Product 78BD0586-2 - Web Catalogo

Description: Brake disc
Axe: Front
No. of Pieces: 2
Barcode: 8424073208491
Url: https://catalogonuevo.icerbrakes.com/Producto/Details?idProducto=78BD0586-2
Weight (gr.): 8530

R90 Homologation: 90R-02C0452/0127
Measures: Ø300x28x47.15
: Brake Disc Type: Vented; Minimum thickness [mm]: 26; Hole Arrangement/Number: 5; Bolt Hole Circle Ø [mm]: 114.3; Wheel Hub Diameter [mm]: 69

Reference applications

Brand	OE Reference
HYUNDAI	51712-3K100
HYUNDAI	51712-3K110
HYUNDAI	51712-3K150
HYUNDAI	517123K300
HYUNDAI	517123V000
HYUNDAI	51712A0000
HYUNDAI	51712M0500
KIA	51712-0Z000
KIA	51712-2Y000
KIA	51712-3K160
KIA	517121M500
KIA	517122L500
KIA	517123Q000
KIA	517123R000
KIA	51712A6600
KIA	S517120Z000
KIA	S517122L500
KIA	S517123K160
KIA	S517123K160A

Maker	Cross reference
BOSCH	0 986 47 C51
HELLA-PAGID	8DD 355 114-511
LETEC	LBD044V
TEXTAR	92166505
TRW	DF6108S

HYUNDAI

CRETA / ix25 / CANTUS (GS) SUV 01/2016-

Vehicle	Engine	Fuel	Date	CC	KW	CV	Traction
1.6	G4FG	1	07/2018-	1591	89	121	1
1.6	G4FG	1	01/2016-01/2021	1591	90	123	1
1.6 4WD	G4FG	1	08/2016-01/2021	1591	90	123	3
2.0	G4NA	1	01/2016-01/2021	1999	110	150	1
2.0 4WD		1	01/2016-01/2021	1999	110	149	3
1.6 Attitude, Pulse, Flex		19	01/2017-01/2021	1591	96	130	1
1.4 CRDi	D4FC	2	01/2016-01/2021	1396	66	90	1
1.6 CRDI	D4FB	2	01/2016-01/2021	1582	94	128	1

CRETA II / ix25 II / CANTUS II (SU2_) SUV 03/2020-

Vehicle	Engine	Fuel	Date	CC	KW	CV	Traction
1.6 MPi 4WD (SU2R)		1	09/2021-	1591	89	121	3
2.0 MPi 4WD (SU2R)		1	09/2021-	1999	110	150	3

GRANDEUR V / AZERA V (HG) Saloon 01/2011-

Vehicle	Engine	Fuel	Date	CC	KW	CV	Traction
2.4	G4KE	1	07/2011-	2359	132	180	1
2.4 16V	G4KE	1	01/2011-10/2016	2359	148	201	1
2.4 GDI		1	02/2011-04/2016	2359	140	190	1
3.0	G6DG	1	02/2011-10/2016	2999	199	271	1
3.0 GDi	G6DG	1	12/2011-	2999	195	265	1
3.0 MPI	G6DE	1	07/2011-	2999	184	250	1
3.0 MPI	G6DE G6DG	1	01/2012-10/2016	2999	184	250	1
3.3	G6DH	1	02/2011-10/2016	3342	216	294	1
3.3	G6DH	1	09/2011-	3342	218	296	1
3.3 GDI	G6DH	1	02/2011-10/2016	3342	210	286	1
2.4 Hybrid		13	07/2011-	2359	150	204	1
2.4 LPI	G4KJ	18	01/2011-10/2013	2359	148	201	1
3.0 LPG	G6DG	18	01/2011-12/2011	2999	173	235	1
2.2 D	D4HB	2	01/2011-	2199	147	200	1

i30 (FD) Estate 10/2007-06/2012

Vehicle	Engine	Fuel	Date	CC	KW	CV	Traction
1.4	G4FA	1	10/2007-06/2012	1396	77	105	1
1.4	G4FA	1	11/2009-06/2012	1396	80	109	1
1.6	G4FC	1	02/2008-06/2012	1591	85	116	1
1.6	G4FC	1	02/2008-06/2012	1591	90	122	1
1.6	G4FC	1	02/2008-06/2012	1591	93	126	1
2.0	G4GC	1	02/2008-06/2012	1975	105	143	1
1.4 LPG	G4FA	18	11/2009-06/2012	1396	80	109	1
1.6 CRDI	D4FB	2	02/2008-06/2012	1582	66	90	1
1.6 CRDI	D4FB	2	02/2008-06/2012	1582	85	116	1
1.6 CRDI	D4FB	2	01/2010-06/2012	1582	94	128	1
2.0 CRDi	D4EA	2	10/2008-06/2012	1991	100	136	1
2.0 CRDi	D4EA	2	02/2008-06/2012	1991	103	140	1

i30 (FD) Hatchback 10/2007-07/2012

Vehicle	Engine	Fuel	Date	CC	KW	CV	Traction
1.4	G4FA	1	10/2007-11/2011	1396	77	105	1
1.4	G4FA	1	10/2007-11/2011	1396	80	109	1
1.6	G4FC	1	10/2007-11/2011	1591	85	116	1
1.6	G4FC	1	10/2007-11/2011	1591	90	122	1
1.6	G4FC	1	02/2008-11/2011	1591	93	126	1
2.0	G4GC	1	09/2008-11/2011	1975	103	140	1
2.0	G4GC	1	10/2007-11/2011	1975	105	143	1
1.4 LPG	G4FA	18	01/2009-11/2011	1396	80	109	1
1.6 CRDI	D4FB	2	10/2007-11/2011	1582	66	90	1
1.6 CRDI	D4FB	2	10/2007-11/2011	1582	85	116	1
1.6 CRDI	D4FB	2	01/2010-11/2011	1582	94	128	1
1.6 CRDi VGT	D4FB	2	10/2007-11/2011	1582	81	110	1
2.0 CRDi	D4EA	2	10/2007-11/2011	1991	100	136	1
2.0 CRDi	D4EA	2	10/2007-11/2011	1991	103	140	1

i30 II (GD) Hatchback 06/2011-

Vehicle	Engine	Fuel	Date	CC	KW	CV	Traction
1.4	G4LC	1	12/2014-12/2016	1368	74	101	1
1.4	G4FA	1	12/2011-12/2015	1396	73	99	1
1.6	G4FC	1	01/2012-12/2016	1591	88	120	1
1.6	G4FC	1	12/2011-12/2015	1591	95	129	1
1.6	G4FC	1	06/2014-	1591	96	131	1
1.6 GDI	G4FD	1	12/2011-12/2016	1591	99	135	1
1.6 GDI	G4FD	1	06/2011-	1591	103	140	1
1.6 MPi		1	06/2014-	1591	94	128	1
1.6 T-GDI	G4FJ	1	01/2015-	1591	137	186	1
1.8		1	08/2013-	1797	107	146	1
1.8	G4NB	1	09/2012-	1797	108	147	1
1.8	G4NB	1	01/2012-	1797	110	150	1
2.0		1	12/2014-02/2017	1999	124	169	1
2.0		1	09/2013-	1999	129	175	1
2.0 GDI	G4NC	1	10/2014-	1999	127	173	1
1.4 LPG	G4FA	18	01/2013-12/2014	1396	73	99	1
1.6 16V Flex	F4FC	19	11/2011-12/2016	1591	94	128	1
1.4 CRDi	D4FC	2	12/2011-12/2016	1396	66	90	1
1.6 CRDI	D4FB	2	12/2011-12/2016	1582	81	110	1
1.6 CRDI	D4FB	2	12/2011-12/2015	1582	94	128	1
1.6 CRDI	D4FB	2	11/2011-12/2016	1582	100	136	1

i30 II (GD) Estate 06/2012-

Vehicle	Engine	Fuel	Date	CC	KW	CV	Traction
1.4	G4LC	1	01/2014-05/2017	1368	74	101	1
1.4	G4FA	1	06/2012-12/2015	1396	73	99	1
1.6	G4FC	1	06/2012-	1591	88	120	1
1.6	G4FD	1	06/2012-12/2015	1591	95	129	1
1.6 GDI	G4FD	1	06/2012-	1591	99	135	1
1.4 CRDi	D4FC	2	06/2012-05/2017	1396	66	90	1
1.6 CRDI	D4FB	2	06/2012-	1582	81	110	1
1.6 CRDI	D4FB	2	06/2012-12/2015	1582	94	128	1
1.6 CRDI	D4FB	2	06/2012-	1582	100	136	1

i30 II (GDE, GD) Estate Van 06/2012-

Vehicle	Engine	Fuel	Date	CC	KW	CV	Traction
1.4 MPI	G4LC	1	05/2015-	1368	74	101	1
1.6 GDI	G4FD	1	05/2015-	1591	99	135	1
1.6 CRDI	D4FB	2	05/2015-	1582	81	110	1

i30 II (GDE) Hatchback Van 06/2012-

Vehicle	Engine	Fuel	Date	CC	KW	CV	Traction
1.6 GDI	G4FD	1	05/2015-	1591	99	135	1
1.6 CRDI	D4FB	2	05/2015-	1582	81	110	1

i30 II (GD) Coupe 05/2013-

Vehicle	Engine	Fuel	Date	CC	KW	CV	Traction
1.4	G4LC	1	12/2014-	1368	74	101	1
1.4	G4FA	1	05/2013-12/2014	1396	73	99	1
1.6 GDI	G4FD	1	05/2013-	1591	99	135	1
1.6 MPi	G4FC	1	05/2013-	1591	88	120	1
1.6 MPi	G4FC	1	06/2014-	1591	96	131	1
1.6 T-GDI	G4FJ	1	01/2015-	1591	137	186	1
1.4 CRDi	D4FC	2	05/2013-05/2017	1396	66	90	1
1.6 CRDI	D4FB	2	05/2013-	1582	81	110	1
1.6 CRDI	D4FB	2	05/2013-	1582	94	128	1
1.6 CRDI	D4FB	2	12/2014-	1582	100	136	1

i40 (VF) Estate Van 07/2011-

Vehicle	Engine	Fuel	Date	CC	KW	CV	Traction
1.7 CRDi	D4FD	2	05/2015-05/2019	1685	85	116	1

i40 I CW (VF) Estate 07/2011-

Vehicle	Engine	Fuel	Date	CC	KW	CV	Traction
1.6 GDI	G4FD	1	07/2011-05/2019	1591	99	135	1
2.0		1	03/2012-05/2019	1999	122	166	1
2.0 CVVT	G4NA	1	10/2012-05/2019	1999	110	150	1
2.0 CVVT	G4NA	1	07/2018-05/2019	1999	112	152	1
2.0 CVVT	G4NA	1	06/2012-05/2019	1999	121	165	1
2.0 CVVT	G4NA	1	07/2011-05/2019	1999	130	177	1
2.0 GDI	G4NC	1	12/2014-05/2019	1999	121	165	1
2.0 GDI	G4NC	1	07/2011-05/2019	1999	130	177	1
1.6 CRDI	D4FE	2	07/2018-05/2019	1598	85	116	1
1.6 CRDI	D4FE	2	07/2018-05/2019	1598	100	136	1
1.7 CRDi	D4FD	2	07/2011-05/2019	1685	85	116	1
1.7 CRDi	D4FD	2	07/2011-05/2019	1685	100	136	1
1.7 CRDi	D4FD	2	03/2012-05/2019	1685	103	140	1
1.7 CRDi	D4FD	2	01/2015-05/2019	1685	104	141	1

i40 (VF) Saloon 03/2012-

Vehicle	Engine	Fuel	Date	CC	KW	CV	Traction
1.6 GDI	G4FD	1	03/2012-05/2019	1591	99	135	1
2.0		1	03/2012-05/2019	1999	123	167	1
2.0 CVVT	G4NA	1	10/2012-05/2019	1999	110	150	1
2.0 CVVT	G4NA	1	03/2012-05/2019	1999	121	165	1
2.0 CVVT	G4NA	1	03/2012-05/2019	1999	130	177	1
2.0 GDI	G4NC	1	12/2014-05/2019	1999	121	165	1
2.0 GDI		1	03/2012-05/2019	1999	122	166	1
2.0 GDI	G4NC	1	03/2012-05/2019	1999	130	177	1
2.0 GDI	G4NC	1	03/2012-05/2019	1999	131	178	1
1.6 CRDI	D4FE	2	07/2018-05/2019	1598	85	116	1
1.6 CRDI	D4FE	2	07/2018-05/2019	1598	100	136	1
1.7 CRDi	D4FD	2	03/2012-05/2019	1685	85	116	1
1.7 CRDi	D4FD	2	03/2012-05/2019	1685	100	136	1
1.7 CRDi	D4FD	2	10/2012-05/2019	1685	103	140	1
1.7 CRDi	D4FD	2	01/2015-05/2019	1685	104	141	1

ix35 / TUCSON II (LM, EL, ELH) SUV 08/2009-

Vehicle	Engine	Fuel	Date	CC	KW	CV	Traction
1.6	G4FD	1	11/2010-12/2015	1591	99	135	1
2.0	G4KD	1	01/2010-07/2013	1998	120	163	1
2.0	G4KD	1	01/2010-12/2015	1998	122	166	1
2.0	G4NA	1	08/2013-12/2015	1999	113	154	1
2.0 4WD	G4KD	1	01/2010-12/2015	1998	120	163	3
2.0 CVVT	G4KD	1	08/2009-07/2013	1998	110	150	1
2.0 CVVT	G4NA	1	08/2013-12/2015	1999	110	150	1
2.0 CVVT 4WD	G4NA	1	08/2013-12/2015	1999	110	150	3
2.0 CVVT 4WD	G4KD	1	08/2009-12/2015	1999	122	166	3
2.0 CVVT AWD	G4KD	1	08/2009-07/2013	1998	110	150	3
2.0 GDI	G4NC	1	08/2013-12/2015	1999	122	166	1
2.0 GDi 4WD	G4NC	1	08/2013-12/2015	1999	122	166	3
2.4 4WD	G4KE	1	09/2012-12/2013	2359	129	175	3
2.4 4WD	G4KE	1	01/2010-12/2015	2359	130	177	3
2.4 DCVVT-I 4WD	G4KE	1	07/2010-12/2013	2359	128	174	3
2.0 Flex		19	05/2012-08/2015	1999	131	178	1
1.7 CRDi	D4FD	2	11/2010-12/2015	1685	85	116	1
2.0 CRDi	D4HA	2	01/2010-12/2015	1995	100	136	1
2.0 CRDi	D4HA	2	01/2012-12/2015	1995	130	177	1
2.0 CRDi	D4HA	2	01/2010-06/2015	1995	132	179	1
2.0 CRDi	D4HA	2	01/2012-12/2015	1995	135	184	1
2.0 CRDi 4WD	D4HA	2	01/2010-12/2015	1995	100	136	3
2.0 CRDi 4WD	D4HA	2	01/2011-12/2015	1995	130	177	3
2.0 CRDi 4WD	D4HA	2	01/2010-06/2015	1995	132	179	3
2.0 CRDi 4WD	D4HA	2	01/2010-12/2015	1995	135	184	3

ix35 / TUCSON II () SUV Van 08/2009-12/2015

Vehicle	Fuel	Date	CC	KW	CV	Traction
GDI	1	05/2015-12/2015	1591	99	135	1
CRDi	2	09/2010-12/2015	1685	85	116	1
CRDi	2	08/2009-12/2015	1995	100	136	1
CRDi 4WD	2	08/2009-12/2015	1995	100	136	3

SONATA V / EMBERA V (NF) Saloon 08/2004-11/2014

Vehicle	Engine	Fuel	Date	CC	KW	CV	Traction
2.0 GLSI	G4KD	1	07/2008-12/2010	1998	119	162	1
2.0 VVTi GLS	G4KA	1	05/2005-12/2010	1998	106	144	1
2.0 VVTi GLS	G4KD	1	01/2008-12/2010	1998	121	165	1
2.4	G4KC	1	01/2005-12/2010	2359	119	162	1
2.4		1	01/2005-12/2008	2359	121	165	1
2.4	G4KC	1	06/2008-12/2010	2359	128	174	1
2.4		1	09/2008-12/2010	2359	130	177	1
2.4		1	11/2007-12/2010	2359	132	180	1
3.3	G6DB	1	01/2005-12/2010	3342	171	233	1
3.3	G6DB	1	06/2005-12/2010	3342	173	235	1
3.3	G6DB	1	09/2005-12/2006	3342	175	238	1
3.3	G6DB	1	01/2008-12/2010	3342	184	250	1
3.3	G6DB	1	09/2007-12/2008	3342	186	253	1
2.0 GLP	G4KA	18	03/2007-12/2008	1998	104	141	1
2.0 CRDi	D4EA	2	02/2006-12/2010	1991	100	136	1
2.0 CRDi	D4EA	2	02/2006-12/2010	1991	103	140	1
2.0 CRDi		2	02/2006-	1991	105	143	2
2.0 CRDi	D4EA	2	03/2009-12/2010	1991	110	150	1

SONATA VI / i45 VI (YF) Saloon 06/2009-12/2015

Vehicle	Engine	Fuel	Date	CC	KW	CV	Traction
2.0	G4KD	1	06/2009-06/2014	1998	110	150	1
2.0	G4NA	1	10/2012-06/2014	1999	126	172	1
2.0 i	G4KD	1	09/2012-06/2014	1998	120	163	1
2.0 i	G4KD	1	01/2011-06/2014	1998	121	165	1
2.4	G4KC	1	06/2009-11/2010	2359	128	174	1
2.4	G4KJ	1	09/2011-12/2014	2359	142	193	1
2.4 GDI		1	01/2009-	2359	148	201	1
2.0 Hybrid	G4NA	13	01/2011-06/2014	1999	110	150	1
2.0 GLP	L4NA	18	01/2011-12/2014	1999	115	156	1
GLP	L4KA	18	06/2009-12/2015	1998	106	144	1

SONATA VII (LF) Saloon 03/2014-06/2023

Vehicle	Engine	Fuel	Date	CC	KW	CV	Traction
2.0 Hybrid		13	09/2014-12/2019	1999	110	150	1

TUCSON (JM) SUV 06/2004-

Vehicle	Engine	Fuel	Date	CC	KW	CV	Traction
2.0	G4GC	1	08/2004-12/2010	1975	104	141	1
2.0	G4GC	1	01/2007-01/2012	1975	105	143	1
2.0	G4NA	1	09/2009-11/2010	1999	116	158	1
2.0 Alas 4 ruedas	G4GC	1	08/2004-03/2010	1975	104	141	3
2.0 Alas 4 ruedas	G4GC	1	07/2005-11/2010	1975	105	143	3
2.0 Alas 4 ruedas		1	07/2007-11/2010	1997	100	136	1
2.4	G4KE	1	12/2014-06/2015	2359	130	177	1
2.4		1	09/2009-03/2010	2359	131	178	1
2.7	G6BA	1	08/2004-12/2009	2656	129	175	1
2.7 A las 4 ruedas	G6BA	1	08/2004-11/2010	2656	129	175	3
2.0 LPG	G4GC	18	06/2004-03/2010	1975	104	141	1
2.0 LPG A las 4 ruedas	G4GC	18	06/2009-03/2010	1975	104	141	3
2.0 GLS Flex		19	01/2013-12/2019	1975	107	146	1
2.0 CRDi	D4EA	2	08/2004-03/2010	1991	83	113	1
2.0 CRDi	D4EA	2	01/2007-03/2010	1991	88	120	1
2.0 CRDi	D4EA	2	01/2006-03/2010	1991	100	136	1
2.0 CRDi	D4EA	2	01/2006-03/2010	1991	103	140	1
2.0 CRDi	D4EA	2	01/2009-03/2010	1991	110	150	1
2.0 CRDi A las 4 ruedas	D4EA	2	08/2004-03/2010	1991	83	113	3
2.0 CRDi A las 4 ruedas	D4EA	2	01/2007-03/2010	1991	88	120	3
2.0 CRDi A las 4 ruedas	D4EA	2	01/2006-03/2010	1991	100	136	3
2.0 CRDi A las 4 ruedas	D4EA	2	01/2006-03/2010	1991	103	140	3
2.0 CRDi A las 4 ruedas	D4EA	2	01/2009-03/2010	1991	110	150	3

TUCSON (JM) SUV Van 06/2004-03/2010

Vehicle	Fuel	Date	CC	KW	CV	Traction
CVVT	1	06/2004-03/2010	1975	104	141	1
CRDi	2	01/2006-03/2010	1991	103	140	1
CRDi VGT	2	01/2009-03/2010	1991	110	150	1

VELOSTER (FS) Coupe 03/2011-

Vehicle	Engine	Fuel	Date	CC	KW	CV	Traction
1.6 T-GDI	G4FJ	1	10/2012-12/2017	1591	137	186	1
1.6 T-GDI		1	08/2012-12/2017	1591	150	204	1

HYUNDAI (BEIJING)

ELANTRA VII (CN) Saloon 10/2020-

Vehicle	Engine	Fuel	Date	CC	KW	CV	Traction
1.5	G4FL	1	10/2020-	1497	85	116	1
240TGDi	G4LD	1	10/2020-	1353	103	140	1

ix25 (GC) Closed Off-Road Vehicle 10/2014-

Vehicle	Engine	Fuel	Date	CC	KW	CV	Traction
2.0		1	10/2014-	1999	118	160	1
2.0		1	10/2014-	1999	118	160	1

ix25 (GC) SUV 10/2014-

Vehicle	Engine	Fuel	Date	CC	KW	CV	Traction
1.4 TGDI	G4LD	1	08/2017-	1353	103	140	1
1.6 T-GDI	G4FJ	1	09/2016-	1591	118	160	1

ix35 (LM) SUV 04/2010-

Vehicle	Engine	Fuel	Date	CC	KW	CV	Traction
2.0		1	04/2010-	1998	120	163	1
2.0		1	04/2010-	1998	120	163	1
2.0	G4NA	1	04/2012-	1999	118	160	1
2.0	G4NA	1	04/2012-	1999	121	165	1
2.0 Alas 4 ruedas	G4NA	1	04/2012-	1999	118	160	3
2.0 Alas 4 ruedas	G4NA	1	04/2012-12/2017	1999	121	165	3
2.4	G4KE	1	04/2012-12/2017	2359	125	170	1
2.4		1	04/2010-	2359	128	174	1
2.4		1	04/2010-	2359	128	174	1
2.4 A las 4 ruedas	G4KE	1	04/2012-	2359	125	170	3

ix35 (NU) SUV 11/2017-

Vehicle	Fuel	Date	CC	KW	CV	Traction
1.4	1	12/2018-	1353	103	140	1
2.0	1	11/2017-	1999	118	160	1
2.0 4WD	1	11/2017-	1999	118	160	3

LAFESTA (SQ) Hatchback 10/2018-

Vehicle	Engine	Fuel	Date	CC	KW	CV	Traction
280TGDI	G4FJ	1	10/2018-	1591	140	190	1
280TGDI	G4FJ	1	10/2018-	1591	150	204	1

MISTRA (CF) Saloon 11/2013-

Vehicle	Engine	Fuel	Date	CC	KW	CV	Traction
1.6 T	G4FJ	1	06/2016-	1591	129	175	1

SONATA (LF) Saloon 03/2015-

Vehicle	Engine	Fuel	Date	CC	KW	CV	Traction
2.4		1	03/2015-	2359	139	189	1
Híbrido	G4NG	13	06/2016-12/2018	1999	115	156	1
PHEV	G4NG	13	08/2018-	1999	115	156	1

KIA

CARENS III / RONDO III (RP) MPV 01/2013-

Vehicle	Engine	Fuel	Date	CC	KW	CV	Traction
1.6 GDI	G4FD	1	03/2013-08/2016	1591	99	135	1
2.0	G4NA	1	01/2017-	1999	116	158	1
2.0 GDI	G4NC	1	03/2013-08/2016	1999	122	166	1
2.0 GDI	G4NC	1	03/2013-	1999	130	177	1
2.0 LPI		1	03/2013-	1999	113	154	1
2.0 MPi		1	03/2013-08/2016	1999	110	150	1
2.0 MPi	G4NA	1	01/2014-	1999	112	152	1
2.0 LPI	G4NC	18	08/2016-	1999	109	148	1
1.7 CRDi	D4FD	2	03/2013-08/2016	1685	85	116	1
1.7 CRDi	D4FD	2	03/2013-	1685	99	135	1
1.7 CRDi	D4FD	2	03/2013-08/2016	1685	100	136	1
1.7 CRDi	D4FD	2	07/2018-	1685	102	139	1
1.7 CRDi	D4FD	2	07/2015-08/2016	1685	104	141	1

CARENS III (A4) Box Body/MPV 03/2013-

Vehicle	Engine	Fuel	Date	CC	KW	CV	Traction
CRDi		2	04/2015-08/2016	1685	85	116	1
CRDi		2	04/2015-08/2016	1685	100	136	1

CEE'D II (JD) Hatchback 05/2012-

Vehicle	Engine	Fuel	Date	CC	KW	CV	Traction
1.0 T-GDI	G3LC	1	07/2015-07/2018	998	74	100	1
1.0 T-GDI	G3LC	1	07/2015-07/2018	998	88	120	1
1.4 CVVT	G4FA	1	05/2012-07/2018	1396	66	90	1
1.4 CVVT	G4FA	1	05/2012-07/2018	1396	73	100	1
1.4 MPI	G4LC	1	04/2015-07/2018	1368	74	101	1
1.6 CVVT	G4FC	1	01/2013-07/2018	1591	95	130	1
1.6 CVVT	G4FC	1	11/2014-07/2018	1591	96	131	1
1.6 GDI	G4FD	1	05/2012-07/2018	1591	99	135	1
1.6 GT	G4FJ	1	06/2013-07/2018	1591	150	204	1
1.4 LPG		18	05/2012-07/2018	1396	72	98	1
1.4 CRDi 90	D4FC	2	05/2012-07/2018	1396	66	90	1
1.6 CRDi 110	D4FB	2	05/2012-07/2018	1582	81	110	1
1.6 CRDi 128	D4FB	2	05/2012-07/2018	1582	94	128	1
1.6 CRDi 136	D4FB	2	07/2015-07/2018	1582	100	136	1

CEE'D II Combi Van (JD) Estate Van 07/2012-

Vehicle	Engine	Fuel	Date	CC	KW	CV	Traction
1.0 T-GDI	G3LC	1	04/2015-07/2018	998	74	101	1
1.0 T-GDI	G3LC	1	04/2015-07/2018	998	88	120	1
1.4 CVVT	G4FA	1	04/2015-07/2018	1396	73	100	1
1.6 GDI	G4FD	1	04/2015-07/2018	1591	99	135	1
1.4 CRDi	D4FC	2	04/2015-07/2018	1396	66	90	1
1.6 CRDI	D4FB	2	07/2012-07/2018	1582	94	128	1

CEE'D II Sport Wagon (JD) Estate 09/2012-

Vehicle	Engine	Fuel	Date	CC	KW	CV	Traction
1.0 T-GDI	G3LC	1	07/2015-07/2018	998	74	100	1
1.0 T-GDI	G3LC	1	07/2015-07/2018	998	88	120	1
1.4 CVVT	G4FA	1	09/2012-07/2015	1396	73	100	1
1.4 MPI	G4LC	1	04/2015-07/2018	1368	74	101	1
1.6 CVVT	G4FC	1	11/2014-07/2018	1591	95	130	1
1.6 CVVT	G4FC	1	11/2014-07/2018	1591	96	131	1
1.6 GDI	G4FD	1	09/2012-07/2018	1591	99	135	1
1.4 LPG	G4FA	18	01/2013-07/2018	1396	72	98	1
1.4 CRDi 90	D4FC	2	09/2012-07/2018	1396	66	90	1
1.6 CRDi 110	D4FB	2	03/2013-07/2018	1582	81	110	1
1.6 CRDi 128	D4FB	2	09/2012-07/2015	1582	94	128	1
1.6 CRDi 136	D4FB	2	07/2015-07/2018	1582	100	136	1

CERATO II / FORTE II / K3 II (TD) Saloon 01/2009-

Vehicle	Engine	Fuel	Date	CC	KW	CV	Traction
1.8		1	04/2013-	1979	110	150	1
2.0		1	04/2013-	1999	129	175	1

CERATO II KOUP / FORTE KOUP / K3 (TD) Coupe 01/2009-

Vehicle	Engine	Fuel	Date	CC	KW	CV	Traction
1.6 CVVT	G4FJ	1	09/2013-02/2014	1591	150	204	1
2.0 GDI		1	09/2013-	1999	129	175	1

CERATO III / FORTE III / K3 (YD) Saloon 09/2012-

Vehicle	Engine	Fuel	Date	CC	KW	CV	Traction
1.6 16V (YD)	G4FG	1	05/2015-	1591	90	122	1
1.6 CVVT		1	11/2014-10/2018	1591	94	128	1
1.6 GDI		1	09/2012-	1591	103	140	1
1.6 MPi	G4FG	1	06/2013-05/2017	1591	96	130	1
1.8		1	01/2014-	1797	107	145	1
2.0 CVVT	G4NA	1	12/2014-12/2018	1999	117	159	1
2.0 MPi	G4KD	1	06/2013-12/2016	1997	110	150	1
2.0 MPi	G4NA	1	03/2016-06/2018	1999	112	152	1
1.6 16V Flex	F4FA	19	06/2013-09/2019	1591	94	128	1
1.6 VGT		2	09/2012-	1582	94	128	2

CERATO III / FORTE III / K3 EURO (YD) Hatchback 09/2012-

Vehicle	Engine	Fuel	Date	CC	KW	CV	Traction
1.6 CVVT	G4FC	1	11/2014-	1591	95	129	1
1.6 GDI		1	09/2012-	1591	103	140	1
1.6 Turbo	G4FJ	1	09/2013-	1591	150	204	1
1.8	G4NB	1	04/2013-03/2016	1797	110	150	1
2.0 CVVT	G4KD	1	05/2013-	1998	116	158	1
2.0 CVVT		1	01/2016-	1999	112	152	1
2.0 DGI	G4NC	1	06/2013-	1999	129	175	1

CERATO III KOUP / K3 KOUP (YD) Coupe 12/2013-

Vehicle	Engine	Fuel	Date	CC	KW	CV	Traction
1.6 GDI	G4FD	1	12/2013-	1591	97	132	1
1.6 GDI		1	12/2013-	1591	103	140	1
1.6 T-GDI	G4FJ	1	12/2013-	1591	150	204	1
2.0 CVVT		1	12/2014-	1999	117	159	1
2.0 GDI	G4NC	1	09/2014-	1998	118	161	1
2.0 GDI		1	09/2014-03/2016	1998	129	175	1
2.0 GDI	G4NC	1	09/2014-	1999	121	165	1
2.0 MPi		1	12/2013-	1998	110	150	1

OPTIMA III / K5 (FSGDS6B) Saloon 01/2010-

Vehicle	Engine	Fuel	Date	CC	KW	CV	Traction
2.0	G4KD	1	03/2012-12/2015	1998	125	170	1
2.0	G4KH	1	09/2010-12/2015	1998	204	277	1
2.0 CVVL	G4KD	1	03/2012-12/2015	1998	121	165	1
2.0 CVVL		1	03/2012-12/2015	1999	126	171	1
2.0 CVVT	G4KD	1	01/2011-12/2015	1998	110	150	1
2.0 CVVT		1	04/2010-12/2015	1999	115	156	1
2.0 CVVT	G4NA	1	12/2014-12/2015	1999	119	162	1
2.0 CVVT	G4NA	1	03/2013-12/2015	1999	121	165	1
2.4		1	06/2010-12/2015	2359	129	175	1
2.4	G4KJ	1	03/2012-12/2015	2359	132	179	1
2.4	G4KC	1	09/2010-12/2013	2359	142	193	1
2.4	G4KJ	1	09/2010-12/2015	2359	149	203	1
2.4 CVVT	G4KE	1	01/2012-12/2015	2359	132	179	1
2.4 GDI	G4KJ	1	09/2013-	2359	143	194	1
2.0 CVVT Hybrid		13	12/2012-12/2015	1999	140	190	1
2.4 Hybrid		13	09/2011-12/2015	2359	154	209	1
2.0 LPI		18	04/2010-12/2015	1998	106	144	1
2.0 LPI		18	04/2010-12/2015	1999	114	155	1
1.7 CRDi	D4FD	2	03/2012-12/2015	1685	100	136	1

OPTIMA IV / K5 (JF) Saloon 09/2015-

Vehicle	Engine	Fuel	Date	CC	KW	CV	Traction
1.6 T-GDI	G4FJ	1	09/2018-12/2019	1591	132	179	1
2.0	G4ND	1	09/2015-12/2019	1999	110	150	1
2.0 CVVL	G4ND	1	09/2015-12/2019	1999	120	163	1
2.0 Gdi Hybrid	G4NG	13	09/2016-12/2019	1999	151	205	1
1.6 CRDI	D4FE	2	09/2018-12/2019	1598	100	136	1
1.7 CRDi	D4FD	2	09/2016-04/2018	1685	99	135	1
1.7 CRDi	D4FD	2	11/2015-04/2018	1685	104	141	1

OPTIMA IV / K5 Sport Wagon (JF) Estate 09/2016-

Vehicle	Engine	Fuel	Date	CC	KW	CV	Traction
1.6 T-GDI	G4FJ	1	01/2018-12/2019	1591	132	179	1
2.0 CVVL		1	09/2016-12/2019	1999	120	163	1
2.0 Gdi Hybrid	G4NG	13	04/2017-12/2019	1999	151	205	1
1.6 CRDI	D4FE	2	01/2018-12/2019	1598	100	136	1
1.7 CRDi	D4FD	2	09/2016-04/2018	1685	99	135	1
1.7 CRDi	D4FD	2	09/2016-04/2018	1685	104	141	1

PRO CEE´D II (JD) Hatchback Van 03/2012-

Vehicle	Engine	Fuel	Date	CC	KW	CV	Traction
1.4 CVVT	G4FA	1	05/2012-07/2018	1396	73	99	1
1.6 GDI	G4FD	1	04/2015-07/2018	1591	99	135	1
1.4 CRDi	D4FC	2	05/2015-07/2018	1396	66	90	1
1.6 CRDI	D4FB	2	10/2012-07/2018	1582	94	128	1

PRO CEE´D II (JD) Hatchback 03/2013-

Vehicle	Engine	Fuel	Date	CC	KW	CV	Traction
1.0 T-GDI	G3LC	1	07/2015-07/2018	998	74	100	1
1.0 T-GDI	G3LC	1	07/2015-07/2018	998	88	120	1
1.4 CVVT	G4FA	1	03/2013-07/2015	1396	73	100	1
1.4 CVVT	G4FA	1	07/2013-07/2018	1396	74	101	1
1.4 MPI		1	07/2013-07/2018	1368	73	100	1
1.4 MPI	G4LC	1	04/2015-07/2018	1368	74	101	1
1.6 CVVT	G4FC	1	03/2013-07/2018	1591	95	130	1
1.6 GDI	G4FD	1	03/2013-07/2018	1591	99	135	1
1.4 CRDi 90	D4FC	2	03/2013-07/2018	1396	66	90	1
1.6 CRDi 110	D4FB	2	03/2013-07/2018	1582	81	110	1
1.6 CRDi 128	D4FB	2	03/2013-07/2015	1582	94	128	1
1.6 CRDi 136	D4FB	2	07/2015-07/2018	1582	100	136	1

SOUL II (PS) Hatchback 02/2014-

Vehicle	Engine	Fuel	Date	CC	KW	CV	Traction
1.6 CVVT	G4FG	1	02/2014-12/2018	1591	91	124	1
1.6 CVVT		1	07/2016-12/2018	1591	95	129	1
1.6 GDI	G4FD	1	02/2014-12/2018	1591	97	132	1
1.6 MPi		1	07/2018-12/2018	1591	90	122	1
1.6 TGDI		1	11/2016-12/2018	1591	150	204	1
2.0 CVVT		1	07/2016-	1998	116	158	1
2.0 CVVT	G4NA	1	08/2016-12/2018	1999	110	150	1
2.0 CVVT	G4NA	1	02/2014-11/2018	1999	112	152	1
2.0 CVVT	G4NA	1	02/2014-12/2018	1999	113	154	1
2.0 GDI		1	09/2016-12/2018	1999	120	163	1
2.0 GDI		1	02/2014-12/2018	1999	122	166	1
1.6 LPG	G4FG	18	12/2014-12/2018	1591	87	118	1
1.6 LPG	G4FG	18	12/2014-12/2018	1591	96	131	1
1.6 CVVT	F4FA	19	09/2014-	1591	88	120	1
1.6 CVVT Flex		19	09/2014-12/2018	1591	94	128	1
1.6 CRDI	D4FB	2	07/2018-	1582	99	135	1
1.6 CRDi 128	D4FB	2	02/2014-12/2018	1582	94	126	1
1.6 CRDi 136	D4FB	2	04/2015-12/2018	1582	100	136	1
EV Electric		11	09/2014-11/2018		25	33	1
EV Electric		11	09/2014-11/2018		47	64	1
EV Electric		11	09/2014-11/2018		81	110	1

SPORTAGE II (JE_, KM_) SUV 09/2004-

Vehicle	Engine	Fuel	Date	CC	KW	CV	Traction
2.0 16V 4WD	G4GC	1	09/2004-08/2010	1975	104	141	3
2.0 i 16V	G4GC	1	09/2004-08/2010	1975	104	141	1
2.7	G6BA	1	09/2005-12/2010	2656	129	175	1
2.7 V6 4WD	G6BA	1	09/2004-08/2010	2656	129	175	3
2.0 LPG	G4GC	18	06/2009-05/2010	1975	101	137	1
2.0 CRDi	D4EA	2	02/2005-12/2006	1991	83	113	1
2.0 CRDi	D4EA	2	01/2006-05/2010	1991	100	136	1
2.0 CRDi	D4EA	2	01/2006-10/2008	1991	103	140	1
2.0 CRDi	D4EA	2	09/2007-12/2010	1991	110	150	1
2.0 CRDi	D4HA	2	01/2009-05/2010	1995	135	184	1
2.0 CRDi 4WD	D4EA	2	09/2004-12/2006	1991	83	113	3
2.0 CRDi 4WD	D4EA	2	01/2006-05/2010	1991	100	136	3
2.0 CRDi 4WD	D4EA	2	01/2006-10/2008	1991	103	140	3
2.0 CRDi 4WD	D4EA	2	09/2008-05/2010	1991	110	150	3

SPORTAGE II VAN (KM_) SUV Van 09/2004-

Vehicle	Engine	Fuel	Date	CC	KW	CV	Traction
2.0 CRDi		2	09/2008-05/2010	1991	110	150	1
2.0 CRDi 4WD		2	09/2008-05/2010	1991	110	150	3

SPORTAGE III (SL) SUV 09/2009-

Vehicle	Engine	Fuel	Date	CC	KW	CV	Traction
1.6 GDI	G4FD	1	06/2010-12/2015	1591	99	135	1
1.6 GDI	G4FD	1	11/2012-12/2015	1591	103	140	1
2.0	G4KH	1	09/2010-	1998	191	260	1
2.0 AWD	G4KH	1	09/2010-	1998	191	260	3
2.0 CVVT	G4KD	1	06/2010-12/2013	1998	110	150	1
2.0 CVVT		1	11/2014-	1998	116	158	1
2.0 CVVT		1	11/2014-	1998	116	158	1
2.0 CVVT	G4KD	1	07/2010-12/2015	1998	120	163	1
2.0 CVVT	G4KD	1	07/2010-12/2015	1998	122	166	1
2.0 CVVT	G4NA	1	01/2014-12/2015	1999	110	150	1
2.0 CVVT		1	08/2015-	1999	111	151	1
2.0 CVVT		1	11/2014-12/2015	1999	113	154	1
2.0 CVVT	G4NA	1	04/2015-12/2015	1999	115	156	1
2.0 CVVT AWD	G4KD	1	06/2010-12/2013	1998	110	150	3
2.0 CVVT AWD	G4KD	1	07/2010-12/2015	1998	120	163	3
2.0 CVVT AWD	G4KD	1	07/2010-12/2015	1998	122	166	3
2.0 CVVT AWD	G4NA	1	01/2014-12/2015	1999	110	150	3
2.0 CVVT AWD	G4NA	1	08/2015-12/2015	1999	111	151	3
2.0 CVVT AWD	G4NA	1	11/2014-12/2015	1999	113	154	3
2.0 GDI	G4NC	1	02/2014-12/2015	1998	122	166	1
2.0 GDI		1	09/2013-12/2015	1998	194	264	1
2.0 GDI AWD	G4NC	1	02/2014-12/2015	1998	122	166	3
2.0 GDI AWD	G4KH	1	09/2013-	1998	194	264	3
2.4		1	09/2010-12/2015	2359	131	178	1
2.4 GDI		1	09/2013-05/2016	2359	136	185	1
2.4 GDI AWD		1	09/2013-05/2016	2359	136	185	3
2.4 i AWD	G4KE	1	08/2010-12/2015	2359	130	177	3
1.6 LPG	G4FD	18	01/2014-12/2015	1591	99	135	1
2.0 CVVT Flex		19	02/2012-12/2016	1998	131	178	1
2.0 CVVT Flex AWD		19	01/2012-12/2016	1998	131	178	3
1.7 CRDi	D4FD	2	12/2010-12/2015	1685	85	116	1
2.0 CRDi	D4HA	2	07/2010-12/2015	1995	100	136	1
2.0 CRDi	D4HA	2	08/2012-12/2016	1995	130	177	1
2.0 CRDi	D4HA	2	08/2010-12/2015	1995	135	184	1
2.0 CRDi AWD	D4HA	2	07/2010-12/2015	1995	100	136	3
2.0 CRDi AWD	D4HA	2	08/2012-12/2016	1995	130	177	3
2.0 CRDi AWD	D4HA	2	08/2010-12/2015	1995	135	184	3

KIA (DYK)

K4 / K4 CACHET () Saloon 09/2014-

Vehicle	Engine	Fuel	Date	CC	KW	CV	Traction
1.6	G4FJ	1	09/2014-	1591	129	175	1

K5 () Saloon 03/2011-

Vehicle	Engine	Fuel	Date	CC	KW	CV	Traction
1.6 T		1	10/2015-	1591	132	180	1
2.0	G4KH	1	12/2013-	1998	180	245	1

K5 () Saloon 10/2015-

Vehicle	Engine	Fuel	Date	CC	KW	CV	Traction
2.0	G4KH	1	10/2015-	1998	180	245	1
2.0 Hybrid	G4NG	13	06/2016-	1999	115	156	1

KX3 (KC) Closed Off-Road Vehicle 03/2015-

Vehicle	Fuel	Date	CC	KW	CV	Traction
1.6 T	1	03/2015-	1591	118	160	1
2.0	1	03/2015-	1999	118	161	1
2.0	1	03/2015-	1999	118	161	1

SPORTAGE-R (SL) Closed Off-Road Vehicle 10/2010-

Vehicle	Fuel	Date	CC	KW	CV	Traction
2.0	1	10/2010-	1998	120	163	1
2.0	1	10/2010-	1998	120	163	1
2.4	1	10/2010-	2359	128	174	1

SPORTAGE-R (SL) SUV 10/2010-

Vehicle	Engine	Fuel	Date	CC	KW	CV	Traction
2.0	G4NA	1	11/2011-12/2018	1999	121	165	1
2.0 4WD	G4NA	1	11/2011-	1999	121	165	3

SPORTAGE III (NP) SUV 04/2018-

Vehicle	Engine	Fuel	Date	CC	KW	CV	Traction
1.4	G4LD	1	03/2019-	1353	103	140	1
2.0	G4NA	1	04/2018-	1999	118	161	1

SOUEAST

DX3 () SUV 11/2016-

Vehicle	Engine	Fuel	Date	CC	KW	CV	Traction
EV	TZ230XS090	11	03/2018-	0	90	122	1
EV400	TZ230XS090	11	08/2018-	0	90	122	1

DX7 () SUV 07/2015-

Vehicle	Engine	Fuel	Date	CC	KW	CV	Traction
1.5 T	4A91T	1	07/2015-	1499	115	156	1
2.0 T	4G63-T	1	07/2015-	1997	143	194	1
280 T	4K20D4T	1	07/2018-	1796	145	197	1

Return
