Product 78BD0812-2 - Web Catalogo

Description: Brake disc
Axe: Front
No. of Pieces: 2
Barcode: 8424073142665
Url: https://catalogonuevo.icerbrakes.com/Producto/Details?idProducto=78BD0812-2
Weight (gr.): 14872

R90 Homologation: 90R-02C0538/0082
Measures: Ø295x28x55
: Brake Disc Type: Vented; Minimum thickness [mm]: 25.4; Hole Arrangement/Number: 5; Bolt Hole Circle Ø [mm]: 112; Wheel Hub Diameter [mm]: 67

Reference applications

Brand	OE Reference
MERCEDES-BENZ	211 421 07 12
MERCEDES-BENZ	211 421 08 12

Maker	Cross reference
ATE	24.0128-0141.1
ATE	24.0128-0176.1
BENDIX ANTIGUO	562212B
BOSCH	0 986 479 038
BOSCH	0 986 479 039
BREMBO	09.9362.10
BREMBO	09.9362.14
BREMBO	09.C893.11
DELPHI LOCKHEED	BG3755
FERODO	DDF1252
GIRLING	6042611
HELLA-PAGID	54151
HELLA-PAGID	54152
LETEC	LBM023V
MINTEX	MDC1616
MINTEX	MDC1977
NECTO	WN1269
ROAD HOUSE	6676.10
SANLI	SL36815
TEXTAR	92115100
TEXTAR	92115200
TRW	DF4261
VALEO	186751
VALEO	672842

MERCEDES-BENZ

E-Class III (W211) Saloon 03/2002-03/2009

Vehicle	Engine	Fuel	Date	CC	KW	CV	Traction
E 200 CGI		1	11/2002-12/2008	1796	125	170	1
E 200 Kompressor (211.042)	M 271.941	1	11/2002-12/2008	1796	120	163	2
E 200 Kompressor (211.042)	M 271.956	1	04/2006-12/2008	1796	135	184	2
E 230 (211.052)	M 272.922	1	09/2007-12/2008	2496	150	204	2
E 240 (211.061)	M 112.913 M 112.917	1	03/2002-12/2008	2597	130	177	2
E 240 4-matic (211.080)	M 112.917	1	03/2003-12/2008	2597	130	177	3
E 280 (211.054)	M 272.943	1	03/2005-12/2008	2996	170	231	2
E 280 4-matic (211.092)	M 272.943 M 272.944	1	01/2006-12/2008	2996	170	231	3
E 350 4-matic (211.087)	M 272.972	1	03/2005-12/2008	3498	200	272	3
E 500 4-matic (211.083)	M 113.969	1	10/2003-12/2008	4966	225	306	3
E 500 4-matic (211.090)	M 273.962	1	04/2006-12/2008	5461	285	388	3
E 200 NGT (211.042)	M 271.941	16	03/2004-12/2008	1796	120	163	2
E 200 CDI (211.004)	OM 646.951	2	07/2002-12/2008	2148	75	102	2
E 200 CDI (211.004)	OM 646.951	2	07/2002-12/2008	2148	90	122	2
E 200 CDI (211.007)	OM 646.820	2	04/2006-12/2008	2148	100	136	2
E 220 CDI	OM 646.821	2	03/2003-12/2008	2149	120	163	2
E 220 CDI (211.006)	OM 646.961	2	03/2002-12/2008	2148	100	136	2
E 220 CDI (211.006)	OM 646.961	2	03/2002-12/2008	2148	110	150	2
E 220 CDI (211.008)	OM 646.821	2	04/2006-12/2008	2148	125	170	2
E 250 CDI		2	08/2008-12/2008	2143	150	204	2
E 270 CDI (211.016)	OM 647.961	2	03/2002-12/2008	2685	120	163	2
E 270 CDI (211.016)	OM 647.961	2	03/2002-12/2008	2685	130	177	2
E 280 CDI (211.020)	OM 642.920	2	03/2005-12/2008	2987	140	190	2
E 280 CDI (211.023)	OM 648.961	2	05/2004-12/2008	3222	130	177	2
E 280 CDI 4-matic (211.084)	OM 642.921	2	03/2005-12/2008	2987	140	190	3
E 300 BlueTEC (211.024)	OM 642.920	2	09/2007-12/2008	2987	155	211	2
E320 CDI (211.022)		2	09/2006-12/2008	2987	156	212	2

E-Class III T-Model (S211) Estate 02/2003-07/2009

Vehicle	Engine	Fuel	Date	CC	KW	CV	Traction
E 200 Kompressor (211.241)	M 271.956	1	04/2006-07/2009	1796	135	184	2
E 200 T Kompressor (211.242)	M 271.941	1	03/2003-07/2009	1796	120	163	2
E 230 T (211.252)	M 272.922	1	05/2007-07/2009	2496	150	204	2
E 240 T (211.261)	M 112.913	1	03/2003-07/2009	2597	130	177	2
E 240 T 4-matic (211.280)	M 112.917	1	07/2003-07/2009	2597	130	177	3
E 280 T (211.254)	M 272.943	1	03/2005-07/2009	2996	170	231	2
E 280 T 4-matic (211.292)	M 272.943 M 272.944	1	03/2005-07/2009	2996	170	231	3
E 500 T 4-matic (211.283)	M 113.969	1	10/2003-07/2009	4966	225	306	3
E 500 T 4-matic (211.290)	M 273.962	1	04/2006-07/2009	5461	285	388	3
E 200 CDI (211.207)	OM 646.821	2	04/2006-07/2009	2148	100	136	2
E 220 CDI (211.206)	OM 646.961	2	03/2003-07/2009	2148	100	136	2
E 220 T CDI (211.206)	OM 646.961	2	03/2003-07/2009	2148	110	150	2
E 220 T CDI (211.208)	OM 646.821	2	04/2006-07/2009	2148	125	170	2
E 270 T CDI (211.216)	OM 647.961	2	03/2003-07/2009	2685	120	163	2
E 270 T CDI (211.216)	OM 647.961	2	03/2003-07/2009	2685	130	177	2
E 280 T CDI (211.220)	OM 642.920	2	03/2005-07/2009	2987	140	190	2
E 280 T CDI (211.223)	OM 648.961	2	05/2004-07/2009	3222	130	177	2
E 280 T CDI 4-matic (211.284)	OM 642.921	2	03/2005-07/2009	2987	140	190	3

E-Class III (VF211) Platform/Chassis 03/2003-07/2009

Vehicle	Engine	Fuel	Date	CC	KW	CV	Traction
E 220 CDI (211.606)	OM 646.961	2	10/2003-07/2006	2148	110	150	2
E 220 CDI (211.608)	OM 646.821	2	04/2006-07/2009	2148	125	170	2

E-Class IV (W212) Saloon 01/2009-

Vehicle	Engine	Fuel	Date	CC	KW	CV	Traction
E 200 CGI (212.048, 212.148)	M 271.820 M 271.860	1	08/2009-12/2015	1796	135	184	2

MERCEDES-BENZ (BBDC)

E-Class (W211) Saloon 11/2005-

Vehicle	Engine	Fuel	Date	CC	KW	CV	Traction
1.8 E 200 Kompressor (211.041)		1	09/2006-12/2012	1796	135	184	2
3.5 E 350 (211.056)		1	11/2005-12/2009	3498	200	272	2
