Product 78BD2863-2
- Description
- Brake disc
- Axe
- Front
- No. of Pieces
- 2
- Barcode
-
8424073144126
- Url
- https://catalogonuevo.icerbrakes.com/Producto/Details?idProducto=78BD2863-2
- Weight (gr.)
- 8312
- R90 Homologation
-
90R-02C0452/0087
- Measures
- Ø286.8x17x29.2
-
Brake Disc Type:
Vented -
Minimum thickness [mm]:
15 -
Hole Arrangement/Number:
5 -
Bolt Hole Circle Ø [mm]:
139.7 -
Wheel Hub Diameter [mm]:
108.25
| Brand | OE Reference |
|---|---|
| SUZUKI | 55211-65D01 |
| SUZUKI | 55211-65D02 |
| Maker | Cross reference |
|---|---|
| ATE | 24.0117-0109.1 |
| ATE | 417109 |
| BENDIX ANTIGUO | 562445B |
| BOSCH | 0 986 479 486 |
| BREMBO | 09.9142.10 |
| DELPHI LOCKHEED | BG3820 |
| FERODO | DDF1687 |
| GIRLING | 6060231 |
| HELLA-PAGID | 8DD 355 111-791 |
| MINTEX | MDC1847 |
| SANLI | SL31502 |
| TEXTAR | 92136800 |
| TRW | DF6023 |
| VALEO | 197065 |
| Vehicle | Engine | Fuel | Date | CC | KW | CV | Traction |
|---|---|---|---|---|---|---|---|
| 2.0 AWD |
L34(121CUL4) |
1 | 08/2005-10/2008 | 1995 | 94 | 128 | 3 |
| Vehicle | Engine | Fuel | Date | CC | KW | CV | Traction |
|---|---|---|---|---|---|---|---|
| 2.0 4x4 (SQ420) |
J20A |
1 | 03/1998-07/2003 | 1995 | 94 | 128 | 3 |
| Vehicle | Engine | Fuel | Date | CC | KW | CV | Traction |
|---|---|---|---|---|---|---|---|
| 1.6 4x4 (SQ416) |
G16B |
1 | 03/1998-07/2003 | 1590 | 69 | 94 | 3 |
| 1.6 4x4 (SQ416) |
G16B |
1 | 02/2000-09/2002 | 1590 | 73 | 99 | 3 |
| 2.0 4x4 (TA52, TL52, SQ420) |
J20A |
1 | 03/1998-07/2003 | 1995 | 94 | 128 | 3 |
| 2.0 HDI 110 4x4 (SQ420D, TD82V) |
RHZ |
2 | 02/2001-12/2003 | 1997 | 80 | 109 | 3 |
