Product 78BD2317-2
- Description
- Brake disc
- Axe
- Front
- No. of Pieces
- 2
- Barcode
-
8424073143822
- Url
- https://catalogonuevo.icerbrakes.com/Producto/Details?idProducto=78BD2317-2
- Weight (gr.)
- 19688
- R90 Homologation
-
90R-02C0433/0076
- Measures
- Ø307x28x47
-
Brake Disc Type:
Vented -
Minimum thickness [mm]:
25.4 -
Hole Arrangement/Number:
5 -
Bolt Hole Circle Ø [mm]:
108 -
Wheel Hub Diameter [mm]:
61
| Brand | OE Reference |
|---|---|
| RENAULT | 77 01 207 378 |
| RENAULT | 82 00 242 317 |
| RENAULT | 82 00 570 677 |
| Maker | Cross reference |
|---|---|
| ATE | 24.0128-0135.1 |
| BOSCH | 0 986 479 199 |
| DELPHI LOCKHEED | BG9016 |
| FERODO | DDF1368 |
| LETEC | LBR754V |
| SANLI | SL37090 |
| TRW | DF4260S |
| Vehicle | Engine | Fuel | Date | CC | KW | CV | Traction |
|---|---|---|---|---|---|---|---|
| 2.0 (JK09) |
F4R 792 |
1 | 11/2002-01/2015 | 1998 | 100 | 136 | 1 |
| 2.0 (JK0A, JK1D, JK0N) |
F4R 796 F4R 797 F4R 896 F4R 897 |
1 | 04/2005- | 1998 | 125 | 170 | 1 |
| 2.0 (JK0K) |
F4R 790 |
1 | 11/2002-12/2015 | 1998 | 98 | 133 | 1 |
| 1.9 dCi (JK0U, JK0G) |
F9Q 680 F9Q 820 F9Q 826 |
2 | 11/2002- | 1870 | 88 | 120 | 1 |
| 1.9 dCi (JK0U) |
F9Q 820 |
2 | 04/2003-02/2005 | 1870 | 85 | 116 | 1 |
| 2.0 dCi (JK02, JK03) |
M9R 740 M9R 750 M9R 760 M9R 761 M9R 762 M9R 763 |
2 | 01/2006- | 1995 | 96 | 131 | 1 |
| Vehicle | Engine | Fuel | Date | CC | KW | CV | Traction |
|---|---|---|---|---|---|---|---|
| 2.0 16V (BG1Y) |
F4R 886 F4R 887 |
1 | 01/2005-09/2007 | 1998 | 150 | 204 | 1 |
| 2.0 16V Turbo (BG0S, BG1L, BG1M) |
F4R 764 F4R 765 |
1 | 01/2003-03/2005 | 1998 | 120 | 163 | 1 |
| 2.9 V6 24V | 1 | 03/2001-08/2007 | 2946 | 155 | 211 | 1 | |
| 2.9 V6 24V | 1 | 09/2002-12/2005 | 2946 | 157 | 210 | 1 | |
| 3.0 V6 24V (BG01, BG02, BG0D, BG0Y) |
L7X 731 |
1 | 03/2001-08/2007 | 2946 | 152 | 207 | 1 |
| 2.2 dCi |
G9T 600 G9T 605 G9T 706 G9T 707 |
2 | 05/2005-08/2007 | 2188 | 102 | 140 | 1 |
| 2.2 dCi (BG09) |
G9T 600 |
2 | 04/2004-10/2005 | 2188 | 85 | 116 | 1 |
| 2.2 dCi (BG0F) |
G9T 700 G9T 702 |
2 | 10/2001-08/2006 | 2188 | 110 | 150 | 1 |
| Vehicle | Engine | Fuel | Date | CC | KW | CV | Traction |
|---|---|---|---|---|---|---|---|
| 2.0 16V (KG03, KG0Z, KG0T, KG1Y) |
F4R 784 F4R 786 F4R 787 |
1 | 01/2005-09/2007 | 1998 | 125 | 170 | 1 |
| 2.0 16V (KG1Y) |
F4R 886 F4R 887 |
1 | 01/2005-09/2007 | 1998 | 150 | 204 | 1 |
| 2.0 16V Turbo (KG0S, KG1L, KG03) |
F4R 764 F4R 765 |
1 | 01/2003-08/2005 | 1998 | 120 | 163 | 1 |
| 2.9 V6 24V | 1 | 09/2002-12/2005 | 2946 | 157 | 210 | 1 | |
| 3.0 V6 24V (KG0D, KG01) |
L7X 731 |
1 | 03/2001-12/2007 | 2946 | 152 | 207 | 1 |
| 2.0 dCi (KG1S) |
M9R 760 |
2 | 01/2006-12/2007 | 1995 | 127 | 173 | 1 |
