Product 78BD2235-2
- Description
- Brake disc
- Axe
- Front
- No. of Pieces
- 2
- Barcode
-
8424073143761
- Url
- https://catalogonuevo.icerbrakes.com/Producto/Details?idProducto=78BD2235-2
- Weight (gr.)
- 17800
- R90 Homologation
-
90R-02C0433/0097
- Measures
- Ø300x26x47
-
Brake Disc Type:
Vented -
Minimum thickness [mm]:
22.8 -
Hole Arrangement/Number:
5 -
Bolt Hole Circle Ø [mm]:
105 -
Wheel Hub Diameter [mm]:
61
| Brand | OE Reference |
|---|---|
| RENAULT | 77 01 20 6614 |
| RENAULT | 82 00 007 122 |
| Maker | Cross reference |
|---|---|
| ATE | 24.0126-0123.1 |
| BOSCH | 0 986 478 743 |
| BREMBO | 09.9074.10 |
| DELPHI LOCKHEED | BG3688 |
| LETEC | LBR711V |
| NECTO | WN1226 |
| ROAD HOUSE | 6612.10 |
| SANLI | SL32315 |
| TRW | DF4229S |
| Vehicle | Engine | Fuel | Date | CC | KW | CV | Traction |
|---|---|---|---|---|---|---|---|
| 1.6 16V (B568, B561) |
K4M 720 K4M 724 |
1 | 11/1997-03/2001 | 1598 | 79 | 107 | 1 |
| 1.8 |
F3P 674 |
1 | 06/1995-02/2001 | 1794 | 69 | 94 | 1 |
| 1.8 (B56A/B) |
F3P 720 F3P 724 |
1 | 11/1993-03/2001 | 1794 | 66 | 90 | 1 |
| 1.8 (B56S/T/0) |
F3P 670 F3P 678 |
1 | 08/1995-03/2001 | 1794 | 66 | 90 | 1 |
| 1.8 (B56Z) |
F3P 720 F3P 724 |
1 | 08/1995-03/2001 | 1794 | 69 | 94 | 1 |
| 1.8 16V (B563, B564) |
F4P 760 F4P 770 |
1 | 04/1998-03/2001 | 1783 | 88 | 120 | 1 |
| Vehicle | Engine | Fuel | Date | CC | KW | CV | Traction |
|---|---|---|---|---|---|---|---|
| 1.6 16V (K568) |
K4M 720 K4M 724 |
1 | 11/1997-03/2001 | 1598 | 79 | 107 | 1 |
| 1.8 (K56S/T/0) |
F3P 670 F3P 678 |
1 | 09/1995-03/2001 | 1794 | 66 | 90 | 1 |
| 1.8 (K56Z) |
F3P 678 F3P 720 F3P 724 |
1 | 09/1995-03/2001 | 1794 | 69 | 94 | 1 |
| 1.8 16V (K563, K564) |
F4P 760 |
1 | 04/1998-03/2001 | 1783 | 88 | 120 | 1 |
| 2.0 16V (A56A/B) |
F4R 780 |
1 | 09/1999-03/2001 | 1998 | 103 | 140 | 1 |
| 2.0 16V (K56D, K56M) |
N7Q 700 N7Q 704 |
1 | 09/1995-03/2001 | 1948 | 102 | 139 | 1 |
| Vehicle | Engine | Fuel | Date | CC | KW | CV | Traction |
|---|---|---|---|---|---|---|---|
| 1.6 |
K4M 710 |
1 | 03/2001-05/2005 | 1598 | 76 | 103 | 1 |
| 1.6 16V (BG0A, BG0L) |
K4M 710 K4M 714 |
1 | 03/2001-05/2005 | 1598 | 79 | 107 | 1 |
| 1.6 16V (BG1G, BG1H) |
K4M 716 |
1 | 02/2005-08/2007 | 1598 | 82 | 112 | 1 |
| 1.8 16V (BG04, BG0B, BG0C, BG0V) |
F4P 770 F4P 774 |
1 | 03/2001-05/2005 | 1783 | 86 | 117 | 1 |
| 1.8 16V (BG06, BG0J, BG0M) |
F4P 770 F4P 771 F4P 773 F4P 774 F4P 775 |
1 | 03/2001-12/2007 | 1783 | 85 | 116 | 1 |
| 1.8 16V (BG0B, BG0C, BG0J, BG0M, BG0V) |
F4P 770 F4P 772 |
1 | 03/2001-05/2005 | 1783 | 89 | 121 | 1 |
| 1.8 16V (BG0B, BG0M) |
F4P 770 F4P 773 |
1 | 03/2001-09/2007 | 1783 | 88 | 120 | 1 |
| 2.0 16V (BG00, BG0K, BG0P, BG0W) |
F4R 712 F4R 713 F4R 714 F4R 715 |
1 | 08/2002-12/2007 | 1998 | 99 | 135 | 1 |
| 2.0 16V (BG00, BG0W, BG0K, BG0P) |
F4R 712 F4R 713 F4R 714 F4R 715 |
1 | 08/2002-12/2006 | 1998 | 98 | 133 | 1 |
| 2.0 16V (BG03, BG0Z, BG0T, BG1Y) |
F4R 784 F4R 786 F4R 787 |
1 | 01/2005-09/2007 | 1998 | 125 | 170 | 1 |
| 2.0 16V IDE (BG0N) |
F5R 700 F5R 701 |
1 | 04/2001-09/2007 | 1998 | 103 | 140 | 1 |
| 1.6 LPG |
K4M 714 |
18 | 03/2001-05/2005 | 1598 | 79 | 107 | 1 |
| 1.9 dCi |
F9Q 718 F9Q 754 |
2 | 03/2001-09/2007 | 1870 | 79 | 107 | 1 |
| 1.9 dCi |
F9Q 750 |
2 | 09/2005-12/2007 | 1870 | 92 | 125 | 1 |
| 1.9 dCi (BG05) |
F9Q 664 |
2 | 03/2004-05/2005 | 1870 | 68 | 92 | 1 |
| 1.9 dCi (BG08, BG0G) |
F9Q 650 F9Q 670 F9Q 674 F9Q 750 |
2 | 03/2001-09/2007 | 1870 | 88 | 120 | 1 |
| 1.9 dCI (BG0E) |
F9Q 752 |
2 | 06/2001-05/2005 | 1870 | 77 | 105 | 1 |
| 1.9 dCi (BG0R, BG0E) |
F9Q 754 |
2 | 10/2001-05/2005 | 1870 | 74 | 100 | 1 |
| 1.9 dCi (BG12) |
F9Q 750 F9Q 758 F9Q 759 |
2 | 09/2005-12/2007 | 1870 | 85 | 116 | 1 |
| 1.9 dCi (BG1A, BG1V) |
F9Q 758 F9Q 759 |
2 | 05/2005-08/2007 | 1870 | 96 | 130 | 1 |
| 1.9 dCi (BG1A, BG1W, BG0G) |
F9Q 674 F9Q 758 |
2 | 01/2005-08/2007 | 1870 | 81 | 110 | 1 |
| 2.0 dCi (BG14, BG1S) |
M9R 760 |
2 | 01/2006-08/2007 | 1995 | 127 | 173 | 1 |
| 2.0 dCi (BG1T) |
M9R 740 |
2 | 08/2005-08/2006 | 1995 | 110 | 150 | 1 |
| 2.2 dCi |
G9T 600 G9T 605 G9T 706 G9T 707 |
2 | 05/2005-08/2007 | 2188 | 102 | 140 | 1 |
| 2.2 dCi (BG0F) |
G9T 700 G9T 702 |
2 | 10/2001-08/2006 | 2188 | 110 | 150 | 1 |
| Vehicle | Engine | Fuel | Date | CC | KW | CV | Traction |
|---|---|---|---|---|---|---|---|
| 1.6 |
K4M 710 |
1 | 03/2001-10/2005 | 1598 | 76 | 103 | 1 |
| 1.6 16V |
K4M 716 |
1 | 02/2005-08/2007 | 1598 | 82 | 112 | 1 |
| 1.6 16V (KG0A, KG0L) |
K4M 710 K4M 714 |
1 | 03/2001-12/2007 | 1598 | 79 | 107 | 1 |
| 1.8 16V |
F4P 770 |
1 | 03/2001-05/2005 | 1783 | 86 | 117 | 1 |
| 1.8 16V |
F4P 770 F4P 774 |
1 | 03/2001-05/2005 | 1783 | 89 | 121 | 1 |
| 1.8 16V (KG0B, KG0M) |
F4P 770 F4P 773 |
1 | 03/2001-05/2005 | 1783 | 88 | 120 | 1 |
| 1.8 16V (KG0J) |
F4P 770 F4P 771 F4P 774 F4P 775 |
1 | 03/2001-05/2005 | 1783 | 85 | 116 | 1 |
| 2.0 16V (KG00, KG0K, KG0W, KG0P) |
F4R 712 F4R 713 F4R 714 F4R 715 |
1 | 10/2004-09/2007 | 1998 | 98 | 133 | 1 |
| 2.0 16V (KG00, KG0K, KG0W, KG0P) |
F4R 712 F4R 713 F4R 714 F4R 715 |
1 | 08/2002-12/2007 | 1998 | 99 | 135 | 1 |
| 2.0 16V (KG03, KG0Z, KG0T, KG1Y) |
F4R 784 F4R 786 F4R 787 |
1 | 01/2005-09/2007 | 1998 | 125 | 170 | 1 |
| 2.0 16V IDE (KG0N) |
F5R 700 F5R 701 |
1 | 04/2001-09/2007 | 1998 | 103 | 140 | 1 |
| 1.6 BiFuel |
K4M 714 |
18 | 06/2005-12/2007 | 1598 | 79 | 107 | 1 |
| 1.9 dCi |
F9Q 664 |
2 | 08/2003-09/2007 | 1870 | 66 | 90 | 1 |
| 1.9 dCi |
F9Q 754 |
2 | 03/2001-12/2007 | 1870 | 79 | 107 | 1 |
| 1.9 dCi |
F9Q 750 |
2 | 09/2005-12/2007 | 1870 | 92 | 125 | 1 |
| 1.9 dCi (KG05) |
F9Q 664 |
2 | 03/2004-05/2005 | 1870 | 68 | 92 | 1 |
| 1.9 dCi (KG0E, KG0R) |
F9Q 752 |
2 | 10/2001-05/2005 | 1870 | 74 | 100 | 1 |
| 1.9 dCI (KG0E) |
F9Q 752 |
2 | 06/2001-05/2005 | 1870 | 77 | 105 | 1 |
| 1.9 dCi (KG0G) |
F9Q 670 F9Q 674 F9Q 750 |
2 | 03/2001-09/2007 | 1870 | 88 | 120 | 1 |
| 1.9 dCi (KG12) |
F9Q 758 F9Q 759 |
2 | 08/2005-09/2007 | 1870 | 85 | 116 | 1 |
| 1.9 dCi (KG1A, KG1W, KG0G) |
F9Q 674 F9Q 758 |
2 | 01/2005-12/2007 | 1870 | 81 | 110 | 1 |
| 1.9 dCi (KG1V) |
F9Q 758 F9Q 759 |
2 | 05/2005-12/2007 | 1870 | 96 | 130 | 1 |
| 2.0 dCi (KG1T) |
M9R 740 |
2 | 08/2005-08/2006 | 1995 | 110 | 150 | 1 |
| 2.2 dCi (KG09) |
G9T 600 |
2 | 04/2004-10/2005 | 2188 | 85 | 116 | 1 |
| 2.2 dCi (KG0F, KG1N) |
G9T 600 G9T 706 G9T 707 |
2 | 05/2005-12/2007 | 2188 | 102 | 140 | 1 |
| 2.2 dCi (KG0F) |
G9T 702 |
2 | 10/2001-08/2006 | 2188 | 110 | 150 | 1 |
