Product 78BD4108-1
- Description
- Brake disc
- Axe
- Rear
- No. of Pieces
- 1
- Barcode
-
8424073145598
- Url
- https://catalogonuevo.icerbrakes.com/Producto/Details?idProducto=78BD4108-1
- Weight (gr.)
- 8720
- R90 Homologation
-
90R-02C0559/0110
- Measures
- Ø300x11x82.2
-
Brake Disc Type:
solid -
Minimum thickness [mm]:
9.5 -
Hole Arrangement/Number:
5 -
Bolt Hole Circle Ø [mm]:
108 -
Wheel Hub Diameter [mm]:
52
| Brand | OE Reference |
|---|---|
| RENAULT | 82 00 244 108 |
| RENAULT | 82 00 649 353 |
| Maker | Cross reference |
|---|---|
| BENDIX-ROULUNDS | 522101 |
| BREMBO | 08.A239.17 |
| VALEO | 675400 |
| Vehicle | Engine | Fuel | Date | CC | KW | CV | Traction |
|---|---|---|---|---|---|---|---|
| 2.0 (JK09) |
F4R 792 |
1 | 11/2002-01/2015 | 1998 | 100 | 136 | 1 |
| 2.0 (JK0A, JK1D, JK0N) |
F4R 796 F4R 797 F4R 896 F4R 897 |
1 | 04/2005- | 1998 | 125 | 170 | 1 |
| 2.0 (JK0K) |
F4R 790 |
1 | 11/2002-12/2015 | 1998 | 98 | 133 | 1 |
| 2.0 Turbo (JK0A, JK0B, JK0N) |
F4R 794 F4R 795 F4R 796 F4R 797 |
1 | 11/2002- | 1998 | 120 | 163 | 1 |
| 3.5 V6 (JK00, JK0F, JK0P, JK0S, JK0W) |
V4Y 711 V4Y 715 |
1 | 11/2002- | 3498 | 177 | 241 | 1 |
| 1.9 dCi (JK0U, JK0G) |
F9Q 680 F9Q 820 F9Q 826 |
2 | 11/2002- | 1870 | 88 | 120 | 1 |
| 1.9 dCi (JK0U) |
F9Q 820 |
2 | 04/2003-02/2005 | 1870 | 85 | 116 | 1 |
| 2.0 dCi (JK01, JK02, JK1J, JK1K, JK1H) |
M9R 740 M9R 750 M9R 814 M9R 815 M9R 858 |
2 | 01/2006- | 1995 | 110 | 150 | 1 |
| 2.0 dCi (JK02, JK03) |
M9R 740 M9R 750 M9R 760 M9R 761 M9R 762 M9R 763 |
2 | 01/2006- | 1995 | 96 | 131 | 1 |
| 2.0 dCi (JK03, JK04, JK1C, JK1G, JK1J, JK1K) |
M9R 760 M9R 761 M9R 762 M9R 763 M9R 812 M9R 815 M9R 859 |
2 | 01/2006- | 1995 | 127 | 173 | 1 |
| 2.2 dCi (JK07) |
G9T 645 |
2 | 02/2006- | 2188 | 102 | 139 | 1 |
| 2.2 dCi (JK0H) |
G9T 742 G9T 743 |
2 | 11/2002-08/2006 | 2188 | 110 | 150 | 1 |
| 3.0 dCi |
P9X 701 P9X 715 |
2 | 09/2005- | 2958 | 120 | 163 | 1 |
| 3.0 dCi (JK0E, JK0Y) |
P9X 715 |
2 | 01/2006-01/2015 | 2958 | 133 | 181 | 1 |
| 3.0 dCi (JK0J, JK0V) |
P9X 701 |
2 | 11/2002-08/2006 | 2958 | 130 | 177 | 1 |
| Vehicle | Engine | Fuel | Date | CC | KW | CV | Traction |
|---|---|---|---|---|---|---|---|
| 2.0 16V Turbo |
F4R 766 F4R 767 |
1 | 04/2004- | 1998 | 125 | 170 | 1 |
| 2.0 16V Turbo (BJ0K) |
F4R 762 F4R 763 |
1 | 06/2002-08/2009 | 1998 | 120 | 163 | 1 |
| 2.0 Turbo |
F4R 867 |
1 | 04/2005- | 1998 | 108 | 147 | 1 |
| 3.5 (BJ01) |
V4Y 715 |
1 | 10/2004- | 3498 | 170 | 231 | 1 |
| 3.5 V6 (BJ0R, BJ0V, BJ0U) |
V4Y 701 V4Y 711 V4Y 715 |
1 | 06/2002- | 3498 | 177 | 241 | 1 |
| 2.0 dCi (BJ03, BJ0B) |
M9R 760 M9R 762 M9R 763 |
2 | 01/2006- | 1995 | 127 | 173 | 1 |
| 2.2 dCi (BJ0E, BJ0F, BJ0G, BJ0H) |
G9T 600 G9T 606 G9T 607 G9T 700 G9T 702 |
2 | 09/2004- | 2188 | 102 | 140 | 1 |
| 2.2 dCi (BJ0E, BJ0F) |
G9T 702 G9T 703 |
2 | 06/2002-08/2009 | 2188 | 110 | 150 | 1 |
| 2.2 dCi (BJ0H) |
G9T 600 G9T 702 |
2 | 04/2004- | 2188 | 85 | 116 | 1 |
| 2.2 dCi (BJ0M) |
G9T 700 G9T 702 |
2 | 12/2004- | 2188 | 83 | 113 | 1 |
| 3.0 dCi (BJ0J, BJ0N) |
P9X 701 |
2 | 06/2002-06/2006 | 2958 | 130 | 177 | 1 |
