Product 78BD3108-2
- Description
- Brake disc
- Axe
- Front
- No. of Pieces
- 2
- Barcode
-
8424073144515
- Url
- https://catalogonuevo.icerbrakes.com/Producto/Details?idProducto=78BD3108-2
- Weight (gr.)
- 9832
- R90 Homologation
-
90R-02C0538/0116
- Measures
- Ø258x22x44
-
Brake Disc Type:
Vented -
Minimum thickness [mm]:
19.8 -
Hole Arrangement/Number:
4 -
Bolt Hole Circle Ø [mm]:
100 -
Wheel Hub Diameter [mm]:
61
| Brand | OE Reference |
|---|---|
| RENAULT | 40 20 622 12R |
| RENAULT | 40 20 631 49R |
| RENAULT | 40 20 668 39R |
| Maker | Cross reference |
|---|---|
| BENDIX-ROULUNDS | 522173 |
| BREMBO | 09.C285.1X |
| BREMBO | 09.C285.75 |
| FERODO | DDF2327C |
| HELLA-PAGID | 8DD 355 119-461 |
| LETEC | LBR762V |
| MINTEX | MDC2525 |
| ROAD HOUSE | 61535.10 |
| SANLI | SL37672 |
| TEXTAR | 92255203 |
| TRW | DF6186 |
| TRW | DF6534 |
| Vehicle | Engine | Fuel | Date | CC | KW | CV | Traction |
|---|---|---|---|---|---|---|---|
| 1.0 SCe 75 |
B4D 400 B4D 401 |
1 | 01/2017- | 998 | 54 | 73 | 1 |
| 1.0 TCe 100 |
H4D 450 H4D 460 |
1 | 11/2019- | 999 | 74 | 101 | 1 |
| 1.6 |
K7M 812 |
1 | 06/2013-08/2016 | 1598 | 63 | 86 | 1 |
| 1.6 16V |
K4M 842 |
1 | 01/2013- | 1598 | 77 | 105 | 1 |
| TCe 90 (L8MA, L8M1, L8AC) |
H4B 400 H4B 408 |
1 | 10/2012- | 898 | 66 | 90 | 1 |
| 1.0 LPG |
H4D 450 H4D 460 |
18 | 11/2019- | 999 | 74 | 101 | 1 |
| 1.2 LPG |
D4F 734 |
18 | 02/2013- | 1149 | 53 | 72 | 1 |
| 1.2 LPG |
D4F 734 |
18 | 10/2012- | 1149 | 55 | 75 | 1 |
| TCe 90 LPG |
H4B 405 H4B 410 |
18 | 09/2015- | 898 | 66 | 90 | 1 |
| 1.5 Blue dCi 95 (L8JL) |
K9K 872 |
2 | 05/2018- | 1461 | 70 | 95 | 1 |
| 1.5 dCi |
K9K 830 K9K 838 |
2 | 01/2013- | 1461 | 63 | 84 | 1 |
| 1.5 dCi |
K9K 612 K9K 626 |
2 | 10/2012- | 1461 | 66 | 90 | 1 |
| 1.5 dCi / Blue dCi 75 |
K9K 612 K9K 626 K9K 872 |
2 | 10/2012- | 1461 | 55 | 75 | 1 |
| Vehicle | Engine | Fuel | Date | CC | KW | CV | Traction |
|---|---|---|---|---|---|---|---|
| 1.0 SCe 75 |
B4D 400 B4D 401 |
1 | 12/2016- | 998 | 54 | 73 | 1 |
| 1.0 TCe 100 |
H4D 450 H4D 460 |
1 | 11/2019- | 999 | 74 | 101 | 1 |
| 1.2 |
D4F 732 |
1 | 05/2015- | 1149 | 54 | 73 | 1 |
| 1.2 |
D4F 732 |
1 | 02/2013- | 1149 | 55 | 75 | 1 |
| 1.6 |
K7M 812 |
1 | 06/2013- | 1598 | 62 | 84 | 1 |
| TCe 90 (K8M1, K8MA, K8AC) |
H4B 400 H4B 408 |
1 | 02/2013- | 898 | 66 | 90 | 1 |
| 1.0 LPG (K8ML) |
H4D 450 H4D 460 |
18 | 11/2019- | 999 | 74 | 101 | 1 |
| 1.2 LPG |
D4F 734 |
18 | 02/2013- | 1149 | 53 | 72 | 1 |
| 1.2 LPG |
D4F 734 |
18 | 02/2013- | 1149 | 55 | 75 | 1 |
| TCe 90 LPG |
H4B 405 H4B 410 |
18 | 09/2015- | 898 | 66 | 90 | 1 |
| 1.5 Blue dCi 95 (K8JL) |
K9K 872 |
2 | 10/2018- | 1461 | 70 | 95 | 1 |
| 1.5 dCi |
K9K 612 K9K 626 |
2 | 02/2013- | 1461 | 55 | 75 | 1 |
| 1.5 dCi |
K9K 830 K9K 838 |
2 | 02/2013- | 1461 | 63 | 84 | 1 |
| 1.5 dCi |
K9K 612 K9K 626 |
2 | 02/2013- | 1461 | 66 | 90 | 1 |
| Vehicle | Engine | Fuel | Date | CC | KW | CV | Traction |
|---|---|---|---|---|---|---|---|
| 1.0 SCe 75 (B8JC, B8JD) |
B4D 400 B4D 401 |
1 | 12/2016- | 999 | 54 | 73 | 1 |
| 1.0 TCe 100 (B8ML) |
H4D 450 H4D 460 |
1 | 11/2019- | 999 | 74 | 101 | 1 |
| 1.6 | 1 | 11/2012- | 1598 | 63 | 86 | 1 | |
| TCe 90 (B8M1, B8MA, B8AC) |
H4B 400 |
1 | 10/2012- | 898 | 66 | 90 | 1 |
| 1.0 LPG (B8ML) |
H4D 450 H4D 460 |
18 | 11/2019- | 999 | 74 | 101 | 1 |
| TCe 90 LPG (B8M1) | 18 | 09/2015- | 898 | 66 | 90 | 1 | |
| 1.5 Blue dCi 95 (B8JL) |
K9K 872 |
2 | 08/2018- | 1461 | 70 | 95 | 1 |
| 1.5 dCi |
K9K 830 |
2 | 01/2013- | 1461 | 63 | 84 | 1 |
| 1.5 dCi |
K9K 612 K9K 626 |
2 | 10/2012- | 1461 | 66 | 90 | 1 |
| 1.5 dCi 75 / Blue dCi 75 (B8JW, B8M4, B8AH, B8M7, B8M6) |
K9K 612 K9K 626 K9K 838 K9K 872 |
2 | 10/2012- | 1461 | 55 | 75 | 1 |
| Vehicle | Engine | Fuel | Date | CC | KW | CV | Traction |
|---|---|---|---|---|---|---|---|
| 0.9 TCe 90 (BHNF, BHMA, BHMH, BHJK, BHJR) |
H4B 400 H4B 408 |
1 | 11/2012-08/2021 | 898 | 66 | 90 | 1 |
| 1.2 16V |
D4F 728 D4F 740 |
1 | 11/2012-08/2021 | 1149 | 54 | 73 | 1 |
| 1.2 TCe 120 (BHAU) |
H5F 408 H5F 412 |
1 | 01/2016-08/2021 | 1197 | 87 | 118 | 1 |
| 1.2 TCe 120 (BHM0) |
H5F 403 |
1 | 03/2013-08/2021 | 1197 | 88 | 120 | 1 |
| 1.6 RS (BHJ4, BHJ6, BHMM) |
M5M 400 M5M 401 M5M 450 |
1 | 03/2013-08/2021 | 1618 | 147 | 200 | 1 |
| 1.6 RS Trophy (BHJ4, BHJ6) |
M5M 401 |
1 | 03/2015-08/2021 | 1618 | 162 | 220 | 1 |
| 0.9 TCe 90 LPG |
H4B 410 |
18 | 06/2016-08/2021 | 898 | 66 | 90 | 1 |
| 1.2 LPG 16V |
D4F 740 |
18 | 11/2012-06/2015 | 1149 | 54 | 73 | 1 |
| 1.0 Campus Flex | 19 | 11/2012- | 999 | 59 | 80 | 1 | |
| 1.5 dCi 110 |
K9K 646 |
2 | 06/2016-08/2021 | 1461 | 81 | 110 | 1 |
| 1.5 dCi 75 |
K9K 612 K9K 628 |
2 | 11/2012-08/2021 | 1461 | 55 | 75 | 1 |
| 1.5 dCi 90 |
K9K 608 K9K 628 K9K 638 |
2 | 11/2012-08/2021 | 1461 | 66 | 90 | 1 |
| Vehicle | Engine | Fuel | Date | CC | KW | CV | Traction |
|---|---|---|---|---|---|---|---|
| 0.9 TCe 90 |
H4B 400 H4B 408 |
1 | 01/2013-08/2021 | 898 | 66 | 90 | 1 |
| 1.2 16V |
D4F 740 |
1 | 01/2013-08/2021 | 1149 | 54 | 73 | 1 |
| 1.2 TCe 120 (KHAU) |
H5F 408 H5F 412 |
1 | 01/2016-08/2021 | 1197 | 87 | 118 | 1 |
| 1.2 TCe 120 (KHM0) |
H5F 403 |
1 | 03/2013-08/2021 | 1197 | 88 | 120 | 1 |
| 1.5 dCi 110 |
K9K 646 |
2 | 06/2016-08/2021 | 1461 | 81 | 110 | 1 |
| 1.5 dCi 75 |
K9K 612 K9K 628 |
2 | 01/2013-08/2021 | 1461 | 55 | 75 | 1 |
| 1.5 dCi 90 (KHN3, KHN4) |
K9K 608 K9K 628 K9K 629 |
2 | 11/2012-08/2021 | 1461 | 66 | 90 | 1 |
| Vehicle | Engine | Fuel | Date | CC | KW | CV | Traction |
|---|---|---|---|---|---|---|---|
| 0.9 TCe 90 |
H4B 400 |
1 | 01/2014-08/2021 | 898 | 66 | 90 | 1 |
| 1.5 dCi 75 |
K9K 612 |
2 | 01/2014-08/2021 | 1461 | 55 | 75 | 1 |
| 1.5 dCi 90 |
K9K 608 |
2 | 01/2014-08/2021 | 1461 | 66 | 90 | 1 |
| Vehicle | Engine | Fuel | Date | CC | KW | CV | Traction |
|---|---|---|---|---|---|---|---|
| 0.9 TCe 75 | 1 | 01/2014-08/2021 | 898 | 56 | 76 | 1 | |
| 0.9 TCe 90 |
H4B 400 H4B 408 |
1 | 01/2014-08/2021 | 898 | 66 | 90 | 1 |
| 1.2 16V | 1 | 01/2014-08/2021 | 1149 | 55 | 75 | 1 | |
| 1.5 dCi 75 |
K9K 612 |
2 | 01/2014-08/2021 | 1461 | 55 | 75 | 1 |
| 1.5 dCi 90 (BHAJ) |
K9K 608 K9K 628 K9K 629 |
2 | 01/2014-08/2021 | 1461 | 66 | 90 | 1 |
| Vehicle | Engine | Fuel | Date | CC | KW | CV | Traction |
|---|---|---|---|---|---|---|---|
| 1.0 SCe 65 (B7MG) | 1 | 11/2021- | 999 | 49 | 67 | 1 | |
| 1.0 SCe 65 (B7MR) |
B4D 409 |
1 | 11/2019- | 999 | 48 | 65 | 1 |
| 1.0 SCe 75 (B7M5) |
B4D 409 |
1 | 06/2019- | 999 | 53 | 72 | 1 |
| 1.0 TCe 100 (B7MT) |
H4D 450 H4D 452 H4D 460 H4D 472 |
1 | 06/2019- | 999 | 74 | 101 | 1 |
| 1.0 TCe 90 (B7MT) | 1 | 08/2020- | 999 | 67 | 91 | 1 | |
| 1.0 LPG (B7MT) | 18 | 11/2021- | 999 | 67 | 91 | 1 | |
| 1.0 LPG (B7MT) |
H4D 450 H4D 452 H4D 460 H4D 472 |
18 | 06/2019- | 999 | 74 | 101 | 1 |
| 1.5 Blue dCi 115 (B7AD) |
K9K 854 K9K 862 K9K 872 |
2 | 06/2019- | 1461 | 85 | 116 | 1 |
| 1.5 Blue dCi 85 (B7AG) |
K9K 854 K9K 872 |
2 | 06/2019- | 1461 | 63 | 86 | 1 |
| Vehicle | Engine | Fuel | Date | CC | KW | CV | Traction |
|---|---|---|---|---|---|---|---|
| 1.6 |
K7M 812 |
1 | 11/2013- | 1598 | 59 | 80 | 1 |
| 1.6 |
K7M 812 |
1 | 04/2014- | 1598 | 60 | 82 | 1 |
| 1.6 |
H4M 438 |
1 | 09/2016- | 1598 | 83 | 113 | 1 |
| 1.6 (L8A9, L8J0) |
K4M 842 K4M 845 |
1 | 04/2014- | 1598 | 75 | 102 | 1 |
| 1.2 16V LPG |
D4F 732 D4F 734 |
18 | 11/2013- | 1149 | 53 | 72 | 1 |
| 1.5 dCi |
K9K 838 |
2 | 12/2013- | 1461 | 62 | 84 | 1 |
| 1.5 dCi | 2 | 12/2013- | 1461 | 66 | 90 | 1 |
| Vehicle | Engine | Fuel | Date | CC | KW | CV | Traction |
|---|---|---|---|---|---|---|---|
| 1.2 16V |
D4F 732 D4F 734 |
1 | 12/2013- | 1149 | 54 | 73 | 1 |
| 1.6 |
K7M 812 |
1 | 12/2013- | 1598 | 59 | 80 | 1 |
| 1.6 (K8A9) | 1 | 12/2013- | 1598 | 78 | 106 | 1 | |
| 1.2 16V LPG |
D4F 732 D4F 734 |
18 | 12/2013- | 1149 | 53 | 72 | 1 |
| 1.5 dCi |
K9K 838 |
2 | 12/2013- | 1461 | 62 | 84 | 1 |
| 1.5 dCi | 2 | 12/2013- | 1461 | 66 | 90 | 1 |
| Vehicle | Engine | Fuel | Date | CC | KW | CV | Traction |
|---|---|---|---|---|---|---|---|
| 1.0 SCe 75 (B8JD) | 1 | 12/2019- | 999 | 54 | 73 | 1 | |
| 1.6 |
K7M 812 |
1 | 11/2013- | 1598 | 59 | 80 | 1 |
| 1.6 | 1 | 11/2013- | 1598 | 60 | 82 | 1 | |
| 1.6 | 1 | 11/2013- | 1598 | 61 | 83 | 1 | |
| 1.6 | 1 | 04/2016- | 1598 | 63 | 86 | 1 | |
| 1.6 | 1 | 05/2015- | 1598 | 66 | 90 | 1 | |
| 1.6 (B8JA) |
H4M 429 H4M 438 |
1 | 09/2016- | 1598 | 83 | 113 | 1 |
| 1.6 16V | 1 | 04/2014- | 1598 | 75 | 102 | 1 | |
| TCe 90 (B8MA, B8M1, B8JR) | 1 | 09/2015- | 898 | 66 | 90 | 1 | |
| 1.6 Flex (B8A6) | 19 | 03/2014-07/2018 | 1598 | 78 | 106 | 1 | |
| 1.5 dCi |
K9K 830 |
2 | 12/2013- | 1461 | 62 | 84 | 1 |
| 1.5 dCi (B8AL) | 2 | 01/2017- | 1461 | 66 | 90 | 1 |
| Vehicle | Engine | Fuel | Date | CC | KW | CV | Traction |
|---|---|---|---|---|---|---|---|
| 0.9 TCe |
H4B 400 |
1 | 06/2014- | 898 | 66 | 90 | 1 |
| 1.0 SCe (L8JC) | 1 | 01/2017-11/2019 | 998 | 54 | 73 | 1 | |
| 1.6 16V |
K4M 842 |
1 | 12/2013- | 1598 | 77 | 105 | 1 |
| Vehicle | Engine | Fuel | Date | CC | KW | CV | Traction |
|---|---|---|---|---|---|---|---|
| 0.9 TCe 110 |
H4B 401 |
1 | 11/2016- | 898 | 80 | 109 | 2 |
| 0.9 TCe 90 (BCM9, BCM2) |
H4B 401 |
1 | 09/2014- | 898 | 66 | 90 | 2 |
| 0.9 TCe 95 |
H4B 453 |
1 | 03/2019- | 898 | 68 | 92 | 2 |
| 1.0 SCe 65 (BCMJ) |
B4D 403 |
1 | 03/2019- | 999 | 48 | 65 | 2 |
| 1.0 SCe 70 |
H4D 400 |
1 | 09/2014- | 999 | 52 | 71 | 2 |
| 1.0 SCe 70 (BCMB) |
H4D 400 |
1 | 09/2015- | 999 | 51 | 69 | 2 |
| 1.0 SCe 75 |
B4D 403 |
1 | 03/2019- | 999 | 54 | 73 | 2 |
| 0.9 TCe 90 LPG (BCMD) |
H4B 451 |
18 | 08/2018- | 898 | 66 | 90 | 2 |
| Z.E: (BCA1) | 11 | 05/2020- | 60 | 82 | 2 |
| Vehicle | Engine | Fuel | Date | CC | KW | CV | Traction |
|---|---|---|---|---|---|---|---|
| 0.9 (453.044, 453.053) |
H4B 409 M 281.910 |
1 | 11/2014- | 898 | 66 | 90 | 2 |
| 0.9 Brabus (453.062) |
M 281.910 |
1 | 07/2016- | 898 | 80 | 109 | 2 |
| 1.0 (453.041) |
M 281.920 |
1 | 11/2014- | 999 | 45 | 60 | 2 |
| 1.0 (453.042, 453.043) |
H4DA401 M 281.920 |
1 | 07/2014- | 999 | 52 | 71 | 2 |
| electric drive (453.091) | 11 | 05/2017- | 60 | 82 | 2 | ||
| electric drive / EQ (453.491) | 11 | 05/2017- | 41 | 56 | 2 |
| Vehicle | Engine | Fuel | Date | CC | KW | CV | Traction |
|---|---|---|---|---|---|---|---|
| 0.9 (453.344, 453.353) |
M 281.910 |
1 | 09/2014- | 898 | 66 | 90 | 2 |
| 0.9 Brabus (453.362) |
M 281.910 |
1 | 07/2016- | 898 | 80 | 109 | 2 |
| 1.0 (453.341) |
M 281.920 |
1 | 11/2014- | 999 | 45 | 60 | 2 |
| 1.0 (453.342, 453.343) |
M 281.920 |
1 | 07/2014- | 999 | 52 | 71 | 2 |
| electric drive (453.391) | 11 | 05/2017- | 60 | 82 | 2 | ||
| electric drive / EQ (453.491) | 11 | 05/2017- | 41 | 56 | 2 |
| Vehicle | Engine | Fuel | Date | CC | KW | CV | Traction |
|---|---|---|---|---|---|---|---|
| 0.9 (453.444, 453.453) |
M 281.910 |
1 | 09/2015- | 898 | 66 | 90 | 2 |
| 0.9 Brabus (453.462) |
M 281.910 |
1 | 07/2016- | 898 | 80 | 109 | 2 |
| 1.0 (453.442, 453.443) |
M 281.920 |
1 | 09/2015- | 999 | 52 | 71 | 2 |
| electric drive (453.491) | 11 | 05/2017- | 60 | 82 | 2 | ||
| electric drive / EQ (453.491) | 11 | 05/2017- | 41 | 56 | 2 |
