Product 78BD1705-2

Description
Brake disc
Axe
Front
No. of Pieces
2
Barcode
EAN13 Code
8424073143310
QR Code
Url
https://catalogonuevo.icerbrakes.com/Producto/Details?idProducto=78BD1705-2
Weight (gr.)
12744
R90 Homologation
R90 90R-02C0452/0118
Measures
Ø282x23x47.5
Brake Disc Type: Vented
Minimum thickness [mm]: 21
Hole Arrangement/Number: 5
Bolt Hole Circle Ø [mm]: 114,3
Wheel Hub Diameter [mm]: 64
Reference applications
Brand OE Reference
HONDA 45251 TEA T00
HONDA 45251-S7A-E10
HONDA 45251-S7A-E11
HONDA 45251-SMG-G10
Maker Cross reference
ATE 24.0123-0110.1
BENDIX ANTIGUO 562457B
BOSCH 0 986 479 364
BREMBO 09.A455.11
BREMBO 09.A455.14
BREMBO 09.A455.1X
DELPHI LOCKHEED BG3980
FERODO DDF1539
LETEC LBH026V
SANLI SL36656
TRW DF4456
VALEO 672856
ACURA
ILX () Saloon 09/2012-
Vehicle Engine Fuel Date CC KW CV Traction
2.0 1 09/2012- 1997 112 152 1
BYD
F6 () Saloon 09/2007-12/2014
Vehicle Engine Fuel Date CC KW CV Traction
1.8 1 06/2010-12/2014 1839 90 122 1
2.0

BYD483QB

 1 03/2008-12/2014 1991 103 140 1
2.4 1 03/2008-12/2011 2378 121 165 1
G6 () Saloon 09/2011-
Vehicle Engine Fuel Date CC KW CV Traction
2.0

BYD483QB

 1 09/2011-12/2018 1991 103 140 1
HONDA
CIVIC VIII (FN, FK) Hatchback 09/2005-
Vehicle Engine Fuel Date CC KW CV Traction
1.4 (FK1, FN4)

L13Z1

 1 10/2008-12/2011 1339 73 100 1
1.4 (FK1)

L13A7

 1 09/2005-09/2008 1339 61 83 1
1.8 (FN1, FK2)

R18A2

 1 09/2005-12/2011 1799 103 140 1
2.2 CTDi (FK3)

N22A2

 2 09/2005-12/2011 2204 103 140 1
CIVIC VIII / BALLADE (FD, FA) Saloon 09/2005-
Vehicle Engine Fuel Date CC KW CV Traction
1.6

R16A1

 1 09/2005-12/2012 1595 92 125 1
1.6

R16B1

 1 01/2012-12/2012 1597 92 125 1
1.6 (FD6)

R16A1

 1 09/2005-12/2012 1595 84 114 1
1.8 (FD1, FD7, FA1)

R18A1

R18A2

 1 09/2005-02/2012 1799 103 140 1
2.0 i-VTEC Type R (FD2)

K20A5

 1 08/2007-09/2010 1998 165 224 1
1.8 EXS Flex

R18A1

 19 11/2006-05/2013 1799 103 140 1
CIVIC IX (FB) Saloon 09/2011-
Vehicle Engine Fuel Date CC KW CV Traction
1.6 (FB7, FB1)

R16B1

R16B2

 1 09/2011-12/2016 1597 92 125 1
1.8 (FB2)

R18Z1

R18Z4

 1 02/2012-12/2016 1798 104 141 1
1.8 (FB2)

R18A1

 1 05/2013-12/2016 1799 103 140 1
1.8 (FB2)

R18A1

 1 09/2011-12/2016 1799 104 141 1
2.0 (FB3) 1 06/2012-12/2016 1997 114 155 1
CIVIC IX (FK) Hatchback 02/2012-
Vehicle Engine Fuel Date CC KW CV Traction
1.4 i-VTEC (FK1)

L13Z4

 1 02/2012-12/2016 1339 73 99 1
1.8 i-VTEC (FK2)

R18Z4

 1 02/2012-12/2016 1798 104 141 1
1.6 i-DTEC (FK3)

N16A1

 2 02/2013-12/2016 1597 88 120 1
2.2 i-DTEC (FK3)

N22B4

 2 02/2012-12/2016 2199 110 150 1
CIVIC X (FC_) Saloon 09/2015-
Vehicle Engine Fuel Date CC KW CV Traction
1.0 iVTEC (FC9)

P10A4

 1 07/2018-12/2022 988 93 126 1
1.5 RS Turbo (FC1)

L15B7

L15BB

 1 06/2016- 1498 127 173 1
1.6 i-VTEC (FC5)

R16B1

R16B2

 1 09/2016-12/2022 1597 92 125 1
1.8 (FC6) 1 06/2016- 1799 104 141 1
1.6 i-VTEC LPG

R16B1

 18 01/2019-12/2022 1597 92 125 1
CIVIC X (FC_, FK_) Hatchback 09/2016-
Vehicle Engine Fuel Date CC KW CV Traction
1.0 VTEC

P10A2

 1 07/2018-12/2022 988 93 126 1
1.0 VTEC (FK6)

P10A2

 1 02/2017-12/2022 988 95 129 1
1.5 VTEC (FK7)

L15B7

 1 03/2017- 1498 127 173 1
1.8 iVTEC (FK5) 1 03/2017- 1799 104 141 1
CIVIC XI (FE) Saloon 01/2021-
Vehicle Engine Fuel Date CC KW CV Traction
1.5 Turbo (FE1) 1 08/2021- 1498 95 129 1
1.5 Turbo Eco LPG (FE1) 18 11/2021- 1498 95 129 1
FR-V / EDIX (BE) MPV 08/2004-
Vehicle Engine Fuel Date CC KW CV Traction
1.7 (BE1)

D17A2

 1 08/2004- 1668 92 125 1
1.8 (BE1)

R18A1

 1 01/2007- 1799 103 140 1
2.0 (BE3)

K20A9

 1 02/2005- 1998 110 150 1
2.2 i CTDi (BE5)

N22A1

 2 07/2005- 2204 103 140 1
