Product 78BD3550-2 - Web Catalogo

Description: Brake disc
Axe: Front
No. of Pieces: 2
Barcode: 8424073145086
Url: https://catalogonuevo.icerbrakes.com/Producto/Details?idProducto=78BD3550-2
Weight (gr.): 9936

Measures: Ø259x20.6x41
: Brake Disc Type: Vented; Minimum thickness [mm]: 17.7; Hole Arrangement/Number: 4; Bolt Hole Circle Ø [mm]: 100; Wheel Hub Diameter [mm]: 61

Reference applications

Brand	OE Reference
DACIA	60 01 548 578
DACIA	77 01 205 653
DACIA	77 01 206 339
NISSAN	40206-00QAA
RENAULT	77 00 780 892
RENAULT	77 00 813 549
RENAULT	77 00 842 131
RENAULT	77 01 204 228
RENAULT	77 01 204 304
RENAULT	77 01 204 828
RENAULT	82 01 464 598

Maker	Cross reference
ATE	24.0121-0106.1
ATE	421106
BENDIX ANTIGUO	561997B
BOSCH	0 986 478 124
BREMBO	09.5802.20
BREMBO	09.5802.24
DELPHI LOCKHEED	BG2625
FERODO	DDF1096
HELLA-PAGID	8DD 355 126-531
NECTO	WN1102
ROAD HOUSE	6144.10
SANLI	SL31867
TRW	DF2586

DACIA

LOGAN (LS_) Saloon 08/2004-

Vehicle	Engine	Fuel	Date	CC	KW	CV	Traction
1.2 16V (LS1N, LS02, BS02)	D4F 732	1	02/2006-	1149	55	75	1
1.6 (LSOB, LSOD, LSOF, LSOH)	K7M 710	1	09/2004-	1598	64	87	1
1.6 16V (LS09, LS0L, LS0M, LS0P, LS0V, LS18, LS1S, LS1V,...	K4M 690 K4M 694 K4M 696 K4M 697 K4M 698	1	02/2006-	1598	77	105	1
1.6 MPI 85	K7M 800	1	05/2010-	1598	62	84	1
1.2 16V LPG	D4F 734	18	02/2006-	1149	55	75	1
1.4 MPI LPG (LS0C)	K7J 710 K7J 714	18	02/2006-12/2012	1390	55	75	1
1.6 BiFuel	K7M 718	18	05/2010-	1598	62	84	1
1.6 LPG	K7M 718	18	08/2004-03/2011	1598	64	87	1
1.0 Hi-Flex (LS0R, LS1G)	D4D 760	19	01/2011-10/2012	999	56	76	1
1.6 16V Flexifuel	K4M 696	19	07/2010-	1598	77	105	1
1.5 dCi (LS04)	K9K 892	2	05/2010-12/2012	1461	55	75	1
1.5 dCi (LS04)	K9K 892	2	05/2010-	1461	65	88	1
1.5 dCi (LS0J, LS0Y)	K9K 790	2	09/2005-	1461	48	65	1

LOGAN MCV (KS_) Estate 02/2007-

Vehicle	Engine	Fuel	Date	CC	KW	CV	Traction
1.4	K7J 710	1	02/2007-	1390	55	75	1
1.6 (KS0B, KS0D, KS0F)	K7M 710	1	02/2007-06/2013	1598	64	87	1
1.6 MPI 85	K7M 800	1	05/2010-	1598	62	84	1
1.6 BiFuel	K7M 718	18	05/2010-	1598	62	84	1
1.6 BiFuel	K7M 710	18	11/2008-	1598	64	87	1
1.6 16V Hi-Flex	K4M 690	19	11/2009-	1598	77	105	1
1.5 dCi	K9K 790	2	04/2008-06/2013	1461	48	65	1
1.5 dCi (KS04)	K9K 892	2	05/2010-06/2013	1461	55	75	1
1.5 dCi (KS04)	K9K 892	2	05/2010-	1461	65	88	1
1.5 dCi (KS0K)	K9K 792	2	02/2007-	1461	50	68	1
1.5 dCi (KS0W)	K9K 796	2	09/2007-12/2012	1461	63	86	1

LOGAN EXPRESS (FS_) Estate Van 10/2007-

Vehicle	Engine	Fuel	Date	CC	KW	CV	Traction
1.6 MPI 85	K7M 800	1	05/2010-	1598	62	84	1
1.6 LPG	K7M 818	18	05/2010-12/2012	1598	62	84	1
1.5 dCi	K9K 892	2	05/2010-	1461	55	75	1
1.5 dCi	K9K 892	2	05/2010-	1461	65	88	1
1.5 dCi (FS0K)	K9K 792	2	03/2009-	1461	50	68	1
1.5 dCi (FS0W)	K9K 796	2	03/2009-	1461	63	86	1
1.5 dCi (FS0Y, FS00, FS0J)		2	10/2007-12/2012	1461	48	65	1

LOGAN (US_) Pickup 03/2008-

Vehicle	Engine	Fuel	Date	CC	KW	CV	Traction
1.4	K7J 710	1	01/2009-	1390	55	75	1
1.6 16V (US1Y)	K4M 690	1	01/2010-08/2013	1598	77	105	1
1.6 MPI 85	K7M 800	1	05/2010-	1598	62	84	1
1.6 BiFuel	K7M 800	18	05/2010-	1598	62	84	1
1.5 dCi	K9K 892	2	05/2010-	1461	55	75	1
1.5 dCi	K9K 892	2	05/2010-	1461	65	88	1
1.5 dCi (US00, US0J, US0Y)	K9K 794	2	04/2008-12/2012	1461	48	65	1

SANDERO (B90) Hatchback 06/2008-

Vehicle	Engine	Fuel	Date	CC	KW	CV	Traction
1.2 16V	D4F 732	1	11/2008-	1149	55	75	1
1.6 16V	K4M 690 K4M 694	1	07/2011-	1598	77	105	1
1.6 MPI 85 (BS03)	K7M 800	1	05/2010-06/2013	1598	62	84	1
1.2 16V LPG	D4F 732	18	11/2008-	1149	55	75	1
1.4 MPI LPG	K7J 714	18	01/2009-	1390	53	72	1
1.6 LPG	K7M 818	18	05/2010-10/2012	1598	62	84	1
1.6 LPG	K7M 718	18	06/2008-12/2012	1598	64	87	1
1.6 LPG (BS03)	K7M 818	18	01/2011-12/2012	1598	60	82	1
1.0 Hi-Flex	D4D 760	19	01/2011-12/2012	999	56	76	1
1.6 Hi-Flex (BS1H)	K7M 732	19	06/2008-12/2012	1598	64	87	1
1.5 dCi	K9K 790	2	11/2008-	1461	48	65	1
1.5 dCi	K9K 892	2	05/2010-	1461	55	75	1
1.5 dCi	K9K 796	2	11/2008-	1461	63	86	1
1.5 dCi	K9K 892	2	05/2010-	1461	65	88	1

LADA

LARGUS (FS0_, FSA_) Van 03/2012-

Vehicle	Engine	Fuel	Date	CC	KW	CV	Traction
1.6 (FS015)	K7M	1	03/2012-	1598	62	84	1
1.6 (FS035)	11189	1	06/2016-	1597	64	87	1
1.6 (FS045)	21129	1	09/2017-	1597	78	106	1
1.6 (FS0Y5)	K4M	1	03/2012-	1598	77	105	1
1.6 CNG (FSA45)	21129	16	11/2018-	1597	69	94	1

LARGUS (KS0_, RS0_, KSA_) Estate Van 03/2012-

Vehicle	Engine	Fuel	Date	CC	KW	CV	Traction
1.6 (KS045, RS045)	21129	1	09/2017-	1597	78	106	1
1.6 (KS0Y5, RS0Y5)	K4M	1	04/2016-	1598	75	102	1
1.6 CNG (KSA45)	21129	16	11/2018-	1597	69	94	1

LARGUS (KS0_, RS0_, KSA_) Estate 03/2012-

Vehicle	Engine	Fuel	Date	CC	KW	CV	Traction
1.6 (KS035, RS035)	11189	1	04/2016-03/2021	1597	64	87	1
1.6 (KS045, RS045)	21129	1	09/2017-	1597	78	106	1
1.6 (KS0Y5, RS0Y5)	K4M	1	03/2012-	1598	77	105	1
1.6 (RS0Y5, KS0Y5)	K7M	1	03/2012-	1598	62	84	1
1.6 CNG (KSA45)	21129	16	11/2018-	1597	69	94	1

MAHINDRA

VERITO () Saloon 01/2011-

Vehicle	Engine	Fuel	Date	CC	KW	CV	Traction
1.4		1	01/2011-	1390	56	76	1
1.5 dCi		2	01/2011-	1461	48	66	2

VERITO VIBE () Saloon 06/2013-

Vehicle	Engine	Fuel	Date	CC	KW	CV	Traction
1.5 dCi		2	06/2013-	1461	48	66	2

MAHINDRA RENAULT

LOGAN () Saloon 04/2007-

Vehicle	Fuel	Date	CC	KW	CV	Traction
1.4	1	04/2007-	1390	55	75	1
1.4 CNG	1	12/2010-	1390	55	75	1
1.6 CNG	1	04/2007-	1598	63	86	1
1.6 CNG	1	04/2007-	1598	63	86	1
1.5 D	2	04/2007-	1461	48	65	2

VERITO () Saloon 03/2011-

Vehicle	Engine	Fuel	Date	CC	KW	CV	Traction
1.4		1	03/2011-	1390	56	76	1
1.5 D		2	03/2011-	1461	48	65	2

NISSAN

KUBISTAR (X76) Van 08/2003-

Vehicle	Engine	Fuel	Date	CC	KW	CV	Traction
1.2	D7F 764	1	08/2003-	1149	44	60	1
1.2 16V	D4F 712	1	04/2006-	1149	55	75	1
1.4	K7J 700	1	08/2003-10/2009	1390	55	75	1
1.6 16V	K4M 752	1	08/2003-10/2009	1598	70	95	1
1.5 dCi	K9K 710 K9K 714	2	08/2003-10/2009	1461	42	57	1
1.5 dCi	K9K 710 K9K 714	2	08/2005-10/2009	1461	45	61	1
1.5 dCi	K9K 704	2	08/2003-	1461	48	65	1
1.5 dCi	K9K 722	2	08/2003-10/2009	1461	60	82	1
1.5 dCi 70	K9K 700 K9K 716	2	09/2005-10/2009	1461	50	68	1
dCi 85	K9K 276 K9K 718	2	04/2006-10/2009	1461	62	84	1

KUBISTAR (X76) MPV 08/2003-10/2009

Vehicle	Fuel	Date	CC	KW	CV	Traction
1.2	1	08/2003-10/2009	1149	44	60	1
1.2 16V	1	04/2006-10/2009	1149	55	75	1
1.6 16V	1	08/2003-10/2009	1598	70	95	1
1.5 dCi	2	08/2003-10/2009	1461	42	57	1
1.5 dCi	2	08/2005-10/2009	1461	45	61	1
1.5 dCi	2	08/2003-10/2009	1461	48	65	1
1.5 dCi	2	08/2003-10/2009	1461	60	82	1
1.5 dCi 70	2	04/2006-10/2009	1461	50	68	1
1.5 dCi 85	2	04/2006-10/2009	1461	62	85	1

RENAULT

CLIO (B/C57_, 5/357_) Hatchback 05/1990-08/1999

Vehicle	Engine	Fuel	Date	CC	KW	CV	Traction
1.8 16V (C57D)	F7P 722	1	01/1991-03/1996	1764	99	135	1
Williams (B/C57M)	F7R 700	1	01/1994-09/1998	1998	108	147	1

CLIO II (BB_, CB_) Hatchback 03/1998-

Vehicle	Engine	Fuel	Date	CC	KW	CV	Traction
1.2		1	06/2001-	1149	55	75	1
1.2 (BB0A, BB0F, BB10, BB1K, BB28, BB2D, BB2H, CB0A,...	D7F 710 D7F 720 D7F 722 D7F 726 D7F 746 D7F 764 D7F 766	1	09/1998-02/2010	1149	43	58	1
1.2 16V (BB05, BB0W, BB11, BB27, BB2T, BB2U, BB2V, CB05,...	D4F 706 D4F 712 D4F 714 D4F 722 D4F 728	1	06/2001-08/2016	1149	55	75	1
1.4 (B/CB0C, B/CB0S)	E7J 634 E7J 635 E7J 780 K7J 700	1	09/1998-05/2005	1390	55	75	1
1.4 16V (B/CB0P, BB13)	K4J 710 K4J 711 K4J 712 K4J 713 K4J 715	1	02/2000-07/2008	1390	72	98	1
1.6 (B/CB0D, BB00)	K7M 744 K7M 745 K7M 746	1	09/1998-05/2005	1598	66	90	1
1.6 (BB01, BB1J)	K4M 740 K4M 748	1	06/1999-02/2009	1598	81	110	1
1.6 16V		1	03/1999-12/2008	1598	82	112	1
1.6 16V (BB01, BB0H, BB0T, BB14, BB1D, BB1R, BB2KL, BB3G...	K4M 708 K4M 740 K4M 742 K4M 743 K4M 744 K4M 745 K4M 748	1	09/1998-04/2005	1598	79	107	1
1.2 LPG	D7F 764 D7F 766	18	09/1998-06/2009	1149	43	58	1
1.6 Flex	K4M 740 K4M 748	19	05/2000-12/2006	1598	81	110	1
1.6 Hi-Flex (CB0H)	K4M 748	19	01/2005-02/2010	1598	86	117	1
1.5 dCi	K9K 704	2	06/2001-12/2006	1461	42	57	1
1.5 dCi	K9K 712	2	10/2003-04/2005	1461	74	100	1
1.5 dCi (B/C2J)	K9K 700 K9K 714	2	08/2004-12/2012	1461	50	68	1
1.5 dCi (B/CB03)	K9K 702	2	06/2001-10/2003	1461	59	80	1
1.5 dCi (B/CB07)	K9K 700 K9K 704	2	06/2001-07/2009	1461	48	65	1
1.5 dCi (B/CB08)	K9K 702	2	06/2001-04/2005	1461	60	82	1
1.5 dCi (B/CB3M)	K9K 740	2	06/2005-12/2010	1461	47	64	1
1.5 dCi (BB3N, CB3N)	K9K 718	2	02/2007-06/2009	1461	62	84	1
1.9 dTi (B/CB0U)	F9Q 780 F9Q 782	2	12/1999-05/2005	1870	59	80	1

CLIO II (SB0/1/2_) Hatchback Van 09/1998-

Vehicle	Engine	Fuel	Date	CC	KW	CV	Traction
1.2 (SB0A, SB0F, SB10)	D7F 722 D7F 726 D7F 746	1	03/1999-10/2003	1149	44	60	1
1.2 (SB0A, SB0F, SB1K, SB2D)	D7F 720 D7F 726 D7F 746	1	09/1998-	1149	43	58	1
1.6 (SB0H)	K4M 746	1	11/2003-	1598	79	107	1
1.5 dCi	K9K 714	2	04/2004-	1461	50	68	1
1.5 dCi	K9K 702	2	06/2001-10/2004	1461	59	80	1
1.5 dCi	K9K 702 K9K 710 K9K 716	2	11/2003-	1461	60	82	1
1.5 dCi (SB07)	K9K 700 K9K 704	2	06/2001-	1461	48	65	1
1.5 dCi (SB3M)		2	06/2005-12/2010	1461	47	64	1
1.9 D (SB0E)	F8Q 630	2	09/1998-	1870	47	64	1
1.9 DTi (SB0U)	F9Q 780	2	02/2000-05/2001	1870	59	80	1

KANGOO (KC0/1_) MPV 08/1997-

Vehicle	Engine	Fuel	Date	CC	KW	CV	Traction
1.0	D4D 700 D4D 720	1	01/2002-01/2007	999	50	70	1
1.0 RN		1	01/2002-01/2007	999	43	58	1
1.2 (KC0A, KC0K, KC0F, KC01)	D7F 710 D7F 720 D7F 722 D7F 726 D7F 744 D7F 746	1	08/1997-	1149	43	58	1
1.2 16V (KC05, KC06, KC03, KC0T, KC0W, KC1D)	D4F 712 D4F 714 D4F 716 D4F 730	1	06/2001-	1149	55	75	1
1.4 (KC0C, KC0H, KC0B, KC0M)	E7J 634 E7J 635 E7J 780 K7J 700 K7J 701	1	08/1997-	1390	55	75	1
1.6 (KC00)	K7M 746	1	09/1999-06/2001	1598	66	90	1
1.6 16V	K4M 706 K4M 730 K4M 750 K4M 752 K4M 753	1	06/2001-	1598	70	95	1
1.6 16V bivalent	K4M 850	16	06/2005-	1598	60	82	1
1.5 dCi	K9K 704	2	07/2003-	1461	42	57	1
1.5 dCi	K9K 700 K9K 702	2	04/2005-06/2010	1461	45	61	1
1.5 dCi	K9K 714	2	06/2005-	1461	50	68	1
1.5 dCi	K9K 718	2	06/2005-	1461	62	84	1
1.5 dCi (KC07)	K9K 700 K9K 704	2	12/2001-	1461	48	65	1
1.5 dCi (KC08, KC09)	K9K 702 K9K 710	2	07/2002-	1461	60	82	1
1.9 dTi (KC0U)	F9Q 780	2	02/2000-	1870	59	80	1
1.9 RXED	F8Q 632	2	09/1999-06/2001	1870	48	65	1
D 55 1.9 (KC0D)	F8Q 662	2	08/1997-	1870	40	54	1
D 65 1.9 (KC0E, KC02, KC0J, KC0N)	F8Q 630 F8Q 632	2	08/1997-06/2001	1870	47	64	1
Elect'road RE	5DC 700	11	01/2002-12/2004		22	30	1

KANGOO EXPRESS (FC0/1_) Box Body/MPV 08/1997-

Vehicle	Engine	Fuel	Date	CC	KW	CV	Traction
1.0		1	07/2003-	998	40	54	1
1.0	D7D 700	1	01/2002-01/2007	999	43	59	1
1.0	D4D 700 D4D 720	1	01/2002-01/2007	999	50	70	1
1.2 (FC01, FC0A, FC0F)	D7F 710 D7F 720 D7F 722 D7F 726 D7F 744 D7F 746	1	08/1997-	1149	43	58	1
1.2 (FC1A)	D7F 710 D7F 722 D7F 744 D7F 764 D7F 766	1	07/1998-07/2001	1149	44	60	1
1.2 16V (FC05, FC0W, FC1D, FC1P, FC1K, FC0T)	D4F 712 D4F 714 D4F 730	1	10/2001-	1149	55	75	1
1.4 (FC0C, FC0B, FC0H, FC0M)	E7J 634 E7J 635 E7J 780 K7J 700 K7J 701	1	08/1997-06/2008	1390	55	75	1
1.6	K7M 746	1	09/1999-06/2001	1598	66	90	1
1.6 16V	K4M 706 K4M 752	1	10/2001-	1598	70	95	1
1.6 16V bivalent	K4M 850	16	06/2005-	1598	60	82	1
1.2 BiFuel	D7F 710 D7F 744	18	07/1998-07/2001	1149	43	58	1
1.6 Flex (FC1U, FC1Y, FC14, FC16, FC17)	K4M 850	19	03/2007-12/2018	1598	72	98	1
1.5 dCi	K9K 716	2	10/2005-	1461	45	61	1
1.5 dCi (FC07, FC1R)	K9K 700 K9K 702 K9K 704	2	12/2001-	1461	48	65	1
1.5 dCi (FC08, FC09)	K9K 702 K9K 710	2	04/2003-	1461	60	82	1
1.5 dCi (FC1E)	K9K 714	2	06/2005-	1461	50	68	1
1.5 dCi (FC1G)	K9K 718	2	06/2005-	1461	62	84	1
1.5 dCi (FC1R)	K9K 704	2	12/2002-	1461	42	57	1
1.9 D (FC0J)	F8Q 632	2	09/1999-06/2003	1870	48	65	1
1.9 dCi (FC0V)	F9Q 782 F9Q 790	2	07/2003-	1870	62	84	1
1.9 dTi (FC0U)	F9Q 780	2	02/2000-	1870	59	80	1
D 55 1.9 (FC0D)	F8Q 662	2	08/1997-	1870	40	54	1
D 65 1.9 (FC0E, FC02, FC0J, FC0N)	F8Q 630 F8Q 632	2	08/1997-	1870	47	64	1

KANGOO II / GRAND KANGOO (KW0/1_) MPV 02/2008-

Vehicle	Engine	Fuel	Date	CC	KW	CV	Traction
1.5 dCi		2	01/2009-	1461	48	65	1
1.5 dCi 70 (KW0V, KW0A)	K9K 800 K9K 802	2	02/2008-	1461	50	68	1

LOGAN / TONDAR 90 (LS_) Saloon 09/2004-

Vehicle	Engine	Fuel	Date	CC	KW	CV	Traction
1.4	K7J 710	1	09/2004-	1390	55	75	1
1.6	K7M 710	1	09/2004-	1598	64	87	1
1.6		1	09/2014-	1598	74	101	1
1.6 (LS0L, LS09, LS0V, LS0P, LS18, LS1S, LS1V, LS1Y,...	K4M 690 K4M 694 K4M 696 K4M 697 K4M 698	1	04/2007-10/2013	1598	77	105	1
1.6 Flex		1	11/2007-08/2012	1598	70	95	1
1.6 Flex		1	07/2007-	1598	82	112	1
1.4 LPG	K7J 714	18	02/2008-10/2013	1390	53	72	1
1.5 dCi	K9K 700 K9K 790 K9K 794	2	04/2006-10/2013	1461	48	65	1
1.5 dCi	K9K 792	2	04/2007-	1461	50	68	1
1.5 dCi	K9K 796	2	02/2008-06/2015	1461	63	86	1

LOGAN / TONDAR 90 (KS_) Estate 04/2007-

Vehicle	Engine	Fuel	Date	CC	KW	CV	Traction
1.4	K7J 710	1	10/2007-	1390	55	75	1
1.5 dCi		2	06/2011-	1461	48	65	1
1.5 dCi	K9K 792	2	04/2007-	1461	50	68	1
1.5 dCi	K9K 796	2	02/2008-06/2015	1461	63	86	1
1.5 dCi (KS04, KS1L)		2	06/2011-06/2015	1461	66	90	1

LOGAN EXPRESS / TONDAR (US_) Estate Van 04/2007-

Vehicle	Engine	Fuel	Date	CC	KW	CV	Traction
1.6	K7M 710	1	04/2007-	1598	64	87	1
1.5 dCi	K9K 792	2	04/2007-	1461	50	68	1

LOGAN II MCV / TONDAR (K8_) Estate 11/2013-

Vehicle	Engine	Fuel	Date	CC	KW	CV	Traction
1.6	K7M 812	1	12/2013-	1598	59	80	1
1.5 dCi	K9K 838	2	12/2013-	1461	62	84	1
1.5 dCi		2	12/2013-	1461	66	90	1

MEGANE (BA0/1_) Hatchback 08/1995-12/2004

Vehicle	Engine	Fuel	Date	CC	KW	CV	Traction
1.4 16V (BA0D, BA1H, BA0W, BA10)	K4J 714 K4J 750	1	03/1999-08/2003	1390	70	95	1
1.4 e (BA0E, BA0V)	E7J 626 E7J 764	1	01/1996-08/2003	1390	55	75	1
1.4 Eco (BA0T)	E7J 624	1	01/1996-03/1999	1390	52	71	1
1.6		1	02/2000-09/2000	1598	64	87	1
1.6 16V		1	11/2001-12/2004	1598	81	110	1
1.6 16V (BA04, BA0B, BA11, BA1J, BA16, BA19, BA1K, BA1V,...	K4M 700 K4M 701 K4M 706 K4M 708 K4M 709	1	03/1999-08/2002	1598	79	107	1
1.6 e (BA0F, BA0S)	K7M 702 K7M 703 K7M 790	1	01/1996-03/1999	1598	66	90	1
1.6 i (BA0L)	K7M 720	1	01/1996-03/1999	1598	55	75	1
2.0	F3R 750 F3R 751 F3R 791 F3R 796 F3R 797 F3R 798	1	05/1998-05/2001	1998	85	115	1
2.0 i (BA0G)	F3R 750 F3R 751	1	01/1996-08/2003	1998	84	114	1
1.6 LPG	K7M 702	18	08/1995-03/1999	1598	66	90	1
1.6 LPG	K4M 704 K4M 712	18	10/2000-08/2002	1598	80	109	1
1.9 D	F8Q 784	2	04/1996-02/2001	1870	69	94	1
1.9 D Eco (BA0A, BA0U, BA0R)	F8Q 620 F8Q 622 F8Q 624	2	01/1996-08/2003	1870	47	64	1
1.9 dCi	F9Q 732 F9Q 738	2	03/1999-08/2003	1870	77	105	1
1.9 DT	F8Q 784	2	08/1998-10/1999	1870	76	104	1
1.9 dT (B/SA0K, B/SA0Y)	F8Q 784 F8Q 786	2	01/1996-08/2003	1870	66	90	1
1.9 dTI	F9Q 730	2	02/2000-09/2000	1870	60	82	1
1.9 dTi (BA08, BA0N)	F9Q 730 F9Q 731 F9Q 734 F9Q 736	2	03/1997-02/2001	1870	72	98	1
1.9 TDI	F8Q 784	2	09/1996-08/2003	1870	69	94	1

MEGANE Hatchback Van (SA0/1_) Hatchback Van 08/1995-07/2003

Vehicle	Engine	Fuel	Date	CC	KW	CV	Traction
1.9 (SA0U, SA0R, SA0A)	F8Q 620 F8Q 622 F8Q 624	2	08/1995-09/2000	1870	47	64	1
1.9 dCi	F9Q 738	2	10/2000-07/2003	1870	59	80	1

MEGANE Coach (DA0/1_) Coupe 03/1996-08/2003

Vehicle	Engine	Fuel	Date	CC	KW	CV	Traction
1.4 16V (DA0D, DA1H, DA0W, DA10)	K4J 700 K4J 714 K4J 750	1	03/1999-07/2003	1390	70	95	1
1.6 e (DA0F)	K7M 702 K7M 703	1	03/1996-03/1999	1598	66	90	1
2.0 i (DA0G)	F3R 750 F3R 751 F3R 798	1	03/1996-08/2003	1998	84	114	1
1.9 dTi (DA0N)	F9Q 731 F9Q 734 F9Q 736	2	03/1997-02/2001	1870	72	98	1

MEGANE Classic (LA0/1_) Saloon 09/1996-08/2008

Vehicle	Engine	Fuel	Date	CC	KW	CV	Traction
1.4 (LA0E, LA0V)	E7J 626 E7J 764	1	09/1996-08/2003	1390	55	75	1
1.4 16V (LA0D, LA1H, lA0W, LA10)	K4J 714 K4J 750	1	03/1999-08/2003	1390	70	95	1
1.6	K7M 704	1	02/2000-09/2000	1598	64	87	1
1.6 16V	K4M 706	1	01/1999-08/2008	1598	73	99	1
1.6 16V		1	09/1999-12/2001	1598	81	110	1
1.6 16V (LA00, LA04, LA0B, LA11, LA16, LA19, LA1J, LA1K,...	K4M 700 K4M 701 K4M 706 K4M 708 K4M 709	1	03/1999-07/2003	1598	79	107	1
1.6 e (LA0F, LA0S)	K7M 702 K7M 703 K7M 790	1	09/1996-03/1999	1598	66	90	1
1.6 i (LA0L)	K7M 720	1	09/1996-03/1999	1598	55	75	1
2.0	F3R 750 F3R 752 F3R 791 F3R 796 F3R 797 F3R 798	1	05/1998-05/2001	1998	85	115	1
2.0 i (LA07, LA0G)	F3R 750 F3R 751 F3R 752 F3R 791 F3R 796 F3R 797 F3R 798	1	09/1996-08/2003	1998	84	114	1
2.0 RT		1	10/1996-02/1999	1998	112	152	1
1.9 D (LA0A, LA0U, LA0R)	F8Q 620 F8Q 622 F8Q 624	2	09/1996-08/2003	1870	47	64	1
1.9 dCi (LA05)	F9Q 732 F9Q 733	2	03/1999-07/2003	1870	77	105	1
1.9 DT	F8Q 784	2	08/1998-10/1999	1870	76	104	1
1.9 dT (LA0K, LA0Y)	F8Q 784 F8Q 786	2	09/1996-08/2003	1870	66	90	1
1.9 dTi (LA08, LA0N, LA0K)	F9Q 730 F9Q 731 F9Q 734 F9Q 736	2	03/1997-02/2001	1870	72	98	1
1.9 TDI	F8Q 784	2	09/1996-08/2003	1870	69	94	1

MEGANE (EA0/1_) Convertible 10/1996-08/2003

Vehicle	Engine	Fuel	Date	CC	KW	CV	Traction
1.4 16V (EA0D, EA1H, EA0W, EA10)	K4J 714 K4J 750	1	03/1999-08/2003	1390	70	95	1
1.6 e (EA0F)	K7M 702 K7M 703	1	10/1996-03/1999	1598	66	90	1
2.0 (EA0G)	F3R 750 F3R 798	1	04/1997-08/2003	1998	84	114	1

MEGANE Scenic (JA0/1_) MPV 10/1996-12/2001

Vehicle	Engine	Fuel	Date	CC	KW	CV	Traction
1.4 i (JA0E)	E7J 764	1	01/1997-09/1999	1390	55	75	1
1.6 e (JA0F)	K7M 702 K7M 703	1	10/1996-10/1999	1598	66	90	1
1.6 i (JA0L)	K7M 720	1	01/1997-09/1999	1598	55	75	1

MEGANE Grandtour (KA0/1_) Estate 03/1999-08/2003

Vehicle	Engine	Fuel	Date	CC	KW	CV	Traction
1.4 16V (KA0D, KA1H, KA0W, KA10)	K4J 714 K4J 750	1	03/1999-08/2003	1390	70	95	1
1.4 e (KA0V)	E7J 626	1	03/1999-08/2003	1390	55	75	1
1.6 16V (KA0B, KA04, KA11)	K4M 700 K4M 701 K4M 708 K4M 709	1	03/1999-08/2003	1598	79	107	1
1.6 BiFuel		1	04/2001-07/2003	1598	79	107	1
1.6 e (KA0F)	K7M 702 K7M 703	1	03/1999-08/2003	1598	66	90	1
1.9 D (KA0J, KA0R)	F8Q 622 F8Q 790	2	04/1999-08/2003	1870	47	64	1

MEGANE Kombi van (KA_) Estate Van 02/2000-07/2003

Vehicle	Engine	Fuel	Date	CC	KW	CV	Traction
1.4 (KA0D)	K4J 714 K4J 750	1	04/2001-07/2003	1390	70	95	1
1.6 (KA0B, KA04)	K4M 700 K4M 701 K4M 708 K4M 709	1	04/2001-07/2003	1598	79	107	1
1.6 BiFuel (KA04)	K4M 704	18	04/2001-07/2003	1598	80	109	1
1.6 BiFuel (KA0B)	K4M 712	18	04/2001-07/2003	1598	79	107	1
1.9 D (KA0R)	F8Q 622	2	02/2000-09/2000	1870	47	64	1
1.9 dTi (KA1U)	F9Q 744	2	04/2001-07/2003	1870	59	80	1

R 19 (B/C53_) Hatchback 01/1988-09/1994

Vehicle	Engine	Fuel	Date	CC	KW	CV	Traction
1.7	F3N 746	1	06/1989-04/1992	1721	79	107	1
1.7 (B/C53C)	F3N 742 F3N 743	1	09/1988-04/1992	1721	66	90	1
1.8 16V	F7P 700	1	06/1989-04/1992	1764	101	137	1
1.8 16V (B/C53D)	F7P 704	1	06/1989-04/1992	1764	99	135	1

R 19 (L53_) Saloon 01/1988-12/1992

Vehicle	Engine	Fuel	Date	CC	KW	CV	Traction
1.7 (L533)	F2N 720 F2N 721	1	09/1988-12/1992	1721	68	92	1
1.7 (L53C)	F3N 742 F3N 743	1	07/1988-04/1992	1721	66	90	1
1.7 (L53F)	F3N 746	1	08/1988-12/1992	1721	79	107	1
1.8 16V	F7P 700	1	06/1989-08/1990	1764	101	137	1
1.8 16V (L53D)	F7P 704	1	10/1989-04/1992	1764	99	135	1

R 19 II (B/C53_) Hatchback 01/1991-06/2001

Vehicle	Engine	Fuel	Date	CC	KW	CV	Traction
1.7	F3N 746	1	05/1992-09/1994	1721	79	107	1
1.7 (B/C53B)	F3N 740 F3N 741	1	04/1992-12/1995	1721	54	73	1
1.7 (B/C53C)	F3N 743	1	04/1992-12/1995	1721	66	90	1
1.8 (5/353A)	F3P 706 F3P 760	1	04/1992-12/1995	1794	66	90	1
1.8 (5/353F, B/C538)	F3P 682 F3P 765	1	05/1994-12/1995	1794	79	107	1
1.8 (B/C538)	F3P 700	1	04/1992-05/1994	1794	81	110	1
1.8 (B/C53Y)	F3P 706 F3P 707 F3P 708 F3P 760	1	04/1992-12/1995	1794	65	88	1
1.8 16V	F7P 702	1	10/1996-06/2001	1764	104	141	1
1.8 16V (B/C53D)	F7P 704	1	04/1992-12/1995	1764	99	135	1
1.9 dT (B/C53T)	F8Q 744	2	04/1992-12/1995	1870	66	90	1

R 19 II (D53_) Convertible 07/1991-04/1992

Vehicle	Engine	Fuel	Date	CC	KW	CV	Traction
1.8 16V (D53D)	F7P 700 F7P 704	1	07/1991-04/1992	1764	101	137	1

R 19 II (D53_, 853_) Convertible 04/1992-06/2001

Vehicle	Engine	Fuel	Date	CC	KW	CV	Traction
1.8		1	01/1995-06/2001	1794	86	117	1
1.8 (853A)	F3P 706 F3P 760	1	09/1993-06/1996	1794	66	90	1
1.8 (D53Y)	F3P 706 F3P 707	1	04/1992-01/1996	1794	69	94	1
1.8 16V (D53D)	F7P 704	1	04/1992-06/1996	1764	99	135	1
1.8 16V (D53D)	F7P 704	1	05/1992-04/1994	1764	101	137	1

R 19 II CHAMADE (L53_) Saloon 04/1992-08/2003

Vehicle	Engine	Fuel	Date	CC	KW	CV	Traction
1.6	K7M 703	1	10/1996-06/2001	1598	66	90	1
1.7 (L533)	F2N 720 F2N 721	1	01/1993-08/1995	1721	68	92	1
1.8	F3P 765	1	05/1992-09/1994	1794	67	91	1
1.8	F3P 700 F3P 706	1	05/1992-11/1995	1794	79	107	1
1.8 (453A/F)	F3P 706 F3P 760	1	04/1992-12/1995	1794	66	90	1
1.8 (L538)	F3P 700	1	04/1992-05/1994	1794	81	110	1
1.8 (L53V, L538)	F3P 682	1	05/1994-12/1995	1794	79	107	1
1.8 (L53Y)	F3P 704 F3P 705 F3P 706 F3P 707 F3P 708 F3P 760	1	04/1992-12/1995	1794	65	88	1
1.8 16V (L53D)	F7P 704	1	04/1992-12/1995	1764	99	135	1
1.9 D	F8Q 740 F8Q 744	2	05/1992-11/1995	1870	68	92	1
1.9 dT (L53T)	F8Q 744	2	04/1992-12/1995	1870	66	90	1

SANDERO/STEPWAY (BS_) Hatchback 11/2007-

Vehicle	Engine	Fuel	Date	CC	KW	CV	Traction
1.4	K7J 710	1	02/2009-	1390	55	75	1
1.6	K7M 718	1	11/2010-	1598	62	84	1
1.6		1	05/2009-	1598	66	90	1
1.6	K7M 710	1	12/2007-	1598	75	102	1
1.6	K4M 697	1	12/2007-07/2013	1598	76	103	1
1.6	K4M 690	1	12/2012-	1598	77	105	1
1.6 (BS0H, BS0F)	K7M 710	1	02/2009-	1598	64	87	1
1.6 (BS0V, BS1V)		1	09/2009-	1598	82	112	1
1.4 LPG	K7J 714	18	02/2009-	1390	53	72	1
1.6 Flex		19	12/2012-	1598	77	105	1
1.6 Flex (BS0V, BS1V, BS09)		19	08/2008-	1598	82	112	1

THALIA / SYMBOL (LB_) Saloon 02/1998-

Vehicle	Engine	Fuel	Date	CC	KW	CV	Traction
1.2 16V	D4F 706 D4F 712 D4F 728	1	04/2002-	1149	55	75	1
1.4 16V	K4J 712	1	08/2000-	1390	72	98	1
1.6	K7M 746	1	03/1998-	1598	66	90	1
1.6	K4M 736	1	01/2004-12/2008	1598	82	112	1
1.6 16V	K4M 740	1	07/2000-02/2009	1598	79	107	1
1.6 Flex		1	11/2004-02/2009	1598	81	110	1
1.6 Authentique Hi-Flex (LB26, LB3E)	K4M 742 K4M 743	19	11/2004-02/2009	1598	86	115	1
1.5 dCi	K9K 740	2	06/2005-	1461	47	64	1
1.5 dCi	K9K 700	2	04/2002-	1461	48	65	1
1.5 dCi	K9K 700 K9K 714	2	02/2003-	1461	50	68	1
1.5 dCi	K9K 706	2	04/2004-11/2009	1461	58	79	1
1.9 D	F8Q 630	2	02/1998-05/2001	1870	48	65	1

THALIA II / SYMBOL (LU_) Saloon 09/2008-

Vehicle	Engine	Fuel	Date	CC	KW	CV	Traction
1.4	K4J 712	1	01/2009-12/2011	1390	72	98	1
1.6 16V	K4M 743	1	09/2008-	1598	77	105	1
1.6 16V (LU1A, LU1B, LU1D, LU2M)	K4M 744 K4M 745	1	01/2009-	1598	79	107	1

TWINGO (C06_) Hatchback 03/1993-10/2012

Vehicle	Engine	Fuel	Date	CC	KW	CV	Traction
1.2 (C066, C068)	D7F 700 D7F 701 D7F 702 D7F 703 D7F 704	1	05/1996-06/2007	1149	43	58	1
1.2 (C067)	D7F 700 D7F 701	1	05/1996-03/2007	1149	40	54	1
1.2 16V (C060)	D4F 708	1	08/2004-06/2007	1149	44	60	1
1.2 16V (C06C, C06D, C06K)	D4F 702	1	01/2001-06/2007	1149	55	75	1
1.2 LPG	D7F 702 D7F 708	18	10/2003-06/2007	1149	44	60	1

TWINGO (S06_) Hatchback Van 03/1993-06/2012

Vehicle	Engine	Fuel	Date	CC	KW	CV	Traction
1.2		1	03/1997-08/2003	1149	44	60	1
1.2 (S066, S068)	D7F 700 D7F 701 D7F 702 D7F 703 D7F 704 D7F 706	1	05/1996-08/2004	1149	43	58	1

TWINGO II (CN0_) Hatchback 03/2007-

Vehicle	Engine	Fuel	Date	CC	KW	CV	Traction
1.2 (CN0D)	D7F 800	1	03/2007-09/2014	1149	43	58	1
1.2 16V	D4F 764	1	03/2008-	1149	55	75	2
1.2 16V (CN04, CN0B)	D4F 764 D4F 770 D4F 772	1	03/2007-09/2014	1149	55	75	1
1.2 16V (CN0K, CN0V, CN0A)	D4F 772	1	03/2007-	1149	56	76	1
1.2 TCe 100 (CN0P)	D4F 780 D4F 782	1	02/2011-	1149	75	102	1
1.2 Turbo (CN0C, CN0F)	D4F 780 D4F 782	1	03/2007-09/2014	1149	74	100	1
1.5 dCi (CN0E)	K9K 740	2	03/2007-09/2014	1461	47	64	1
1.5 dCi (CN0U)	K9K 718	2	04/2008-09/2014	1461	62	84	1
1.5 dCi 75	K9K 820	2	10/2010-	1461	55	75	1
1.5 dCi 90	K9K 820	2	10/2010-	1461	63	86	1

TWINGO II (CNO_) Hatchback Van 09/2010-09/2014

Vehicle	Engine	Fuel	Date	CC	KW	CV	Traction
1.2 (CN01, CN06)	D4F 770	1	09/2010-09/2014	1149	55	75	1
1.5 dCi (CN03)	K9K 820	2	10/2010-09/2014	1461	55	75	1

Return
