Product 78BD1788-2

Description
Brake disc
Axe
Front
No. of Pieces
2
Barcode
EAN13 Code
8424073143358
QR Code
Url
https://catalogonuevo.icerbrakes.com/Producto/Details?idProducto=78BD1788-2
Weight (gr.)
12564
R90 Homologation
R90 90R-02C0452/0078
Measures
Ø280x26x50.3
Brake Disc Type: Vented
Minimum thickness [mm]: 23
Hole Arrangement/Number: 5
Bolt Hole Circle Ø [mm]: 108
Wheel Hub Diameter [mm]: 68
Reference applications
Brand OE Reference
VOLVO 2 717 88
VOLVO 2 717 882
VOLVO 9 140 759
VOLVO 9 140 759 3
Maker Cross reference
ATE 24.0126-0102.1
BOSCH 0 986 478 603
BREMBO 09.5568.20
BREMBO 09.5568.21
BREMBO 09.5568.24
ROAD HOUSE 6410.10
SANLI SL35018
TRW DF2671
VOLVO
850 (854) Saloon 06/1991-10/1997
Vehicle Engine Fuel Date CC KW CV Traction
2.0

B 5202 S

 1 08/1994-12/1996 1984 93 126 1
2.0

B 5204 FS

 1 06/1991-12/1996 1984 105 143 1
2.0 Turbo

B 5204 T2

 1 09/1993-10/1996 1984 132 179 1
2.0 Turbo

B 5204 FT

B 5204 T

 1 08/1993-12/1996 1984 155 210 1
2.3 1 01/1996-10/1996 2319 106 144 1
2.3 Turbo R

B 5234 T5

 1 06/1995-10/1996 2319 177 241 1
2.3 Turbo R

B 5234 T5

 1 09/1994-10/1997 2319 179 243 1
2.4

B 5252

 1 06/1991-07/1994 2435 103 140 1
2.4

B 5252 FS

 1 08/1994-12/1996 2435 106 144 1
2.4

B 5254 S

 1 08/1991-12/1996 2435 125 170 1
2.4 GLE

B 5254 T

 1 09/1993-10/1997 2435 142 193 1
T5

B 5234 FT

 1 08/1993-07/1996 2319 166 226 1
T5 R

B 5234 T2

 1 04/1996-10/1996 2319 176 239 1
T5-R

B 5234 T4

 1 08/1995-12/1996 2319 184 250 1
2.5 TDI

D 5252 T

 2 08/1995-12/1996 2460 103 140 1
850 (855) Estate 04/1992-10/1997
Vehicle Engine Fuel Date CC KW CV Traction
2.0

B 5202 S

 1 08/1994-12/1996 1984 93 126 1
2.0

B 5204 FS

 1 02/1993-12/1996 1984 105 143 1
2.0 Turbo

B 5204 T2

 1 09/1993-10/1997 1984 132 180 1
2.0 Turbo

B 5204 FT

B 5204 T

 1 02/1993-12/1996 1984 155 210 1
2.3 1 01/1996-10/1996 2319 106 144 1
2.3 Turbo R

B 5234 T5

 1 06/1995-10/1997 2319 177 241 1
2.3 Turbo R

B 5234 T5

 1 09/1994-10/1997 2319 179 243 1
2.4

B 5252

 1 08/1992-07/1994 2435 103 140 1
2.4

B 5252 FS

 1 08/1994-12/1996 2435 106 144 1
2.4

B 5254 S

 1 09/1992-12/1996 2435 125 170 1
2.4 AWD

B 5254 T

 1 04/1996-10/1997 2435 142 193 3
2.4 GLE

B 5254 T

 1 09/1993-10/1997 2435 142 193 1
T5

B 5234 FT

 1 02/1993-12/1996 2319 166 226 1
T5 R

B 5234 T2

 1 04/1996-10/1996 2319 176 239 1
T5-R

B 5234 T4

 1 08/1995-12/1996 2319 184 250 1
2.5 TDI

D 5252 T

 2 08/1995-12/1996 2460 103 140 1
940 (944) Saloon 08/1990-03/1995
Vehicle Engine Fuel Date CC KW CV Traction
2.0

B 200 F

 1 01/1992-07/1994 1986 82 112 2
2.3

B 230 FB

B 230 G

 1 08/1990-12/1994 2316 96 131 2
2.3

B 230 FK

 1 05/1991-03/1995 2316 99 135 2
2.4 Turbo Diesel

D 24 T

 2 08/1990-12/1994 2383 80 109 2
940 Kombi (945) Estate 08/1990-10/1995
Vehicle Engine Fuel Date CC KW CV Traction
2.0

B 200 F

 1 01/1992-07/1994 1986 82 112 2
2.4 TD Intercooler

D 24 TIC

 2 08/1990-08/1994 2383 90 122 2
2.4 Turbo Diesel

D 24 T

 2 08/1990-07/1994 2383 80 109 2
940 (945) Estate 09/1990-10/1998
Vehicle Engine Fuel Date CC KW CV Traction
2.4 TD Interc.

D 24 TIC

 2 08/1994-10/1998 2383 90 122 2
940 (944) Saloon 08/1994-12/1998
Vehicle Engine Fuel Date CC KW CV Traction
2.4 TD Interc.

D 24 TIC

 2 08/1994-10/1998 2383 90 122 2
960 (964) Saloon 08/1990-07/1994
Vehicle Engine Fuel Date CC KW CV Traction
2.9

B 6304 F

B 6304 FS

B 6304 GS

 1 08/1990-07/1994 2922 150 204 2
2.4 TD Interc.

D 24 TIC

 2 09/1991-07/1994 2383 85 115 2
960 Kombi (965) Estate 08/1990-07/1994
Vehicle Engine Fuel Date CC KW CV Traction
2.9

B 6304 F

B 6304 S

 1 08/1990-07/1994 2922 150 204 2
960 (964) Saloon 07/1994-12/1996
Vehicle Engine Fuel Date CC KW CV Traction
2.5

B 6254 S

 1 07/1994-12/1996 2473 125 170 2
2.9

B 6304 S

 1 07/1994-12/1996 2922 150 204 2
960 (965) Estate 07/1994-12/1996
Vehicle Engine Fuel Date CC KW CV Traction
2.5

B 6254 S

 1 08/1994-12/1996 2473 125 170 2
2.9

B 6304 S

 1 09/1994-12/1996 2922 150 204 2
C70 (872) Coupe 03/1997-09/2002
Vehicle Engine Fuel Date CC KW CV Traction
2.4

B 5254 S

 1 03/1999-09/2002 2435 121 165 1
2.4

B 5244 S

B 5254 S

 1 05/1999-09/2002 2435 125 170 1
S70 (874) Saloon 11/1996-11/2000
Vehicle Engine Fuel Date CC KW CV Traction
2.0

B 5202 FS

B 5202 S

 1 01/1997-11/2000 1984 93 126 1
2.0

B 5204 F

 1 01/1997-11/2000 1984 105 143 1
2.0

B 5204 T4

 1 01/1997-11/2000 1984 120 163 1
2.0

B 5204 T2

 1 01/1997-11/2000 1984 132 180 1
2.0 Turbo

B 5204 T

 1 01/1997-11/2000 1984 155 210 1
2.0 Turbo

B 5204 T3

 1 01/1997-11/2000 1984 166 226 1
2.3

B 5234 T3

 1 11/1996-11/2000 2319 177 241 1
2.3 1 04/1999-09/2000 2319 195 265 1
2.3

B 5234 T7

 1 04/1999-09/2000 2319 195 265 1
2.3 T5 1 07/1997-09/2000 2319 184 250 1
2.3 T5 AWD

B 5234 T3

 1 11/1996-09/1998 2319 177 241 3
2.3 T5 R 1 11/1996-09/1998 2319 176 239 1
2.3 Turbo

B 5234 T4

 1 01/1997-11/2000 2319 184 250 1
2.4

B 5244 S2

B 5244 SG

 1 08/1999-11/2000 2435 103 140 1
2.4

B 5252 FS

 1 01/1997-11/2000 2435 106 144 1
2.4

B 5254 S

 1 06/1998-11/2000 2435 121 165 1
2.4

B 5244 S

B 5254 S

 1 01/1997-11/2000 2435 125 170 1
2.4 AWD

B 5244 S2

 1 04/1999-09/2000 2435 103 140 3
2.4 AWD

B 5252 FS

 1 11/1996-05/1999 2435 106 144 3
2.4 AWD

B 5254 S

 1 10/1998-05/1999 2435 121 165 3
2.4 AWD

B 5244 S

 1 04/1999-09/2000 2435 125 170 3
2.4 T5 AWD

B 5254 T

 1 11/1996-04/1999 2435 142 193 3
2.4 Turbo

B 5244 T

B 5254 T

 1 01/1997-11/2000 2435 142 193 1
T5

B 5234 T3

 1 01/1997-11/2000 2319 176 239 1
2.4 Bifuel

B 5244 SG

 16 07/1999-11/2000 2435 103 140 1
2.4 Bifuel

GB 5252 S

 16 10/1998-11/2000 2435 106 144 1
2.4 Blu-Fuel

B 5244 S2

B 5244 SG

 16 07/1997-09/2000 2435 103 140 1
2.5 TDI

D 5252 T

 2 01/1997-11/2000 2460 103 140 1
2.5 TDi AWD

D 5252 T

 2 10/1999-09/2000 2460 103 140 3
S90 (964) Saloon 11/1996-12/1998
Vehicle Engine Fuel Date CC KW CV Traction
2.5

B 6254 FS

 1 11/1996-10/1998 2473 125 170 2
2.5

B 6244 FS

 1 11/1996-10/1997 2473 132 179 2
2.9

B 6304 S2

 1 01/1997-05/1998 2922 132 180 2
2.9

B 6304 GS

 1 01/1997-05/1998 2922 150 204 2
V70 (875, 876) Estate 12/1995-12/2000
Vehicle Engine Fuel Date CC KW CV Traction
2.0

B 5202 FS

B 5202 S

 1 12/1995-03/2000 1984 93 126 1
2.0

B 5204 F

 1 12/1995-03/2000 1984 105 143 1
2.0

B 5204 T4

 1 01/1997-12/2000 1984 120 163 1
2.0

B 5204 T2

 1 11/1996-03/2000 1984 132 180 1
2.0 Turbo

B 5204 T

 1 12/1995-03/2000 1984 155 211 1
2.0 Turbo

B 5204 T3

 1 11/1996-12/2000 1984 166 226 1
2.0 Turbo AWD

B 5204 T3

 1 11/1996-12/2000 1984 166 226 3
2.3

B 5234 T3

 1 11/1996-11/2000 2319 177 241 1
2.3 AWD

B 5234 T3

 1 04/1997-09/1998 2319 177 241 3
2.3 AWD

B 5234 T7

B 5234 T8

 1 12/1998-02/2000 2319 195 265 3
2.3 T AWD

B 5234 T4

 1 04/1997-03/2000 2319 184 250 3
2.3 T-5

B 5234 T3

 1 11/1996-12/2000 2319 176 239 1
2.3 T-5 AWD

B 5234 T3

 1 01/1997-12/2000 2319 176 239 3
2.3 Turbo

B 5234 T4

 1 12/1995-03/2000 2319 184 250 1
2.4

B 5244 S2

B 5244 SG2

 1 03/1999-12/2000 2435 103 140 1
2.4

B 5252 FS

 1 12/1995-03/2000 2435 106 144 1
2.4

B 5254 S

 1 06/1998-12/1999 2435 121 165 1
2.4

B 5244 S

B 5254 FS

B 5254 S

 1 12/1995-05/2000 2435 125 170 1
2.4 AWD

B 5254 S

 1 06/1998-12/1999 2435 121 165 3
2.4 Turbo

B 5244 T

B 5254 T

 1 04/1996-12/2000 2435 142 193 1
2.4 Turbo 1 05/1999-02/2000 2435 195 265 1
2.4 Turbo AWD

B 5244 T

B 5254 T

 1 04/1996-12/2000 2435 142 193 3
2.4 Turbo AWD

B 5244 T2

 1 03/1999-12/2000 2435 195 265 3
2.4 Bifuel

B 5244 SG

 16 08/1999-12/2000 2435 103 140 1
2.4 Bifuel

GB 5252 S

 16 05/1998-12/1999 2435 106 144 1
2.5 TDI

D 5252 T

 2 12/1995-12/2000 2460 103 140 1
2.5 TDi AWD

D 5252 T

 2 11/1996-02/2000 2460 103 140 3
V90 (965) Estate 11/1996-12/1998
Vehicle Engine Fuel Date CC KW CV Traction
2.5

B 6254 FS

 1 11/1996-10/1998 2473 125 170 2
2.5

B 6244 FS

 1 11/1996-10/1997 2473 132 179 2
2.9

B 6304 S2

 1 01/1997-12/1998 2922 132 180 2
2.9

B 6304 FS

B 6304 GS

 1 01/1997-12/1998 2922 150 204 2
XC70 CROSS COUNTRY / V70 XC (295) Estate 10/1997-10/2007
Vehicle Engine Fuel Date CC KW CV Traction
T5 AWD

B 5204 T3

 1 10/1997-03/1999 1984 166 226 3
