Product 78BD3015-2

Description: Brake disc
Axe: Front
No. of Pieces: 2
Barcode: 8424073144393
Url: https://catalogonuevo.icerbrakes.com/Producto/Details?idProducto=78BD3015-2
Weight (gr.): 13520

R90 Homologation: 90R-02C0452/0118
Measures: Ø280x24x55.2
: Brake Disc Type: Vented; Minimum thickness [mm]: 20; Hole Arrangement/Number: 5; Bolt Hole Circle Ø [mm]: 112; Wheel Hub Diameter [mm]: 68.2

Reference applications

Brand	OE Reference
VW	701 615 301 F
VW	7D0 615 301 A
VW	7D0 615 301 C

Maker	Cross reference
ATE	24.0124-0128.1
BOSCH	0 986 478 846
BREMBO	09.7131.10
BREMBO	09.7131.14
LETEC	LBA018V
ROAD HOUSE	6551.10
SANLI	SL32140
TRW	DF2809

VW

CALIFORNIA T4 (7DJ, 7DK, 70J) Bus 09/1990-08/2004

Vehicle	Engine	Fuel	Date	CC	KW	CV	Traction
2.5		1	05/1998-04/2002	2461	81	110	1
2.5		1	05/1998-04/2003	2461	85	115	1
2.8 VR6		1	07/1996-05/2000	2792	103	140	1
1.9 TD		2	07/1994-04/2002	1896	50	68	1
2.4 D		2	05/1998-04/2002	2370	55	75	1
2.5 TDI		2	05/1998-04/2003	2461	65	88	1
2.5 TDI		2	05/1998-04/2002	2461	75	102	1
2.5 TDI		2	07/1999-04/2003	2461	111	151	1

TRANSPORTER T4 / EUROVAN (70A, 70H, 7DA, 7DH) Van 07/1990-04/2003

Vehicle	Engine	Fuel	Date	CC	KW	CV	Traction
2.0	AAC	1	07/1990-04/2003	1968	62	84	1
2.5	AAF ACU AEN AEU	1	11/1990-04/2003	2461	81	110	1
2.5	AET APL AVT	1	08/1996-04/2003	2461	85	115	1
2.5 Syncro	ACU AEU	1	11/1992-11/2001	2461	81	110	3
2.5 Syncro	AET APL AVT	1	08/1996-04/2003	2461	85	115	3
2.8 VR6	AES	1	05/1996-05/2000	2792	103	140	1
2.8 VR6	AMV AXK	1	06/2000-04/2003	2792	150	204	1
2.5 TDI	AJT AYY	2	12/1998-04/2003	2461	65	88	1
2.5 TDI	ACV AUF AYC	2	09/1995-04/2003	2461	75	102	1
2.5 TDI	AHY AXG	2	09/2000-04/2003	2461	111	151	1
2.5 TDI Syncro	ACV AXL	2	09/1995-04/2003	2461	75	102	3

TRANSPORTER T4 / EUROVAN (70E, 70L, 70M, 7DE, 7DL, 7DM) Platform/Chassis 07/1990-04/2003

Vehicle	Engine	Fuel	Date	CC	KW	CV	Traction
2.5	AAF ACU AEN AEU	1	11/1990-04/2003	2461	81	110	1
2.5	AET APL AVT	1	08/1996-04/2003	2461	85	115	1
2.5 Syncro	AAF ACU AEU	1	11/1992-11/2001	2461	81	110	3
2.5 Syncro	AET APL AVT	1	08/1996-04/2003	2461	85	115	3
2.8	AES	1	05/1996-05/2000	2792	103	140	1
2.8 VR6	AMV	1	06/2000-04/2003	2792	150	204	1
2.5 TDI	AJT AYY	2	05/1998-04/2003	2461	65	88	1
2.5 TDI	ACV AUF AYC	2	09/1995-04/2003	2461	75	102	1
2.5 TDI Syncro	ACV AXL	2	05/1998-04/2003	2461	75	102	3

TRANSPORTER T4 / EUROVAN (70B, 70C, 7DB, 7DK, 70J, 70K, 7DC, 7DJ) Bus 09/1990-10/2004

Vehicle	Engine	Fuel	Date	CC	KW	CV	Traction
2.5	AAF ACU AEN AEU	1	09/1990-06/2003	2461	81	110	1
2.5	AET APL AVT	1	08/1996-04/2003	2461	85	115	1
2.5 Syncro	AAF ACU AEU	1	08/1992-04/2003	2461	81	110	3
2.5 Syncro	AET APL AVT	1	07/1996-04/2003	2461	85	115	3
2.8		1	01/1996-04/1996	2792	103	140	1
2.8 VR6	AES	1	11/1995-04/2000	2792	103	140	1
2.8 VR6	AMV AXK	1	04/2000-04/2003	2792	150	204	1
2.5 TDI	AJT AYY	2	05/1998-04/2003	2461	65	88	1
2.5 TDI	ACV AUF AYC	2	09/1995-04/2003	2461	75	102	1
2.5 TDI	AHY AXG	2	05/1998-04/2003	2461	111	151	1
2.5 TDI Syncro	ACV AXL	2	01/1996-04/2003	2461	75	102	3
