Product 78BD3466-2 - Web Catalogo

Description: Brake disc
Axe: Front-Rear
No. of Pieces: 2
Barcode: 8424073145024
Url: https://catalogonuevo.icerbrakes.com/Producto/Details?idProducto=78BD3466-2
Weight (gr.): 8956

R90 Homologation: 90R-02C0415/0017
Measures: Ø257x12x40.5
: Brake Disc Type: solid; Minimum thickness [mm]: 10.2; Hole Arrangement/Number: 4; Bolt Hole Circle Ø [mm]: 98; Wheel Hub Diameter [mm]: 59

Reference applications

Brand	OE Reference
ALFA ROMEO	6 080 88 72
FIAT	7 173 837 3
FIAT	7 545 556
FIAT	7 645 055
FIAT	7 645 556
FIAT	9 249 860 9
FIAT	9 663 465
LANCIA	4 655 430 2
LANCIA	4 682 065 5
LANCIA	7 663 466

Maker	Cross reference
ATE	24.0112-0127.1
ATE	412127
BENDIX ANTIGUO	561469B
BOSCH	0 986 478 343
BREMBO	08.5086.10
BREMBO	08.5086.14
BREMBO	08.9621.14
DELPHI LOCKHEED	BG2411
LETEC	LBY003S
ROAD HOUSE	6191.00
SANLI	SL10876
TRW	DF1747
TRW	DF6231

ALFA ROMEO

145 (3 door) (930_) Hatchback 07/1994-01/2001

Vehicle	Engine	Fuel	Date	CC	KW	CV	Traction
1.4 i.e. (930.A3)	AR 33501	1	07/1994-12/1996	1351	66	90	1
1.6 i.e. (930.A2)	AR 33201	1	10/1994-12/1996	1596	76	103	1
1.9 D		2	07/1994-02/1999	1929	68	92	2
1.9 TD (930.A4)	AR 33601 AR 67501	2	10/1994-02/1999	1929	66	90	1

146 (5 door) (930_) Hatchback 12/1994-10/2001

Vehicle	Engine	Fuel	Date	CC	KW	CV	Traction
1.4 i.e. (930.B3)	AR 33501	1	12/1994-12/1996	1351	66	90	1
1.6 i.e. (930.B2)	AR 33201	1	12/1994-12/1996	1596	76	103	1
1.9 D		2	05/1995-09/1996	1929	68	92	2
1.9 TD (930.B4A)	AR 33601 AR 67501	2	12/1994-02/1999	1929	66	90	1

155 (167_) Saloon 01/1992-12/1997

Vehicle	Engine	Fuel	Date	CC	KW	CV	Traction
1.9 TD (167.A3B, 167.A3)	AR 67501	2	04/1993-12/1997	1929	66	90	1

CHRYSLER

YPSILON () Hatchback 05/2011-

Vehicle	Engine	Fuel	Date	CC	KW	CV	Traction
1.2	169 A4.000	1	05/2011-12/2021	1242	51	69	1

FIAT

500 II (312_) Hatchback 07/2007-

Vehicle	Engine	Fuel	Date	CC	KW	CV	Traction
0.9 (312AXG1A, 312.AXG11)	312 A2.000	1	07/2010-	875	63	86	1
0.9 (312AXH1A)	312 A4.000	1	09/2012-	964	48	65	1
0.9 (312AXN1A)	312 A5.000	1	12/2013-	875	59	80	1
0.9 (312AXP1A)	312 A4.000 312 A6.000	1	12/2013-	964	44	60	1
1.2 LPG (312AXA1A)	169 A4.000	18	12/2010-	1242	51	69	1

500 C II (312_) Convertible 09/2009-

Vehicle	Engine	Fuel	Date	CC	KW	CV	Traction
0.9 (312AG1A)	312 A2.000	1	09/2009-	875	63	86	1
0.9 (312AXH1A)	312 A4.000	1	09/2012-	964	48	65	1
0.9 (312AXN1A, 312AXN11)	312 A5.000	1	12/2013-	875	59	80	1
0.9 (312AXP1A)	312 A6.000	1	12/2013-	964	44	60	1
1.2 (312CXA1A, 312AXA1A)	169 A4.000	1	09/2009-	1242	51	69	1

BRAVA II (182_) Hatchback 10/1995-06/2003

Vehicle	Engine	Fuel	Date	CC	KW	CV	Traction
1.2 16V 80	188 A5.000	1	10/2000-10/2001	1242	59	80	1
1.2 16V 80	182 B2.000	1	12/1998-12/2002	1242	60	82	1
1.4 (182.BG)	182 A5.000	1	10/1995-10/2001	1370	55	75	1
1.4 12 V (182.BA)	182 A3.000	1	10/1995-08/1998	1370	59	80	1
1.6 16V (182.BB)	182 A4.000	1	02/1996-10/2001	1581	76	103	1
1.6 16V (182.BB)		1	08/1999-03/2000	1581	78	106	1
1.6 16V (182.BH)	182 A6.000	1	10/1995-10/2001	1581	66	90	1
1.6 16V (182.BU)	182 B6.000	1	01/1999-12/2002	1596	76	103	1
1.9 D	160 A7.000	2	10/1995-10/2001	1929	48	65	1
1.9 TD 75 S (182.BF)	182 A8.000	2	03/1996-10/2001	1910	55	75	1

BRAVO (182_) Hatchback 10/1995-10/2001

Vehicle	Engine	Fuel	Date	CC	KW	CV	Traction
1.2 16V 80	188 A5.000	1	10/2000-10/2001	1242	59	80	1
1.2 16V 80	182 B2.000	1	12/1998-10/2000	1242	60	82	1
1.4 (182.AA)	182 A3.000	1	10/1995-10/2001	1370	59	80	1
1.4 (182.AG)	182 A5.000	1	10/1995-10/2001	1370	55	75	1
1.6	182 B6.000	1	09/2000-10/2001	1596	76	103	1
1.6 16V (182.AB)	182 A4.000	1	03/1996-10/2001	1581	76	103	1
1.6 16V (182.AH)	182 A6.000	1	10/1995-10/2001	1581	66	90	1
1.9 D	160 A7.000	2	10/1995-10/2001	1929	48	65	1
1.9 TD 75 S (182.AF)	182 A8.000	2	03/1996-10/2001	1910	55	75	1

MAREA (185_) Saloon 05/1996-12/2007

Vehicle	Engine	Fuel	Date	CC	KW	CV	Traction
1.4 80 12V	182 A3.000	1	09/1996-05/2002	1370	59	80	1
1.6 16V	185 A3.000	1	04/1997-02/1999	1581	75	102	1
1.9 JTD 105 (185AXN1A)	182 B4.000	2	12/1998-12/2002	1910	77	105	1
1.9 TD 75	182 A8.000	2	09/1996-05/2002	1910	55	75	1

MAREA Weekend (185_) Estate 09/1996-12/2007

Vehicle	Engine	Fuel	Date	CC	KW	CV	Traction
1.4 80 12V	182 A3.000	1	09/1996-05/2002	1370	59	80	1
1.9 JTD 105 (185BXN1A)	182 B4.000	2	12/1998-12/2002	1910	77	105	1
1.9 TD 75	182 A8.000	2	09/1996-05/2002	1910	55	75	1

PANDA III (312_, 319_) Hatchback 02/2012-

Vehicle	Engine	Fuel	Date	CC	KW	CV	Traction
0.9 (312PXH1A)	312 A4.000	1	02/2012-	964	48	65	1
0.9 (312PXN1A, 312PXN11)	312 A5.000	1	12/2013-	875	59	80	1
0.9 (312PXP1A)	312 A4.000 312 A6.000	1	12/2013-	964	44	60	1
0.9 4x4 (312PXR2B)	312 A2.000 312 A7.000	1	06/2014-	875	66	90	3
1.2 (312PXA1A)	169 A4.000	1	02/2012-	1242	51	69	1
0.9 Natural Power (312PXN1A)	463 37 566	16	03/2019-	875	51	69	1
0.9 Natural Power (312PXN1A)	312 A2.000	16	01/2015-	875	59	80	1
1.3 D Multijet 4x4 (312PXU1A)	199 A9.000 225 A2.000 312 A8.000 312 B2.000	2	06/2014-	1248	59	80	3
1.3 D Multijet 4x4 (312PXU1A)	199 B1.000 312 B1.000 330 A1.000	2	04/2015-	1248	70	95	3

PANDA III VAN (312_, 519_) Hatchback Van 02/2012-

Vehicle	Engine	Fuel	Date	CC	KW	CV	Traction
0.9 (312.PXN1A)	312 A2.000	1	11/2013-	875	59	80	1
0.9 (312CXH1A, 312DXH1A)	312 A4.000	1	02/2012-	964	48	65	1
0.9 (312DXG1A)	312 A2.000	1	02/2012-	875	63	86	1
0.9 4x4 (312CXG2B)	312 A2.000	1	09/2012-	875	63	86	3
1.2 (312CXA1A, 312DXA1A)	169 A4.000	1	02/2012-	1242	51	69	1
0.9 Natural Power (312CXG1A)	312 A2.000	16	01/2015-	875	59	80	1
0.9 Natural Power (312DXG1A)	312 A2.000	16	07/2012-	875	63	86	1
1.2 LPG (312CXA1A)	169 A4.000	18	06/2012-	1242	51	69	1
1.3 D Multijet 4x4 (312CXL2A)	199 A9.000	2	06/2012-	1248	55	75	3
1.3 D Multijet 4x4 (312PXU1A)	225 A2.000	2	06/2014-	1248	59	80	3

PUNTO (176_) Hatchback 09/1993-09/1999

Vehicle	Engine	Fuel	Date	CC	KW	CV	Traction
1.2 16V	176 B9.000	1	04/1997-09/1999	1242	63	86	1
1.6	176 A9.000	1	01/1994-04/1997	1581	65	88	1
55 1.1	176 A6.000 176 B2.000	1	09/1993-09/1999	1108	40	54	1
60 1.2	176 A7.000	1	01/1994-09/1999	1242	43	58	1
60 1.2 (176AP, 176AR, 176AQ, 176BB)	176 B1.000 176 B4.000	1	09/1993-09/1999	1242	44	60	1
75 1.2	176 A8.000	1	10/1993-09/1999	1242	54	73	1
1.7 TD	176 A3.000	2	01/1994-09/1999	1698	51	69	1
1.7 TD	176 A5.000	2	01/1994-09/1999	1698	52	71	1
1.7 TD (176AT)	176 B7.000	2	09/1996-09/1999	1698	46	63	1

PUNTO (176_) Convertible 04/1994-06/2000

Vehicle	Engine	Fuel	Date	CC	KW	CV	Traction
85 16V 1.2	176 B9.000	1	04/1997-06/2000	1242	63	86	1
90 1.6	176 A9.000	1	04/1994-04/1997	1581	65	88	1

PUNTO (176_) Hatchback Van 04/1996-02/2000

Vehicle	Engine	Fuel	Date	CC	KW	CV	Traction
1.7 TD	176 B7.000	2	09/1996-09/1999	1698	46	63	1
1.7 TD	176 A5.000	2	04/1996-02/2000	1698	52	71	1

PUNTO II (188_) Hatchback 09/1999-07/2012

Vehicle	Engine	Fuel	Date	CC	KW	CV	Traction
1.2 16V 80 (188.233, .235, .253, .255, .333, .353, .639,...	188 A5.000	1	09/1999-04/2006	1242	59	80	1
1.9 DS 60 (188.031, .051, .231, .251)	188 A3.000	2	09/1999-03/2012	1910	44	60	1

PUNTO II-III (188_) Hatchback Van 02/2000-12/2010

Vehicle	Engine	Fuel	Date	CC	KW	CV	Traction
1.9 D 60	188 A3.000	2	02/2000-10/2009	1910	44	60	1

TEMPRA (159_) Saloon 03/1990-12/1998

Vehicle	Engine	Fuel	Date	CC	KW	CV	Traction
1.6 i.e. (159.AE)	159 A3.046	1	06/1990-07/1992	1581	57	78	1
1.6 i.e. (159.AJ)	159 B9.000	1	06/1994-08/1996	1581	66	90	1
1.6 i.e. (159.AS, 159.AT)	159 A3.048 835 C1.000	1	06/1992-08/1996	1581	55	75	1
1.8 i.e. (159.AN)	159 A4.046	1	03/1992-08/1996	1756	77	105	1
1.8 i.e. (159.AN)	159 A4.000	1	03/1990-08/1996	1756	81	110	1
1.8 i.e. (159.AV)	835 C2.000	1	09/1993-08/1996	1756	76	103	1
1.8 i.e. (159.AZ)	835 C4.000	1	09/1993-08/1996	1756	66	90	1
1.8 i.e. (159.BY)	836 A5.000	1	10/1994-08/1996	1756	74	101	1
2.0		1	11/1992-04/1994	1995	71	99	1
2.0		1	05/1994-12/1998	1995	76	103	1
2.0		1	10/1995-12/1998	1998	93	126	1
2.0 16V		1	01/1994-06/1998	1995	97	132	1
2.0 Turbo		1	11/1994-05/1998	1995	121	165	1
1.9 D (159.AG)	149 A1.000 160 A7.000	2	07/1991-08/1996	1929	48	65	1
1.9 TD (159.AQ)	160 B6.046	2	07/1992-08/1996	1929	59	80	1
1.9 TD (159.CU, 159.AU, 159.AI, 159.BI)	160 A6.000 160 D1.000	2	05/1990-08/1996	1929	66	90	1

TEMPRA S.W (159_) Estate 03/1990-10/1997

Vehicle	Engine	Fuel	Date	CC	KW	CV	Traction
1.4 i.e. (159.AC, 159.AX)	159 A2.000 160 A1.046 836 A4.000	1	10/1992-08/1996	1372	51	69	1
1.4 i.e. (159.AC)	159 A2.000	1	03/1991-08/1996	1372	57	78	1
1.6	159 A3.048	1	07/1993-07/1996	1581	51	69	1
1.6	159 A3.000	1	12/1990-04/1993	1581	63	86	1
1.6 i.e. (159.AE)	159 A3.046 835 C1.000	1	10/1990-08/1996	1581	57	78	1
1.6 i.e. (159.AJ)	159 B9.000	1	06/1994-08/1996	1581	66	90	1
1.6 i.e. (159.AS, 159.AT)	159 A3.048 835 C1.000	1	10/1992-08/1996	1581	55	75	1

TEMPRA / MARENGO (159_) Estate Van 04/1990-07/1996

Vehicle	Engine	Fuel	Date	CC	KW	CV	Traction
1.9 TD (159AI, 159BI)		2	04/1990-07/1996	1929	66	90	1

TIPO (160_) Hatchback 07/1987-10/1997

Vehicle	Engine	Fuel	Date	CC	KW	CV	Traction
1.4 i.e. (160.AP, 160.AD, 160.EA)	160 A1.046 160 A1.048 836 A4.000	1	05/1989-04/1995	1372	51	70	1
1.6	159 A3.046 159 A3.048 835 C1.000	1	03/1993-10/1995	1581	56	76	1
1.6	160 A2.000	1	03/1988-10/1992	1581	58	79	1
1.6 (160.AE)	160 A2.000	1	01/1988-10/1991	1581	61	83	1
1.6 i.e.	149 C2.046	1	02/1988-05/1991	1595	66	90	1
1.6 i.e. (160.A1, 160.EC, 160.EB)	159 A3.048 835 C1.000	1	10/1992-04/1995	1581	55	75	1
1.6 i.e. (160.AF)	159 A3.046	1	07/1990-01/1993	1581	57	78	1
1.6 SX DGT	159 A3.000	1	05/1989-10/1995	1581	66	90	1
1.8 i.e	836 A5.000	1	03/1993-04/1995	1756	71	97	1
1.8 i.e.	835 C4.000	1	09/1993-04/1995	1756	66	90	1
1.9 D	149 A1.000 160 A7.000	2	07/1991-08/1995	1929	48	65	1
1.9 TD (160.AW)	160 B6.046	2	03/1992-06/1993	1929	59	80	1
1.9 TD (160.EL, 160.GL, 160.AQ, 160.EI, 160.AR)	160 A6.000 160 A6.046 160 D1.000	2	09/1990-04/1995	1929	66	90	1
1.9 TD (160AR)	160 A6.046	2	04/1990-10/1992	1929	69	94	1

LANCIA

DEDRA (835_) Saloon 01/1989-07/1999

Vehicle	Engine	Fuel	Date	CC	KW	CV	Traction
1.6 16V (835EI)	182 A4.000	1	01/1996-07/1999	1581	76	103	1
1.6 i.e. (835AA)	835 A1.000	1	08/1989-06/1994	1581	66	90	1
1.6 i.e. (835AB)	835 A1.046	1	08/1989-03/1993	1581	57	78	1
1.6 i.e. (835AN)	835 C1.000	1	04/1993-07/1999	1581	55	75	1
1.6 LE Cat (835EB)	159 B9.000	1	07/1994-07/1999	1581	66	90	1
1.8 i.e. (835AC, 835BC)	835 A2.000	1	09/1989-06/1994	1756	80	109	1
1.8 i.e. (835AT)	835 C5.000	1	08/1993-07/1999	1756	66	90	1
1.9 TDS (835EE, 835EF)	160 D1.000 835 A4.000 835 A4.046	2	04/1989-07/1999	1929	66	90	1

DEDRA SW (835_) Estate 07/1994-07/1999

Vehicle	Engine	Fuel	Date	CC	KW	CV	Traction
1.6 (835EB)	159 B9.000	1	10/1994-07/1999	1581	66	90	1

DELTA II (836_) Hatchback 06/1993-09/1999

Vehicle	Engine	Fuel	Date	CC	KW	CV	Traction
1.6 i.e. (836AD)	835 C1.000	1	06/1993-08/1999	1581	55	75	1
1.6 i.e. (836AP)	182 A6.000	1	03/1996-08/1999	1581	66	90	1
1.6 i.e. 16V (836AO)	182 A4.000	1	01/1996-08/1999	1581	76	103	1
1.8		1	02/1996-09/1999	1747	66	90	1
1.8 i.e. (836AE)	835 C2.000	1	06/1993-08/1999	1756	76	103	1
1.8 i.e. (836AG, 836AL)	835 C4.000 836 A6.000 836 C4.000	1	07/1994-08/1999	1756	66	90	1
1.9 TD (836AM, 836AN)	160 D1.000 835 A4.000	2	10/1994-08/1999	1929	66	90	1

Y (840_) Hatchback 11/1995-09/2003

Vehicle	Engine	Fuel	Date	CC	KW	CV	Traction
1.1 (840AE)	176 B2.000	1	11/1995-09/2003	1108	40	54	1
1.2 (840AA, 840AF1A)	188 A4.000 840 A3.000	1	03/1996-09/2003	1242	44	60	1
1.2 16V (840AD)	176 B9.000	1	04/1997-09/2003	1242	63	86	1
1.2 16V (840AG1A)	188 A5.000	1	10/2000-09/2003	1242	59	80	1
1.4 12V (840AB)	840 A2.000	1	10/1996-09/2003	1370	59	80	1
1.4 12V (840AC)	840 A4.000	1	03/1996-09/2003	1370	55	75	1

YPSILON II (843_) Hatchback 10/2003-12/2011

Vehicle	Engine	Fuel	Date	CC	KW	CV	Traction
1.2 (843.AXA1A)	188 A4.000	1	10/2003-12/2011	1242	44	60	1
1.2 (843.AXL1A)	169 A4.000	1	08/2010-12/2011	1242	51	69	1

YPSILON III (312_) Hatchback 05/2011-

Vehicle	Engine	Fuel	Date	CC	KW	CV	Traction
1.2 (312.PXA1A, 312.YXA1A)	169 A4.000	1	05/2011-12/2021	1242	51	69	1
1.2 Bi-fuel (312.YXA1A)	169 A4.000	18	05/2011-	1242	49	67	1
1.2 Bi-fuel (312.YXA1A)	169 A4.000	18	05/2011-	1242	51	69	1

LEXUS

NX (_Z1_) SUV 07/2014-

Vehicle	Engine	Fuel	Date	CC	KW	CV	Traction
200t AWD (AGZ15_)	8AR-FTS	1	07/2014-09/2017	1998	173	235	3

Return
