Product 78BD2950-2
- Description
- Brake disc
- Axe
- Front
- No. of Pieces
- 2
- Barcode
-
8424073193360
- Url
- https://catalogonuevo.icerbrakes.com/Producto/Details?idProducto=78BD2950-2
- Weight (gr.)
- 16260
- Measures
- Ø293x28x47.1
-
Brake Disc Type:
Vented -
Minimum thickness [mm]:
26 -
Hole Arrangement/Number:
5 -
Bolt Hole Circle Ø [mm]:
114.3 -
Wheel Hub Diameter [mm]:
64.1
| Brand | OE Reference |
|---|---|
| HONDA | 45251SWAA00 |
| HONDA | 45251SWAA20 |
| HONDA | 45251SWE000 |
| HONDA | 45251SWWG01 |
| HONDA | 45251T1EG00 |
| HONDA | 45251T1EG01 |
| Maker | Cross reference |
|---|---|
| BREMBO | 09.A866.10 |
| BREMBO | 09.A866.1X |
| BREMBO | 09.B648.1X |
| TEXTAR | 92184803 |
| TRW | DF4613S |
| Vehicle | Engine | Fuel | Date | CC | KW | CV | Traction |
|---|---|---|---|---|---|---|---|
| 2.0 i-VTEC (RE5, RE1) |
R20A1 R20A2 |
1 | 01/2007-06/2012 | 1997 | 110 | 150 | 1 |
| 2.0 i-VTEC (RE5) | 1 | 11/2009-06/2012 | 1997 | 105 | 143 | 1 | |
| 2.0 i-VTEC 4WD (RE5, RE2) |
R20A1 R20A2 |
1 | 10/2006-06/2012 | 1997 | 110 | 150 | 3 |
| 2.4 | 1 | 06/2006-06/2012 | 2354 | 134 | 182 | 1 | |
| 2.4 | 1 | 06/2006-06/2012 | 2354 | 134 | 182 | 1 | |
| 2.4 (RE3) |
K24Z1 |
1 | 06/2006-06/2012 | 2354 | 124 | 168 | 1 |
| 2.4 (RE3) |
K24A1 |
1 | 04/2007-12/2012 | 2354 | 125 | 170 | 1 |
| 2.4 4WD (RE4) |
K24A K24Z1 |
1 | 09/2006-06/2012 | 2354 | 124 | 168 | 3 |
| 2.4 i-VTEC | 1 | 10/2006- | 2354 | 118 | 161 | 1 | |
| 2.4 i-VTEC 4WD (RE4) |
K24Z1 |
1 | 10/2006-10/2012 | 2354 | 118 | 160 | 3 |
| 2.4 i-VTEC 4WD (RE4) |
K24Z1 |
1 | 04/2007-12/2012 | 2354 | 125 | 170 | 3 |
| 2.4 i-VTEC 4WD (RE7) |
K24Z1 K24Z4 |
1 | 09/2009-12/2012 | 2354 | 122 | 166 | 3 |
| 2.2 i-CTDi 4WD (RE6) |
N22A2 |
2 | 01/2007-02/2010 | 2204 | 103 | 140 | 3 |
| 2.2 i-DTEC 4WD (RE6) |
N22B3 |
2 | 01/2007-06/2012 | 2199 | 110 | 150 | 3 |
| Vehicle | Engine | Fuel | Date | CC | KW | CV | Traction |
|---|---|---|---|---|---|---|---|
| 2.0 (RM1) |
R20A |
1 | 01/2012-12/2018 | 1997 | 110 | 150 | 1 |
| 2.0 AWD (RE5, RM2) |
R20A6 R20A9 |
1 | 10/2012-12/2018 | 1997 | 114 | 155 | 3 |
| 2.0 Flex | 1 | 07/2015- | 1997 | 114 | 155 | 1 | |
| 2.0 iVtec (RE5, RM1) |
R20A5 R20A6 R20A9 |
1 | 10/2012-12/2018 | 1997 | 114 | 155 | 1 |
| 2.4 4WD |
K24Z7 |
1 | 09/2012-12/2016 | 2354 | 138 | 188 | 3 |
| 2.4 AWD (RM4) |
K24Z9 |
1 | 01/2012-12/2018 | 2354 | 140 | 190 | 3 |
| 2.0 Flex (RE5) |
R20A1 |
19 | 01/2013- | 1997 | 114 | 155 | 1 |
| 1.6 i-DTEC (RE6) |
N16A1 |
2 | 10/2013-08/2018 | 1597 | 88 | 120 | 1 |
| 1.6 i-DTEC 4WD (RE6) |
N16A4 |
2 | 02/2015-08/2018 | 1597 | 118 | 160 | 3 |
| 2.2 i-DTEC 4WD (RE6) | 2 | 11/2012-05/2015 | 2199 | 110 | 150 | 3 | |
| 2.2 i-DTEC AWD (RE6) |
N22B4 |
2 | 10/2012- | 2199 | 110 | 150 | 3 |
