Product 78BD3555-2

Description
Brake disc
Axe
Front
No. of Pieces
2
Barcode
EAN13 Code
8424073145109
QR Code
Url
https://catalogonuevo.icerbrakes.com/Producto/Details?idProducto=78BD3555-2
Weight (gr.)
18776
Measures
Ø330x24x66.3
Brake Disc Type: Vented
Minimum thickness [mm]: 22.4
Hole Arrangement/Number: 5
Bolt Hole Circle Ø [mm]: 120
Wheel Hub Diameter [mm]: 75
Reference applications
Brand OE Reference
BMW 34 11 6 794 429
Maker Cross reference
ATE 24.0124-0239.2
ATE 424239
BREMBO 09.C410.13
DELPHI LOCKHEED BG9129BC
GIRLING 6066165
LETEC LBB048V
ROAD HOUSE 61548.10
SANLI SL37025
TEXTAR 92265825
TRW DF6616S
BMW
5 Serie VI (F10) Saloon 01/2009-10/2016
Vehicle Engine Fuel Date CC KW CV Traction
520 i

N20 B16 A

 1 07/2013-10/2016 1592 125 170 2
520 i

N20 B20 A

N20 B20 B

 1 09/2011-10/2016 1997 120 163 2
520 i

N20 B20 A

N20 B20 B

 1 09/2011-10/2016 1997 135 184 2
523 i

N52 B25 A

N52 B25 AF

N52 B25 B

N52 B25 BF

 1 01/2010-08/2011 2497 150 204 2
523 i

N53 B30 A

 1 06/2009-08/2011 2996 150 204 2
523 i

N53 B30 A

 1 01/2010-08/2011 2996 155 211 2
528 i xDrive

N20 B20 A

 1 09/2011-10/2016 1997 180 245 3
528i

N20 B20 A

 1 09/2011-10/2016 1997 180 245 2
528i

N52 B30 A

 1 10/2009-08/2011 2996 179 243 2
530i

N52 B30 A

N52 B30 AF

N52 B30 BF

 1 03/2010-06/2013 2996 190 258 2
518 d

N47 D20 C

 2 07/2013-10/2016 1995 100 136 2
518 d

N47 D20 C

 2 07/2013-06/2014 1995 105 143 2
518 d

B47 D20 A

 2 07/2014-10/2016 1995 110 150 2
518 d

B47 D20 A

 2 10/2013-10/2016 1995 120 163 2
520 d

N47 D20 C

 2 01/2013-06/2014 1995 100 136 2
520 d

B47 D20 A

N47 D20 C

 2 06/2010-10/2016 1995 120 163 2
520 d

N47 D20 C

 2 06/2010-06/2014 1995 135 184 2
520 d

B47 D20 A

 2 07/2014-10/2016 1995 140 190 2
520 d

N47 D20 C

 2 06/2010-06/2014 1995 147 200 2
520 d

B47 D20 A

 2 07/2014-10/2016 1995 151 205 2
520 d

B47 D20 A

 2 10/2013-10/2016 1995 155 211 2
520 d xDrive

N47 D20 C

 2 01/2013-06/2014 1995 100 136 3
520 d xDrive

B47 D20 A

 2 07/2013-10/2016 1995 120 163 3
520 d xDrive

N47 D20 C

 2 07/2013-06/2014 1995 135 184 3
520 d xDrive

B47 D20 A

 2 07/2014-10/2016 1995 140 190 3
520 d xDrive

N47 D20 C

 2 01/2013-06/2014 1995 147 200 3
520 d xDrive

B47 D20 A

 2 07/2014-10/2016 1995 151 205 3
520 d xDrive

B47 D20 A

 2 10/2013-10/2016 1995 155 211 3
525 d

N47 D20 D

 2 09/2011-10/2016 1995 155 211 2
525 d

N47 D20 D

 2 09/2011-10/2016 1995 160 218 2
525 d

N57 D30 A

 2 03/2010-08/2011 2993 150 204 2
525 d xDrive

N47 D20 D

 2 09/2011-10/2016 1995 155 211 3
525 d xDrive

N47 D20 D

 2 09/2011-10/2016 1995 160 218 3
5 Serie VI Touring (F11) Estate 11/2009-
Vehicle Engine Fuel Date CC KW CV Traction
520 i

N20 B20 A

N20 B20 B

 1 09/2011-02/2017 1997 120 163 2
520 i

N20 B20 A

N20 B20 B

 1 10/2010-02/2017 1997 135 184 2
523 i

N52 B25 A

N52 B25 AF

N52 B25 B

 1 11/2009-08/2011 2497 150 204 2
523 i

N53 B30 A

 1 11/2009-08/2011 2996 150 204 2
528 i xDrive

N20 B20 A

 1 09/2011-02/2017 1997 180 245 3
528i

N20 B20 A

 1 09/2011-02/2017 1997 180 245 2
528i

N53 B30 A

 1 11/2009-08/2011 2996 190 258 2
530i

N53 B30 A

 1 07/2011-06/2013 2996 200 272 2
518 d

B47 D20 A

N47 D20 C

 2 07/2013-02/2017 1995 100 136 2
518 d

N47 D20 C

 2 07/2013-06/2014 1995 105 143 2
518 d

B47 D20 A

 2 07/2014-02/2017 1995 110 150 2
518 d

B47 D20 A

 2 07/2014-02/2017 1995 120 163 2
520 d

N47 D20 C

 2 06/2010-06/2014 1995 100 136 2
520 d

B47 D20 A

N47 D20 C

 2 06/2010-02/2017 1995 120 163 2
520 d

N47 D20 C

 2 06/2010-06/2014 1995 135 184 2
520 d

B47 D20 A

 2 07/2014-02/2017 1995 140 190 2
520 d

N47 D20 C

 2 06/2010-06/2014 1995 147 200 2
520 d

B47 D20 A

 2 07/2014-02/2017 1995 151 205 2
520 d

B47 D20 A

 2 07/2014-02/2017 1995 155 211 2
520 d xDrive

N47 D20 C

 2 07/2013-06/2014 1995 100 136 3
520 d xDrive

B47 D20 A

 2 07/2013-02/2017 1995 120 163 3
520 d xDrive

N47 D20 C

 2 07/2013-06/2014 1995 135 184 3
520 d xDrive

B47 D20 A

 2 07/2014-02/2017 1995 140 190 3
520 d xDrive

N47 D20 C

 2 07/2013-06/2014 1995 147 200 3
520 d xDrive

B47 D20 A

 2 07/2014-02/2017 1995 151 205 3
520 d xDrive

B47 D20 A

 2 07/2014-02/2017 1995 155 211 3
525 d

N47 D20 D

 2 09/2011-02/2017 1995 160 218 2
525 d

N57 D30 A

 2 09/2010-08/2011 2993 150 204 2
525 d xDrive

N47 D20 D

 2 07/2013-02/2017 1995 160 218 3
BMW (BRILLIANCE)
5 SERIES VI (F10, F18) Saloon 08/2010-
Vehicle Engine Fuel Date CC KW CV Traction
520 Li

N20 B20 D

 1 09/2013-05/2017 1997 135 184 2
525 Li

N20 B20 A,N20 B20 C

 1 08/2012-05/2017 1997 160 218 2
