Product 78BD2232-2

Description
Brake disc
Axe
Front
No. of Pieces
2
Barcode
EAN13 Code
8424073143730
QR Code
Url
https://catalogonuevo.icerbrakes.com/Producto/Details?idProducto=78BD2232-2
Weight (gr.)
11632
R90 Homologation
R90 90R-02C0452/0119
Measures
Ø262x22x44
Brake Disc Type: Vented
Minimum thickness [mm]: 19.8
Hole Arrangement/Number: 4
Bolt Hole Circle Ø [mm]: 100
Wheel Hub Diameter [mm]: 61
Reference applications
Brand OE Reference
RENAULT 77 00 802 232
RENAULT 77 00 841 563
RENAULT 77 01 204 300
RENAULT 77 01 204 495
RENAULT 77 01 204 499
RENAULT 77 01 205 085
RENAULT 77 01 205 228
RENAULT 77 01 205 840
Maker Cross reference
ATE 24.0122-0148.1
BOSCH 0 986 478 598
BREMBO 09.7292.30
BREMBO 09.7292.34
DELPHI LOCKHEED BG2693
FERODO DDF1124
LETEC LBR718V
NECTO WN926
ROAD HOUSE 6227.10
SANLI SL31865
TRW DF1032
RENAULT
LAGUNA I (B56_, 556_) Hatchback 11/1993-08/2002
Vehicle Engine Fuel Date CC KW CV Traction
1.8

F3P 674

 1 06/1995-02/2001 1794 69 94 1
1.8

F3P 676

 1 06/1995-06/1998 1794 70 95 1
1.8 (B56A/B)

F3P 720

F3P 724

 1 11/1993-03/2001 1794 66 90 1
1.8 (B56S/T/0)

F3P 670

F3P 678

 1 08/1995-03/2001 1794 66 90 1
1.8 (B56Z)

F3P 720

F3P 724

 1 08/1995-03/2001 1794 69 94 1
1.8 i 1 07/1995-04/1998 1783 92 125 1
2.0 1 11/1993-03/2001 1994 70 95 1
2.0

F3R 611

 1 03/1999-03/2001 1998 80 109 1
2.0

F3R 722

F3R 768

 1 06/1995-02/2001 1998 84 114 1
2.0 (B56C/H/N)

F3R 722

F3R 723

 1 11/1993-03/2001 1998 83 113 1
2.2 D (B56F/2)

G8T 706

G8T 752

G8T 790

G8T 794

 2 11/1993-03/2001 2188 61 83 1
LAGUNA I Grandtour (K56_) Estate 09/1995-08/2002
Vehicle Engine Fuel Date CC KW CV Traction
1.8 (K56S/T/0)

F3P 670

F3P 678

 1 09/1995-03/2001 1794 66 90 1
1.8 (K56Z)

F3P 678

F3P 720

F3P 724

 1 09/1995-03/2001 1794 69 94 1
1.8 16V (K563, K564)

F4P 760

 1 04/1998-03/2001 1783 88 120 1
2.0

F3R 728

F3R 768

 1 10/1998-01/2001 1998 84 114 1
2.0 (K56C/H)

F3R 722

F3R 723

 1 09/1995-03/2001 1998 83 113 1
2.2 D (K56F/2, S56F)

G8T 706

G8T 752

G8T 790

G8T 794

 2 09/1995-03/2001 2188 61 83 1
2.2 dT (K569)

G8T 760

 2 03/1996-03/2001 2188 83 113 1
MEGANE (BA0/1_) Hatchback 08/1995-12/2004
Vehicle Engine Fuel Date CC KW CV Traction
1.6 16V 1 11/2001-12/2004 1598 81 110 1
1.6 16V (BA04, BA0B, BA11, BA1J, BA16, BA19, BA1K, BA1V,...

K4M 700

K4M 701

K4M 706

K4M 708

K4M 709

 1 03/1999-08/2002 1598 79 107 1
2.0 16V (BA0H)

F7R 710

F7R 714

 1 07/1996-08/2003 1998 108 147 1
MEGANE Coach (DA0/1_) Coupe 03/1996-08/2003
Vehicle Engine Fuel Date CC KW CV Traction
1.6 16V (DA0B, DA04, DA11)

K4M 700

K4M 701

K4M 708

K4M 709

 1 03/1999-07/2003 1598 79 107 1
2.0 16V

F4R 746

 1 01/2002-08/2003 1998 102 139 1
2.0 16V (DA0H)

F7R 710

F7R 714

 1 03/1996-11/1999 1998 108 147 1
2.0 16V IDE (DA03, DA0P, DA14)

F5R 740

 1 11/1999-08/2003 1998 103 140 1
2.0 i

F3R 791

F3R 796

 1 03/1999-08/2003 1998 80 109 1
MEGANE Classic (LA0/1_) Saloon 09/1996-08/2008
Vehicle Engine Fuel Date CC KW CV Traction
1.6 16V 1 09/1999-12/2001 1598 81 110 1
1.6 16V (LA00, LA04, LA0B, LA11, LA16, LA19, LA1J, LA1K,...

K4M 700

K4M 701

K4M 706

K4M 708

K4M 709

 1 03/1999-07/2003 1598 79 107 1
MEGANE (EA0/1_) Convertible 10/1996-08/2003
Vehicle Engine Fuel Date CC KW CV Traction
1.6 16V (EA04, EA0B, EA11, EA1J)

K4M 700

K4M 701

K4M 708

K4M 709

 1 03/1999-07/2003 1598 79 107 1
2.0 16V (EA0H)

F7R 710

F7R 714

 1 10/1996-11/1999 1998 108 147 1
MEGANE Scenic (JA0/1_) MPV 10/1996-12/2001
Vehicle Engine Fuel Date CC KW CV Traction
1.6 e (JA0F)

K7M 702

K7M 703

 1 10/1996-10/1999 1598 66 90 1
1.6 i (JA0L)

K7M 720

 1 01/1997-09/1999 1598 55 75 1
2.0 i (JA0G)

F3R 750

F3R 751

 1 01/1997-09/1999 1998 84 114 1
2.0 RXE 4x4

F3R 750

 1 05/1997-10/1999 1998 84 114 3
1.9 D (JA0J)

F8Q 790

 2 03/1997-09/1999 1870 47 64 1
1.9 dT (JA0K, JA0Y)

F8Q 784

F8Q 786

 2 01/1997-09/1999 1870 66 90 1
1.9 dT (JA0Y)

F8Q 784

 2 03/1997-08/1999 1870 69 94 1
1.9 dTi (JA0N)

F9Q 730

F9Q 734

 2 04/1997-09/1999 1870 72 98 1
MEGANE Scenic VAN (JA0/1_) Box Body/MPV 10/1996-12/2001
Vehicle Engine Fuel Date CC KW CV Traction
1.9 DT (JA0K) 2 01/1997-09/1999 1870 66 90 1
1.9 dTi (JA0N) 2 04/1997-09/1999 1870 72 98 1
MEGANE Grandtour (KA0/1_) Estate 03/1999-08/2003
Vehicle Engine Fuel Date CC KW CV Traction
1.4 16V (KA0D, KA1H, KA0W, KA10)

K4J 714

K4J 750

 1 03/1999-08/2003 1390 70 95 1
1.4 e (KA0V)

E7J 626

 1 03/1999-08/2003 1390 55 75 1
1.6 16V (KA0B, KA04, KA11)

K4M 700

K4M 701

K4M 708

K4M 709

 1 03/1999-08/2003 1598 79 107 1
1.6 BiFuel 1 04/2001-07/2003 1598 79 107 1
1.6 e (KA0F)

K7M 702

K7M 703

 1 03/1999-08/2003 1598 66 90 1
1.9 dTi (KA0N)

F9Q 731

F9Q 736

 2 03/1999-02/2001 1870 72 98 1
MEGANE Kombi van (KA_) Estate Van 02/2000-07/2003
Vehicle Engine Fuel Date CC KW CV Traction
1.4 (KA0D)

K4J 714

K4J 750

 1 04/2001-07/2003 1390 70 95 1
1.6 (KA0B, KA04)

K4M 700

K4M 701

K4M 708

K4M 709

 1 04/2001-07/2003 1598 79 107 1
1.6 BiFuel (KA04)

K4M 704

 18 04/2001-07/2003 1598 80 109 1
1.6 BiFuel (KA0B)

K4M 712

 18 04/2001-07/2003 1598 79 107 1
SAFRANE (B54_) Hatchback 04/1992-10/1997
Vehicle Engine Fuel Date CC KW CV Traction
2.0 (B540)

J7R 732

J7R 733

 1 11/1992-07/1996 1995 77 105 1
2.0 12V (B542, B54E)

J7R 734

J7R 735

 1 04/1992-07/1996 1995 97 132 1
2.2 (B541)

J7T 762

 1 04/1992-07/1996 2165 79 107 1
2.2 (B543)

J7T 760

J7T 761

 1 04/1992-07/1996 2165 101 137 1
2.1 dT (B546)

J8S 760

 2 11/1993-07/1996 2068 65 88 1
