Product 78BD4034-1

Description
Brake disc
Axe
Rear
No. of Pieces
1
Barcode
EAN13 Code
8424073288738
QR Code
Url
https://catalogonuevo.icerbrakes.com/Producto/Details?idProducto=78BD4034-1
Weight (gr.)
5390
R90 Homologation
R90 90R-02C0559/0102
Measures
Ø249x9x73.2
Brake Disc Type: solid
Minimum thickness [mm]: 7
Hole Arrangement/Number: 4
Bolt Hole Circle Ø [mm]: 108
Wheel Hub Diameter [mm]: 55.9
Reference applications
Brand OE Reference
CITROËN 16 092 499 80
DS 16 192 387 80
PEUGEOT 4249.65
PEUGEOT 4249.66
Maker Cross reference
ATE 24.0109-0171.2
BOSCH 0 986 479 400
BREMBO 08.A858.17
FERODO DDF1696C-1
GIRLING 6060426
HELLA-PAGID 8DD 355 123-301
LETEC LBP026S*
MINTEX MDC2031
TEXTAR 92194103
TRW DF6042BS
CITROËN
C4 (LA_) Coupe 11/2004-12/2013
Vehicle Engine Fuel Date CC KW CV Traction
1.6 16V

NFU (TU5JP4)

 1 03/2011-12/2013 1587 81 110 1
C4 Picasso (UD_) MPV 10/2006-12/2015
Vehicle Engine Fuel Date CC KW CV Traction
1.6 16V

5FX (EP6DT)

 1 07/2008-08/2013 1598 110 150 1
C4 II (NC_) Hatchback 02/2009-
Vehicle Engine Fuel Date CC KW CV Traction
1.2 THP 110 (NCHNZ6, NCHNV6)

HNZ (EB2DT)

 1 02/2015-12/2017 1199 81 110 1
1.4 VTi 95 (NC8FP0)

8FP (EP3C)

 1 11/2009-11/2015 1397 70 95 1
1.6 (NCNFU0) 1 01/2010- 1587 81 110 1
1.6 THP 155

5FV (EP6CDT)

 1 11/2009-12/2016 1598 115 156 1
1.6 VTi 120 (NC5FS0, NC5FS9)

5FS (EP6C)

 1 11/2009-12/2016 1598 88 120 1
2.0 Flex 1 11/2009- 1997 111 151 1
1.6 VTi 120 LPG (NC5FS0)

5FS (EP6C)

 18 09/2011- 1598 88 120 1
2.0 Exclusive GLX Flex 19 02/2009-07/2013 1997 109 148 1
1.6 BlueHDi 100

BHY (DV6FD)

 2 07/2014- 1560 73 99 1
1.6 BlueHDi 115

BHX (DV6FC)

 2 08/2014- 1560 85 115 1
1.6 BlueHDi 120

BHZ (DV6FC)

 2 02/2015- 1560 88 120 1
1.6 HDi 110

9HR (DV6C)

 2 11/2009- 1560 82 112 1
1.6 HDi 115

9HD (DV6C)

 2 07/2012- 1560 84 114 1
1.6 HDi 90

9HJ (DV6DTEDM)

9HP (DV6DTED)

 2 11/2009- 1560 68 92 1
2.0 HDi / BlueHDi 150

AHR (DW10FD)

RHE (DW10CTED4)

 2 11/2009- 1997 110 150 1
C4 II (NC_) Hatchback Van 11/2009-
Vehicle Engine Fuel Date CC KW CV Traction
1.6 BlueHDi

BHY (DV6FD)

 2 07/2014- 1560 73 99 1
1.6 BlueHDi

BHZ (DV6FC)

 2 02/2015- 1560 88 120 1
1.6 HDi

9HP (DV6DTED)

 2 06/2010- 1560 68 92 1
1.6 HDi

9HR (DV6C)

 2 11/2009- 1560 82 111 1
C4 II (NC_) Saloon 01/2013-
Vehicle Engine Fuel Date CC KW CV Traction
1.6

NFP (EC5)

 1 01/2013- 1587 85 116 1
1.6

5FS (EP6C)

 1 01/2013- 1598 88 120 1
1.6 Flex 1 12/2014- 1598 127 173 1
1.6 THP

5FE (EP6CDTMD)

 1 01/2013- 1598 110 150 1
1.6 THP 165 1 08/2013- 1598 121 165 1
2.0 16V 1 09/2013- 1997 105 143 1
2.0 Flex 1 08/2013- 1997 111 151 1
1.6 HDi

9HD (DV6C)

9HR (DV6C)

 2 08/2013- 1560 84 115 1
DS4 (NX_) Hatchback 03/2011-07/2015
Vehicle Engine Fuel Date CC KW CV Traction
1.6 THP 155

5FV (EP6CDT)

 1 04/2011-07/2015 1598 115 156 1
1.6 THP160

5FM (EP6CDTM)

 1 04/2012-07/2015 1598 120 163 1
1.6 THP200

5FU (EP6DTX)

 1 04/2011-07/2015 1598 147 200 1
1.6 VTI 120

5FS (EP6C)

 1 04/2011-07/2015 1598 88 120 1
1.6 BlueHDi 120

BHZ (DV6FC)

 2 07/2014-07/2015 1560 88 120 1
1.6 HDi 110

9HR (DV6C)

 2 04/2011-07/2015 1560 82 112 1
1.6 HDi 115

9HD (DV6C)

 2 08/2012-07/2015 1560 84 114 1
1.6 HDi 90

9HP (DV6DTED)

 2 05/2011-07/2015 1560 68 92 1
2.0 BlueHDi 150

AHX (DW10FD)

 2 07/2014-07/2015 1997 110 150 1
2.0 BlueHDi 180

AHW (DW10FC)

 2 07/2014-07/2015 1997 133 180 1
2.0 HDi / BlueHDi 135

AHS (DW10FD)

AHV (DW10FD)

RHD (DW10CB)

RHD (DW10CTED4)

 2 09/2011-07/2015 1997 100 136 1
2.0 HDi 165

RHH (DW10CTED4)

 2 04/2011-07/2015 1997 120 163 1
DS
DS 4 / DS 4 CROSSBACK (NX_) Hatchback 07/2015-
Vehicle Engine Fuel Date CC KW CV Traction
1.6 THP 208

5GR (EP6FDTX)

 1 03/2017-12/2018 1598 153 208 1
1.6 THP 210

5GM (EP6FDTX)

 1 07/2015-12/2018 1598 155 210 1
1.6 VTi

5FS (EP6C)

 1 07/2015-12/2018 1598 88 120 1
1.6 BlueHDi 100

BHY (DV6FD)

 2 04/2016-12/2018 1560 73 99 1
1.6 BlueHDi 120

BHZ (DV6FC)

 2 07/2015-12/2018 1560 88 120 1
1.6 e- HDI 115

9HD (DV6C)

 2 07/2015-12/2018 1560 84 114 1
2.0 BlueHDi 180

AHW (DW10FC)

 2 07/2015-12/2018 1997 133 180 1
PEUGEOT
308 (4A_, 4C_) Hatchback 09/2007-
Vehicle Engine Fuel Date CC KW CV Traction
1.4 16V

8FS (EP3)

EP3

 1 09/2007-10/2014 1397 70 95 1
1.4 16V

8FR (EP3)

 1 12/2009-10/2014 1397 72 98 1
1.6 1 02/2012-12/2015 1587 85 115 1
1.6 1 01/2012-12/2015 1598 120 163 1
1.6

5FM (EP6CDTM), 5GY(5P6FDTM)

 1 09/2009-12/2010 1598 121 165 1
1.6 16V

5FW (EP6)

EP6

 1 09/2007-10/2014 1598 88 120 1
1.6 16V

5FT (EP6DT)

 1 09/2007-10/2014 1598 103 140 1
1.6 16V

5FX (EP6DT)

 1 09/2007-10/2014 1598 110 150 1
1.6 16V

5FY (EP6DTS)

 1 03/2008-10/2014 1598 128 174 1
1.6 BioFlex 1 01/2012- 1587 90 122 1
1.6 THP 16V

5FV (EP6CDT)

 1 10/2009-10/2014 1598 115 156 1
2.0 1 12/2011- 1997 105 143 1
2.0 Bioflex 1 01/2012- 1997 111 151 1
1.6 BioFlex

NFU (TU5JP4)

 19 04/2008-10/2014 1587 80 109 1
2.0 Bioflex

RFJ (EW10A)

 19 01/2008-12/2012 1997 103 140 1
1.6 HDi

9HV (DV6TED4B)

9HV (DV6TED4BU)

9HX (DV6ATED4)

 2 09/2007-10/2014 1560 66 90 1
1.6 HDi

9HJ (DV6DTEDM)

9HP (DV6DTED)

 2 11/2009-10/2014 1560 68 92 1
1.6 HDi

9HZ (DV6TED4)

 2 09/2007-10/2014 1560 80 109 1
1.6 HDi

9HR (DV6C)

 2 12/2009-10/2014 1560 82 112 1
1.6 HDi

9HD (DV6C)

9HG (DV6C M)

 2 03/2013-10/2014 1560 84 114 1
2.0 HDi

RHR (DW10BTED4)

RHR (DW10CB)

 2 09/2007-10/2014 1997 100 136 1
2.0 HDi

RHR (DW10BTED4)

 2 07/2010-12/2012 1997 103 140 1
2.0 HDi

RHE (DW10CTED4)

 2 10/2011-10/2014 1997 110 150 1
2.0 HDi

RHH (DW10CTED4)

 2 04/2012-10/2014 1997 120 163 1
308 SW (4E_, 4H_) Estate 09/2007-
Vehicle Engine Fuel Date CC KW CV Traction
1.4 16V

8FR (EP3)

 1 12/2009-10/2014 1397 72 98 1
1.6 16V

5FT (EP6DT)

 1 09/2007-10/2014 1598 103 140 1
1.6 16V

5FX (EP6DT)

 1 09/2007-10/2014 1598 110 150 1
1.6 16V

5FY (EP6DTS)

 1 03/2008-10/2014 1598 128 174 1
1.6 THP 16V

5FV (EP6CDT)

 1 10/2009-10/2014 1598 115 156 1
2.0 Bioflex

RFJ (EW10A)

 19 01/2008-12/2011 1997 103 140 1
1.6 HDi

9HV (DV6TED4BU)

9HX (DV6ATED4)

 2 09/2007-10/2014 1560 66 90 1
1.6 HDi

9HR (DV6C)

 2 12/2009-10/2014 1560 82 112 1
1.6 HDi

9HD (DV6C)

 2 03/2013-10/2014 1560 84 114 1
2.0 HDi

RHR (DW10BTED4)

 2 09/2007-12/2012 1997 100 136 1
2.0 HDi

RHR (DW10BTED4)

 2 09/2007-10/2014 1997 103 140 1
2.0 HDi

RHE (DW10CTED4)

 2 04/2011-10/2014 1997 110 150 1
2.0 HDi

RHH (DW10CTED4)

 2 06/2009-10/2014 1997 120 163 1
308 SW (4E_) Estate Van 01/2008-12/2012
Vehicle Engine Fuel Date CC KW CV Traction
2.0 HDi

RHR (DW10BTED4)

 2 01/2008-12/2011 1997 100 136 1
308 CC (4B_) Convertible 02/2009-
Vehicle Engine Fuel Date CC KW CV Traction
1.6 1 10/2012-12/2015 1598 121 165 1
1.6 1 07/2009- 1598 129 175 1
1.6 16V

EP6

 1 06/2009-12/2014 1598 88 120 1
1.6 16V

5FT (EP6DT)

 1 06/2009-12/2014 1598 103 140 1
1.6 16V

5FX (EP6DT)

 1 06/2009-12/2014 1598 110 150 1
1.6 16V

5FV (EP6CDT)

 1 06/2009-12/2014 1598 115 156 1
1.6 THP

5FM (EP6CDTM)

 1 08/2012-12/2014 1598 120 163 1
2.0 CVVT

RFJ (EW10A)

 1 07/2009-12/2014 1997 103 140 1
1.6 HDi

9HR (DV6C)

 2 06/2009-12/2014 1560 82 112 1
1.6 HDi

9HZ (DV6TED4)

 2 02/2009-05/2012 1560 82 111 1
1.6 HDi

9HD (DV6C)

 2 03/2013-12/2014 1560 84 114 1
2.0 HDi

RHF (DW10BTED4)

 2 04/2009-12/2012 1997 103 140 1
2.0 HDi

RHH (DW10CTED4)

 2 06/2009-12/2014 1997 120 163 1
2.0 HDi (4BRHRH, 4BRHRJ)

RHR (DW10BTED4)

 2 04/2009-12/2014 1997 100 136 1
