Product 78BD3113-1

Description
Brake disc
Axe
Front
No. of Pieces
1
Barcode
EAN13 Code
8424073144539
QR Code
Url
https://catalogonuevo.icerbrakes.com/Producto/Details?idProducto=78BD3113-1
Weight (gr.)
8040
Measures
Ø258x16x92.1
Brake Disc Type: solid
Minimum thickness [mm]: 13
Hole Arrangement/Number: 5
Bolt Hole Circle Ø [mm]: 112
Wheel Hub Diameter [mm]: 67.9
Reference applications
Brand OE Reference
VW 251 407 617 D
VW 251 407 617 F
VW 251 407 617 G
VW 251 407 617 K
VW 251 407 617 L
VW 251 407 617 M
VW 251 407 617 N
Maker Cross reference
ATE 24.0116-0104.1
BOSCH 0 986 478 224
BREMBO 08.5177.10
BREMBO 08.5177.20
ROAD HOUSE 6415.00
SANLI SL21306
TRW DF2587
VW
TRANSPORTER T3 (24_) Platform/Chassis 05/1979-12/1992
Vehicle Engine Fuel Date CC KW CV Traction
1.6 1 04/1983-09/1990 1584 50 68 1
1.9

DF

 1 09/1982-07/1992 1913 44 60 2
1.9

DG

 1 08/1982-07/1992 1913 57 78 2
1.9

DH

 1 10/1984-02/1989 1913 61 83 2
2.1

MV

 1 08/1985-07/1992 2109 70 95 2
2.1

DJ

 1 03/1986-07/1992 2109 82 112 2
2.1 i

SS

 1 07/1989-07/1992 2109 68 92 2
1.6 D

CS

 2 01/1981-07/1987 1588 37 50 2
1.6 TD

JX

 2 10/1984-07/1992 1588 51 70 2
1.6 TD

JX

 2 08/1985-07/1987 1588 51 69 2
1.7 D

KY

 2 08/1985-07/1992 1715 42 57 2
1.7 D

KY

 2 08/1985-07/1987 1715 42 57 2
TRANSPORTER T3 (24_, 25_) Van 05/1979-12/1992
Vehicle Engine Fuel Date CC KW CV Traction
1.6 1 04/1983-09/1990 1584 50 68 1
1.6 1 05/1979-07/1989 1584 54 73 1
1.9

DF

 1 10/1982-07/1992 1913 44 60 2
1.9

DG

 1 10/1982-07/1992 1913 57 78 2
1.9

DH

 1 10/1984-02/1989 1913 61 83 2
1.9

GW

 1 08/1983-02/1989 1913 66 90 2
2.1

MV

 1 08/1985-07/1992 2109 70 95 2
2.1

DJ

 1 03/1986-07/1992 2109 82 112 2
2.1 i

SS

 1 07/1989-07/1992 2109 68 92 2
1.6 D

CS

 2 01/1981-07/1987 1588 37 50 2
1.6 TD

JX

 2 10/1984-07/1992 1588 51 69 2
1.7 D

KY

 2 08/1984-07/1992 1715 42 57 2
1.7 D 2 08/1985-07/1987 1715 42 57 2
TRANSPORTER T3 / CARAVELLE / VANAGON (25_) Bus 05/1979-07/1992
Vehicle Engine Fuel Date CC KW CV Traction
1.9

DF

 1 08/1982-07/1992 1913 44 60 2
1.9

DG

 1 08/1982-07/1992 1913 57 78 2
2.1

SR

 1 10/1986-07/1992 2109 64 87 2
2.1

MV

 1 08/1985-07/1992 2109 70 95 2
2.1

DJ

 1 08/1984-07/1992 2109 82 112 2
2.1 Cat

MV

 1 06/1989-07/1992 2109 70 95 2
2.1 i

SS

 1 07/1989-07/1992 2109 68 92 2
1.6 D

CS

 2 01/1981-07/1987 1588 37 50 2
1.6 TD

JX

 2 08/1984-07/1992 1588 51 70 2
1.7 D

KY

 2 10/1986-07/1992 1716 42 57 2
