Product 78BD3269-2
- Description
- Brake disc
- Axe
- Front
- No. of Pieces
- 2
- Barcode
-
8424073144737
- Url
- https://catalogonuevo.icerbrakes.com/Producto/Details?idProducto=78BD3269-2
- Weight (gr.)
- 14784
- R90 Homologation
-
90R-02C0452/0118
- Measures
- Ø283x25x48.5
-
Brake Disc Type:
Vented -
Minimum thickness [mm]:
23 -
Hole Arrangement/Number:
5 -
Bolt Hole Circle Ø [mm]:
114.3 -
Wheel Hub Diameter [mm]:
72
| Brand | OE Reference |
|---|---|
| MAZDA | GJ6Y-33-25XA |
| Maker | Cross reference |
|---|---|
| ATE | 24.0125-0147.1 |
| BOSCH | 0 986 479 132 |
| BREMBO | 09.9131.10 |
| BREMBO | 09.9131.14 |
| DELPHI LOCKHEED | BG3874 |
| LETEC | LBMZ016V |
| ROAD HOUSE | 6673.10 |
| SANLI | SL34185 |
| TRW | DF4386 |
| Vehicle | Engine | Fuel | Date | CC | KW | CV | Traction |
|---|---|---|---|---|---|---|---|
| 1.8 |
L813 |
1 | 08/2002-08/2007 | 1798 | 88 | 120 | 1 |
| 2.0 (GYEW) |
LF17 LF18 |
1 | 08/2002-08/2007 | 1999 | 104 | 141 | 1 |
| 2.0 (GYEW) |
LFF7 |
1 | 03/2005-08/2007 | 1999 | 108 | 147 | 1 |
| 2.3 (GY3W, GY10) |
L3C1 |
1 | 01/2002-02/2008 | 2261 | 122 | 166 | 1 |
| 2.3 AWD (GY3W) |
L3C1 |
1 | 11/2002-08/2007 | 2261 | 119 | 162 | 3 |
| 2.0 CiTD | 2 | 10/2002-02/2005 | 1998 | 89 | 121 | 2 | |
| 2.0 CiTD | 2 | 10/2002-02/2005 | 1998 | 100 | 136 | 2 | |
| 2.0 DI (GY19) |
RF5C |
2 | 08/2002-08/2007 | 1998 | 89 | 121 | 1 |
| 2.0 DI (GY19) |
RF5C |
2 | 08/2002-02/2005 | 1998 | 100 | 136 | 1 |
| 2.0 DI (GY19) |
RF7J |
2 | 06/2005-08/2007 | 1998 | 105 | 143 | 1 |
| Vehicle | Engine | Fuel | Date | CC | KW | CV | Traction |
|---|---|---|---|---|---|---|---|
| 2.0 (GGEP, GG10) |
LF17 LF18 |
1 | 06/2002-08/2007 | 1999 | 104 | 141 | 1 |
| 2.0 (GGEP, GG10) |
LFF7 |
1 | 03/2005-08/2007 | 1999 | 108 | 147 | 1 |
| 2.3 | 1 | 07/2003-02/2005 | 2261 | 119 | 162 | 1 | |
| 2.3 |
L3C1 |
1 | 03/2005-07/2007 | 2261 | 120 | 163 | 1 |
| 2.3 (GG3P) |
L3C1 |
1 | 06/2002-08/2007 | 2261 | 122 | 166 | 1 |
| 2.3 MPS Turbo (GG3P) |
L3KG |
1 | 12/2005-08/2007 | 2261 | 191 | 260 | 3 |
| 2.0 DI (GG14) |
RF5C |
2 | 08/2002-08/2007 | 1998 | 89 | 121 | 1 |
| 2.0 DI (GG14) |
RF5C |
2 | 06/2002-08/2007 | 1998 | 100 | 136 | 1 |
| 2.0 DI (GG14) |
RF7J |
2 | 06/2005-08/2007 | 1998 | 105 | 143 | 1 |
| Vehicle | Engine | Fuel | Date | CC | KW | CV | Traction |
|---|---|---|---|---|---|---|---|
| 2.0 (GGES) |
LF17 LF18 |
1 | 08/2002-08/2007 | 1999 | 104 | 141 | 1 |
| 2.0 (GGES) |
LFF7 |
1 | 03/2005-08/2007 | 1999 | 108 | 147 | 1 |
| 2.3 (GG3S) |
L3C1 |
1 | 08/2002-08/2007 | 2261 | 122 | 166 | 1 |
| 3.0 |
AJ |
1 | 01/2004-12/2007 | 2967 | 162 | 220 | 1 |
| 3.0 |
AJ |
1 | 01/2005-12/2007 | 2967 | 164 | 223 | 1 |
| 2.0 DI (GG14) |
RF5C |
2 | 08/2002-08/2007 | 1998 | 89 | 121 | 1 |
| 2.0 DI (GG14) |
RF5C |
2 | 08/2002-08/2007 | 1998 | 100 | 136 | 1 |
| 2.0 DI (GG14) |
RF7J |
2 | 06/2005-08/2007 | 1998 | 105 | 143 | 1 |
