Product 78BD1018-2
- Description
- Brake disc
- Axe
- Front
- No. of Pieces
- 2
- Barcode
-
8424073142863
- Url
- https://catalogonuevo.icerbrakes.com/Producto/Details?idProducto=78BD1018-2
- Weight (gr.)
- 19060
- R90 Homologation
-
90R-02C0593/1584
- Measures
- Ø320x30x51
-
Brake Disc Type:
Vented -
Minimum thickness [mm]:
27.4 -
Hole Arrangement/Number:
5 -
Bolt Hole Circle Ø [mm]:
112 -
Wheel Hub Diameter [mm]:
67
| Brand | OE Reference |
|---|---|
| MERCEDES-BENZ | 246 421 27 12 |
| Maker | Cross reference |
|---|---|
| ATE | 24.0130-0238.1 |
| ATE | 430238 |
| BOSCH | 0 986 479 A60 |
| BREMBO | 09.B807.51 |
| DELPHI LOCKHEED | BG4658C |
| FERODO | DDF2559C |
| GIRLING | 6066335 |
| HELLA-PAGID | 8DD 355 120-351 |
| MINTEX | MDC2569 |
| SANLI | SL37845X |
| TEXTAR | 92262103 |
| Vehicle | Engine | Fuel | Date | CC | KW | CV | Traction |
|---|---|---|---|---|---|---|---|
| A 220 4-matic (176.047) |
M 270.920 |
1 | 05/2014-05/2018 | 1991 | 135 | 184 | 3 |
| A 250 (176.044) |
M 270.920 |
1 | 06/2012-05/2018 | 1991 | 155 | 211 | 1 |
| A 250 (176.050) |
M 270.920 |
1 | 07/2015-05/2018 | 1991 | 160 | 218 | 1 |
| A 250 4-matic (176.046) |
M 270.920 |
1 | 06/2013-05/2018 | 1991 | 155 | 211 | 3 |
| A 250 4-matic (176.051) |
M 270.920 |
1 | 07/2015-05/2018 | 1991 | 160 | 218 | 3 |
| A 180 CDI (176.007) | 2 | 06/2013-10/2014 | 2143 | 80 | 109 | 1 | |
| A 200 CDI / d (176.008) |
OM 651.930 |
2 | 02/2014-05/2018 | 2143 | 100 | 136 | 1 |
| A 200 CDI / d 4-matic (176.002) |
OM 651.930 |
2 | 02/2014-05/2018 | 2143 | 100 | 136 | 3 |
| A 220 CDI (176.003) |
OM 651.930 |
2 | 01/2014-05/2018 | 2143 | 120 | 163 | 1 |
| A 220 CDI (176.003) |
OM 651.930 |
2 | 09/2012-05/2018 | 2143 | 125 | 170 | 1 |
| A 220 CDI 4-matic (176.005) |
OM 651.930 |
2 | 02/2014-05/2018 | 2143 | 125 | 170 | 3 |
| A 220 d (176.003) |
OM 651.930 |
2 | 07/2015-05/2018 | 2143 | 130 | 177 | 1 |
| A 220 d 4-matic (176.005) |
OM 651.930 |
2 | 07/2015-05/2018 | 2143 | 130 | 177 | 3 |
| Vehicle | Engine | Fuel | Date | CC | KW | CV | Traction |
|---|---|---|---|---|---|---|---|
| B 220 4-matic (246.247) |
M 270.920 |
1 | 05/2013-12/2018 | 1991 | 135 | 184 | 3 |
| B 250 (246.244) |
M 270.920 |
1 | 05/2012-12/2018 | 1991 | 155 | 211 | 1 |
| B 250 4-matic (246.246) |
M 270.920 |
1 | 08/2014-12/2018 | 1991 | 155 | 211 | 3 |
| B 200 CDI / d (246.208) |
OM 651.930 |
2 | 08/2014-12/2018 | 2143 | 100 | 136 | 1 |
| B 200 CDI / d 4-matic (246.202) |
OM 651.930 |
2 | 08/2014-12/2018 | 2143 | 100 | 136 | 3 |
| B 220 CDI / d (246.203) |
OM 651.930 |
2 | 06/2013-12/2018 | 2143 | 120 | 163 | 1 |
| B 220 CDI / d (246.203) |
OM 651.930 |
2 | 11/2011-12/2018 | 2143 | 125 | 170 | 1 |
| B 220 CDI / d (246.203) |
OM 651.930 |
2 | 08/2014-12/2018 | 2143 | 130 | 177 | 1 |
| B 220 CDI / d 4-matic (246.205) |
OM 651.930 |
2 | 08/2014-12/2018 | 2143 | 130 | 177 | 3 |
| Vehicle | Engine | Fuel | Date | CC | KW | CV | Traction |
|---|---|---|---|---|---|---|---|
| CLA 220 4-matic (117.347) |
M 270.920 |
1 | 04/2016-03/2019 | 1991 | 135 | 184 | 3 |
| CLA 250 (117.344) |
M 270.920 |
1 | 01/2013-03/2019 | 1991 | 155 | 211 | 1 |
| CLA 250 (117.350) |
M 270.920 |
1 | 07/2015-03/2019 | 1991 | 160 | 218 | 1 |
| CLA 250 4-matic (117.346) |
M 270.920 |
1 | 07/2013-03/2019 | 1991 | 155 | 211 | 3 |
| CLA 250 4-matic (117.351) |
M 270.920 |
1 | 07/2015-03/2019 | 1991 | 160 | 218 | 3 |
| CLA 220 CDI / d (117.303) |
OM 651.930 |
2 | 01/2013-03/2019 | 2143 | 120 | 163 | 1 |
| CLA 220 CDI / d (117.303) |
OM 651.930 |
2 | 01/2013-03/2019 | 2143 | 125 | 170 | 1 |
| CLA 220 CDI / d (117.303) |
OM 651.930 |
2 | 09/2014-03/2019 | 2143 | 130 | 177 | 1 |
| CLA 220 CDI / d 4-matic (117.905) |
OM 651.930 |
2 | 08/2014-03/2019 | 2143 | 120 | 163 | 3 |
| CLA 220 CDI / d 4-matic (117.905) |
OM 651.930 |
2 | 09/2014-03/2019 | 2143 | 130 | 177 | 3 |
| CLA 220 CDI 4-matic (117.305) |
OM 651.930 |
2 | 07/2014-03/2019 | 2143 | 125 | 170 | 3 |
| Vehicle | Engine | Fuel | Date | CC | KW | CV | Traction |
|---|---|---|---|---|---|---|---|
| CLA 220 4-matic (117.947) |
M 270.920 |
1 | 04/2016-03/2019 | 1991 | 135 | 184 | 3 |
| CLA 250 (117.944) |
M 270.920 |
1 | 01/2015-03/2019 | 1991 | 155 | 211 | 1 |
| CLA 250 4-matic (117.946) |
M 270.920 |
1 | 01/2015-03/2019 | 1991 | 155 | 211 | 3 |
| CLA 250 4-matic (117.951) |
M 270.920 |
1 | 07/2015-03/2019 | 1991 | 160 | 218 | 3 |
| CLA 220 CDI / d (117.903) |
OM 651.930 |
2 | 01/2015-03/2019 | 2143 | 120 | 163 | 1 |
| CLA 220 CDI / d (117.903) |
OM 651.930 |
2 | 01/2015-03/2019 | 2143 | 130 | 177 | 1 |
| Vehicle | Engine | Fuel | Date | CC | KW | CV | Traction |
|---|---|---|---|---|---|---|---|
| GLA 250 (156.944) |
M 270.920 |
1 | 12/2013-12/2019 | 1991 | 155 | 211 | 1 |
| GLA 250 4-matic (156.946) |
M 270.920 |
1 | 12/2013-12/2019 | 1991 | 155 | 211 | 3 |
| GLA 250 Flex (156.944) |
M 270.920 |
19 | 01/2015-12/2019 | 1991 | 155 | 211 | 1 |
| GLA 220 CDI (156.903) |
OM 651.930 |
2 | 12/2013-05/2019 | 2143 | 125 | 170 | 1 |
| GLA 220 CDI / d (156.903) |
OM 651.930 |
2 | 12/2013-05/2019 | 2143 | 120 | 163 | 1 |
| GLA 220 CDI / d 4-matic (156.905) |
OM 651.930 |
2 | 12/2013-12/2019 | 2143 | 120 | 163 | 3 |
| GLA 220 d (156.903) |
OM 651.930 |
2 | 07/2015-05/2019 | 2143 | 130 | 177 | 1 |
| GLA 220 d 4-matic (156.905) |
OM 651.930 |
2 | 07/2015-12/2019 | 2143 | 130 | 177 | 3 |
