Product 78BD2611-2

Description
Brake disc
Axe
Front
No. of Pieces
2
Barcode
EAN13 Code
8424073143990
QR Code
Url
https://catalogonuevo.icerbrakes.com/Producto/Details?idProducto=78BD2611-2
Weight (gr.)
18520
R90 Homologation
R90 90R-02C0452/0114
Measures
Ø295.8x32x50.9
Brake Disc Type: Vented
Minimum thickness [mm]: 30
Hole Arrangement/Number: 5
Bolt Hole Circle Ø [mm]: 114,3
Wheel Hub Diameter [mm]: 62
Reference applications
Brand OE Reference
LEXUS 43512-50120
Maker Cross reference
BENDIX ANTIGUO 562248B
BENDIX BRAKING-TMD BDS1918
DELPHI LOCKHEED BG2829
FERODO DDF1134
LETEC LBT037V
TRW DF4182S
LEXUS
GS (JZS147_) Saloon 01/1993-08/1997
Vehicle Engine Fuel Date CC KW CV Traction
300 (JZS147_, JZS147R)

2JZ-GE

 1 01/1993-08/1997 2997 156 212 2
GS II (_S16_) Saloon 08/1997-12/2004
Vehicle Engine Fuel Date CC KW CV Traction
300 (JZS160_, JZS160R)

2JZ-GE

 1 10/2000-12/2004 2997 161 219 2
300 (JZS160_, JZS160R)

2JZ-GE

 1 08/1997-10/2000 2997 163 222 2
430 (UZS161_, UZS161R)

3UZ-FE

 1 11/2000-12/2004 4293 208 283 2
IS (_E1_) Saloon 04/1999-07/2005
Vehicle Engine Fuel Date CC KW CV Traction
200 (GXE10)

1G-FE

 1 04/1999-07/2005 1988 114 155 2
300 (JCE10)

2JZ-GE

 1 09/2001-07/2005 2997 157 213 2
IS SportCross (_E1_) Estate 10/2001-10/2005
Vehicle Engine Fuel Date CC KW CV Traction
200 (GXE10_, GXE10R)

1G-FE

 1 10/2002-10/2005 1988 114 155 2
300 (JCE10_, JCE10R)

2JZ-GE

 1 10/2001-10/2005 2997 157 213 2
LS (_F1_) Saloon 09/1989-12/1995
Vehicle Engine Fuel Date CC KW CV Traction
400 (UCF10)

1UZ-FE

 1 12/1989-12/1995 3969 180 245 2
SC (_ZZ3_) Coupe 08/1991-07/2000
Vehicle Engine Fuel Date CC KW CV Traction
300 (JZZ31)

2JZ-GE

 1 01/1995-03/2000 2997 162 220 2
400 (UZZ30)

1UZ-FE

 1 09/1991-07/2000 3969 186 253 2
400 (UZZ30)

1UZ-FE

 1 08/1991-12/1997 3969 194 264 2
SC II / SOARER (UZZ40_) Convertible 01/2001-07/2010
Vehicle Engine Fuel Date CC KW CV Traction
430 (UZZ40_, UZZ40R)

3UZ-FE

 1 05/2001-07/2010 4293 210 286 2
TOYOTA
ALTEZZA GITA (_XE1_) Estate 10/1998-12/2005
Vehicle Engine Fuel Date CC KW CV Traction
2.0 1 01/2001-12/2005 1998 154 209 2
2.0 (GXE10)

1G-FE

1G-GE

 1 01/1999-06/2001 1988 114 155 2
2.0 (GXE10)

1G-FE

1G-GE

 1 07/2001-07/2005 1988 118 160 2
2.0 (GXE15)

1G-FE

1G-GE

 1 07/2001-07/2005 1988 118 160 3
3.0 (JCE10)

2JZ-GE

 1 07/2001-11/2005 2997 157 214 2
3.0 (JCE10)

2JZ-GE

 1 07/2001-11/2005 2997 162 220 2
ALTEZZA (_E1_) Saloon 01/1999-11/2005
Vehicle Engine Fuel Date CC KW CV Traction
2.0 VVTi (GXE10)

1G-FE

 1 01/1999-05/2005 1988 118 160 2
2.0 VVTi (SXE10)

3S-GE

 1 10/1998-11/2005 1998 147 200 2
2.0 VVTi (SXE10)

3S-GE

 1 02/1999-11/2005 1998 154 209 2
ARISTO (_S14_) Saloon 10/1990-07/1997
Vehicle Engine Fuel Date CC KW CV Traction
3.0 (JZS147)

2JZ-GE

 1 10/1990-07/1997 2997 169 230 2
3.0 (JZS147)

2JZ-GTE

 1 10/1990-09/1996 2997 205 279 2
4.0 4WD (UZS143)

1UZ-FE

 1 10/1992-07/1997 3969 173 235 3
ARISTO II (_S16_) Saloon 08/1997-10/2004
Vehicle Engine Fuel Date CC KW CV Traction
3.0 (JZS160)

2JZ-GE

 1 08/1997-09/2004 2997 170 231 2
3.0 (JZS161)

2JZ-GTE

 1 08/1997-09/2004 2997 206 280 2
CELSIOR II (UCF2_) Saloon 05/1993-08/2000
Vehicle Engine Fuel Date CC KW CV Traction
4.0 (UCF20,UCF21)

1UZ-FE

 1 07/1997-08/2000 3969 206 280 2
CELSIOR III (UCF3_) Saloon 09/2000-08/2006
Vehicle Engine Fuel Date CC KW CV Traction
4.3 VVTi (UCF30, UCF31)

3UZ-FE

 1 09/2000-08/2006 4293 208 283 2
CHASER VI (_X10_) Saloon 09/1996-05/2001
Vehicle Engine Fuel Date CC KW CV Traction
2.5 (JZX100_, JZX100)

1JZ-GTE

 1 10/1996-05/2001 2491 206 280 2
CROWN XI / ROYAL (_S17_) Saloon 09/1999-05/2004
Vehicle Engine Fuel Date CC KW CV Traction
2.5 (JZS171) 1 09/1999-11/2003 2491 206 280 2
MARK II () Saloon 04/1988-09/1996
Vehicle Engine Fuel Date CC KW CV Traction
2.5 (JZX90)

1JZ-GTE

 1 10/1992-09/1996 2491 206 280 2
MARK II (_X10_) Saloon 09/1996-09/2001
Vehicle Engine Fuel Date CC KW CV Traction
2.5 VVTi (JZX100)

1JZ-GTE

 1 10/1996-09/2001 2491 206 280 2
MARK II (_X11_) Saloon 10/2000-11/2004
Vehicle Engine Fuel Date CC KW CV Traction
2.5 (JZX110)

1JZ-GTE

 1 10/2000-11/2004 2491 206 280 2
SOARER III (_Z3_) Coupe 09/1990-12/2000
Vehicle Engine Fuel Date CC KW CV Traction
2.5 Turbo (JZZ30)

1JZ-GTE

 1 09/1990-09/2000 2491 206 280 2
4.0 (UZZ31, UZZ32, UZZ30)

1UZ-FE

 1 05/1991-09/1997 3969 191 260 2
VEROSSA (_X11_) Saloon 10/2000-04/2004
Vehicle Engine Fuel Date CC KW CV Traction
2.5 VVTi (JZX110)

1JZ-GTE

 1 10/2000-11/2003 2491 206 280 2
