 10/1999-09/2000 2387 99 135 1
2.4 JTD (839BXL1A)

839 A6.000

 2 09/2000-10/2005 2387 103 140 1
MUSA (350_) MPV 10/2004-09/2012
Vehicle Engine Fuel Date CC KW CV Traction
1.6 D Multijet (350.AXH1A)

350 A2.000

 2 07/2008-09/2012 1598 88 120 1
1.6 D Multijet (350.AXL1A, 350.AXH1A)

350 A2.000

350 A3.000

 2 07/2008-09/2012 1598 85 116 1
1.9 D Multijet (350.AXC1A)

188 B2.000

 2 10/2004-09/2012 1910 74 101 1
THEMA (834_) Saloon 11/1984-07/1994
Vehicle Engine Fuel Date CC KW CV Traction
2000 16V Turbo (834AC)

834 C1.000

 1 12/1988-06/1990 1995 133 181 1
2000 16V Turbo (834GC, 834FC)

834 F2.000

 1 10/1992-07/1994 1995 148 201 1
2000 i.e. 16V Turbo (834AL)

834 C1.246

 1 04/1989-05/1992 1995 130 177 1
2000 i.e. Turbo (834C)

834 C.000

 1 11/1984-12/1989 1995 122 166 1
THEMA SW (834_) Estate 03/1987-07/1994
Vehicle Engine Fuel Date CC KW CV Traction
2000 i.e. 16V Turbo (834AL)

834 C1.246

 1 04/1989-03/1993 1995 130 177 1
2000 i.e. 16V Turbo (834AL)

834 C1.000

 1 12/1988-06/1990 1995 133 181 1
2000 Turbo (834.FA, 834.BV, 834.CV)

834 C.146

 1 12/1988-03/1992 1995 110 150 1
2000 Turbo 16V (834GC, 834FC)

834 F2.000

 1 11/1992-07/1994 1995 148 201 1
3000 V6 (834GD, 834FD)

834 F.000

 1 09/1992-07/1994 2959 126 171 1
