Product 78BD3634-2

Description: Brake disc
Axe: Rear
No. of Pieces: 2
Barcode: 8424073145192
Url: https://catalogonuevo.icerbrakes.com/Producto/Details?idProducto=78BD3634-2
Weight (gr.): 7010

R90 Homologation: 90R-02C0100/0101
Measures: Ø224.8x10x46.2
: Brake Disc Type: solid; Minimum thickness [mm]: 8; Hole Arrangement/Number: 5; Bolt Hole Circle Ø [mm]: 112; Wheel Hub Diameter [mm]: 68

Reference applications

Brand	OE Reference
AUDI	443 615 601 B
AUDI	4D0 615 601 A

Maker	Cross reference
ATE	24.0110-0116.1
BENDIX ANTIGUO	561361B
BOSCH	0 986 478 315
DELPHI LOCKHEED	BG2520
ROAD HOUSE	6124.00
SANLI	SL10145
TEXTAR	92037400
TEXTAR	92037405
TRW	DF2666

AUDI

100 III C3 / 500 / 5000 (443, 444) Saloon 08/1982-07/1991

Vehicle	Engine	Fuel	Date	CC	KW	CV	Traction
1.8 Cat quattro	4B PH	1	08/1985-11/1990	1781	66	90	3
1.8 quattro	SH	1	08/1986-07/1990	1781	65	88	3
1.8 quattro	JW NP	1	10/1984-07/1988	1781	66	90	3
2.2 Cat quattro	HX KU	1	10/1984-12/1987	2226	101	137	3
2.2 E quattro	PX	1	08/1985-07/1986	2226	88	120	3
2.2 E Turbo quattro	MC	1	08/1986-11/1990	2226	121	165	3
2.2 quattro	KU	1	08/1984-12/1988	2226	101	137	3
2.2 Turbo	MC	1	08/1986-11/1990	2226	121	165	1
2.3 E	NF	1	01/1990-11/1990	2309	98	133	1
2.3 E quattro	NF	1	08/1986-11/1990	2309	100	136	3
2.3 quattro	NF	1	01/1990-11/1990	2309	98	133	3

100 III C3 Avant / 500 / 5000 (445, 446) Estate 08/1982-11/1990

Vehicle	Engine	Fuel	Date	CC	KW	CV	Traction
1.8 Cat quattro	4B PH	1	08/1985-10/1990	1781	66	90	3
1.8 quattro	SH	1	08/1986-07/1990	1781	65	88	3
1.8 quattro	JW NP	1	10/1984-07/1988	1781	66	90	3
2.2 Cat quattro	HX KU	1	06/1989-11/1990	2226	101	137	3
2.2 E quattro	PX	1	08/1985-07/1986	2226	88	120	3
2.2 Turbo	MC	1	08/1986-11/1990	2226	121	165	1
2.2 Turbo quattro	MC	1	08/1986-11/1990	2226	121	165	3
2.3 E quattro	NF	1	08/1986-11/1990	2309	100	136	3
2.3 quattro	NF	1	01/1990-11/1990	2309	98	133	3

200 II C3 (447, 448) Saloon 06/1983-12/1991

Vehicle	Engine	Fuel	Date	CC	KW	CV	Traction
2.2 Turbo	2B	1	02/1988-12/1990	2226	140	190	1
2.2 Turbo	1B	1	02/1988-12/1990	2226	147	200	1

A8 D2 (4D2, 4D8) Saloon 03/1994-12/2005

Vehicle	Engine	Fuel	Date	CC	KW	CV	Traction
2.8	AEJ	1	07/1995-03/1996	2771	120	163	1
2.8	AAH	1	03/1994-03/1996	2771	128	174	1
2.8	ACK ALG AMX APR AQD	1	04/1996-09/2002	2771	142	193	1
2.8 quattro	AEJ	1	07/1995-03/1996	2771	120	163	3
2.8 quattro	AAH	1	03/1994-03/1996	2771	128	174	3
2.8 quattro	ACK ALG AMX APR AQD	1	04/1996-09/2002	2771	142	193	3
3.7	AKC AQG	1	11/1998-09/2002	3697	191	260	1
2.5 TDI	AFB AKN	2	01/1997-04/2000	2496	110	150	1
2.5 TDI quattro	AFB AKN	2	07/1997-04/2000	2496	110	150	3
