Product 78BD2609-2

Description
Brake disc
Axe
Front
No. of Pieces
2
Barcode
EAN13 Code
8424073143976
QR Code
Url
https://catalogonuevo.icerbrakes.com/Producto/Details?idProducto=78BD2609-2
Weight (gr.)
11590
R90 Homologation
R90 90R-02C0074/0061
Measures
Ø255x25x46.5
Brake Disc Type: Vented
Minimum thickness [mm]: 23
Hole Arrangement/Number: 5
Bolt Hole Circle Ø [mm]: 110
Wheel Hub Diameter [mm]: 84
Reference applications
Brand OE Reference
TOYOTA 43512-26090
Maker Cross reference
BENDIX ANTIGUO 561746B
BOSCH 0 978 478 452
BREMBO 09.6710.10
DELPHI LOCKHEED BG3174
FERODO DDF703
GIRLING 6027451
MINTEX MDC1072
ROAD HOUSE 61247.10
SANLI SL31821
TEXTAR 92080300
TRW DF2745
TOYOTA
DYNA (LH8_) Platform/Chassis 08/1985-05/1995
Vehicle Engine Fuel Date CC KW CV Traction
2.4 D (LH80_, LH80R)

2L

 2 08/1987-04/1995 2446 55 75 2
DYNA 100 (YH_) Platform/Chassis 08/1985-04/1995
Vehicle Engine Fuel Date CC KW CV Traction
1.8 (YH81_, YH81R)

2Y

 1 08/1987-04/1995 1812 61 83 2
DYNA 100 (LY1_, YY1_) Platform/Chassis 05/1995-07/2001
Vehicle Engine Fuel Date CC KW CV Traction
2.4 D (LY100_, LY100R)

2L

 2 05/1995-07/2001 2446 54 73 2
2.4 D (LY100_)

2L

 2 05/1995-07/2001 2446 58 79 2
DYNA 150 (LY_) Platform/Chassis 08/1988-06/1995
Vehicle Engine Fuel Date CC KW CV Traction
2.4 D (LY60)

2L

 2 09/1988-04/1995 2446 55 75 2
HiAce II (_H11, _H2_, _H3_, _H4_) Van 02/1977-03/1983
Vehicle Engine Fuel Date CC KW CV Traction
1.6 (RH30)

12R

 1 02/1977-03/1983 1588 49 67 2
2.0 (RH32)

18R

 1 02/1977-03/1983 1968 65 88 2
2.2 D (LH20, LH30)

L

 2 01/1979-03/1983 2188 49 67 2
HiAce III (_H5_, _H6_, _H7_, _H8_, _H9_) Bus 11/1982-09/2007
Vehicle Engine Fuel Date CC KW CV Traction
2.2 (YH56, YH66, YH73)

4Y

 1 08/1986-08/1989 2237 69 94 2
HiAce III (_H5_, _H6_, _H7_, _H8_, _H9_) Van 12/1982-08/2005
Vehicle Engine Fuel Date CC KW CV Traction
2.0 (YH51, YH61)

3Y

 1 12/1982-08/1989 1998 65 88 2
2.2 (YH56, YH66, YH53, YH63)

4Y

 1 08/1986-08/1989 2237 69 94 2
2.2 D (LH50, LH60)

L

 2 12/1982-11/1989 2188 49 67 2
2.4 D (LH61, LH51)

2L

 2 12/1982-11/1989 2446 55 75 2
HiAce IV / QUANTUM (_H1_) Bus 08/1987-12/2004
Vehicle Engine Fuel Date CC KW CV Traction
2.0 (RZH102, RZH112)

1RZ

 1 08/1989-04/1998 1998 74 101 2
2.0 (RZH124) 1 11/1996-10/2000 1998 81 110 2
2.4 (RZH103, RZH183)

2RZ-E

 1 08/1989-08/2003 2438 88 120 2
2.4 (RZH125) 1 08/1989-10/1996 2438 72 98 2
2.4 4WD (RZH103_, RZH109_, RZH113_, RZH115_, RZH103R,...

2RZ-E

 1 08/1989-07/1995 2438 88 120 3
2.4 D (LH100, LH110, LH104, LH114)

2L

 2 08/1989-12/2004 2446 57 78 2
2.4 D (LH102)

2L

 2 08/1989-08/1995 2446 55 75 2
2.4 D 4WD (LH51_, LH61_, LH66_, LH71_, LH51R, LH61R,...

2L

 2 08/1987-08/1995 2446 55 75 3
2.8 D (LH105, LH125)

3L

 2 08/1989-08/2000 2779 61 83 2
3.0 D (LH174) 2 08/1998-08/2004 2986 65 88 2
HiAce IV (_H1_) Van 08/1989-02/2005
Vehicle Engine Fuel Date CC KW CV Traction
2.0 (RZH102, RZH112)

1RZ

 1 02/1990-08/2004 1998 74 101 2
2.0 (RZH102, RZH112) 1 11/1996-10/2000 1998 81 110 2
2.4 (RZH10)

2RZ-E

 1 08/1989-08/1995 2438 88 120 2
2.4 (RZH103_, RZH103R) 1 08/1989-10/1996 2438 72 98 2
2.4 4WD (RCH103_, RCH113_, RCH103R, RCH113R)

2RZ-E

 1 08/1989-08/1995 2438 88 120 3
2.4 D

2L

 2 01/1992-08/1995 2446 53 72 2
2.4 D (LH102, LH104, LH112)

2L

 2 09/1989-08/1995 2446 57 78 2
2.4 D (LH112)

2L

 2 08/1989-08/2004 2446 55 75 2
2.4 D 4WD

2L

 2 09/1989-08/1995 2446 57 78 3
2.4 D 4WD (LH108, LH118)

2L

 2 08/1989-07/1999 2446 55 75 3
2.8 D (LH105, LH103, LH113)

3L

 2 08/1989-08/2000 2779 61 83 2
3.0 D (LH162, LH172) 2 08/1998-08/2004 2986 65 88 2
HILUX IV / PICKUP (_N5_, _N6_) Pickup 11/1982-11/1998
Vehicle Engine Fuel Date CC KW CV Traction
1.6 (YN55) 1 11/1983-09/1987 1626 55 75 2
2.2 D (LN50, LN55)

L

 2 08/1983-08/1984 2188 49 67 2
HiLux IV-VI (LN_, _N1_) Platform/Chassis 08/1983-08/2005
Vehicle Engine Fuel Date CC KW CV Traction
1.8 (YN56)

2Y

 1 08/1983-07/1988 1812 58 79 2
2.7 EFI (RZN154, RZN149)

3RZ-FE

 1 08/1997-08/2005 2694 107 145 2
HiLux SUV V / HiLux SURF (LN_, KZN1_, VZN1_, RN1_) SUV 08/1988-11/1998
Vehicle Engine Fuel Date CC KW CV Traction
2.4 TD (LN85) 2 10/1991-07/1997 2446 66 90 2
HILUX V (_N_, KZN1_, VZN1_) Pickup 09/1988-08/2001
Vehicle Engine Fuel Date CC KW CV Traction
1.8 (YN85, YN90)

2Y

 1 09/1988-06/1998 1812 61 83 2
2.2 4WD (YN106) 1 01/1992-01/1999 2237 69 94 3
2.4 (RN90, RN85) 1 10/1988-12/1998 2367 75 102 2
2.4 D (LN5_, LN85, LN90)

2L

 2 10/1988-07/1997 2446 55 75 2
2.4 TD (LN90) 2 01/1992-01/1999 2446 66 90 2
2.8 D 4WD (LN107, LN111, LN166, LN106)

3L

 2 10/1988-12/1997 2779 60 82 3
HILUX VI (_N1_) Pickup 08/1994-03/2006
Vehicle Engine Fuel Date CC KW CV Traction
2.4 D (LN145, LN150)

2L

 2 08/1997-07/2005 2446 58 79 2
2.4 D (LN145, LN150)

2L

 2 08/1997-08/2001 2446 61 83 2
2.4 TD (LN190)

2L-T

 2 08/1997-07/2001 2446 66 90 2
3.0 D 2 11/1997-05/2005 2986 70 95 2
3.0 D (LN147, LN192)

5L

5L-E

 2 01/1998-04/2005 2986 71 97 2
3.0 D 4WD 2 11/1997-05/2005 2986 70 95 3
3.0 D 4WD (LN14_, LN152_, N140) 2 11/1997-04/2005 2986 65 88 3
3.0 D 4WD (LN167, LN172)

5L-E

 2 01/1998-07/2005 2986 71 97 3
HiLux SUV VI / SW4 (_N1_, _N2_) SUV 01/1995-08/2005
Vehicle Engine Fuel Date CC KW CV Traction
3.0 D (LN157) 2 11/1997-05/2005 2986 70 95 2
3.0 D 4WD (LN157) 2 11/1997-05/2005 2986 70 95 3
LITEACE (_M3_, _M4_) Van 01/1983-04/1998
Vehicle Engine Fuel Date CC KW CV Traction
1.8 (YM30, YM35, YM31)

2Y

 1 01/1986-12/1992 1812 61 83 2
