Product 78BD3562-2

Description
Brake disc
Axe
Rear
No. of Pieces
2
Barcode
EAN13 Code
8424073145123
QR Code
Url
https://catalogonuevo.icerbrakes.com/Producto/Details?idProducto=78BD3562-2
Weight (gr.)
19512
Measures
Ø345x24x69
Brake Disc Type: Vented
Minimum thickness [mm]: 22.4
Hole Arrangement/Number: 5
Bolt Hole Circle Ø [mm]: 120
Wheel Hub Diameter [mm]: 75
Reference applications
Brand OE Reference
BMW 34 21 6 775 289
Maker Cross reference
ATE 24.0124-0233.2
ATE 424233
BREMBO 09.C404.13
DELPHI LOCKHEED BG9130BC
FERODO DDF2037VC
GIRLING 6066105
HELLA-PAGID 8DD 355 119-281
HELLA-PAGID 8DD 355 132-501
ROAD HOUSE 61551.10
SANLI SL36974
TEXTAR 92253925
TEXTAR 98200 2539 0 1
TRW DF6610S
BMW
5 Serie VI (F10) Saloon 01/2009-10/2016
Vehicle Engine Fuel Date CC KW CV Traction
3.0 535i 1 03/2010- 2996 225 306 1
535 i xDrive

N55 B30 A

 1 03/2011-10/2016 2979 225 306 3
535 i xDrive

N55 B30 A

 1 07/2013-10/2016 2979 240 326 3
535i

N55 B30 A

 1 01/2010-10/2016 2979 225 306 2
535i

N55 B30 A

 1 07/2013-10/2016 2979 240 326 2
550 i xDrive

N63 B44 A

 1 08/2010-06/2013 4395 300 408 3
550 i xDrive

N63 B44 B

 1 07/2013-10/2016 4395 330 449 3
550i

N63 B44 A

 1 03/2010-06/2013 4395 300 408 2
550i

N63 B44 B

 1 07/2013-10/2016 4395 330 449 2
ActiveHybrid

N55 B30 A

 13 12/2011-10/2016 2979 225 306 2
ActiveHybrid

N55 B30 A

 13 12/2011-10/2016 2979 250 340 2
530 d

N57 D30 A

 2 01/2010-08/2011 2993 180 245 2
530 d

N57 D30 A

 2 09/2011-10/2016 2993 190 258 2
530 d

N57 D30 A

 2 09/2010-10/2016 2993 210 286 2
530 d xDrive

N57 D30 A

 2 03/2011-10/2016 2993 190 258 3
530 d xDrive

N57 D30 A

 2 03/2011-10/2016 2993 210 286 3
535 d

N57 D30 B

 2 09/2010-08/2011 2993 220 299 2
535 d

N57 D30 B

 2 09/2011-10/2016 2993 230 313 2
535 d xDrive

N57 D30 B

 2 09/2011-10/2016 2993 230 313 3
M 550 d xDrive

N57 D30 C

 2 03/2012-10/2016 2993 280 381 3
5 Serie VI GRAN TURISMO (F07) Hatchback 01/2009-
Vehicle Engine Fuel Date CC KW CV Traction
528i

N20 B20 A

 1 07/2013-02/2017 1997 180 245 2
535 i xDrive

N55 B30 A

 1 09/2010-02/2017 2979 225 306 3
535i

N55 B30 A

 1 01/2009-02/2017 2979 225 306 2
520 d

N47 D20 C

 2 07/2013-02/2017 1995 100 136 2
520 d

N47 D20 C

 2 07/2012-06/2013 1995 120 163 2
520 d

N47 D20 C

 2 04/2011-02/2017 1995 135 184 2
530 d

N57 D30 A

 2 09/2010-02/2017 2993 155 211 2
530 d

N57 D30 A

 2 08/2009-06/2012 2993 180 245 2
530 d

N57 D30 A

 2 07/2012-02/2017 2993 190 258 2
530 d xDrive

N57 D30 A

 2 06/2010-06/2012 2993 180 245 3
530 d xDrive

N57 D30 A

 2 07/2012-02/2017 2993 190 258 3
535 d

N57 D30 B

 2 03/2010-06/2012 2993 220 299 2
535 d

N57 D30 B

 2 07/2012-02/2017 2993 230 313 2
535 d xDrive

N57 D30 B

 2 03/2010-06/2012 2993 220 299 3
535 d xDrive

N57 D30 B

 2 07/2012-02/2017 2993 230 313 3
5 Serie VI Touring (F11) Estate 11/2009-
Vehicle Engine Fuel Date CC KW CV Traction
528 i xDrive

N20 B20 A

 1 09/2011-02/2017 1997 180 245 3
528i

N20 B20 A

 1 09/2011-02/2017 1997 180 245 2
528i

N53 B30 A

 1 11/2009-08/2011 2996 190 258 2
535 i xDrive

N55 B30 A

 1 09/2011-02/2017 2979 225 306 3
535 i xDrive

N55 B30 A

 1 07/2013-02/2017 2979 240 326 3
535i

N55 B30 A

 1 06/2010-02/2017 2979 225 306 2
535i

N55 B30 A

 1 07/2013-02/2017 2979 240 326 2
550i

N63 B44 A

 1 09/2010-06/2013 4395 300 408 2
550i

N63 B44 B

 1 07/2013-02/2017 4395 330 449 2
518 d

B47 D20 A

N47 D20 C

 2 07/2013-02/2017 1995 100 136 2
518 d

N47 D20 C

 2 07/2013-06/2014 1995 105 143 2
518 d

B47 D20 A

 2 07/2014-02/2017 1995 110 150 2
520 d

B47 D20 A

N47 D20 C

 2 06/2010-02/2017 1995 120 163 2
520 d

N47 D20 C

 2 06/2010-06/2014 1995 135 184 2
520 d

B47 D20 A

 2 07/2014-02/2017 1995 140 190 2
520 d xDrive

B47 D20 A

 2 07/2013-02/2017 1995 120 163 3
520 d xDrive

N47 D20 C

 2 07/2013-06/2014 1995 135 184 3
520 d xDrive

B47 D20 A

 2 07/2014-02/2017 1995 140 190 3
525 d

N47 D20 D

 2 09/2011-02/2017 1995 155 211 2
525 d

N47 D20 D

 2 09/2011-02/2017 1995 160 218 2
525 d

N57 D30 A

 2 09/2010-08/2011 2993 150 204 2
525 d xDrive

N47 D20 D

 2 07/2013-02/2017 1995 155 211 3
525 d xDrive

N47 D20 D

 2 07/2013-02/2017 1995 160 218 3
530 d

N57 D30 A

 2 06/2010-08/2011 2993 180 245 2
530 d

N57 D30 A

 2 09/2011-02/2017 2993 190 258 2
530 d

N57 D30 A

 2 09/2011-02/2017 2993 210 286 2
530 d xDrive

N57 D30 A

 2 03/2011-02/2017 2993 190 258 3
530 d xDrive

N57 D30 A

 2 03/2011-02/2017 2993 210 286 3
535 d

N57 D30 B

 2 09/2010-08/2011 2993 220 299 2
535 d

N57 D30 B

 2 09/2011-02/2017 2993 230 313 2
535 d xDrive

N57 D30 B

 2 09/2011-02/2017 2993 230 313 3
M 550 d xDrive

N57 D30 C

 2 03/2012-02/2017 2993 280 381 3
5 Serie VI (F10, F18 U.S.A.) Saloon 03/2010-
Vehicle Engine Fuel Date CC KW CV Traction
550i 1 09/2012- 298 405 1
6 Serie III (F12) Convertible 12/2010-06/2018
Vehicle Engine Fuel Date CC KW CV Traction
640 i

N55 B30 A

 1 09/2011-06/2018 2979 235 320 2
640 i xDrive

N55 B30 A

 1 03/2013-06/2018 2979 235 320 3
650 i 1 01/2012- 3982 300 408 1
650 i

N63 B44 A

 1 09/2011-12/2012 4395 298 405 2
650 i 1 09/2011- 4395 298 405 1
650 i

N63 B44 A

 1 12/2010-06/2012 4395 300 408 2
650 i

N63 B44 A

N63 B44 B

 1 07/2012-06/2018 4395 330 449 2
650 i xDrive

N63 B44 A

 1 09/2011-06/2012 4395 300 407 3
650 i xDrive

N63 B44 A

N63 B44 B

 1 07/2012-06/2018 4395 330 449 3
640 d

N57 D30 B

 2 09/2011-06/2018 2993 230 313 2
640 d xDrive

N57 D30 B

 2 03/2012-06/2018 2993 230 313 3
6 Serie III (F13) Coupe 07/2011-10/2017
Vehicle Engine Fuel Date CC KW CV Traction
640 i

N55 B30 A

 1 07/2011-10/2017 2979 235 320 2
640 i xDrive

N55 B30 A

 1 03/2013-10/2017 2979 235 320 3
650 i 1 01/2011- 3982 300 408 1
650 i 1 09/2011- 4395 298 405 1
650 i

N63 B44 A

 1 09/2011-12/2012 4395 298 405 2
650 i

N63 B44 A

 1 07/2011-06/2012 4395 300 408 2
650 i

N63 B44 B

 1 07/2012-10/2017 4395 330 449 2
650 i xDrive

N63 B44 A

 1 09/2011-02/2015 4395 300 408 3
650 i xDrive

N63 B44 B

 1 07/2012-10/2017 4395 330 449 3
640 d

N57 D30 B

 2 09/2011-10/2017 2993 230 313 2
640 d xDrive

N57 D30 B

 2 03/2012-10/2017 2993 230 313 3
6 Serie III (F06) Coupe 03/2012-10/2018
Vehicle Engine Fuel Date CC KW CV Traction
640 i

N55 B30 A

 1 03/2012-10/2018 2979 235 320 2
640 i xDrive

N55 B30 A

 1 03/2013-10/2018 2979 235 320 3
650 i 1 05/2013- 3982 300 408 1
650 i

N63 B44 B

 1 07/2012-10/2018 4395 330 449 2
650 i 1 07/2013- 4395 332 452 1
650 i xDrive

N63 B44 B

 1 07/2012-10/2018 4395 330 449 3
640 d

N57 D30 B

 2 03/2012-10/2018 2993 230 313 2
640 d xDrive

N57 D30 B

 2 03/2013-10/2018 2993 230 313 3
7 Serie V (F01, F02, F03, F04) Saloon 02/2008-12/2015
Vehicle Engine Fuel Date CC KW CV Traction
730 i, Li

N52 B30 A

N52 B30 AF

N52 B30 BF

 1 09/2009-06/2015 2996 190 258 2
740 i, Li xDrive

N55 B30 A

 1 07/2012-12/2015 2979 235 320 3
740 i,Li 1 09/2010-12/2015 2979 224 305 2
740 i,Li

N55 B30 A

 1 07/2012-12/2015 2979 235 320 2
740 i,Li

N54 B30 A

 1 09/2008-06/2012 2979 240 326 2
ActiveHybrid 7

N55 B30 A

 13 08/2012-06/2015 2979 235 320 2
ActiveHybrid 7

N55 B30 A

 13 08/2012-06/2015 2979 260 354 2
730 d

N57 D30 A

 2 02/2008-05/2015 2993 155 211 2
730 d

N57 D30 A

 2 09/2008-06/2012 2993 180 245 2
730 d

N57 D30 A

 2 07/2012-05/2015 2993 190 258 2
730 d xDrive

N57 D30 A

 2 11/2011-05/2015 2993 155 211 3
730 d xDrive

N57 D30 A

 2 11/2011-05/2015 2993 190 258 3
740 d

N57 D30 B

 2 09/2009-06/2012 2993 225 306 2
740 d

N57 D30 B

 2 07/2012-06/2015 2993 230 313 2
740d xDrive

N57 D30 B

 2 09/2010-12/2012 2993 225 306 3
740d xDrive

N57 D30 B

 2 07/2012-06/2015 2993 230 313 3
