Product 78BD0416-2 - Web Catalogo

Description: Brake disc
Axe: Rear
No. of Pieces: 2
Barcode: 8424073142429
Url: https://catalogonuevo.icerbrakes.com/Producto/Details?idProducto=78BD0416-2
Weight (gr.): 9932

R90 Homologation: 90R-02C0453/0108
Measures: Ø296x10x57.8
: Brake Disc Type: solid; Minimum thickness [mm]: 8; Hole Arrangement/Number: 5; Bolt Hole Circle Ø [mm]: 112; Wheel Hub Diameter [mm]: 67

Reference applications

Brand	OE Reference
MERCEDES-BENZ	639 423 01 12

Vehicle	Engine	Fuel	Date	CC	KW	CV	Traction
3.2 (639.711, 639.811, 639.813)	M 112.951	1	09/2003-	3199	140	190	2
3.2 (639.713, 639.813, 639.815)	M 112.951	1	09/2003-	3199	160	218	2
3.5 (639.811, 639.813, 639.815)	M 272.978	1	09/2007-	3498	190	258	2
3.7 (639.811, 639.813, 639.815)	M 112.976	1	06/2004-07/2007	3724	165	224	2
3.7 (639.815)	M 112.976	1	06/2004-	3724	170	231	2
CDI 2.0 (639.711, 639.713, 639.811, 639.813, 639.815)	OM 646.982	2	09/2003-	2148	80	109	2
CDI 2.0 (639.711, 639.713, 639.811, 639.813, 639.815)	OM 646.982	2	08/2005-	2148	85	116	2
CDI 2.0 4-matic (639.713)	OM 646.982	2	07/2005-	2148	80	109	3
CDI 2.0 4-matic (639.713)	OM 646.982	2	03/2006-	2148	85	116	3
CDI 2.2 (639.711, 639.713, 639.811, 639.813, 639.815)		2	09/2010-	2143	70	95	2
CDI 2.2 (639.711, 639.713, 639.811, 639.813, 639.815)	OM 646.980 OM 646.982	2	09/2003-	2148	110	150	2
CDI 2.2 (639.811, 639.813, 639.815, 639.711, 639.713)	OM 651.940	2	07/2010-	2143	100	136	2
CDI 2.2 (639.811, 639.813, 639.815, 639.711, 639.713)	OM 651.940	2	01/2014-	2143	110	150	2
CDI 2.2 (639.811, 639.813, 639.815, 639.711, 639.713)	OM 651.940	2	07/2010-	2143	120	163	2
CDI 2.2 4-matic (639.711, 639.713, 639.811, 639.813,...	OM 646.982	2	07/2005-	2148	110	150	3
CDI 2.2 4-matic (639.811, 639.813, 639.815, 639.711,...	OM 651.940	2	07/2010-	2143	100	136	3
CDI 2.2 4-matic (639.811, 639.813, 639.815, 639.711,...	OM 651.940	2	07/2010-	2143	120	163	3
CDI 3.0 (639.811, 639.813, 639.815)	OM 642.990	2	03/2006-	2987	150	204	2
CDI 3.0 (639.811, 639.813, 639.815)	OM 642.890	2	07/2010-	2987	165	224	2

Vehicle	Engine	Fuel	Date	CC	KW	CV	Traction
119 (639.601, 639.603, 639.605)	M 112.951	1	09/2003-	3199	140	190	2
122 (639.601, 639.603, 639.605)	M 112.951	1	09/2003-	3199	160	218	2
123 (639.601, 639.603, 639.605)	M 112.976	1	06/2004-07/2008	3724	165	224	2
123 (639.601)	M 112.976	1	06/2004-07/2008	3724	170	231	2
126 (639.601, 639.603, 639.605)	M 272.978	1	09/2007-	3498	190	258	2
109 CDI (639.601, 639.603, 639.605)	OM 646.983	2	09/2003-	2148	65	88	2
109 CDI (639.601, 639.603, 639.605)	OM 646.980 OM 646.981	2	08/2006-	2148	70	95	2
110 CDI (639.601, 639.603, 639.605)	OM 651.940	2	09/2010-	2143	70	95	2
111 CDI (639.601, 639.603, 639.605)		2	05/2012-02/2015	2143	85	116	2
111 CDI (639.601, 639.603, 639.605)	OM 646.982	2	09/2003-	2148	80	109	2
111 CDI (639.601, 639.603, 639.605)	OM 646.980 OM 646.982	2	09/2007-	2148	85	116	2
111 CDI 4x4 (639.601, 639.603, 639.605)	OM 646.982	2	09/2007-	2148	80	109	3
113 CDI (639.601, 639.603, 639.605)	OM 651.940	2	09/2010-	2143	100	136	2
113 CDI 4x4 (639.601, 639.603, 639.605)	OM 651.940	2	09/2010-	2143	100	136	3
115 CDI (639.601, 639.603, 639.605)	OM 646.980 OM 646.982	2	09/2003-	2148	110	150	2
115 CDI (639.605, 639.601, 639.603)	OM 651.940	2	05/2012-02/2015	2143	110	150	2
115 CDI 4x4 (639.601, 639.603, 639.605)	OM 646.982	2	07/2006-	2148	110	150	3
116 CDI (639.601, 639.603, 639.605)	OM 651.940	2	09/2010-	2143	120	163	2
116 CDI 4x4 (639.601, 639.603, 639.605)	OM 651.940	2	09/2010-	2143	120	163	3
120 CDI (639.601, 639.603, 639.605)	OM 642.990	2	07/2006-	2987	150	204	2
122 CDI (639.601, 639.603, 639.605)	OM 642.890	2	09/2010-	2987	165	224	2
E-CELL (639.601, 639.603, 639.605)	EM 780.994	11	03/2012-		60	82	1

Vehicle	Engine	Fuel	Date	CC	KW	CV	Traction
119 (639.701, 639.703, 639.705)	M 112.951	1	09/2003-	3199	140	190	2
122 (639.701, 639.703, 639.705)	M 112.951	1	09/2003-	3199	160	218	2
123 (639.701, 639.703, 639.705)	M 112.976	1	06/2004-07/2008	3724	165	224	2
123 (639.701)	M 112.976	1	06/2004-07/2008	3724	170	231	2
126 (639.701, 639.703, 639.705)	M 272.978	1	09/2007-	3498	190	258	2
109 CDI (639.701, 639.703, 639.705)	OM 646.983	2	09/2003-	2148	65	88	2
109 CDI (639.701, 639.703, 639.705)	OM 646.980	2	09/2006-	2148	70	95	2
109 CDI 4x4 (639.701)	OM 646.981	2	09/2007-08/2014	2148	70	95	3
110 CDI (639.701, 639.703, 639.705)	OM 651.940	2	09/2010-08/2014	2143	70	95	2
111 CDI (639.701, 639.703, 639.705)	OM 646.982	2	09/2003-	2148	80	109	2
111 CDI (639.701, 639.703, 639.705)	OM 646.980	2	09/2007-	2148	85	116	2
111 CDI 4x4 (639.701, 639.703, 639.705)	OM 646.982	2	09/2007-08/2014	2148	80	109	3
113 CDI (639.701, 639.703, 639.705)	OM 651.940	2	09/2010-	2143	100	136	2
113 CDI 4x4 (639.701, 639.703, 639.705)	OM 651.940	2	09/2010-08/2014	2143	100	136	3
115 CDI (639.701, 639.703, 639.705)		2	05/2012-02/2015	2143	110	150	2
115 CDI (639.701, 639.703, 639.705)	OM 646.980 OM 646.982	2	09/2003-	2148	110	150	2
115 CDI 4x4 (639.701, 639.705)	OM 646.982	2	09/2007-08/2014	2148	110	150	3
116 CDI (639.701, 639.703, 639.705)	OM 651.940	2	09/2010-	2143	120	163	2
116 CDI 4x4 (639.701, 639.703, 639.705)	OM 651.940	2	09/2010-08/2014	2143	120	163	3
120 CDI (639.701, 639.703, 639.705)	OM 642.990	2	07/2006-	2987	150	204	2
122 CDI (639.701, 639.703, 639.705)	OM 642.890	2	09/2010-	2987	165	224	2
E-CELL (639.703)	EM 780.994	11	03/2012-		60	82	1

Vehicle	Fuel	Date	CC	KW	CV	Traction
119 2.5	1	01/2010-03/2016	2496	140	190	2
122 3.0	1	05/2013-03/2016	2996	165	224	2
115 CDI 2.2	2	01/2010-12/2011	2148	110	150	2
2.1	2	08/2013-03/2016	2143	110	150	2
