Product 78BD2376-2

Description
Brake disc
Axe
Front
No. of Pieces
2
Barcode
EAN13 Code
8424073143839
QR Code
Url
https://catalogonuevo.icerbrakes.com/Producto/Details?idProducto=78BD2376-2
Weight (gr.)
10176
R90 Homologation
R90 90R-02C0452/0077
Measures
Ø257x22x36
Brake Disc Type: Vented
Minimum thickness [mm]: 20.6
Hole Arrangement/Number: 6
Bolt Hole Circle Ø [mm]: 109
Wheel Hub Diameter [mm]: 88
Reference applications
Brand OE Reference
BEDFORD 53707
BEDFORD 8943619270
ISUZU 8-94172-376-1
ISUZU 8-94361-927-0
ISUZU 8-94361-927-1
ISUZU 8-94372-435-0
ISUZU 9-41723-76
OPEL 5 69 801
OPEL 5 96 210
OPEL 89 436 192 70
VAUXHALL 89 43 619 270
VAUXHALL 94 172 376
Maker Cross reference
ATE 24.0122-0156.1
BOSCH 0 986 478 596
BREMBO 09.5577.10
HELLA-PAGID 8DD 355 134-071
LETEC LBG017V
ROAD HOUSE 6188.10
SANLI SL32075
TRW DF3049
BEDFORD
BRAVA () Pickup 12/1988-07/1990
Vehicle Engine Fuel Date CC KW CV Traction
2.2 D

C223

 2 12/1988-02/1990 2238 39 53 2
2.2 D 4WD

C223

 2 12/1988-02/1990 2238 39 53 3
2.5 D

4JA1

 2 02/1990-07/1990 2499 56 76 2
2.5 D 4WD

4JA1

 2 02/1990-07/1990 2499 56 76 3
ISUZU
CAMPO / FASTER (KB) Pickup 04/1977-12/1991
Vehicle Engine Fuel Date CC KW CV Traction
2.2 (TFS)

4ZD1

 1 01/1989-12/1990 2254 66 90 2
2.2 4WD 1 04/1988-12/1988 2254 66 90 3
2.2 D (KBD27)

C223

 2 04/1986-12/1990 2238 39 53 2
2.2 D (KBD27)

C223

 2 01/1983-12/1991 2238 45 61 2
2.2 D 4WD (KBD42, KBD47)

C223

 2 01/1983-12/1990 2238 39 53 3
2.5 D (KB27)

4JA1

 2 01/1983-12/1990 2499 55 75 2
2.5 D 4WD (KBD47)

4JA1

 2 01/1983-12/1990 2499 55 75 3
D-MAX / RODEO (TFR, TFS) Pickup 05/2002-12/2012
Vehicle Engine Fuel Date CC KW CV Traction
2.5 DiTD (TFR86_, TFR54_)

4JA1-TC

 2 10/2002-06/2012 2499 74 101 2
3.0 D 4WD (TFS77H)

4JH1-T

 2 06/2003-10/2004 2999 88 120 3
3.0 DiTD 4x4 2 06/2003-12/2012 2999 100 136 3
3.0 DiTD 4x4 (TFS77H)

4JH1-TC

 2 05/2002-06/2012 2999 96 131 3
GEMINI II (JT) Saloon 09/1984-06/1990
Vehicle Engine Fuel Date CC KW CV Traction
1.5

4XC1U KAT.

 1 02/1988-12/1989 1471 52 71 1
1.6

4XE1

 1 09/1988-12/1989 1588 93 126 1
1.5 D

4EC1

 2 02/1988-12/1989 1488 37 50 1
1.5 TD

4EC1T

 2 02/1988-12/1989 1488 49 67 1
GEMINI II (JT) Hatchback 10/1984-12/1990
Vehicle Engine Fuel Date CC KW CV Traction
1.5

4XC1U KAT.

 1 02/1988-12/1990 1471 52 71 1
1.5

4XC1UT

 1 02/1988-06/1990 1471 88 120 1
1.6 GTI 16V

4XE1

 1 08/1988-12/1990 1588 84 114 1
1.6 GTI 16V

4XE1

 1 03/1988-06/1990 1588 92 125 1
1.5 D

4EC1

 2 02/1988-12/1990 1488 37 50 1
1.5 TD

4EC1T

 2 02/1988-12/1990 1488 49 67 1
GEMINI III () Hatchback 01/1990-12/1993
Vehicle Engine Fuel Date CC KW CV Traction
1.5

4XC1

 1 01/1990-12/1993 1471 73 99 1
1.6

4XE1-WU

 1 01/1990-12/1993 1588 97 132 1
1.6

4XE1-WUT

 1 01/1990-12/1993 1588 132 180 3
1.8

4XF1

 1 01/1990-12/1993 1809 105 143 1
1.7 TD

4EE1

 2 01/1990-12/1993 1686 65 88 1
GEMINI III () Saloon 01/1990-12/1993
Vehicle Engine Fuel Date CC KW CV Traction
1.5 i

4XC1

 1 01/1990-12/1993 1471 73 99 1
1.6 i

4XE1-V

 1 01/1990-12/1993 1588 71 96 1
1.6 i

4XE1-WU

 1 01/1990-12/1993 1588 97 132 1
1.6 i Turbo

4XE1-WUT

 1 01/1990-12/1993 1588 132 180 3
1.8

4XF1

 1 01/1990-12/1993 1809 105 143 1
1.7 TD

4EE1

 2 01/1990-12/1993 1686 65 88 1
KB III () Pickup 05/1988-08/2004
Vehicle Engine Fuel Date CC KW CV Traction
2.3

4ZD1

 1 12/1990-09/2003 2254 64 87 2
2.3

4ZD1

 1 12/1990-10/1995 2254 66 90 2
2.3 4WD

4ZD1

 1 12/1990-04/2000 2254 64 87 3
2.5 TDI

4JA1T

 2 12/1990-04/2000 2499 66 90 2
2.8 TD

4JB1-TC

 2 12/1990-09/2003 2771 78 106 2
2.8 TD 4WD

4JB1-TC

 2 12/1990-04/2000 2771 78 106 3
3.1 TD

4JG2

 2 12/1994-04/2000 3059 72 98 2
3.1 TD 4WD

4JG2

 2 12/1994-09/2003 3059 72 98 3
MU / CAMEO (_U_) Closed Off-Road Vehicle 02/1989-08/2002
Vehicle Engine Fuel Date CC KW CV Traction
3.0 D 4x4 (UES73EW)

4JX1-TC

 2 06/1998-08/2002 2999 107 146 3
3.1 TD 4x4 (UCS69) 2 08/1993-05/1998 3059 88 120 3
3.2 2 06/1998-08/2002 3165 158 215 2
PICK UP (TF) Pickup 07/1996-
Vehicle Engine Fuel Date CC KW CV Traction
2.8 TD (TFR55) 2 07/1999-08/2004 2771 74 101 2
TF / SPACECAB () Pickup 10/1997-09/2003
Vehicle Engine Fuel Date CC KW CV Traction
2.8 TD

4JB1-T

 2 05/2000-09/2003 2771 78 106 2
TFR-TFS / KB (TF_) Pickup 09/1988-12/2002
Vehicle Engine Fuel Date CC KW CV Traction
2.3

F23A7

 1 09/1994-08/1999 2254 110 150 2
2.3 (TFR16H)

4ZD1

 1 10/1992-08/1993 2254 66 90 2
2.5 TD 4WD

4JA1T

 2 09/1988-08/1991 2499 86 117 3
TROOPER / BIGHORN (UBS) Closed Off-Road Vehicle 01/1983-12/1991
Vehicle Engine Fuel Date CC KW CV Traction
1.9 1 07/1983-10/1986 1949 58 79 2
2.3 4WD

4ZD1

 1 09/1984-12/1991 2254 66 90 3
2.6 4WD

4ZE1

 1 11/1986-07/1991 2559 85 116 3
2.6 CLS Plane 1 11/1986-07/1991 2559 66 90 1
2.2 D 2 01/1983-12/1983 2238 45 61 2
2.2 D 4WD

C223

 2 05/1984-12/1989 2238 39 53 3
2.2 TD 4WD 2 03/1984-12/1991 2238 53 72 3
2.8 TD

4JB1-T

 2 10/1987-12/1991 2771 74 101 3
2.8 TD (UBS55)

4JB1-T

 2 10/1987-12/1991 2771 71 97 3
2.8 TD (UBS55)

4JB1-TC

 2 10/1988-12/1991 2771 78 106 3
2.8 TD 4WD 2 11/1986-07/1991 2771 81 110 3
TROOPER / BIGHORN (UBS) Open Off-Road Vehicle 01/1983-12/1991
Vehicle Engine Fuel Date CC KW CV Traction
2.0 (UBS13)

G200Z

 1 01/1983-12/1985 1949 58 79 2
2.3 (UBS16)

4ZD1

 1 11/1985-12/1991 2254 66 90 3
2.6 CLS Plane 1 11/1986-07/1991 2559 66 90 1
2.6 i (UBS17)

4ZE1

 1 10/1987-12/1991 2559 85 116 3
2.2 D (UBS52)

C223-T

 2 01/1983-12/1983 2238 45 61 2
2.2 D 4x4

C223

 2 05/1984-07/1989 2238 39 53 3
2.2 TD (UBS52)

C223-T

 2 03/1984-12/1991 2238 53 72 3
2.8 TD 4x4 2 11/1986-07/1991 2771 81 110 3
OPEL
CAMPO (TF0, TF1) Pickup 08/1987-06/2002
Vehicle Engine Fuel Date CC KW CV Traction
2.3 (TFR16)

4 ZD1

 1 08/1991-08/1994 2254 69 94 2
2.3 (TFR16)

4 ZD1

 1 08/1994-09/1996 2254 72 98 2
2.3 4x4 (TFS16)

4 ZD1

 1 08/1991-08/1994 2254 69 94 3
2.3 4x4 (TFS16)

4 ZD1

 1 08/1994-09/1996 2254 72 98 3
2.2 D

4FD1

 2 09/1990-08/1992 2189 45 61 2
2.2 D (TFR52) 2 08/1991-09/1996 2238 39 53 2
2.2 D (TFR52)

C223

 2 08/1987-08/1990 2238 45 61 2
2.2 D 4x4

4FD1

 2 09/1990-08/1992 2189 45 61 3
2.2 D 4x4 (TFS52) 2 08/1991-09/1996 2238 39 53 3
2.2 D 4x4 (TFS52)

C223

 2 08/1987-08/1990 2238 45 61 3
2.5 D (TFR54)

4JA1

 2 08/1991-06/1994 2499 56 76 2
2.5 D 4x4 (TFS54)

4JA1

 2 08/1991-06/1994 2499 56 76 3
2.5 DTi

4JA1-TC

 2 07/2001-12/2001 2499 74 101 2
2.5 DTI 4x4

4JA1-TC

 2 07/2001-12/2001 2499 74 101 3
2.5 TD (TFR54)

4JA1-T

 2 07/1994-06/2001 2499 56 76 2
2.5 TD 4x4 (TFS54)

4JA1-T

 2 07/1994-06/2001 2499 56 76 3
3.1 TD (TFR69)

4 JG2T

 2 12/1992-06/2001 3059 80 109 2
3.1 TD 4x4 (TFS69)

4 JG2T

 2 12/1992-06/2001 3059 80 109 3
FRONTERA A Sport (U92) Open Off-Road Vehicle 03/1992-10/1998
Vehicle Engine Fuel Date CC KW CV Traction
2.0 i (52SUD2, 55SUD2)

C 20 NE

X 20 SE

 1 03/1992-10/1998 1998 85 115 3
VAUXHALL
BRAVA (TF0, TF1) Pickup 12/1988-12/2002
Vehicle Engine Fuel Date CC KW CV Traction
2.3 (TFR16)

4 ZD1

 1 08/1991-08/1994 2254 69 94 2
2.3 (TFR16)

23 P

 1 08/1994-09/1996 2254 72 98 2
2.3 4x4 (TFS16)

4 ZD1

 1 06/1990-08/1994 2254 69 94 3
2.3 4x4 (TFS16)

23 P

 1 08/1994-09/1996 2254 72 98 3
2.2 D 2 07/1990-09/1992 2189 45 61 2
2.2 D (TFR52) 2 12/1988-09/1996 2238 39 53 2
2.2 D 4x4 (TFS52) 2 12/1988-09/1996 2238 39 53 3
2.5 DTi

4JA1-T

 2 08/2001-12/2002 2499 74 101 2
2.5 DTI 4x4

4JA1-T

 2 08/2001-12/2002 2499 74 101 3
2.5 TD (TFR54)

4JA1-T

 2 08/1991-06/1994 2499 56 76 2
2.5 TD (TFR54)

4JA1-T

 2 07/1994-12/2002 2499 56 76 2
2.5 TD 4x4 (TFS54)

4JA1-T

 2 06/1990-06/1994 2499 56 76 3
2.5 TD 4x4 (TFS54)

4JA1-T

 2 07/1994-12/2002 2499 56 76 3
3.1 D 2 07/1991-07/2001 3059 80 108 2
FRONTERA Mk I (A) (U92) Closed Off-Road Vehicle 09/1991-10/1998
Vehicle Engine Fuel Date CC KW CV Traction
2.4 i

C 24 NE

 1 03/1992-10/1998 2410 92 125 3
2.3 TD

23 DTR

 2 09/1991-06/1998 2260 74 100 3
FRONTERA Mk I (A) Sport (U92) Open Off-Road Vehicle 03/1992-10/1998
Vehicle Engine Fuel Date CC KW CV Traction
2.0 i

C 20 NE

X 20 SE

 1 03/1992-10/1998 1998 85 115 3
