Product 78BD3017-1

Description
Brake disc
Axe
Front
No. of Pieces
1
Barcode
EAN13 Code
8424073144409
QR Code
Url
https://catalogonuevo.icerbrakes.com/Producto/Details?idProducto=78BD3017-1
Weight (gr.)
9110
R90 Homologation
R90 90R-02C0100/1732
Measures
Ø281x20x80.5
Brake Disc Type: solid
Minimum thickness [mm]: 18
Hole Arrangement/Number: 5
Bolt Hole Circle Ø [mm]: 115
Wheel Hub Diameter [mm]: 91
Reference applications
Brand OE Reference
VW 281 615 283 A
Maker Cross reference
ATE 24.0120-0114.1
BOSCH 0 986 478 138
BREMBO 08.2982.10
ROAD HOUSE 6543.00
TRW DF1523
RENAULT
VEL SATIS (BJ0_) Hatchback 06/2002-
Vehicle Engine Fuel Date CC KW CV Traction
2.0 dCi (BJ03, BJ0B)

M9R 760

M9R 762

M9R 763

 2 01/2006- 1995 127 173 1
2.0 dCi (BJ03)

M9R 760

 2 08/2005- 1995 110 150 1
3.0 dCi (BJ0S)

P9X 715

 2 06/2006-08/2009 2958 133 181 1
VW
K 70 (48) Saloon 08/1970-10/1974
Vehicle Engine Fuel Date CC KW CV Traction
1.8

DC

 1 08/1973-10/1974 1807 74 100 1
LT 28-35 / LT 28-50 (281-363) Bus 04/1975-06/1996
Vehicle Engine Fuel Date CC KW CV Traction
2.0

CH

 1 04/1975-09/1983 1984 55 75 2
2.4

1E

 1 08/1988-12/1995 2383 70 95 2
2.4

DL

 1 12/1982-07/1992 2384 66 90 2
2.4 i

1E

 1 08/1989-06/1996 2383 69 94 2
2.4 D

1S

ACT

 2 08/1989-06/1996 2383 51 70 2
2.4 D

CP

DW

 2 01/1979-07/1992 2383 55 75 2
2.4 TD

1G

 2 08/1989-08/1992 2384 68 92 2
2.4 TD

ACL

 2 09/1992-06/1996 2384 70 95 2
2.4 TD

DV

 2 12/1982-07/1989 2384 75 102 2
LT 28-35 / LT 28-50 (281-363) Van 04/1975-06/1996
Vehicle Engine Fuel Date CC KW CV Traction
2.0

CH

 1 04/1975-09/1983 1984 55 75 2
2.4

DL

 1 12/1982-07/1992 2384 66 90 2
2.4 i

1E

 1 08/1989-06/1996 2383 69 94 2
2.4 D

1S

ACT

 2 07/1990-05/1996 2383 51 69 2
2.4 D

CP

DW

 2 01/1979-07/1992 2383 55 75 2
2.4 D 2 12/1982-07/1992 2383 57 78 2
2.4 TD

1G

 2 08/1988-08/1992 2384 68 92 2
2.4 TD

ACL

 2 06/1992-05/1996 2384 70 95 2
2.4 TD

DV

 2 02/1986-08/1992 2384 75 102 2
2.4 TD Syncro

ACL

 2 08/1992-04/1996 2384 70 95 3
2.7 D

CG

 2 11/1975-01/1980 2702 48 65 2
LT 28-35 / LT 28-50 (281-363) Platform/Chassis 04/1975-06/1996
Vehicle Engine Fuel Date CC KW CV Traction
2.0

CH

 1 04/1975-09/1983 1984 55 75 2
2.4

DL

 1 12/1982-07/1992 2384 66 90 2
2.4 i

1E

 1 03/1994-06/1996 2383 69 94 2
2.4 Syncro

1E

 1 08/1992-07/1994 2383 70 95 3
2.4 Syncro

DL

 1 08/1991-07/1992 2384 66 90 3
2.4 D

1S

ACT

 2 08/1990-06/1996 2383 51 69 2
2.4 D

CP

DW

 2 12/1978-02/1991 2383 55 75 2
2.4 D 2 12/1982-07/1992 2383 57 78 2
2.4 D Syncro

1S

 2 08/1991-07/1992 2383 51 69 3
2.4 D Syncro

DW

 2 08/1991-07/1992 2383 55 75 3
2.4 TD

1G

 2 08/1990-08/1992 2384 68 92 2
2.4 TD

ACL

 2 08/1992-06/1996 2384 70 95 2
2.4 TD

DV

 2 12/1982-09/1993 2384 75 102 2
2.4 TD Syncro

1G

 2 08/1991-07/1992 2384 68 92 3
2.4 TD Syncro

ACL

 2 08/1992-04/1996 2384 70 95 3
2.4 TD Syncro

DV

 2 08/1991-07/1992 2384 75 102 3
2.7 D

CG

 2 11/1975-01/1980 2702 48 65 2
LT 40-55 (291-512) Van 04/1975-06/1996
Vehicle Engine Fuel Date CC KW CV Traction
2.0

CH

 1 04/1975-09/1983 1984 55 75 2
2.4

DL

 1 12/1982-07/1992 2384 66 90 2
2.4 4WD

DL

 1 12/1982-07/1992 2384 66 90 3
2.4 i

1E

 1 01/1993-06/1996 2383 69 94 2
2.4 D

1S

ACT

 2 07/1990-05/1996 2383 51 69 2
2.4 D

CP

DW

 2 01/1979-07/1992 2383 55 75 2
2.4 D 2 12/1982-07/1992 2383 57 78 2
2.4 D 4WD

DW

 2 12/1982-07/1991 2383 55 75 3
2.4 TD

1G

 2 08/1988-08/1992 2384 68 92 2
2.4 TD

ACL

 2 06/1992-05/1996 2384 70 95 2
2.4 TD

DV

 2 02/1986-08/1992 2384 75 102 2
2.4 TD 4WD

DV

 2 12/1982-07/1991 2384 75 102 3
2.4 TD Syncro

ACL

 2 08/1992-04/1996 2384 70 95 3
LT 40-55 (293-909) Platform/Chassis 04/1975-06/1996
Vehicle Engine Fuel Date CC KW CV Traction
2.0

CH

 1 04/1975-09/1983 1984 55 75 2
2.4

1E

 1 08/1988-07/1989 2383 70 95 2
2.4

DL

 1 08/1985-07/1989 2384 66 90 2
2.4 i

1E

 1 03/1994-06/1996 2383 69 94 2
2.4 Syncro

DL

 1 12/1982-07/1989 2384 66 90 3
2.4 D

1S

ACT

 2 08/1990-06/1996 2383 51 69 2
2.4 D

CP

DW

 2 12/1978-02/1991 2383 55 75 2
2.4 D 2 12/1982-07/1992 2383 57 78 2
2.4 TD

1G

 2 08/1988-07/1991 2384 68 92 2
2.4 TD

ACL

 2 08/1992-06/1996 2384 70 95 2
2.4 TD

DV

 2 12/1982-09/1993 2384 75 102 2
2.4 TD Syncro

1G

 2 08/1991-07/1992 2384 68 92 3
2.4 TD Syncro

ACL

 2 08/1992-04/1996 2384 70 95 3
2.4 TD Syncro

DV

 2 12/1982-07/1992 2384 75 102 3
