Product 78BD1674-1 - Web Catalogo

Description: Brake disc
Axe: Rear
No. of Pieces: 1
Barcode: 8424073143259
Url: https://catalogonuevo.icerbrakes.com/Producto/Details?idProducto=78BD1674-1
Weight (gr.): 5722

R90 Homologation: 90R-02C0453/0106
Measures: Ø288x12x65
: Brake Disc Type: solid; Minimum thickness [mm]: 10; Hole Arrangement/Number: 5; Bolt Hole Circle Ø [mm]: 108; Wheel Hub Diameter [mm]: 68

Reference applications

Brand	OE Reference
VOLVO	9 434 167 0
VOLVO	9 434 167 4

Vehicle	Engine	Fuel	Date	CC	KW	CV	Traction
2.0 T	B 5204 T5	1	07/2000-04/2010	1984	132	180	1
2.4		1	02/2004-04/2010	2401	191	260	1
2.4	B 5244 S2	1	07/2000-04/2010	2435	103	140	1
2.4	B 5244 S	1	11/2000-04/2010	2435	125	170	1
2.4	B 5244 T4	1	01/2005-10/2006	2435	132	180	1
2.4 T	B 5244 T3	1	07/2000-04/2010	2435	147	200	1
2.4 T AWD	B 5244 T3	1	06/2001-04/2010	2435	147	200	3
2.5		1	09/2003-04/2010	2521	224	300	1
2.5 T	B 5254 T2	1	01/2003-04/2010	2521	154	210	1
2.5 T AWD	B 5254 T2	1	07/2002-04/2010	2521	154	210	3
R 2,5 T AWD	B 5254 T4	1	01/2003-04/2010	2521	221	300	3
T5	B 5234 T3	1	07/2000-04/2010	2319	184	250	1
T5	B 5234 T7	1	07/2000-09/2002	2319	195	265	1
T5	B 5244 T5	1	04/2004-04/2010	2401	191	260	1
2.4 Bifuel (CNG)	B 5244 SG	16	07/2001-04/2010	2435	103	140	1
2.4 Bifuel (LPG)	B 5244 SG2	18	07/2001-04/2010	2435	103	140	1
2.4 CDI	D 5244 T3	2	10/2003-12/2005	2401	85	116	1
2.4 D	D 5244 T7	2	03/2005-04/2010	2400	93	126	1
2.4 D	D 5244 T6	2	05/2005-12/2006	2401	90	122	1
2.4 D	D 5244 T2	2	05/2001-04/2010	2401	96	130	1
D5	D 5244 T	2	01/2001-04/2010	2400	120	163	1
D5	D 5244 T4	2	03/2005-04/2010	2401	136	185	1

Vehicle	Engine	Fuel	Date	CC	KW	CV	Traction
2.0	B 5204 T4	1	06/1998-07/2006	1984	120	163	1
2.0 T	B 5204 T5	1	12/1999-07/2006	1984	132	180	1
2.0 T	B 5204 T3	1	06/1998-07/2006	1984	166	226	1
2.3 R	B 5234 T7	1	04/2000-08/2005	2319	195	265	1
2.4	B 5244 S2	1	01/1999-07/2006	2435	103	140	1
2.4	B 5244 S	1	01/1999-07/2006	2435	125	170	1
2.4 LTP		1	06/2004-07/2006	2435	132	179	1
2.4 T	B 5244 T3	1	06/2000-07/2006	2435	147	200	1
2.5 T	B 5254 T2	1	03/2003-07/2006	2521	154	210	1
2.5 T AWD	B 5254 T2	1	07/2003-07/2006	2521	154	210	3
2.9		1	05/1998-02/2008	2922	144	196	1
2.9	B 6294 S	1	03/1999-07/2006	2922	147	200	1
2.9	B 6304 S3	1	05/1998-07/2006	2922	150	204	1
3.0	B 6294 S2	1	06/2001-07/2006	2922	144	196	1
T5 AWD	B 5244 T3	1	04/2000-09/2003	2435	147	200	3
T6	B 6284 T	1	05/1998-12/2001	2783	200	272	1
T6	B 6294 T	1	06/2001-07/2006	2922	200	272	1
T6		1	06/2001-07/2006	2922	200	272	1
2.4 Bifuel (CNG)	B 5244 SG2	16	09/2001-07/2006	2435	103	140	1
2.4 Bifuel (LPG)	B 5244 SG	18	09/2001-07/2006	2435	103	140	1
2.4 D	D 5244 T2	2	10/2001-07/2006	2401	96	131	1
2.5 TDI	D 5252 T	2	01/1999-07/2006	2460	103	140	1
D5	D 5244 T	2	08/2001-07/2006	2401	120	163	1

Vehicle	Engine	Fuel	Date	CC	KW	CV	Traction
2.4	B 5244 S2 B 5244 SG2	1	03/1999-12/2000	2435	103	140	1
2.4	B 5252 FS	1	12/1995-03/2000	2435	106	144	1
2.4	B 5254 S	1	06/1998-12/1999	2435	121	165	1
2.4	B 5244 S B 5254 FS B 5254 S	1	12/1995-05/2000	2435	125	170	1
2.4 AWD	B 5254 S	1	06/1998-12/1999	2435	121	165	3
2.4 Turbo	B 5244 T B 5254 T	1	04/1996-12/2000	2435	142	193	1
2.4 Turbo		1	05/1999-02/2000	2435	195	265	1
2.4 Turbo AWD	B 5244 T B 5254 T	1	04/1996-12/2000	2435	142	193	3
2.4 Turbo AWD	B 5244 T2	1	03/1999-12/2000	2435	195	265	3
2.4 Bifuel	B 5244 SG	16	08/1999-12/2000	2435	103	140	1
2.4 Bifuel	GB 5252 S	16	05/1998-12/1999	2435	106	144	1
2.5 TDI	D 5252 T	2	12/1995-12/2000	2460	103	140	1
2.5 TDi AWD	D 5252 T	2	11/1996-02/2000	2460	103	140	3

Vehicle	Engine	Fuel	Date	CC	KW	CV	Traction
2.0 T	B 5204 T5	1	11/1999-08/2007	1984	132	180	1
2.3		1	10/2000-09/2004	2319	195	265	1
2.3	B 5234 T7	1	10/2000-09/2004	2319	195	265	1
2.4	B 5244 S2	1	03/2000-08/2007	2435	103	140	1
2.4		1	03/2000-09/2003	2435	121	165	1
2.4		1	03/2000-09/2003	2435	121	165	1
2.4	B 5244 S	1	03/2000-08/2007	2435	125	170	1
2.4 T	B 5244 T3	1	11/1999-08/2003	2435	147	200	1
2.4 T AWD	B 5244 T3	1	09/2001-08/2002	2435	147	200	3
2.5 AWD	B 5254 T2	1	09/2002-12/2004	2521	155	211	3
2.5 R Sport		1	12/2002-08/2007	2521	221	300	1
2.5 T	B 5254 T2	1	07/2001-08/2007	2521	154	209	1
2.5 T AWD	B 5254 T2	1	07/2002-08/2007	2521	154	209	3
R 2,5 T AWD	B 5254 T4	1	03/2003-08/2007	2521	221	300	3
T5	B 5234 T3	1	11/1999-12/2004	2319	184	250	1
T5	B 5244 T5	1	04/2004-08/2007	2401	191	260	1
2.4 Bifuel (CNG)	B 5244 SG	16	09/2001-08/2007	2435	103	140	1
2.4 Bifuel (LPG)	B 5244 SG2	18	09/2001-08/2007	2435	103	140	1
2.4 CDI	D 5244 T6	2	07/2005-12/2008	2401	90	122	1
2.4 D	D 5244 T7	2	04/2005-12/2008	2400	93	126	1
2.4 D	D 5244 T2	2	07/2001-08/2007	2401	96	131	1
2.4 D5		2	08/2005-07/2007	2400	120	163	1
2.5 TDI	D 5252 T	2	11/1999-08/2007	2460	103	140	1
D5	D 5244 T D 5244 T2 D 5244 T5	2	01/2001-12/2008	2401	120	163	1
D5	D 5244 T4	2	04/2005-12/2008	2401	136	185	1
D5 AWD	D 5244 T D 5244 T2 D 5244 T5	2	07/2002-08/2007	2401	120	163	3
D5 AWD	D 5244 T4	2	05/2005-08/2007	2401	136	185	3

Vehicle	Engine	Fuel	Date	CC	KW	CV	Traction
2.4		1	03/2000-09/2003	2435	121	165	1
2.4 T XC AWD	B 5254 T	1	11/1997-09/2002	2435	142	193	3
2.4 T XC AWD	B 5244 T3	1	03/2000-09/2002	2435	147	200	3
2.5 T XC AWD	B 5254 T2	1	09/2002-08/2007	2521	154	209	3
D5 AWD	D 5244 T4	2	12/2005-08/2007	2401	136	185	3
D5 XC AWD	D 5244 T	2	09/2002-08/2007	2401	120	163	3
