Product 78BD3272-2

Description: Brake disc
Axe: Front
No. of Pieces: 2
Barcode: 8424073144751
Url: https://catalogonuevo.icerbrakes.com/Producto/Details?idProducto=78BD3272-2
Weight (gr.): 14324

R90 Homologation: 90R-02C0452/0118
Measures: Ø278x25x48.8
: Brake Disc Type: Vented; Minimum thickness [mm]: 23; Hole Arrangement/Number: 5; Bolt Hole Circle Ø [mm]: 114.3; Wheel Hub Diameter [mm]: 72

Reference applications

Brand	OE Reference
MAZDA	BP4Y-33-25XB
MAZDA	BP4Y-33-25XC
MAZDA	BP4Y-33-25XD

Maker	Cross reference
ATE	24.0125-0165.1
BOSCH	0 986 479 179
BREMBO	09.9464.2X
LETEC	LBMZ017V
ROAD HOUSE	6671.10
SANLI	SL32559
TRW	DF4384

FIAT

FIORINO II (146_) Pickup 01/1988-05/2001

Vehicle	Engine	Fuel	Date	CC	KW	CV	Traction
1.5		1	05/1988-11/1993	1497	52	71	1

IVECO

DAILY III () Van 05/1999-10/2009

Vehicle	Engine	Fuel	Date	CC	KW	CV	Traction
65C15	8140.43N	2	11/2001-04/2006	2798	107	146	2

MAZDA

3 / AXELA (BK) Saloon 09/1999-12/2009

Vehicle	Engine	Fuel	Date	CC	KW	CV	Traction
1.6 (BK12)	Z601 Z627	1	02/2004-06/2009	1598	77	105	1
2.0 (BK10F, BKEP)	LF17	1	10/2003-06/2006	1999	104	141	1
1.6 DI Turbo (BK12Y)	Y601 Y603 Y605 Y642	2	06/2004-06/2009	1560	80	109	1

3 / AXELA (BK) Hatchback 10/2003-12/2009

Vehicle	Engine	Fuel	Date	CC	KW	CV	Traction
1.3 (BK14)	ZJ07 ZJ30 ZJ32	1	10/2003-06/2009	1349	62	84	1
1.4		1	02/2004-06/2009	1388	59	80	1
1.6 (BK14)	Z601 Z627	1	10/2003-06/2009	1598	77	105	1
2.0 (BK10F, BKEP)		1	10/2003-06/2006	1999	104	141	1
2.3 MPS		1	01/2007-06/2009	2261	196	267	1
1.6 DI Turbo	Y601 Y603 Y605 Y642	2	06/2004-06/2009	1560	80	109	1
1.6 MZ-CD	Y406	2	06/2006-12/2009	1560	66	90	1

3 II / AXELA (BL) Saloon 12/2008-

Vehicle	Engine	Fuel	Date	CC	KW	CV	Traction
1.6 MZR (BL12)	Z668 Z682 Z683	1	12/2008-09/2014	1598	77	105	1
2.0 (BLFFP)	PEY2	1	09/2011-09/2014	1998	113	154	1
2.0 MZR		1	06/2010-	1999	108	147	1
2.0 MZR (BL12)	LF5H LF5W	1	03/2009-09/2014	1999	110	150	1
2.0 MZR DISI (BL12)	LFZ2	1	02/2009-05/2013	1999	111	151	1
2.5		1	05/2009-09/2014	2488	122	166	1
2.5		1	01/2010-	2488	125	170	1
1.6 MZR CD (BL12)	Y642	2	12/2008-05/2013	1560	80	109	1
1.6 MZR CD (BL14)	Y650 Y655	2	09/2010-05/2013	1560	85	116	1
2.2 MZR CD (BL10)	R2AA	2	01/2009-09/2014	2184	110	150	1
2.2 MZR CD (BL10)	R2AA	2	06/2009-05/2013	2184	136	185	1

3 II / AXELA (BL) Hatchback 12/2008-09/2014

Vehicle	Engine	Fuel	Date	CC	KW	CV	Traction
1.6 MZR	Z6	1	01/2010-12/2013	1598	79	107	1
1.6 MZR (BL14)	Z668 Z682 Z683	1	12/2008-09/2014	1598	77	105	1
2.0 (BLFFW, BL107)		1	09/2011-10/2013	1998	113	154	1
2.0 DISI (BLEFW)	LF-VDS	1	05/2009-02/2012	1998	110	150	1
2.0 MZR (BLEFW, BL10F)	LF5H LF5W	1	04/2009-09/2014	1999	108	147	1
2.0 MZR DISI (BLEFW)	LFZ2	1	12/2008-05/2013	1999	111	151	1
2.3 MPS Turbo		1	06/2009-	2261	196	267	1
2.3 MPS Turbo (BL14)	L3Y7	1	12/2008-09/2014	2261	191	260	1
2.5		1	01/2012-12/2013	2488	125	170	1
2.0		19	06/2010-05/2013	1999	108	147	1
1.6 MZ-CD (BL14)	Y642	2	12/2008-05/2013	1560	80	109	1
1.6 MZR CD (BL14)	Y650 Y655	2	09/2010-05/2013	1560	85	116	1
2.2 MZR CD (BL10)	R2AA	2	01/2009-10/2013	2184	110	150	1
2.2 MZR CD (BL10)	R2AA	2	01/2009-05/2013	2184	136	185	1

3 III / AXELA (BM_, BN_) Saloon 09/2013-

Vehicle	Engine	Fuel	Date	CC	KW	CV	Traction
2.0		1	01/2014-05/2019	1998	116	158	1

5 II / PREMACY (CR) MPV 02/2005-12/2010

Vehicle	Engine	Fuel	Date	CC	KW	CV	Traction
1.8 (CR19)	L823	1	02/2005-05/2010	1798	85	116	1
2.0 (CREW)	LFF7	1	02/2005-05/2010	1999	107	146	1
2.3 (CR3W)		1	02/2005-09/2008	2261	122	166	1
2.0 CD (CR19)	RF7J	2	02/2005-05/2010	1998	81	110	1
2.0 CD (CR19)	RF7J	2	02/2005-05/2010	1998	105	143	1

5 III / PREMACY (CW) MPV 06/2010-

Vehicle	Engine	Fuel	Date	CC	KW	CV	Traction
2.0	LF-ZB	1	01/2011-	1999	108	147	1
2.0 (CWFFW)		1	08/2014-	1998	111	151	1
