Product 78BD1269-2
- Description
- Brake disc
- Axe
- Rear
- No. of Pieces
- 2
- Barcode
-
8424073143082
- Url
- https://catalogonuevo.icerbrakes.com/Producto/Details?idProducto=78BD1269-2
- Weight (gr.)
- 15750
- Measures
- Ø345x18x77
-
Brake Disc Type:
Vented -
Minimum thickness [mm]:
16 -
Hole Arrangement/Number:
5 -
Bolt Hole Circle Ø [mm]:
150 -
Wheel Hub Diameter [mm]:
112
| Brand | OE Reference |
|---|---|
| TOYOTA | 42431-60290 |
| Maker | Cross reference |
|---|---|
| BENDIX ANTIGUO | 562761BC |
| BOSCH | 0 986 479 R32 |
| BREMBO | 09.A967.10 |
| BREMBO | 09.A967.11 |
| FERODO | DDF1799 |
| HELLA-PAGID | 8DD 355 116-331 |
| MINTEX | MDC2288 |
| ROAD HOUSE | 61257.10 |
| TEXTAR | 92198503 |
| TRW | DF4965S |
| Vehicle | Engine | Fuel | Date | CC | KW | CV | Traction |
|---|---|---|---|---|---|---|---|
| 250 |
G6BV |
1 | 10/2003-09/2005 | 2493 | 123 | 167 | 1 |
| Vehicle | Engine | Fuel | Date | CC | KW | CV | Traction |
|---|---|---|---|---|---|---|---|
| 570 (URJ201) |
3UR-FE |
1 | 01/2015- | 5663 | 266 | 362 | 3 |
| 570 (URJ201) |
3UR-FE |
1 | 11/2007- | 5663 | 270 | 367 | 3 |
| 570 (URJ201) |
3UR-FE |
1 | 11/2007- | 5663 | 282 | 384 | 3 |
| 570 (URJ201) |
3UR-FE |
1 | 08/2007- | 5663 | 285 | 387 | 3 |
| 450d (VDJ201) |
1VD-FTV |
2 | 09/2015- | 4461 | 200 | 272 | 3 |
| Vehicle | Engine | Fuel | Date | CC | KW | CV | Traction |
|---|---|---|---|---|---|---|---|
| 4.0 4x4 (GRJ79) |
1GR-FE |
1 | 03/2007- | 3956 | 170 | 231 | 3 |
| Vehicle | Engine | Fuel | Date | CC | KW | CV | Traction |
|---|---|---|---|---|---|---|---|
| 4.0 (GRJ200_, GRJ200R) |
1GR-FE |
1 | 01/2010- | 3956 | 176 | 239 | 3 |
| 4.0 (GRJ200) |
1GR-FE |
1 | 01/2012- | 3956 | 199 | 271 | 3 |
| 4.6 V8 (URJ202_) |
1UR-FE |
1 | 01/2012- | 4608 | 224 | 305 | 3 |
| 4.6 V8 (URJ202) |
1UR-FE |
1 | 09/2010- | 4608 | 227 | 309 | 3 |
| 4.6 V8 (URJ202W) |
1UR-FE |
1 | 01/2012- | 4608 | 234 | 318 | 3 |
| 4.7 V8 (UZJ200) |
2UZ-FE |
1 | 04/2011- | 4664 | 199 | 271 | 3 |
| 4.7 V8 (UZJ200) |
2UZ-FE |
1 | 08/2007- | 4664 | 202 | 275 | 3 |
| 4.7 V8 (UZJ200) |
2UZ-FE |
1 | 01/2008- | 4664 | 212 | 288 | 3 |
| 4.7 V8 (UZJ200) |
2UZ-FE |
1 | 01/2008- | 4664 | 232 | 315 | 3 |
| 5.7 V8 (URJ200_, URJ200R) |
3UR-FE |
1 | 08/2007- | 5663 | 284 | 386 | 3 |
| 5.7 V8 (URJ200_) |
3UR-FE |
1 | 08/2015- | 5663 | 266 | 362 | 3 |
| 5.7 V8 (URJ200_) |
3UR-FE |
1 | 09/2011-07/2015 | 5663 | 270 | 367 | 3 |
| 5.7 V8 (URJ200) | 1 | 08/2008- | 5663 | 280 | 381 | 3 | |
| 5.7 V8 VVTi | 1 | 08/2007- | 5695 | 280 | 381 | 1 | |
| 4.0 D VVTi | 2 | 08/2007- | 3995 | 176 | 240 | 2 | |
| 4.5 D V8 (VDJ200) |
1VD-FTV |
2 | 01/2008- | 4461 | 210 | 286 | 3 |
| 4.5 D4-D (VDJ200_) |
1VD-FTV |
2 | 08/2015- | 4461 | 183 | 249 | 3 |
| 4.5 D4-D (VDJ200) |
1VD-FTV |
2 | 01/2012- | 4461 | 160 | 218 | 3 |
| 4.5 D4-D (VDJ200) |
1VD-FTV |
2 | 01/2013- | 4461 | 171 | 232 | 3 |
| 4.5 D4-D (VDJ200) |
1VD-FTV |
2 | 08/2007- | 4461 | 173 | 235 | 3 |
| 4.5 D4-D (VDJ200) |
1VD-FTV |
2 | 09/2007- | 4461 | 195 | 265 | 3 |
| 4.5 D4-D (VDJ200) |
1VD-FTV |
2 | 01/2012- | 4461 | 200 | 272 | 3 |
| Vehicle | Engine | Fuel | Date | CC | KW | CV | Traction |
|---|---|---|---|---|---|---|---|
| 4.7 (UCK35_, UCK35L) |
2UZ-FE |
1 | 09/2000-10/2007 | 4664 | 175 | 238 | 2 |
| 4.7 4WD (UCK45_, UCK45L) |
2UZ-FE |
1 | 09/2000-10/2007 | 4664 | 175 | 238 | 3 |
| 4.7 4WD (UCK45_, UCK45L) |
2UZ-FE |
1 | 09/2000-10/2007 | 4664 | 204 | 277 | 3 |
| Vehicle | Engine | Fuel | Date | CC | KW | CV | Traction |
|---|---|---|---|---|---|---|---|
| 4.7 (UCK60_) |
2UZ-FE |
1 | 11/2007-04/2014 | 4664 | 206 | 280 | 2 |
| 4.7 4WD (UCK65_) |
2UZ-FE |
1 | 11/2007-04/2014 | 4664 | 206 | 280 | 3 |
| 5.7 (USK60_) |
3UR-FE |
1 | 11/2007- | 5663 | 280 | 381 | 2 |
| 5.7 4WD (USK65_) |
3UR-FE |
1 | 11/2007- | 5663 | 280 | 381 | 3 |
| 5.7 4WD (USK65_) |
3UR-FE |
1 | 11/2007- | 5663 | 284 | 386 | 3 |
| 5.7 FLEX (USK60_) | 19 | 09/2008- | 5663 | 284 | 386 | 2 | |
| 5.7 FLEX 4WD (USK65) |
3UR-FBE |
19 | 11/2007- | 5663 | 280 | 381 | 3 |
| Vehicle | Engine | Fuel | Date | CC | KW | CV | Traction |
|---|---|---|---|---|---|---|---|
| 4.0 (GSK50_) |
1GR-FE |
1 | 11/2006- | 3956 | 176 | 239 | 2 |
| 4.6 (UPK51) |
1UR-FE |
1 | 11/2006-09/2013 | 4608 | 228 | 310 | 2 |
| 4.7 (UCK50_, UCK51_, UCK52_, UCK55_, UCK56_, UCK57_) |
2UZ-FE |
1 | 11/2006-03/2009 | 4664 | 206 | 280 | 2 |
| 4.7 4WD (UCK50_, UCK51_, UCK52_, UCK55_, UCK56_, UCK57_) |
2UZ-FE |
1 | 11/2006-12/2009 | 4664 | 206 | 280 | 3 |
| 5.7 (USK50_, USK51, USK52_, USK56_, USK57_, USK52L,... |
3UR-FE |
1 | 11/2006- | 5663 | 284 | 386 | 2 |
| 5.7 4WD (USK56_, USK57_, USK55_, USK75_, USK55L, USK57L,... |
3UR-FE |
1 | 11/2006- | 5663 | 284 | 386 | 3 |
| 5.7 Flexfuel (USK51, USK52, USK55) |
3UR-FBE 3UR-FE |
19 | 11/2006- | 5663 | 280 | 381 | 2 |
| 5.7 Flexfuel (USK51, USK52, USK55) | 19 | 08/2008- | 5663 | 284 | 386 | 2 | |
| 5.7 Flexfuel 4WD (USK55_, USK56_, USK57_, USK55L, USK56L... |
3UR-FBE |
19 | 04/2009-07/2013 | 5663 | 280 | 381 | 3 |
| 5.7 Flexfuel 4WD (USK55_, USK56_, USK57_, USK55L, USK56L... |
3UR-FBE |
19 | 08/2008- | 5663 | 284 | 386 | 3 |
| Vehicle | Engine | Fuel | Date | CC | KW | CV | Traction |
|---|---|---|---|---|---|---|---|
| 4.0 A las 4 ruedas (GRJ200) |
1GR-FE |
1 | 12/2007-12/2012 | 3956 | 179 | 243 | 3 |
| 4.7 (UZJ200) |
2UZ |
1 | 12/2007-12/2012 | 4664 | 202 | 275 | 3 |
