Product 78BD1257-2

Description
Brake disc
Axe
Front
No. of Pieces
2
Barcode
EAN13 Code
8424073143051
QR Code
Url
https://catalogonuevo.icerbrakes.com/Producto/Details?idProducto=78BD1257-2
Weight (gr.)
12744
R90 Homologation
R90 90R-02C0452/0118
Measures
Ø281.8x23x47.1
Brake Disc Type: Vented
Minimum thickness [mm]: 21
Hole Arrangement/Number: 5
Bolt Hole Circle Ø [mm]: 114,3
Wheel Hub Diameter [mm]: 64.15
Reference applications
Brand OE Reference
HONDA 45251-S7A-N10
HONDA 45251-S87-A00
HONDA 45251-SCA-E00
Maker Cross reference
ATE 24.0123-0109.1
BENDIX ANTIGUO 562457B
BOSCH 0 986 479 365
BREMBO 09.6752.20
DELPHI LOCKHEED BG3720
FERODO DDF1496
HELLA-PAGID 8DD 355 133-981
LETEC LBH026V
SANLI SL33237
TRW DF4486
TRW DF4610
BYD
G6 () Saloon 09/2011-
Vehicle Engine Fuel Date CC KW CV Traction
1.5 1 09/2011- 1497 113 154 1
SIRUI () Saloon 04/2013-
Vehicle Engine Fuel Date CC KW CV Traction
1.5 1 04/2013-12/2016 1497 113 154 1
HONDA
CIVIC VII (EU, EP, EV) Hatchback 01/2000-02/2006
Vehicle Engine Fuel Date CC KW CV Traction
2.0 i Sport (EV1)

K20A3

 1 09/2001-09/2005 1998 118 160 1
CIVIC IX (FB) Saloon 09/2011-
Vehicle Engine Fuel Date CC KW CV Traction
1.8 (FB2)

R18Z1

R18Z4

 1 02/2012-12/2016 1798 104 141 1
CR-V II (RD_) SUV 09/2001-07/2007
Vehicle Engine Fuel Date CC KW CV Traction
2.0 1 03/2002-09/2006 1998 112 152 3
2.0 (RD5)

K20A4

 1 09/2001-03/2007 1998 110 150 3
2.4 4WD (RD7) 1 09/2001-12/2006 2354 119 162 3
2.4 Vtec (RD6) 1 01/2002-12/2006 2354 118 160 1
2.4 Vtec 4WD (RD7)

K24A1

 1 09/2001-09/2006 2354 118 160 3
2.2 CTDi (RD9)

N22A2

 2 02/2005-09/2006 2204 103 140 3
CR-Z (ZF) Coupe 06/2010-
Vehicle Engine Fuel Date CC KW CV Traction
1.5 IMA (ZF1)

LEA1

LEA3

 13 09/2010-12/2013 1497 91 124 1
1.5 IMA (ZF2) 13 12/2013- 1497 87 118 1
1.5 IMA (ZF2)

LEA1

LEA3

 13 11/2012- 1497 101 137 1
STEPWGN II (LA-RF_, UA-RF_) MPV 10/2000-09/2005
Vehicle Engine Fuel Date CC KW CV Traction
2.0 (RF3)

K20A9

 1 10/2000-09/2005 1998 118 160 1
2.0 4WD (RF4)

K20A9

 1 10/2000-09/2005 1998 118 160 3
2.4 (RF7) 1 10/2000-09/2005 2354 119 162 1
STEPWGN III (DBA-RG_) MPV 10/2005-09/2009
Vehicle Engine Fuel Date CC KW CV Traction
2.0 (RG1) 1 10/2005-09/2009 1998 114 155 1
2.0 4WD (RG2) 1 10/2005-09/2009 1998 114 155 3
2.4 Z FF (RG3) 1 10/2005-09/2009 2354 119 162 1
STREAM (RN) MPV 05/2001-
Vehicle Engine Fuel Date CC KW CV Traction
1.7 16V (RN1)

D17A2

D17A5

 1 05/2001-09/2006 1668 92 125 1
2.0 16V (RN3)

K20A1

K20A5

 1 05/2001-09/2006 1998 115 156 1
STREAM II (RN) MPV 10/2005-
Vehicle Engine Fuel Date CC KW CV Traction
1.8 Vtec (RN6)

R18A2

 1 10/2005- 1798 103 140 1
1.8 Vtec AWD (RN7)

R18A2

 1 10/2006-05/2014 1798 103 140 3
2.0 Vtec (RN8) 1 10/2005- 1997 110 150 1
2.0 Vtec AWD (RN9) 1 10/2006-05/2014 1997 110 150 3
HONDA (DONGFENG)
CR-V II (RD_) Closed Off-Road Vehicle 06/2004-02/2007
Vehicle Engine Fuel Date CC KW CV Traction
2.0 1 06/2004-02/2007 1998 110 148 1
2.4 1 06/2004-02/2007 2354 118 158 1
