Product 78BD2592-2
- Description
- Brake disc
- Axe
- Front
- No. of Pieces
- 2
- Barcode
-
8424073143952
- Url
- https://catalogonuevo.icerbrakes.com/Producto/Details?idProducto=78BD2592-2
- Weight (gr.)
- 19920
- R90 Homologation
-
90R-02C0593/1548
- Measures
- Ø330x32x64.5
-
Brake Disc Type:
Vented -
Minimum thickness [mm]:
29.4 -
Hole Arrangement/Number:
5 -
Bolt Hole Circle Ø [mm]:
112 -
Wheel Hub Diameter [mm]:
67
| Brand | OE Reference |
|---|---|
| MERCEDES-BENZ | 230 421 05 12 |
| MERCEDES-BENZ | 230 421 08 12 |
| Maker | Cross reference |
|---|---|
| ATE | 24.0132-0153.1 |
| ATE | 432153 |
| BOSCH | 0 986 479 415 |
| BREMBO | 09.9825.10 |
| BREMBO | 09.9825.11 |
| DELPHI LOCKHEED | BG3883 |
| FERODO | DDF1458 |
| GIRLING | 6064335 |
| HELLA-PAGID | 8DD 355 109-461 |
| MINTEX | MDC1671 |
| ROAD HOUSE | 61142.10 |
| SANLI | SL34932X |
| TEXTAR | 92120203 |
| TEXTAR | 98200 1202 0 1 |
| TRW | DF6433S |
| Vehicle | Engine | Fuel | Date | CC | KW | CV | Traction |
|---|---|---|---|---|---|---|---|
| E 200 CGI | 1 | 11/2002-12/2008 | 1796 | 125 | 170 | 1 | |
| E 200 Kompressor (211.042) |
M 271.941 |
1 | 11/2002-12/2008 | 1796 | 120 | 163 | 2 |
| E 200 Kompressor (211.042) |
M 271.956 |
1 | 04/2006-12/2008 | 1796 | 135 | 184 | 2 |
| E 230 (211.052) |
M 272.922 |
1 | 09/2007-12/2008 | 2496 | 150 | 204 | 2 |
| E 240 (211.061) |
M 112.913 M 112.917 |
1 | 03/2002-12/2008 | 2597 | 130 | 177 | 2 |
| E 280 (211.054) |
M 272.943 |
1 | 03/2005-12/2008 | 2996 | 170 | 231 | 2 |
| E 350 (211.056) |
M 272.964 |
1 | 03/2005-12/2008 | 3498 | 200 | 272 | 2 |
| E 350 4-matic (211.087) |
M 272.972 |
1 | 03/2005-12/2008 | 3498 | 200 | 272 | 3 |
| E 350 CGI (211.057) |
M 272.985 |
1 | 09/2007-12/2008 | 3498 | 215 | 292 | 2 |
| E 500 (211.070) |
M 113.967 |
1 | 03/2002-12/2008 | 4966 | 225 | 306 | 2 |
| E 500 (211.072) |
M 273.960 |
1 | 04/2006-12/2008 | 5461 | 285 | 388 | 2 |
| E 500 4-matic (211.083) |
M 113.969 |
1 | 10/2003-12/2008 | 4966 | 225 | 306 | 3 |
| E 55 AMG Kompressor (211.076) |
M 113.990 |
1 | 10/2002-12/2008 | 5439 | 350 | 476 | 2 |
| E 200 NGT (211.042) |
M 271.941 |
16 | 03/2004-12/2008 | 1796 | 120 | 163 | 2 |
| E 200 CDI (211.004) |
OM 646.951 |
2 | 07/2002-12/2008 | 2148 | 75 | 102 | 2 |
| E 200 CDI (211.004) |
OM 646.951 |
2 | 07/2002-12/2008 | 2148 | 90 | 122 | 2 |
| E 200 CDI (211.007) |
OM 646.820 |
2 | 04/2006-12/2008 | 2148 | 100 | 136 | 2 |
| E 220 CDI |
OM 646.821 |
2 | 03/2003-12/2008 | 2149 | 120 | 163 | 2 |
| E 220 CDI (211.006) |
OM 646.961 |
2 | 03/2002-12/2008 | 2148 | 100 | 136 | 2 |
| E 220 CDI (211.006) |
OM 646.961 |
2 | 03/2002-12/2008 | 2148 | 110 | 150 | 2 |
| E 220 CDI (211.008) |
OM 646.821 |
2 | 04/2006-12/2008 | 2148 | 125 | 170 | 2 |
| E 270 CDI (211.016) |
OM 647.961 |
2 | 03/2002-12/2008 | 2685 | 130 | 177 | 2 |
| E 280 CDI (211.020) |
OM 642.920 |
2 | 03/2005-12/2008 | 2987 | 140 | 190 | 2 |
| E 280 CDI (211.023) |
OM 648.961 |
2 | 05/2004-12/2008 | 3222 | 130 | 177 | 2 |
| E 300 BlueTEC (211.024) |
OM 642.920 |
2 | 09/2007-12/2008 | 2987 | 155 | 211 | 2 |
| E 320 CDI (211.026) |
OM 648.961 |
2 | 11/2002-12/2008 | 3222 | 150 | 204 | 2 |
| E 320 CDI 4-matic (211.089) |
OM 642.910 OM 642.921 |
2 | 03/2005-12/2008 | 2987 | 165 | 224 | 3 |
| E320 CDI (211.022) |
OM 642.920 |
2 | 03/2005-12/2008 | 2987 | 165 | 224 | 2 |
| Vehicle | Engine | Fuel | Date | CC | KW | CV | Traction |
|---|---|---|---|---|---|---|---|
| 350 CGI (211.257) |
M 272.985 |
1 | 05/2006-07/2009 | 3498 | 215 | 292 | 2 |
| E 200 Kompressor (211.241) |
M 271.956 |
1 | 04/2006-07/2009 | 1796 | 135 | 184 | 2 |
| E 200 T Kompressor (211.242) |
M 271.941 |
1 | 03/2003-07/2009 | 1796 | 120 | 163 | 2 |
| E 230 T (211.252) |
M 272.922 |
1 | 05/2007-07/2009 | 2496 | 150 | 204 | 2 |
| E 240 T (211.261) |
M 112.913 |
1 | 03/2003-07/2009 | 2597 | 130 | 177 | 2 |
| E 280 T (211.254) |
M 272.943 |
1 | 03/2005-07/2009 | 2996 | 170 | 231 | 2 |
| E 280 T 4-matic (211.292) |
M 272.943 M 272.944 |
1 | 03/2005-07/2009 | 2996 | 170 | 231 | 3 |
| E 350 T (211.256) |
M 272.964 |
1 | 03/2005-07/2009 | 3498 | 200 | 272 | 2 |
| E 350 T 4-matic (211.287) |
M 272.972 |
1 | 03/2005-07/2009 | 3498 | 200 | 272 | 3 |
| E 500 T (211.270) |
M 113.967 |
1 | 10/2003-07/2009 | 4966 | 225 | 306 | 2 |
| E 500 T (211.272) |
M 273.960 |
1 | 04/2006-07/2009 | 5461 | 285 | 388 | 2 |
| E 55 T AMG Kompressor (211.276) |
M 113.990 |
1 | 07/2003-07/2009 | 5439 | 350 | 476 | 2 |
| E 200 CDI (211.207) |
OM 646.821 |
2 | 04/2006-07/2009 | 2148 | 100 | 136 | 2 |
| E 220 CDI (211.206) |
OM 646.961 |
2 | 03/2003-07/2009 | 2148 | 100 | 136 | 2 |
| E 220 T CDI |
OM 646.821 |
2 | 03/2003-07/2009 | 2148 | 120 | 163 | 2 |
| E 220 T CDI (211.206) |
OM 646.961 |
2 | 03/2003-07/2009 | 2148 | 110 | 150 | 2 |
| E 220 T CDI (211.208) |
OM 646.821 |
2 | 04/2006-07/2009 | 2148 | 125 | 170 | 2 |
| E 280 T CDI (211.220) |
OM 642.920 |
2 | 03/2005-07/2009 | 2987 | 140 | 190 | 2 |
| E 320 T CDI (211.222) |
OM 642.920 |
2 | 03/2005-07/2009 | 2987 | 165 | 224 | 2 |
| E 320 T CDI (211.226) |
OM 648.961 |
2 | 03/2003-07/2009 | 3222 | 150 | 204 | 2 |
| E 320 T CDI 4-matic (211.289) |
OM 642.921 |
2 | 03/2005-07/2009 | 2987 | 165 | 224 | 3 |
| Vehicle | Engine | Fuel | Date | CC | KW | CV | Traction |
|---|---|---|---|---|---|---|---|
| E 200 CGI (212.048, 212.148) |
M 271.820 M 271.860 |
1 | 08/2009-12/2015 | 1796 | 135 | 184 | 2 |
| Vehicle | Engine | Fuel | Date | CC | KW | CV | Traction |
|---|---|---|---|---|---|---|---|
| 280 (230.454) |
M 272.949 |
1 | 03/2008-01/2012 | 2996 | 170 | 231 | 2 |
| 300 (230.454) |
M 272.949 |
1 | 04/2009-01/2012 | 2996 | 170 | 231 | 2 |
| 350 (230.456) |
M 272.966 |
1 | 03/2006-01/2012 | 3498 | 200 | 272 | 2 |
| 350 (230.458) |
M 272.968 |
1 | 04/2008-01/2012 | 3498 | 232 | 316 | 2 |
| 500 (230.471) |
M 273.965 |
1 | 03/2006-01/2012 | 5461 | 285 | 388 | 2 |
| 500 (230.475) |
M 113.963 |
1 | 10/2001-01/2012 | 4966 | 225 | 306 | 2 |
| Vehicle | Engine | Fuel | Date | CC | KW | CV | Traction |
|---|---|---|---|---|---|---|---|
| 1.8 E 200 Kompressor (211.041) | 1 | 09/2006-12/2012 | 1796 | 135 | 184 | 2 |
