Product 78BD2671-2

Description
Brake disc
Axe
Front
No. of Pieces
2
Barcode
EAN13 Code
8424073144034
QR Code
Url
https://catalogonuevo.icerbrakes.com/Producto/Details?idProducto=78BD2671-2
Weight (gr.)
14240
R90 Homologation
R90 90R-02C0074/1560
Measures
Ø274x28x51
Brake Disc Type: Vented
Minimum thickness [mm]: 26
Hole Arrangement/Number: 5
Bolt Hole Circle Ø [mm]: 114.3
Wheel Hub Diameter [mm]: 72
Reference applications
Brand OE Reference
MAZDA TY01-33-25X
MAZDA TY01-33-25XA
Maker Cross reference
ATE 24.0128-0175.1
BENDIX ANTIGUO 562112B
BOSCH 0 986 479 016
BREMBO 09.6863.10
DELPHI LOCKHEED BG3232
FERODO DDF738
SANLI SL34188
TRW DF4012
EUNOS
800 (E65, TA) Saloon 09/1993-12/2002
Vehicle Engine Fuel Date CC KW CV Traction
2.3 Miller (TA3A, TA3P)

KJ15

 1 07/1996-07/1998 2255 155 211 1
2.5

KLZ5

 1 09/2000-12/2002 2497 120 163 1
2.5

KL68

 1 09/1993-08/2000 2497 123 167 1
MAZDA
MPV I / 8 (LV) MPV 09/1988-09/1999
Vehicle Engine Fuel Date CC KW CV Traction
3.0 i V6 (LV10, LV12, LV521, LV321)

JE96

 1 11/1988-05/1999 2954 113 154 2
3.0 i V6 (LVEW)

JE94

JE96

 1 11/1989-09/1999 2954 109 148 2
2.5 TD (LVLW)

WL11

 2 05/1996-09/1999 2500 85 115 2
MPV II / 8 (LW) MPV 08/1999-12/2006
Vehicle Engine Fuel Date CC KW CV Traction
2.0 (LWEW)

FS

 1 08/2000-07/2002 1991 88 120 1
2.0 (LWEW)

FS-DS

 1 09/1999-08/2000 1991 90 122 1
2.3 (LW3W)

L3

 1 07/2002-02/2006 2261 104 141 1
2.5 V6 (LW5W)

GY-DE

 1 09/1999-03/2002 2495 125 170 1
2.0 DI

RF5C

 2 07/2002-02/2006 1998 100 136 1
MPV III / 8 (LY) MPV 02/2006-
Vehicle Engine Fuel Date CC KW CV Traction
2.3 1 02/2006- 2261 122 166 1
2.3 (LY3P) 1 02/2006- 2261 120 163 1
2.3 4WD (LY3P) 1 02/2006- 2261 120 163 3
2.3 4WD (LY3P) 1 02/2006- 2261 180 245 3
XEDOS 9 / EUNOS 800 / MILLENIA (TA) Saloon 07/1993-09/2002
Vehicle Engine Fuel Date CC KW CV Traction
2.0 (TAFP) 1 08/1998-08/2002 1995 118 160 1
2.0 24V

KF

 1 08/1993-01/2000 1995 105 143 1
2.3 24V (TA3P)

KJ -ZEM

 1 02/1995-01/2000 2255 155 211 1
2.5 1 09/1994-09/2002 2497 127 173 1
2.5 (TA5P)

KL-ZE

 1 09/2000-09/2002 2496 147 200 1
2.5 24V (TA5P)

KL

 1 07/1993-07/2000 2497 123 167 1
2.5 V6 (TA5P)

KL

 1 07/2000-09/2002 2497 120 163 1
