Product 78BD2593-2
- Description
- Brake disc
- Axe
- Front
- No. of Pieces
- 2
- Barcode
-
8424073143969
- Url
- https://catalogonuevo.icerbrakes.com/Producto/Details?idProducto=78BD2593-2
- Weight (gr.)
- 22440
- R90 Homologation
-
90R-02C0074/1445
- Measures
- Ø330x32x64.5
-
Brake Disc Type:
Vented -
Minimum thickness [mm]:
29.4 -
Hole Arrangement/Number:
5 -
Bolt Hole Circle Ø [mm]:
112 -
Wheel Hub Diameter [mm]:
67
| Brand | OE Reference |
|---|---|
| MERCEDES-BENZ | 204 421 13 12 |
| MERCEDES-BENZ | 204 421 14 12 |
| MERCEDES-BENZ | 204 421 29 12 |
| Maker | Cross reference |
|---|---|
| ATE | 24.0132-0144.1 |
| ATE | 432144 |
| BENDIX ANTIGUO | 562331B |
| BOSCH | 0 986 479 332 |
| BREMBO | 09.9825.20 |
| DELPHI LOCKHEED | BG3877 |
| FERODO | DDF1595 |
| GIRLING | 6073515 |
| HELLA-PAGID | 8DD 355 109-421 |
| MINTEX | MDC1788 |
| ROAD HOUSE | 61142.10 |
| SANLI | SL34932 |
| TEXTAR | 92119903 |
| TEXTAR | 92163405 |
| TRW | DF7351S |
| Vehicle | Engine | Fuel | Date | CC | KW | CV | Traction |
|---|---|---|---|---|---|---|---|
| C 300 (204.254) |
M 272.947 |
1 | 08/2007-08/2014 | 2996 | 170 | 231 | 2 |
| C 300 CDI 4-matic (204.292) |
OM 642.832 |
2 | 06/2011-08/2014 | 2987 | 170 | 231 | 3 |
| C 350 CDI (204.225) |
OM 642.830 |
2 | 08/2007-08/2014 | 2987 | 165 | 224 | 2 |
| C 350 CDI 4-matic (204.292) |
OM 642.961 |
2 | 08/2007-12/2011 | 2987 | 165 | 224 | 3 |
| Vehicle | Engine | Fuel | Date | CC | KW | CV | Traction |
|---|---|---|---|---|---|---|---|
| C 350 4-matic (204.388) |
M 276.957 |
1 | 09/2013- | 3498 | 225 | 306 | 3 |
| Vehicle | Engine | Fuel | Date | CC | KW | CV | Traction |
|---|---|---|---|---|---|---|---|
| CLS 280 (219.354) |
M 272.943 |
1 | 07/2008-12/2010 | 2996 | 170 | 231 | 2 |
| CLS 300 (219.354) |
M 272.943 |
1 | 04/2009-12/2010 | 2996 | 170 | 231 | 2 |
| CLS 350 (219.356) |
M 272.964 |
1 | 10/2004-12/2010 | 3498 | 200 | 272 | 2 |
| CLS 350 (219.357) |
M 272.985 |
1 | 04/2006-12/2010 | 3498 | 215 | 292 | 2 |
| CLS 350 CGI (219.357) | 1 | 04/2009-12/2010 | 3498 | 215 | 292 | 2 | |
| CLS 500 (219.372) |
M 273.960 |
1 | 04/2006-12/2010 | 5461 | 285 | 388 | 2 |
| CLS 500 (219.375) |
M 113.967 |
1 | 10/2004-12/2010 | 4966 | 225 | 306 | 2 |
| CLS 350 CDI |
OM 642.920 |
2 | 04/2009-12/2010 | 2987 | 200 | 272 | 2 |
| Vehicle | Engine | Fuel | Date | CC | KW | CV | Traction |
|---|---|---|---|---|---|---|---|
| E 320 (211.065) |
M 112.949 |
1 | 03/2002-12/2008 | 3199 | 165 | 224 | 2 |
| E 350 (211.056) |
M 272.964 |
1 | 03/2005-12/2008 | 3498 | 200 | 272 | 2 |
| E 350 CGI (211.057) |
M 272.985 |
1 | 09/2007-12/2008 | 3498 | 215 | 292 | 2 |
| E 500 (211.070) |
M 113.967 |
1 | 03/2002-12/2008 | 4966 | 225 | 306 | 2 |
| E 280 CDI (211.020) |
OM 642.920 |
2 | 03/2005-12/2008 | 2987 | 140 | 190 | 2 |
| E 300 BlueTEC (211.024) |
OM 642.920 |
2 | 09/2007-12/2008 | 2987 | 155 | 211 | 2 |
| E 400 CDI (211.028) |
OM 628.961 |
2 | 02/2003-12/2008 | 3996 | 191 | 260 | 2 |
| E320 CDI (211.022) |
OM 642.920 |
2 | 03/2005-12/2008 | 2987 | 165 | 224 | 2 |
| Vehicle | Engine | Fuel | Date | CC | KW | CV | Traction |
|---|---|---|---|---|---|---|---|
| 350 CGI (211.257) |
M 272.985 |
1 | 05/2006-07/2009 | 3498 | 215 | 292 | 2 |
| E 350 T (211.256) |
M 272.964 |
1 | 03/2005-07/2009 | 3498 | 200 | 272 | 2 |
| E 500 T (211.270) |
M 113.967 |
1 | 10/2003-07/2009 | 4966 | 225 | 306 | 2 |
| E 500 T 4-matic (211.283) |
M 113.969 |
1 | 10/2003-07/2009 | 4966 | 225 | 306 | 3 |
| E 270 T CDI (211.216) |
OM 647.961 |
2 | 03/2003-07/2009 | 2685 | 130 | 177 | 2 |
| Vehicle | Engine | Fuel | Date | CC | KW | CV | Traction |
|---|---|---|---|---|---|---|---|
| E 220 CDI (211.606) |
OM 646.961 |
2 | 10/2003-07/2006 | 2148 | 110 | 150 | 2 |
| E 220 CDI (211.608) |
OM 646.821 |
2 | 04/2006-07/2009 | 2148 | 125 | 170 | 2 |
| E 270 CDI (211.616) |
OM 647.961 |
2 | 03/2003-07/2009 | 2685 | 120 | 163 | 2 |
| E 270 CDI (211.616) |
OM 647.961 |
2 | 10/2003-07/2005 | 2685 | 130 | 177 | 2 |
| E 280 CDI (211.620) |
OM 642.920 |
2 | 08/2005-07/2009 | 2987 | 140 | 190 | 2 |
| Vehicle | Engine | Fuel | Date | CC | KW | CV | Traction |
|---|---|---|---|---|---|---|---|
| E 180 (212.040) |
M 274.910 |
1 | 08/2013-12/2015 | 1595 | 115 | 156 | 2 |
| E 200 (212.034) |
M 274.920 |
1 | 01/2013-12/2016 | 1991 | 135 | 184 | 2 |
| E 250 (212.036) |
M 274.920 |
1 | 01/2013-12/2016 | 1991 | 155 | 211 | 2 |
| E 250 (212.052) | 1 | 05/2009-12/2011 | 2496 | 150 | 204 | 2 | |
| E 300 (212.054) |
M 272.952 |
1 | 01/2009-12/2013 | 2996 | 170 | 231 | 2 |
| E 400 (212.065) |
M 276.820 |
1 | 01/2013-12/2016 | 2996 | 245 | 333 | 2 |
| E 400 4-matic (212.067) |
M 276.820 |
1 | 01/2013-12/2016 | 2996 | 245 | 333 | 3 |
| E 220 BlueTEC (212.001) |
OM 651.924 |
2 | 05/2014-12/2015 | 2143 | 130 | 177 | 2 |
| E 350 CDI | 2 | 09/2010-12/2015 | 2987 | 157 | 214 | 2 |
| Vehicle | Engine | Fuel | Date | CC | KW | CV | Traction |
|---|---|---|---|---|---|---|---|
| E 400 (207.361) |
M 276.850 |
1 | 07/2014-12/2016 | 3498 | 245 | 333 | 2 |
| E 220 BlueTEC (207.301) |
OM 651.911 |
2 | 05/2014-12/2016 | 2143 | 130 | 177 | 2 |
| E 350 BlueTEC / d (207.326) |
OM 642.838 |
2 | 05/2014-12/2016 | 2987 | 190 | 258 | 2 |
| Vehicle | Engine | Fuel | Date | CC | KW | CV | Traction |
|---|---|---|---|---|---|---|---|
| E 400 (212.265) |
M 276.820 |
1 | 01/2013-12/2016 | 2996 | 245 | 333 | 2 |
| E 400 4-matic (212.267) |
M 276.820 |
1 | 01/2013-12/2016 | 2996 | 245 | 333 | 3 |
| E 400 4-matic (212.299) |
M 276.850 |
1 | 07/2014-12/2016 | 3498 | 245 | 333 | 3 |
| E 220 BlueTEC |
OM 651.924 |
2 | 05/2015-12/2016 | 2143 | 130 | 177 | 2 |
| E 220 CDI (212.202) |
OM 651.924 |
2 | 08/2009-08/2014 | 2143 | 120 | 163 | 2 |
| E 300 CDI / BlueTEC (212.227, 212.221) |
OM 642.850 OM 642.852 |
2 | 11/2009-12/2016 | 2987 | 170 | 231 | 2 |
| Vehicle | Engine | Fuel | Date | CC | KW | CV | Traction |
|---|---|---|---|---|---|---|---|
| E 350 (207.456) |
M 272.961 M 272.988 |
1 | 03/2010-12/2011 | 3498 | 200 | 272 | 2 |
| E 400 (207.461) |
M 276.850 |
1 | 07/2014-12/2016 | 3498 | 245 | 333 | 2 |
| E 220 BlueTEC (207.401) |
OM 651.911 |
2 | 05/2014-12/2016 | 2143 | 130 | 177 | 2 |
| E 220 CDI (207.402) |
OM 651.911 |
2 | 02/2010-12/2016 | 2143 | 120 | 163 | 2 |
| Vehicle | Engine | Fuel | Date | CC | KW | CV | Traction |
|---|---|---|---|---|---|---|---|
| 250 4-matic (204.937) |
M 274.920 |
1 | 08/2013-06/2015 | 1991 | 155 | 211 | 3 |
| 280 4-matic (204.981) |
M 272.948 |
1 | 06/2008-06/2009 | 2996 | 170 | 231 | 3 |
| 300 4-matic (204.981) |
M 272.948 |
1 | 07/2009-12/2015 | 2996 | 170 | 231 | 3 |
| 300 4-matic (204.990) |
M 276.957 |
1 | 09/2009-12/2015 | 3498 | 182 | 248 | 3 |
| 300 4-matic (204.990) |
M 276.957 |
1 | 09/2009-06/2015 | 3498 | 185 | 252 | 3 |
| 350 (204.956) |
M 272.991 |
1 | 04/2009-06/2015 | 3498 | 200 | 272 | 2 |
| 350 4-matic (204.987) |
M 272.971 |
1 | 06/2008-04/2011 | 3498 | 200 | 272 | 3 |
| 350 4-matic (204.988) |
M 276.957 |
1 | 06/2008-06/2015 | 3498 | 225 | 306 | 3 |
| 200 CDI (204.901) |
OM 651.916 |
2 | 12/2013-06/2015 | 2143 | 100 | 136 | 2 |
| 200 CDI (204.901) |
OM 651.913 OM 651.916 |
2 | 07/2010-06/2015 | 2143 | 105 | 143 | 2 |
| 220 CDI (204.902) |
OM 651.916 |
2 | 12/2008-06/2015 | 2143 | 120 | 163 | 2 |
| 220 CDI (204.902) |
OM 651.916 |
2 | 12/2008-06/2015 | 2143 | 125 | 170 | 2 |
| 220 CDI 4-matic (204.984, 204.997) |
OM 651.912 |
2 | 12/2008-06/2015 | 2143 | 120 | 163 | 3 |
| 220 CDI 4-matic (204.984, 204.997) |
OM 651.912 |
2 | 12/2008-06/2015 | 2143 | 125 | 170 | 3 |
| 250 CDI 4-matic (204.982, 204.904) |
OM 651.912 |
2 | 09/2009-06/2015 | 2143 | 150 | 204 | 3 |
| 320 CDI 4-matic (204.983) |
OM 642.961 |
2 | 06/2008-06/2015 | 2987 | 165 | 224 | 3 |
| 350 CDI 4-matic (204.993) |
OM 642.832 |
2 | 07/2009-01/2010 | 2987 | 165 | 224 | 3 |
| 350 CDI 4-matic (204.993) |
OM 642.832 |
2 | 02/2010-06/2015 | 2987 | 170 | 231 | 3 |
| 350 CDI 4-matic (204.993) |
OM 642.835 |
2 | 07/2012-06/2015 | 2987 | 195 | 265 | 3 |
