Product 78BD1701-2

Description
Brake disc
Axe
Front
No. of Pieces
2
Barcode
EAN13 Code
8424073143273
QR Code
Url
https://catalogonuevo.icerbrakes.com/Producto/Details?idProducto=78BD1701-2
Weight (gr.)
8560
R90 Homologation
R90 90R-02C0452/0079
Measures
Ø240x21x44.7
Brake Disc Type: Vented
Minimum thickness [mm]: 19
Hole Arrangement/Number: 4
Bolt Hole Circle Ø [mm]: 100
Wheel Hub Diameter [mm]: 61
Reference applications
Brand OE Reference
HONDA 45251-SH1-A00
HONDA 45251-SH3-A00
HONDA 45251-SH3-A10
HONDA 45251-SR0-A10
HONDA 45251-SR3-A00
HONDA 45251-SR3-A10
Maker Cross reference
ATE 24.0121-0104.1
BENDIX BRAKING-TMD BDS1960
BOSCH 0 986 478 115
BREMBO 09.5285.10
HELLA-PAGID 8DD 355 133-941
LETEC LBH003V
ROAD HOUSE 6108.10
TRW DF1436
HONDA
BRIO (DD_) Hatchback 01/2011-
Vehicle Engine Fuel Date CC KW CV Traction
1.2 i-VTEC (DD1) 1 01/2011- 1198 65 88 1
CITY V / BALADE (GM2, GM3) Saloon 09/2008-
Vehicle Engine Fuel Date CC KW CV Traction
1.5 1 09/2008- 1497 79 107 1
1.5 i-VTEC

L15A7

 1 08/2009- 1497 85 114 1
1.5 i-VTEC (GM2)

L15A7

 1 02/2009- 1497 88 120 1
1.5 CNG (GM2) 16 01/2011-11/2013 1497 75 102 1
iVtec CNG (GM2) 16 01/2011-11/2013 1497 75 102 1
1.5 Flex 19 08/2009-12/2014 1497 85 114 1
CITY VI / BALLADE / GREIZ / GIENIA (GM4, GM5, GM6, GM9, GM7) Saloon 07/2013-
Vehicle Engine Fuel Date CC KW CV Traction
1.5 (GM6) 1 06/2015- 1496 97 132 1
1.5 4WD (GM9) 1 06/2015- 1496 97 132 3
1.5 i-VTEC (GM6) 1 09/2014- 1497 86 117 1
1.5 i-VTEC (GM6)

L15A7

L15Z1

 1 01/2014- 1497 88 119 1
1.5 Hybrid (GM4) 13 12/2014- 1496 81 110 1
1.5 Hybrid (GM7) 13 09/2017- 1496 81 110 1
1.5 Hybrid 4WD (GM5) 13 12/2014- 1496 81 110 3
1.5 CNG (GM6) 16 01/2014-10/2019 1497 75 102 1
1.5 Flex

L15-A7

 19 09/2014-10/2021 1497 85 116 1
1.5 i-DTEC

N15A1

 2 01/2014- 1498 74 100 1
CITY VII / BALLADE (GN1, GN2, GN3) Saloon 12/2019-
Vehicle Engine Fuel Date CC KW CV Traction
i-VTEC (GN2) 1 06/2020- 1498 89 121 1
1.0 Vtec Flexfuel (GN1)

P10A6

 19 12/2019- 988 90 122 1
CITY VII / BALLADE (GN6, GN2) Hatchback 11/2020-
Vehicle Engine Fuel Date CC KW CV Traction
1.5 1.5 DOHC i-VTEC (GN5)

L15B1

 1 04/2021- 1498 89 121 1
1.5 DOHC i-VTEC (GN5) 1 03/2021- 1498 89 121 1
1.0 Vtec Flexfuel

P10A6

 19 11/2020- 988 90 122 1
CIVIC V (EG) Hatchback 10/1991-11/1995
Vehicle Engine Fuel Date CC KW CV Traction
1.4 16V 1 01/1995-04/1997 1396 66 90 1
1.5 i 16V (EG4)

D15B2

D15B3

D15B4

D15Z2

 1 10/1991-11/1995 1493 66 90 1
1.5 i 16V (EG4)

D15B2

D15Z1

 1 10/1991-11/1995 1493 69 94 1
1.6 1 10/1991-09/1995 1590 96 131 1
1.6 16V Vtec (EG5)

D16Z6

 1 10/1991-11/1995 1590 92 125 1
CIVIC V (EG, EH) Saloon 10/1991-12/1996
Vehicle Engine Fuel Date CC KW CV Traction
1.3 (EG7)

D13B2

 1 01/1992-12/1992 1343 55 75 1
1.5 1 01/1992-12/1992 1493 61 83 1
1.5

D15B2

 1 10/1993-12/1995 1493 66 90 1
1.5 1 06/1993-09/1995 1493 88 120 1
1.5 (EG8)

D15B7

 1 10/1993-12/1995 1493 67 91 1
1.5 (EG8)

D15B2

D15B7

D15Z1

 1 10/1991-12/1995 1493 74 101 1
1.5 i 16V (EG8)

D15B2

D15Z1

 1 10/1991-11/1995 1493 69 94 1
CIVIC VI (MA, MB) Hatchback 09/1994-02/2001
Vehicle Engine Fuel Date CC KW CV Traction
2.0 TDiC (MB7)

20T2N

 2 11/1998-10/2000 1994 77 105 1
CIVIC VI / BALLADE (EJ, EK, SO) Saloon 06/1995-03/2001
Vehicle Engine Fuel Date CC KW CV Traction
1.4 (EJ9)

D14A4

 1 11/1995-10/1998 1396 55 75 1
1.4 i (EJ9)

D14A4

D14Z2

D14Z4

 1 11/1995-02/2001 1396 66 90 1
1.6 i Vtec 4x4

D16Z7

 1 11/1995-02/2001 1590 92 125 3
CIVIC VI (EJ, EK) Hatchback 10/1995-03/2001
Vehicle Engine Fuel Date CC KW CV Traction
1.4 i (EJ9)

D14A3

D14Z1

 1 11/1995-02/2001 1396 55 75 1
1.4 i S (EJ9)

D14A4

D14Z2

D14Z4

 1 11/1995-02/2001 1396 66 90 1
1.6

D16Y7

 1 10/1995-12/2000 1590 79 107 1
1.4 LPG

D14Z4

 18 01/1997-02/2001 1396 66 90 1
2.0 TDiC

20T2N

 2 11/1998-10/2000 1994 77 105 1
CIVIC VI (EJ, EM1) Coupe 03/1996-12/2000
Vehicle Engine Fuel Date CC KW CV Traction
1.6 (EJ6)

D16Y7

 1 05/1996-04/1999 1590 79 107 1
1.6 i (EJ6)

D16Y7

 1 03/1996-03/2000 1590 77 105 1
1.6 i Vtec (EM1)

D16Y8

 1 03/1996-03/2000 1590 92 125 1
CIVIC VII (EU, EP, EV) Hatchback 01/2000-02/2006
Vehicle Engine Fuel Date CC KW CV Traction
1.7 (ES1) 1 01/2000-08/2005 1668 92 125 1
CIVIC VII (ES, ET) Saloon 10/2000-04/2006
Vehicle Engine Fuel Date CC KW CV Traction
1.5 (ES8)

D15Y3

 1 02/2003-09/2005 1493 82 112 1
1.7

D17A6

D17Z2

 1 02/2001-09/2005 1668 85 116 1
1.7 LX, LXL 1 01/2001-04/2006 1668 85 116 1
1.8 1 07/2003-08/2005 1850 77 105 1
2.0 (ET1)

K20A3

 1 10/2003-09/2005 1998 118 160 1
CRX III (EH, EG) Targa 03/1992-12/1998
Vehicle Engine Fuel Date CC KW CV Traction
1.5 (EG1)

D15B7

 1 08/1993-12/1995 1493 76 103 1
1.5 (EG1)

D15B7

 1 01/1994-04/1998 1493 77 105 1
DOMANI (MB_) Saloon 10/1995-09/1999
Vehicle Engine Fuel Date CC KW CV Traction
1.5 (MB3) 1 10/1995-09/1999 1493 69 94 1
1.6 (MB4)

D16A

D16Z2

 1 10/1995-09/1999 1590 88 120 1
1.6 A las 4 ruedas (MB5)

D16A

D16Z2

 1 10/1995-09/1999 1590 88 120 3
INSIGHT II (ZE_) Hatchback 04/2009-
Vehicle Engine Fuel Date CC KW CV Traction
1.3 IMA (ZE2)

LDA3

 13 04/2009- 1339 73 99 1
1.3 IMA (ZE28, ZE2)

LDA3

 13 04/2009- 1339 65 88 1
1.5 IMA (ZE3) 13 10/2011- 1497 82 112 1
INTEGRA II (DA5, DA6, DA7, DA8, DA9, DB1, DB2) Saloon 06/1989-08/1993
Vehicle Engine Fuel Date CC KW CV Traction
1.6 (DA5)

ZC

 1 06/1989-07/1993 1590 88 120 1
INTEGRA III (DC) Coupe 07/1993-11/2001
Vehicle Engine Fuel Date CC KW CV Traction
1.5

D15B

 1 09/1995-08/1999 1493 96 131 1
1.8 (DC2)

B18B2

 1 07/1993-11/2001 1834 107 146 1
1.8 SiR (DC2)

B18C

 1 09/1993-08/2001 1797 132 180 1
1.8 VTiR (DC2) 1 07/1993-11/1999 1797 125 170 1
1.8 VTiR (DC2)

B18C1

 1 07/1993-11/1999 1797 127 173 1
JAZZ II (GE_, GG_, GP_, ZA_) Hatchback 10/2007-
Vehicle Engine Fuel Date CC KW CV Traction
1.4

L13Z1

 1 11/2008- 1339 74 101 1
1.5 i-VTEC (GE8)

L15A7

 1 07/2008-06/2014 1496 88 120 1
1.3 HYBRID (GP1)

LDA3

 13 04/2011- 1339 75 102 1
1.5 Flex 19 11/2008-03/2014 1497 85 116 1
1.5 Flexfuel (GE8) 19 07/2008- 1496 88 120 1
JAZZ II SHUTTLE (GG8, GG7, GP2) Estate 03/2011-
Vehicle Engine Fuel Date CC KW CV Traction
1.5 (GG7)

L15A

 1 03/2011-03/2014 1497 88 120 1
1.5 4WD (GG8)

L15A

 1 03/2011-03/2014 1497 88 120 3
JAZZ III (GK_) Hatchback 09/2013-
Vehicle Engine Fuel Date CC KW CV Traction
1.3

L13B

L13B2

 1 09/2015- 1318 75 102 1
1.5

L15B3

 1 09/2017- 1498 96 130 1
1.5 (GK5) 1 09/2014- 1496 97 132 1
1.5 4WD (GK6) 1 12/2013- 1496 97 132 3
1.5 i-VTEC Flex

L15Z2

 19 09/2014- 1497 88 120 1
MOBILIO (GB_) MPV 12/2001-10/2008
Vehicle Engine Fuel Date CC KW CV Traction
1.5 (GB1) 1 12/2001-10/2008 1497 66 90 1
1.5 (GB1) 1 12/2001-10/2008 1497 81 110 1
1.5 4WD (GB2) 1 12/2001-10/2008 1497 66 90 3
NSX (NA) Convertible 03/1995-09/2005
Vehicle Engine Fuel Date CC KW CV Traction
3.0 24V Vtec Automatic (NA1)

C30A4

 1 03/1995-09/2005 2977 188 256 2
ORTHIA / PARTNER (EL_, EY_) Estate 10/1995-09/2002
Vehicle Engine Fuel Date CC KW CV Traction
1.3 (EY6) 1 10/1995-09/2002 1343 67 91 1
