Product 78BD2830-2
- Description
- Brake disc
- Axe
- Front
- No. of Pieces
- 2
- Barcode
-
8424073144119
- Url
- https://catalogonuevo.icerbrakes.com/Producto/Details?idProducto=78BD2830-2
- Weight (gr.)
- 10152
- R90 Homologation
-
90R-02C0452/0077
- Measures
- Ø257x22x34
-
Brake Disc Type:
Vented -
Minimum thickness [mm]:
20 -
Hole Arrangement/Number:
4 -
Bolt Hole Circle Ø [mm]:
104 -
Wheel Hub Diameter [mm]:
86
| Brand | OE Reference |
|---|---|
| HYUNDAI | 51712-28300 |
| Maker | Cross reference |
|---|---|
| ATE | 24.0122-0170.1 |
| BOSCH | 0 986 478 675 |
| BREMBO | 09.5587.10 |
| DELPHI LOCKHEED | BG2628 |
| LETEC | LBD004V |
| ROAD HOUSE | 6375.10 |
| SANLI | SL34587 |
| TRW | DF1428 |
| Vehicle | Engine | Fuel | Date | CC | KW | CV | Traction |
|---|---|---|---|---|---|---|---|
| 1.6 16V |
G4GR |
1 | 03/1998-04/2002 | 1599 | 85 | 116 | 1 |
| 1.6 i 16V |
G4GR |
1 | 12/1996-04/2002 | 1599 | 84 | 114 | 1 |
| 1.8 SX | 1 | 07/1996-04/2002 | 1795 | 94 | 128 | 1 | |
| 2.0 |
G4DF |
1 | 08/1999-01/2002 | 1975 | 101 | 137 | 1 |
| 2.0 16V |
G4DF |
1 | 03/2001-04/2002 | 1975 | 99 | 135 | 1 |
| 2.0 16V |
G4DF G4GF |
1 | 08/1996-04/2002 | 1975 | 102 | 139 | 1 |
| Vehicle | Engine | Fuel | Date | CC | KW | CV | Traction |
|---|---|---|---|---|---|---|---|
| 1.5 i.e. |
G4DJ |
1 | 10/1990-11/1995 | 1468 | 63 | 86 | 1 |
| 1.6 i.e. 16V |
G4CR |
1 | 10/1990-11/1995 | 1596 | 78 | 106 | 1 |
| 1.6 i.e. 16V |
G4CR |
1 | 10/1990-11/1995 | 1596 | 84 | 114 | 1 |
| 1.8 i.e. 16V |
G4CN |
1 | 10/1990-11/1995 | 1836 | 93 | 127 | 1 |
| Vehicle | Engine | Fuel | Date | CC | KW | CV | Traction |
|---|---|---|---|---|---|---|---|
| 1.5 12V |
G4EK |
1 | 12/1996-09/2000 | 1495 | 65 | 88 | 1 |
| 1.6 16V |
G4GR |
1 | 11/1995-09/2000 | 1599 | 84 | 114 | 1 |
| 1.6 16V |
G4GR |
1 | 06/1995-09/2000 | 1599 | 87 | 118 | 1 |
| 1.6 i |
G4GR |
1 | 11/1995-09/2000 | 1599 | 66 | 90 | 1 |
| 1.8 | 1 | 09/1995-12/1997 | 1795 | 97 | 132 | 1 | |
| 1.8 | 1 | 09/1997-12/1998 | 1835 | 97 | 132 | 1 | |
| 1.8 16V |
G4GM |
1 | 11/1995-09/2000 | 1795 | 94 | 128 | 1 |
| 1.8 16V | 1 | 09/1995-09/2000 | 1795 | 101 | 138 | 1 | |
| 2.0 |
G4JP |
1 | 04/1997-05/2000 | 1997 | 100 | 136 | 1 |
| 2.0 16V |
G4GF |
1 | 08/1996-09/2000 | 1975 | 102 | 139 | 1 |
| 1.9 D |
DJY |
2 | 03/1998-09/2000 | 1905 | 50 | 68 | 1 |
| Vehicle | Engine | Fuel | Date | CC | KW | CV | Traction |
|---|---|---|---|---|---|---|---|
| 1.5 12V |
G4EK |
1 | 04/1997-10/2000 | 1495 | 65 | 88 | 1 |
| 1.6 16V |
G4GR |
1 | 02/1996-10/2000 | 1599 | 84 | 114 | 1 |
| 1.6 i |
G4GR |
1 | 02/1996-10/2000 | 1599 | 66 | 90 | 1 |
| 1.8 | 1 | 02/1996-12/1997 | 1795 | 97 | 132 | 1 | |
| 1.8 16V |
G4GM |
1 | 02/1996-10/2000 | 1795 | 94 | 128 | 1 |
| 2.0 |
G4JP |
1 | 04/1997-05/2000 | 1997 | 100 | 136 | 1 |
| 2.0 16V |
G4GF |
1 | 11/1995-10/2000 | 1975 | 102 | 139 | 1 |
| 1.9 D |
DJY |
2 | 03/1998-10/2000 | 1905 | 50 | 68 | 1 |
