Product 78BD4046-2

Description
Brake disc
Axe
Front
No. of Pieces
2
Barcode
EAN13 Code
8424073145383
QR Code
Url
https://catalogonuevo.icerbrakes.com/Producto/Details?idProducto=78BD4046-2
Weight (gr.)
14004
R90 Homologation
R90 90R-02C0433/0051
Measures
Ø286x26x50.3
Brake Disc Type: Vented
Minimum thickness [mm]: 23
Hole Arrangement/Number: 5
Bolt Hole Circle Ø [mm]: 108
Wheel Hub Diameter [mm]: 68
Reference applications
Brand OE Reference
VOLVO 2 724 03
VOLVO 2 724 032
VOLVO 2 724 037
VOLVO 3 126 270 6
Maker Cross reference
BREMBO 09.8633.10
DELPHI LOCKHEED BG3513
LETEC LBV014V
SANLI SL34404
VOLVO
S60 (384) Saloon 07/2000-04/2010
Vehicle Engine Fuel Date CC KW CV Traction
2.0 T

B 5204 T5

 1 07/2000-04/2010 1984 132 180 1
2.4 1 02/2004-04/2010 2401 191 260 1
2.4

B 5244 S2

 1 07/2000-04/2010 2435 103 140 1
2.4

B 5244 S

 1 11/2000-04/2010 2435 125 170 1
2.4

B 5244 T4

 1 01/2005-10/2006 2435 132 180 1
2.4 T

B 5244 T3

 1 07/2000-04/2010 2435 147 200 1
2.4 T AWD

B 5244 T3

 1 06/2001-04/2010 2435 147 200 3
2.5 1 09/2003-04/2010 2521 224 300 1
2.5 T

B 5254 T2

 1 01/2003-04/2010 2521 154 210 1
2.5 T AWD

B 5254 T2

 1 07/2002-04/2010 2521 154 210 3
R 2,5 T AWD

B 5254 T4

 1 01/2003-04/2010 2521 221 300 3
T5

B 5234 T3

 1 07/2000-04/2010 2319 184 250 1
T5

B 5234 T7

 1 07/2000-09/2002 2319 195 265 1
T5

B 5244 T5

 1 04/2004-04/2010 2401 191 260 1
2.4 Bifuel (CNG)

B 5244 SG

 16 07/2001-04/2010 2435 103 140 1
2.4 Bifuel (LPG)

B 5244 SG2

 18 07/2001-04/2010 2435 103 140 1
2.4 CDI

D 5244 T3

 2 10/2003-12/2005 2401 85 116 1
2.4 D

D 5244 T7

 2 03/2005-04/2010 2400 93 126 1
2.4 D

D 5244 T6

 2 05/2005-12/2006 2401 90 122 1
2.4 D

D 5244 T2

 2 05/2001-04/2010 2401 96 130 1
D5

D 5244 T

 2 01/2001-04/2010 2400 120 163 1
D5

D 5244 T4

 2 03/2005-04/2010 2401 136 185 1
S80 (184) Saloon 05/1998-02/2008
Vehicle Engine Fuel Date CC KW CV Traction
2.0

B 5204 T4

 1 06/1998-07/2006 1984 120 163 1
2.0 T

B 5204 T5

 1 12/1999-07/2006 1984 132 180 1
2.0 T

B 5204 T3

 1 06/1998-07/2006 1984 166 226 1
2.3 R

B 5234 T7

 1 04/2000-08/2005 2319 195 265 1
2.4

B 5244 S2

 1 01/1999-07/2006 2435 103 140 1
2.4

B 5244 S

 1 01/1999-07/2006 2435 125 170 1
2.4 LTP 1 06/2004-07/2006 2435 132 179 1
2.4 T

B 5244 T3

 1 06/2000-07/2006 2435 147 200 1
2.5 T

B 5254 T2

 1 03/2003-07/2006 2521 154 210 1
2.5 T AWD

B 5254 T2

 1 07/2003-07/2006 2521 154 210 3
2.9

B 6294 S

 1 03/1999-07/2006 2922 147 200 1
2.9

B 6304 S3

 1 05/1998-07/2006 2922 150 204 1
3.0

B 6294 S2

 1 06/2001-07/2006 2922 144 196 1
T5 AWD

B 5244 T3

 1 04/2000-09/2003 2435 147 200 3
T6

B 6284 T

 1 05/1998-12/2001 2783 200 272 1
T6

B 6294 T

 1 06/2001-07/2006 2922 200 272 1
2.4 Bifuel (CNG)

B 5244 SG2

 16 09/2001-07/2006 2435 103 140 1
2.4 Bifuel (LPG)

B 5244 SG

 18 09/2001-07/2006 2435 103 140 1
2.4 D

D 5244 T2

 2 10/2001-07/2006 2401 96 131 1
2.5 TDI

D 5252 T

 2 01/1999-07/2006 2460 103 140 1
D5

D 5244 T

 2 08/2001-07/2006 2401 120 163 1
V70 II (285) Estate 11/1999-12/2008
Vehicle Engine Fuel Date CC KW CV Traction
2.0 T

B 5204 T5

 1 11/1999-08/2007 1984 132 180 1
2.3 1 10/2000-09/2004 2319 195 265 1
2.3

B 5234 T7

 1 10/2000-09/2004 2319 195 265 1
2.4

B 5244 S2

 1 03/2000-08/2007 2435 103 140 1
2.4 1 03/2000-09/2003 2435 121 165 1
2.4 1 03/2000-09/2003 2435 121 165 1
2.4

B 5244 S

 1 03/2000-08/2007 2435 125 170 1
2.4 T

B 5244 T3

 1 11/1999-08/2003 2435 147 200 1
2.4 T AWD

B 5244 T3

 1 09/2001-08/2002 2435 147 200 3
2.5 AWD

B 5254 T2

 1 09/2002-12/2004 2521 155 211 3
2.5 R Sport 1 12/2002-08/2007 2521 221 300 1
2.5 T

B 5254 T2

 1 07/2001-08/2007 2521 154 209 1
2.5 T AWD

B 5254 T2

 1 07/2002-08/2007 2521 154 209 3
R 2,5 T AWD

B 5254 T4

 1 03/2003-08/2007 2521 221 300 3
T5

B 5234 T3

 1 11/1999-12/2004 2319 184 250 1
T5

B 5244 T5

 1 04/2004-08/2007 2401 191 260 1
2.4 Bifuel (CNG)

B 5244 SG

 16 09/2001-08/2007 2435 103 140 1
2.4 Bifuel (LPG)

B 5244 SG2

 18 09/2001-08/2007 2435 103 140 1
2.4 CDI

D 5244 T6

 2 07/2005-12/2008 2401 90 122 1
2.4 D

D 5244 T7

 2 04/2005-12/2008 2400 93 126 1
2.4 D

D 5244 T2

 2 07/2001-08/2007 2401 96 131 1
2.4 D5 2 08/2005-07/2007 2400 120 163 1
2.5 TDI

D 5252 T

 2 11/1999-08/2007 2460 103 140 1
D5

D 5244 T

D 5244 T2

D 5244 T5

 2 01/2001-12/2008 2401 120 163 1
D5

D 5244 T4

 2 04/2005-12/2008 2401 136 185 1
D5 AWD

D 5244 T

D 5244 T2

D 5244 T5

 2 07/2002-08/2007 2401 120 163 3
D5 AWD

D 5244 T4

 2 05/2005-08/2007 2401 136 185 3
XC70 CROSS COUNTRY / V70 XC (295) Estate 10/1997-10/2007
Vehicle Engine Fuel Date CC KW CV Traction
2.4 1 03/2000-09/2003 2435 121 165 1
2.4 T XC AWD

B 5254 T

 1 11/1997-09/2002 2435 142 193 3
2.4 T XC AWD

B 5244 T3

 1 03/2000-09/2002 2435 147 200 3
D5 AWD

D 5244 T4

 2 12/2005-08/2007 2401 136 185 3
D5 XC AWD

D 5244 T

 2 09/2002-08/2007 2401 120 163 3
