Product 78BD3268-2

Description
Brake disc
Axe
Rear
No. of Pieces
2
Barcode
EAN13 Code
8424073144720
QR Code
Url
https://catalogonuevo.icerbrakes.com/Producto/Details?idProducto=78BD3268-2
Weight (gr.)
8544
R90 Homologation
R90 90R-02C0415/0088
Measures
Ø280x10x40
Brake Disc Type: solid
Minimum thickness [mm]: 8
Hole Arrangement/Number: 5
Bolt Hole Circle Ø [mm]: 114.3
Wheel Hub Diameter [mm]: 72
Reference applications
Brand OE Reference
MAZDA GF3Y-26-251
MAZDA GF3Y-26-251A
MAZDA GFYY-26-251
MAZDA N123-26-251
MAZDA N123-26-251A
MAZDA NF47-26-251
Maker Cross reference
ATE 24.0110-0302.1
BOSCH 0 986 479 131
BREMBO 08.A112.10
DELPHI LOCKHEED BG3875
LETEC LBMZ020S
ROAD HOUSE 6881.00
SANLI SL17039
TRW DF4442
BESTURN (FAW)
B50 () Saloon 05/2009-
Vehicle Engine Fuel Date CC KW CV Traction
1.6

BWH

 1 05/2009- 1595 76 103 1
B70 () Saloon 01/2006-12/2014
Vehicle Engine Fuel Date CC KW CV Traction
1.8

CA4GD5

 1 06/2012-12/2014 1798 102 139 1
B70 () Saloon 05/2014-
Vehicle Engine Fuel Date CC KW CV Traction
1.8 1 05/2014-12/2020 1796 137 186 1
2.0

CA4GD1

 1 05/2014-12/2020 1999 108 147 1
X80 () SUV 05/2013-
Vehicle Engine Fuel Date CC KW CV Traction
2.0 1 05/2013- 1999 108 147 1
2.3 1 05/2013-12/2014 2259 118 160 1
ISUZU
IMPULSE II () Coupe 01/1990-12/1993
Vehicle Engine Fuel Date CC KW CV Traction
1.6

4XE1-V

 1 01/1990-12/1993 1588 71 97 1
MAZDA
6 / ATENZA Station Wagon (GY) Estate 01/2002-02/2008
Vehicle Engine Fuel Date CC KW CV Traction
1.8

L813

 1 08/2002-08/2007 1798 88 120 1
2.0 (GYEW)

LF17

LF18

 1 08/2002-08/2007 1999 104 141 1
2.0 (GYEW)

LFF7

 1 03/2005-08/2007 1999 108 147 1
2.3 (GY3W, GY10)

L3C1

 1 01/2002-02/2008 2261 122 166 1
2.3 AWD (GY3W)

L3C1

 1 11/2002-08/2007 2261 119 162 3
2.0 CiTD 2 10/2002-02/2005 1998 89 121 2
2.0 CiTD 2 10/2002-02/2005 1998 100 136 2
2.0 DI (GY19)

RF5C

 2 08/2002-08/2007 1998 89 121 1
2.0 DI (GY19)

RF5C

 2 08/2002-02/2005 1998 100 136 1
2.0 DI (GY19)

RF7J

 2 06/2005-08/2007 1998 105 143 1
6 / ATENZA (GG) Saloon 06/2002-12/2008
Vehicle Engine Fuel Date CC KW CV Traction
1.8

L813

L829

 1 08/2002-08/2007 1798 88 120 1
2.0 (GGEP, GG10)

LF17

LF18

 1 06/2002-08/2007 1999 104 141 1
2.0 (GGEP, GG10)

LFF7

 1 03/2005-08/2007 1999 108 147 1
2.3 1 07/2003-02/2005 2261 119 162 1
2.3

L3C1

 1 03/2005-07/2007 2261 120 163 1
2.3 (GG3P)

L3C1

 1 06/2002-08/2007 2261 122 166 1
2.3 MPS Turbo (GG3P)

L3KG

 1 12/2005-08/2007 2261 191 260 3
2.0 DI (GG14)

RF5C

 2 08/2002-08/2007 1998 89 121 1
2.0 DI (GG14)

RF5C

 2 06/2002-08/2007 1998 100 136 1
2.0 DI (GG14)

RF7J

 2 06/2005-08/2007 1998 105 143 1
6 / ATENZA (GG) Hatchback 08/2002-12/2008
Vehicle Engine Fuel Date CC KW CV Traction
1.8

L813

 1 08/2002-08/2007 1798 88 120 1
2.0 (GGES)

LF17

LF18

 1 08/2002-08/2007 1999 104 141 1
2.0 (GGES)

LFF7

 1 03/2005-08/2007 1999 108 147 1
2.3 (GG3S)

L3C1

 1 08/2002-08/2007 2261 122 166 1
3.0

AJ

 1 01/2004-12/2007 2967 162 220 1
3.0

AJ

 1 01/2005-12/2007 2967 164 223 1
2.0 DI (GG14)

RF5C

 2 08/2002-08/2007 1998 89 121 1
2.0 DI (GG14)

RF5C

 2 08/2002-08/2007 1998 100 136 1
2.0 DI (GG14)

RF7J

 2 06/2005-08/2007 1998 105 143 1
6 II / ATENZA (GH) Hatchback 08/2007-07/2013
Vehicle Engine Fuel Date CC KW CV Traction
1.8 MZR

L813

 1 08/2007-07/2013 1798 88 120 1
2.0 MZR (GHEFS)

LF17

 1 08/2007-07/2013 1999 108 147 1
2.0 MZR (GHEFS)

LFDE

 1 01/2010-12/2012 1999 114 155 1
2.5 MZR (GH5FS)

L5-VE

 1 08/2007-03/2013 2488 125 170 1
2.0 MZR-CD (GH14)

RF7J

 2 08/2007-10/2009 1998 103 140 1
2.2 D (GH10)

R2BF

 2 01/2010-12/2012 2184 95 129 1
2.2 MZR-CD (GH10)

R2BF

 2 01/2009-12/2012 2184 92 125 1
2.2 MZR-CD (GH10)

R2AA

 2 01/2009-12/2012 2184 120 163 1
2.2 MZR-CD (GH10)

R2AA

 2 01/2010-12/2012 2184 132 180 1
2.2 MZR-CD (GH10)

R2AA

 2 01/2009-12/2012 2184 136 185 1
6 II / ATENZA (GH) Saloon 08/2007-12/2013
Vehicle Engine Fuel Date CC KW CV Traction
1.8 MZR

L813

 1 08/2007-07/2013 1798 88 120 1
2.0 MZR (GHEFP, GH10F)

LF4J

LF4K

LFYA

LFYB

 1 08/2007-12/2012 1999 108 147 1
2.0 MZR (GHEFP)

LFDE

 1 01/2010-12/2012 1999 114 155 1
2.5 MZR (GH5FS, GH5FP)

L5-VE

 1 08/2007-07/2013 2488 125 170 1
3.7 1 09/2008-12/2012 3726 203 272 1
2.0 MZR-CD (GH14)

RF7J

 2 08/2007-10/2010 1998 103 140 1
2.2 D (GH10)

R2AA

 2 01/2010-07/2013 2183 132 180 1
2.2 D (GH10)

R2BF

 2 01/2010-12/2012 2184 95 129 1
2.2 MZR-CD (GH10)

R2BF

 2 01/2009-12/2012 2184 92 125 1
2.2 MZR-CD (GH10)

R2AA

 2 01/2009-12/2012 2184 120 163 1
2.2 MZR-CD (GH10)

R2AA

 2 01/2009-12/2012 2184 136 185 1
6 II / ATENZA (GH) Estate 12/2007-07/2013
Vehicle Engine Fuel Date CC KW CV Traction
1.8 MZR

L813

 1 02/2008-07/2013 1798 88 120 1
2.0 MZR (GHEFW, GH10F)

LF17

 1 12/2007-07/2013 1999 108 147 1
2.0 MZR (GHEFW)

LFDE

 1 01/2010-07/2013 1999 114 155 1
2.5 MZR (GH5FW)

L5-VE

 1 02/2008-07/2013 2488 125 170 1
2.0 MZR-CD (GH14)

RF7J

 2 12/2007-12/2010 1998 103 140 1
2.2 D (GH10)

R2BF

 2 01/2010-07/2013 2184 95 129 1
2.2 MZR-CD (GH10)

R2AA

 2 01/2010-07/2013 2183 132 180 1
2.2 MZR-CD (GH10)

R2BF

 2 01/2009-12/2010 2184 92 125 1
2.2 MZR-CD (GH10)

R2AA

 2 08/2008-07/2013 2184 120 163 1
2.2 MZR-CD (GH10)

R2AA

 2 08/2008-12/2011 2184 136 185 1
323 S VIII / 323 PROTEGÉ / ETUDE / FAMILIA (BJ) Saloon 05/1998-07/2004
Vehicle Engine Fuel Date CC KW CV Traction
2.0 (BJ10S)

FS

 1 02/2000-05/2004 1991 98 133 1
2.0 (BJFP)

FS7E

FS7G

 1 01/2001-05/2004 1991 96 131 1
323 F VIII / 323 ASTINA / 323 F-P / ETUDE / FAMILIA (BJ) Hatchback 09/1998-07/2004
Vehicle Engine Fuel Date CC KW CV Traction
2.0 (BJFW)

FS7E

FS7G

 1 01/2001-05/2004 1991 96 131 1
626 VII / CAPELLA Station Wagon (GW) Estate 01/1998-12/2002
Vehicle Engine Fuel Date CC KW CV Traction
1.9

FP9A

 1 01/2000-10/2002 1840 74 100 1
2.0 DITD (GWFW)

RF3F

 2 09/1999-10/2002 1998 66 90 1
2.0 TD (GWFW)

RF4F

 2 10/2000-10/2002 1998 81 110 1
2.0 Turbo DI (GWFW)

RF4F

 2 04/1998-10/2002 1998 74 101 1
MX-5 III (NC) Convertible 03/2005-12/2014
Vehicle Engine Fuel Date CC KW CV Traction
1.8 (NC18)

L828

L831

 1 03/2005-12/2014 1798 93 126 2
2.0

LFY7

 1 10/2008-12/2014 1999 123 167 2
2.0 1 03/2005-12/2007 1999 127 173 2
2.0 (NC18)

LFG7

LFG8

LFY7

LFZD

 1 07/2005-12/2014 1999 118 160 2
PREMACY (CP) MPV 01/1999-03/2005
Vehicle Engine Fuel Date CC KW CV Traction
1.9 (CP8W)

FP

 1 07/1999-03/2005 1840 74 100 1
PREMACY (CP_) Box Body/MPV 01/1999-06/2005
Vehicle Engine Fuel Date CC KW CV Traction
1.8 (CP19) 1 07/1999-06/2005 1840 74 101 1
1.8 (CP19) 1 07/1999-03/2005 1840 84 114 1
2.0 (CP19) 1 08/2001-06/2005 1991 96 131 1
DiTD (CP19) 2 08/2000-06/2005 1998 74 101 1
MAZDA (HAINAN)
PREMACY () MPV 01/2001-02/2007
Vehicle Engine Fuel Date CC KW CV Traction
1.8 1 01/2001-02/2007 1839 90 121 1
