Product 78BD3002-2

Description
Brake disc
Axe
Front
No. of Pieces
2
Barcode
EAN13 Code
8424073144348
QR Code
Url
https://catalogonuevo.icerbrakes.com/Producto/Details?idProducto=78BD3002-2
Weight (gr.)
14410
R90 Homologation
R90 90R-02C0074/0807
Measures
Ø281x28x38.1
Brake Disc Type: Vented
Minimum thickness [mm]: 25.3
Hole Arrangement/Number: 5
Bolt Hole Circle Ø [mm]: 114,3
Wheel Hub Diameter [mm]: 73.4
Reference applications
Brand OE Reference
CHRYSLER 4721820 AC
CHRYSLER 4721820 AE
CHRYSLER 4721820 AF
CHRYSLER 5073069 AA
Maker Cross reference
ATE 24.0128-0148.1
BENDIX BRAKING-TMD BDS1944
BOSCH 0 986 478 109
DELPHI LOCKHEED BG3715
FERODO DDF1214
SANLI SL32907
TEXTAR 92108700
TRW DF4550
CHRYSLER
CARAVAN () MPV 09/1994-12/2000
Vehicle Engine Fuel Date CC KW CV Traction
2.4 1 01/1995-12/2000 2429 110 150 1
2.4 1 01/1995-08/2000 2429 111 151 1
GRAND VOYAGER III VAN (GS) Box Body/MPV 01/1995-12/2001
Vehicle Engine Fuel Date CC KW CV Traction
2.4 1 01/1998-12/2001 2429 111 151 1
3.3 1 01/1995-03/2001 3301 116 158 1
2.5 TD 2 01/1995-03/2001 2499 85 116 1
VOYAGER / GRAND VOYAGER IV (RG) Box Body/MPV 02/2000-02/2008
Vehicle Engine Fuel Date CC KW CV Traction
2.8 CRD 2 04/2004-02/2008 2777 110 150 1
PROWLER () Convertible 09/1998-12/2002
Vehicle Engine Fuel Date CC KW CV Traction
3.5

EGJ

 1 09/2000-12/2002 3518 189 257 2
RAM VAN (RG) Box Body/MPV 11/2005-07/2009
Vehicle Engine Fuel Date CC KW CV Traction
2.8 CRD 2 11/2005-07/2009 2777 110 150 1
VOYAGER III / GRAND VOYAGER III (GS_, NS_) MPV 01/1995-03/2001
Vehicle Engine Fuel Date CC KW CV Traction
3.8

EGH

 1 01/1995-09/2000 3778 121 165 1
3.8

EGH

 1 10/1997-09/2000 3778 131 178 1
3.8

EGH

 1 09/1997-12/2000 3778 134 182 1
3.8 AWD 1 09/1997-12/2000 3778 134 182 3
VOYAGER III VAN (GS_) Box Body/MPV 01/1995-12/2001
Vehicle Engine Fuel Date CC KW CV Traction
2.4 (GSHY52) 1 01/1995-03/2001 2429 111 151 1
3.3 (GSHY52) 1 01/1995-03/2001 3301 116 158 1
3.8 AWD (GSHC52) 1 10/1995-09/1997 3778 122 166 3
2.5 TD (GSHY52, GSHZ52) 2 01/1995-03/2001 2499 85 116 1
VOYAGER IV / GRAND VOYAGER IV / TOWN & COUNTRY IV (RG, RS) MPV 09/1999-12/2008
Vehicle Engine Fuel Date CC KW CV Traction
2.4

EDZ

 1 02/2000-12/2008 2429 108 147 1
2.4

EDZ

 1 04/2003-12/2007 2429 111 151 1
3.0 1 09/1999-12/2000 2972 112 152 1
3.3

EGA

EGM

 1 02/2000-12/2008 3301 128 174 1
3.3

EGM

 1 10/2000-09/2002 3301 131 178 1
3.3 1 09/2000-12/2007 3301 134 182 1
3.3 AWD

EGA

 1 02/2000-12/2008 3301 128 174 3
3.8

EGH

 1 02/2000-12/2008 3778 160 218 1
3.8 AWD

EGH

 1 02/2000-12/2008 3778 160 218 3
3.3 Flex-Fuel 19 02/2000-12/2008 3301 128 174 1
2.5 CRD

EDK

 2 08/2005-12/2008 2499 88 120 1
2.5 CRD

ENJ

 2 02/2000-12/2008 2499 105 141 1
2.8 CRD

ENR

 2 06/2004-12/2008 2777 110 150 1
VOYAGER IV VAN (S_) Box Body/MPV 09/1999-12/2008
Vehicle Engine Fuel Date CC KW CV Traction
3.3 (SYM53, SYH53) 1 10/2000-06/2007 3301 128 174 1
3.8 AWD (SCH53) 1 10/2000-06/2007 3778 160 218 3
DODGE
CARAVAN III VAN (NS) Box Body/MPV 01/1995-03/2001
Vehicle Engine Fuel Date CC KW CV Traction
3.8 1 10/1995-06/2000 3778 122 166 1
3.8 1 10/1995-06/2000 3778 131 178 1
CARAVAN IV (RG_) MPV 02/2000-12/2007
Vehicle Engine Fuel Date CC KW CV Traction
3.3

EGA

 1 02/2000-12/2007 3301 128 174 1
3.3

EGM

 1 04/2001-05/2007 3301 132 179 1
3.3 AWD

EGA

 1 02/2000-12/2007 3301 128 174 3
3.8

EGH

 1 04/2001-05/2007 3778 154 209 1
3.8

EGH

 1 02/2000-12/2007 3778 160 218 1
3.8 AWD

EGH

 1 04/2001-12/2007 3778 153 208 3
3.8 AWD 1 04/2001-05/2007 3778 154 209 3
3.8 AWD

EGH

 1 02/2000-12/2007 3778 160 218 3
GRAND CARAVAN IV (U.S.A.) Van 09/2000-12/2007
Vehicle Engine Fuel Date CC KW CV Traction
3.3

EGA

 1 09/2006-12/2007 3301 126 171 1
