Product 78BD3608-2
- Description
- Brake disc
- Axe
- Front
- No. of Pieces
- 2
- Barcode
-
8424073145154
- Url
- https://catalogonuevo.icerbrakes.com/Producto/Details?idProducto=78BD3608-2
- Weight (gr.)
- 14808
- R90 Homologation
-
90R-02C0538/0124
- Measures
- Ø305x28x39.7
-
Brake Disc Type:
Vented -
Minimum thickness [mm]:
26 -
Hole Arrangement/Number:
5 -
Bolt Hole Circle Ø [mm]:
110 -
Wheel Hub Diameter [mm]:
70
| Brand | OE Reference |
|---|---|
| FIAT | 46843608 |
| FIAT | 51760621 |
| JEEP | K68249840AA |
| JEEP | K68249840AB |
| JEEP | K68249840AC |
| Maker | Cross reference |
|---|---|
| ATE | 24.0128-0192.1 |
| ATE | 428192 |
| BENDIX ANTIGUO | 562299B |
| BOSCH | 0 986 479 293 |
| BREMBO | 09.9363.10 |
| BREMBO | 09.9363.20 |
| BREMBO | 09.D209.1X |
| DELPHI LOCKHEED | BG3951 |
| FERODO | DDF1449 |
| FERODO | DDF2882C |
| GIRLING | 6044761 |
| HELLA-PAGID | 8DD 355 112-501 |
| MINTEX | MDC1739 |
| ROAD HOUSE | 6964.10 |
| TEXTAR | 92145003 |
| TRW | DF4476 |
| Vehicle | Engine | Fuel | Date | CC | KW | CV | Traction |
|---|---|---|---|---|---|---|---|
| 1.8 MPI (939AXL1A) |
939 A4.000 |
1 | 06/2005-11/2011 | 1796 | 103 | 140 | 1 |
| 1.9 JTS (939AXA1B) |
939 A6.000 |
1 | 09/2005-11/2011 | 1859 | 118 | 160 | 1 |
| 2.2 JTS (939AXB1B, 939AXB11) |
939 A5.000 |
1 | 09/2005-11/2011 | 2198 | 136 | 185 | 1 |
| 1.9 JTDM 16V (939AXC1B, 939AXC12) |
939 A2.000 |
2 | 09/2005-11/2011 | 1910 | 110 | 150 | 1 |
| 1.9 JTDM 16V (939AXF1B, 939AXC1B) |
937 A8.000 939 A8.000 |
2 | 09/2005-11/2011 | 1910 | 100 | 136 | 1 |
| 1.9 JTDM 8V (939AXE1B, 939BXE1B, 939BXH1B) |
937 A7.000 939 A7.000 |
2 | 09/2005-11/2011 | 1910 | 85 | 115 | 1 |
| 1.9 JTDM 8V (939AXE1B) |
939 A1.000 |
2 | 09/2005-11/2011 | 1910 | 88 | 120 | 1 |
| 2.0 JTDM (939AXP1B) |
939 B3.000 |
2 | 05/2009-11/2011 | 1956 | 125 | 170 | 1 |
| 2.0 JTDM (939AXQ1B) |
844 A2.000 |
2 | 05/2009-11/2011 | 1956 | 120 | 163 | 1 |
| 2.0 JTDM (939AXR1B) |
939 B4.000 |
2 | 06/2010-11/2011 | 1956 | 100 | 136 | 1 |
| Vehicle | Engine | Fuel | Date | CC | KW | CV | Traction |
|---|---|---|---|---|---|---|---|
| 1.8 MPI (939BXL1A) |
939 A4.000 |
1 | 06/2005-11/2011 | 1796 | 103 | 140 | 1 |
| 1.9 JTS (939BXA1B) |
939 A6.000 |
1 | 03/2006-11/2011 | 1859 | 118 | 160 | 1 |
| 2.2 JTS (939BXB1B, 939BXB11) |
939 A5.000 |
1 | 03/2006-11/2011 | 2198 | 136 | 185 | 1 |
| 1.9 JTDM 16V (939BXC1B, 939BXC12) |
939 A2.000 |
2 | 03/2006-11/2011 | 1910 | 110 | 150 | 1 |
| 1.9 JTDM 16V (939BXC1B) |
937 A8.000 |
2 | 03/2006-11/2011 | 1910 | 100 | 136 | 1 |
| 1.9 JTDM 8V (939AXH1B, 939BXH1B) |
937 A7.000 |
2 | 03/2006-11/2011 | 1910 | 85 | 115 | 1 |
| 1.9 JTDM 8V (939BXE1B) |
939 A1.000 |
2 | 03/2006-11/2011 | 1910 | 88 | 120 | 1 |
| 2.0 JTDM (939BXP1B) |
939 B3.000 |
2 | 07/2009-11/2011 | 1956 | 125 | 170 | 1 |
| 2.0 JTDM (939BXQ1B) |
844 A2.000 |
2 | 05/2009-11/2011 | 1956 | 120 | 163 | 1 |
| 2.0 JTDM (939BXR1B) |
939 B4.000 |
2 | 06/2010-11/2011 | 1956 | 100 | 136 | 1 |
| Vehicle | Engine | Fuel | Date | CC | KW | CV | Traction |
|---|---|---|---|---|---|---|---|
| 2.2 JTS (939.DXB11) |
939 A5.000 |
1 | 01/2006-05/2011 | 2198 | 136 | 185 | 1 |
| 2.0 JTDM (939DXP1B) |
939 B3.000 |
2 | 05/2009-06/2010 | 1956 | 125 | 170 | 1 |
| 2.0 JTDM (939DXQ1B) |
844 A2.000 |
2 | 03/2008-06/2010 | 1956 | 120 | 163 | 1 |
| Vehicle | Engine | Fuel | Date | CC | KW | CV | Traction |
|---|---|---|---|---|---|---|---|
| 1.4 TB (940FXB1A, 940FXB11) |
940 A2.000 |
1 | 04/2010-10/2018 | 1368 | 125 | 170 | 1 |
| 1.4 TB (940FXG1A) |
955 A8.000 |
1 | 04/2010-10/2018 | 1368 | 120 | 163 | 1 |
| 2.0 JTDM (940.FXL1A) |
940 A5.000 940 C3.000 |
2 | 04/2010-12/2020 | 1956 | 103 | 140 | 1 |
| 2.0 JTDM (940FXE1A, 940FXG11) |
552 83 099 940 A4.000 940 B4.000 |
2 | 04/2010-12/2020 | 1956 | 125 | 170 | 1 |
| 2.0 JTDM (940FXH1A, 940FXH11, 940FXZ11, 940FXZ1A) |
940 A7.000 940 B9.000 |
2 | 04/2010-10/2018 | 1956 | 120 | 163 | 1 |
| 2.0 JTDM (940FXM1A, 940FXS1A, 940FYD1A) |
940 A8.000 940 B6.000 940 C4.000 |
2 | 04/2010-02/2016 | 1956 | 100 | 136 | 1 |
| 2.0 JTDM (940FXQ1A, 940FYC1A) |
940 B5.000 940 C3.000 |
2 | 08/2013-10/2018 | 1956 | 110 | 150 | 1 |
| 2.0 JTDM (940FXV11) |
940 B4.000 |
2 | 11/2013-10/2018 | 1956 | 129 | 175 | 1 |
| Vehicle | Engine | Fuel | Date | CC | KW | CV | Traction |
|---|---|---|---|---|---|---|---|
| 1.4 (940FXB1A) |
940 A2.000 |
1 | 04/2011-12/2020 | 1368 | 125 | 170 | 1 |
| 2.0 JTDM (940FXE1A) |
940 A4.000 |
2 | 04/2011-02/2016 | 1956 | 125 | 170 | 1 |
| 2.0 JTDM (940FXL1A) |
940 A5.000 |
2 | 07/2013-02/2016 | 1956 | 103 | 140 | 1 |
| 2.0 JTDM (940FXQ1A) |
940 B5.000 |
2 | 08/2013-02/2016 | 1956 | 110 | 150 | 1 |
| 2.0 JTDM (940FXV11) |
940 B4.000 |
2 | 05/2015-12/2020 | 1956 | 129 | 175 | 1 |
| Vehicle | Engine | Fuel | Date | CC | KW | CV | Traction |
|---|---|---|---|---|---|---|---|
| 2.2 JTS (939EXB1B, 939EXB11) |
939 A5.000 |
1 | 03/2006-03/2011 | 2198 | 136 | 185 | 1 |
| 2.0 JTDM (939DXP1B, 939EXP1B) |
939 B3.000 |
2 | 05/2009-06/2010 | 1956 | 125 | 170 | 1 |
| 2.0 JTDM (939DXQ1B) |
844 A2.000 |
2 | 04/2009-03/2011 | 1956 | 120 | 163 | 1 |
| Vehicle | Engine | Fuel | Date | CC | KW | CV | Traction |
|---|---|---|---|---|---|---|---|
| 1.3 | 1 | 08/2020- | 1332 | 96 | 131 | 1 | |
| 1.3 T270 | 1 | 08/2020- | 1332 | 127 | 173 | 1 | |
| 1.3 T270 | 1 | 09/2021- | 1332 | 129 | 175 | 1 | |
| 1.4 Multiair |
552 63 624 EAQ |
1 | 03/2017- | 1368 | 103 | 140 | 1 |
| 1.4 Multiair | 1 | 03/2017- | 1368 | 120 | 163 | 1 | |
| 1.4 MultiAir 4x4 |
552 63 623 EAQ |
1 | 03/2017- | 1368 | 125 | 170 | 3 |
| 2.4 | 1 | 09/2017- | 2360 | 134 | 182 | 1 | |
| 2.4 16V 4x4 | 1 | 05/2021- | 2360 | 110 | 150 | 3 | |
| 2.4 4x4 |
ED6 EDD |
1 | 09/2017- | 2360 | 134 | 182 | 3 |
| 2.4 MultiAir |
ED6 EDD |
1 | 09/2017- | 2360 | 129 | 175 | 1 |
| 2.4 MultiAir 4x4 |
ED6 EDD |
1 | 09/2017- | 2360 | 129 | 175 | 3 |
| 1.5 T4 Hybrid | 13 | 03/2022- | 1469 | 96 | 131 | 1 | |
| 1.3 T270 Turbo Flex | 19 | 06/2021- | 1332 | 136 | 185 | 1 | |
| 2.0 Flex | 19 | 01/2016-04/2021 | 1995 | 122 | 166 | 1 | |
| 2.0 Flex 4x4 | 19 | 09/2017-12/2018 | 1995 | 122 | 166 | 3 | |
| 1.6 CRD |
552 60 384 EJJ |
2 | 03/2017- | 1598 | 88 | 120 | 1 |
| 1.6 MultiJet | 2 | 04/2021- | 1598 | 96 | 130 | 1 | |
| 2.0 CRD 4x4 |
552 63 087 EBS EBT |
2 | 03/2017- | 1956 | 103 | 140 | 3 |
| 2.0 CRD 4x4 |
552 63 088 EBS |
2 | 12/2016- | 1956 | 125 | 170 | 3 |
| 2.0 Multijet II | 2 | 10/2018- | 1956 | 127 | 173 | 1 | |
| 2.0 Multijet II 4x4 |
552 63 088 EBS EBT |
2 | 03/2017- | 1956 | 127 | 173 | 3 |
| Vehicle | Engine | Fuel | Date | CC | KW | CV | Traction |
|---|---|---|---|---|---|---|---|
| 1.0 T-GDI |
552 82 151 |
1 | 08/2018- | 999 | 88 | 120 | 1 |
| 1.3 T-GDi |
552 82 328 |
1 | 08/2018- | 1332 | 110 | 150 | 1 |
| 1.3 T-GDi 4x4 |
552 82 328 EYF |
1 | 08/2018- | 1332 | 132 | 180 | 3 |
| 1.4 |
552 63 624 |
1 | 01/2016- | 1368 | 100 | 136 | 1 |
| 2.4 |
500 52 375 ED6 |
1 | 09/2015- | 2360 | 132 | 179 | 1 |
| 2.4 4x4 |
500 52 375 ED6 |
1 | 09/2015- | 2360 | 132 | 179 | 3 |
| 2.4 4x4 |
ED6 |
1 | 06/2016- | 2360 | 134 | 182 | 3 |
| 1.4 LPG | 18 | 01/2016- | 1368 | 88 | 120 | 1 | |
| 2.0 CRD 4x4 |
552 63 087 EBT |
2 | 07/2014- | 1956 | 88 | 120 | 3 |
| 2.0 CRD 4x4 |
552 63 087 552 63 088 552 83 099 552 84 064 EBT |
2 | 07/2014- | 1956 | 103 | 140 | 3 |
| 2.0 CRD 4x4 |
552 63 088 552 83 099 EBT |
2 | 07/2014- | 1956 | 125 | 170 | 3 |
| Vehicle | Engine | Fuel | Date | CC | KW | CV | Traction |
|---|---|---|---|---|---|---|---|
| 1.4 | 1 | 07/2014- | 1368 | 103 | 140 | 1 | |
| 1.4 4x4 | 1 | 07/2014- | 1368 | 125 | 170 | 3 | |
| 1.6 E-torQ | 1 | 07/2014-09/2018 | 1598 | 81 | 110 | 1 | |
| 1.6 MultiJet | 2 | 07/2014- | 1598 | 88 | 120 | 1 | |
| 2.0 MultiJet 4x4 | 2 | 07/2014- | 1956 | 103 | 140 | 3 | |
| 2.0 MultiJet 4x4 | 2 | 07/2014- | 1956 | 125 | 170 | 3 |
