Product 78BD4113-2
- Description
- Brake disc
- Axe
- Front
- No. of Pieces
- 2
- Barcode
-
8424073193414
- Url
- https://catalogonuevo.icerbrakes.com/Producto/Details?idProducto=78BD4113-2
- Weight (gr.)
- 16936
- R90 Homologation
-
90R-02C0452/0130
- Measures
- Ø319x28x67.4
-
Brake Disc Type:
Vented -
Minimum thickness [mm]:
26 -
Hole Arrangement/Number:
6 -
Bolt Hole Circle Ø [mm]:
139.7 -
Wheel Hub Diameter [mm]:
108
| Brand | OE Reference |
|---|---|
| TOYOTA | 435120K090 |
| TOYOTA | 435120K100 |
| TOYOTA | 435120K101 |
| TOYOTA | 435120K140 |
| Maker | Cross reference |
|---|---|
| BOSCH | 0 986 479 G19 |
| BREMBO | 09.B627.10 |
| BREMBO | 09.D617.1X |
| ROAD HOUSE | 62527.10 |
| TEXTAR | 92274903 |
| TRW | DF6726S |
| Vehicle | Engine | Fuel | Date | CC | KW | CV | Traction |
|---|---|---|---|---|---|---|---|
| 4.0 (GRN210) |
1GR-FE |
1 | 11/2002-07/2009 | 3956 | 183 | 249 | 2 |
| Vehicle | Engine | Fuel | Date | CC | KW | CV | Traction |
|---|---|---|---|---|---|---|---|
| 4.0 (GSJ15) |
1GR-FE |
1 | 01/2006-12/2011 | 3956 | 178 | 242 | 2 |
| 4.0 (GSJ15) |
1GR-FE |
1 | 01/2010-06/2014 | 3956 | 191 | 260 | 2 |
| 4.0 (GSJ15) | 1 | 01/2007-12/2014 | 3956 | 194 | 264 | 2 | |
| 4.0 4WD (GSJ15_, GSJ15R) |
1GR-FE |
1 | 12/2010- | 3956 | 200 | 272 | 3 |
| 4.0 4WD (GSJ15_, GSJ15W) |
1GR-FE |
1 | 06/2005-01/2018 | 3956 | 203 | 276 | 3 |
| 4.0 4WD (GSJ15_) |
1GR-FE |
1 | 01/2010-06/2014 | 3956 | 191 | 260 | 3 |
| 4.0 4WD (GSJ15_) |
1GR-FE |
1 | 01/2007-06/2014 | 3956 | 194 | 264 | 3 |
| 4.0 4WD (GSJ15) | 1 | 12/2011-06/2014 | 3956 | 199 | 271 | 3 |
| Vehicle | Engine | Fuel | Date | CC | KW | CV | Traction |
|---|---|---|---|---|---|---|---|
| 2.7 (TGN61_) |
2TR-FE |
1 | 03/2009-05/2015 | 2694 | 116 | 158 | 2 |
| 2.7 4WD (TGN51_, TGN51R) |
2TR-FE |
1 | 06/2004-05/2015 | 2694 | 118 | 160 | 3 |
| 2.7 4WD (TGN51_) |
2TR-FE |
1 | 08/2008-03/2015 | 2694 | 116 | 158 | 3 |
| 4.0 (GGN50_, GGN60_) |
1GR-FE |
1 | 07/2005-05/2015 | 3956 | 175 | 238 | 2 |
| 4.0 4WD (GGN60) |
1GR-FE |
1 | 01/2005-05/2015 | 3956 | 175 | 238 | 3 |
| 2.5 D-4D (KUN60) |
2KD-FTV |
2 | 01/2009-05/2015 | 2494 | 106 | 144 | 2 |
| 2.5 D-4D 4WD (RZN215, KUN50) |
2KD-FTV |
2 | 07/2011-05/2015 | 2494 | 106 | 144 | 3 |
| 3.0 D 4WD (KUN51_) |
1KD-FTV |
2 | 08/2009-05/2015 | 2982 | 126 | 171 | 3 |
| 3.0 D 4WD (KUN51) |
1KD-FTV |
2 | 06/2004-05/2015 | 2982 | 120 | 163 | 3 |
| Vehicle | Engine | Fuel | Date | CC | KW | CV | Traction |
|---|---|---|---|---|---|---|---|
| 2.4 D (LN85_, LN110, LN90) |
2L |
2 | 09/1988-08/1997 | 2446 | 61 | 83 | 2 |
| 2.4 D 4WD (LN105, LN110) |
2L |
2 | 09/1988-08/1997 | 2446 | 61 | 83 | 3 |
| 2.4 D 4WD (LN110_, LN110R) |
2L |
2 | 01/1994-12/1997 | 2446 | 58 | 79 | 3 |
| Vehicle | Engine | Fuel | Date | CC | KW | CV | Traction |
|---|---|---|---|---|---|---|---|
| 2.4 i 4WD (RZN14_, RZN16_, RZN19_) |
2RZ-FE |
1 | 08/1997-10/2005 | 2438 | 103 | 140 | 3 |
| 2.7 EFI 4WD (RZN174, RZN169) |
3RZ-FE |
1 | 11/1997-04/2005 | 2694 | 108 | 147 | 3 |
| 2.4 D (LN150, LN145) |
2L |
2 | 08/1997-04/2005 | 2446 | 55 | 75 | 2 |
| 2.5 D-4D (KDN145, KDN150) |
2KD-FTV |
2 | 11/2001-07/2005 | 2494 | 65 | 88 | 2 |
| 3.0 D 4WD (LN172, LN167) |
5L |
2 | 08/1997-07/2005 | 2986 | 67 | 91 | 3 |
| Vehicle | Engine | Fuel | Date | CC | KW | CV | Traction |
|---|---|---|---|---|---|---|---|
| 2.7 EFI (RZN149) | 1 | 08/2001-07/2004 | 2694 | 107 | 145 | 2 | |
| 3.4 4WD (KYN195) |
5VZ-FE |
1 | 08/2000-07/2005 | 3378 | 131 | 178 | 3 |
| 3.4 EFI 4WD (VZN185) | 1 | 11/1995-07/2000 | 3378 | 136 | 185 | 3 | |
| 2.4 TD 4WD (LN165) | 2 | 08/1997-07/2001 | 2446 | 66 | 90 | 3 |
| Vehicle | Engine | Fuel | Date | CC | KW | CV | Traction |
|---|---|---|---|---|---|---|---|
| 2.7 VVTi (TGN16) |
2TR-FE |
1 | 08/2005-05/2015 | 2694 | 118 | 160 | 2 |
| 2.7 VVTi 4WD (TGN26) |
2TR-FE |
1 | 08/2005-05/2015 | 2694 | 118 | 160 | 3 |
| 2.5 D-4D (KUN15, KUN35) |
2KD-FTV |
2 | 01/2010-05/2015 | 2494 | 106 | 144 | 2 |
| 2.5 D-4D 4WD (KUN25) |
2KD-FTV |
2 | 12/2007-05/2015 | 2494 | 106 | 144 | 3 |
| 3.0 D-4D (KUN16) |
1KD-FTV |
2 | 08/2006-05/2015 | 2982 | 126 | 171 | 2 |
| 3.0 D-4D 4WD (KUN26) |
1KD-FTV |
2 | 03/2005-05/2015 | 2982 | 120 | 163 | 3 |
| 3.0 D-4D 4WD (KUN26) | 2 | 08/2005-05/2015 | 2982 | 124 | 169 | 3 | |
| 3.0 D-4D 4WD (KUN26) |
1KD-FTV |
2 | 08/2005-09/2015 | 2982 | 126 | 171 | 3 |
| 3.0 D-4D 4WD (KUN26) |
1KD-FTV |
2 | 05/2008-12/2012 | 2982 | 145 | 197 | 3 |
| Vehicle | Engine | Fuel | Date | CC | KW | CV | Traction |
|---|---|---|---|---|---|---|---|
| 3.0 D 4WD (KUN26) | 2 | 02/2005-08/2006 | 2982 | 120 | 163 | 3 |
| Vehicle | Engine | Fuel | Date | CC | KW | CV | Traction |
|---|---|---|---|---|---|---|---|
| 2.7 4WD (TGN126_) |
2TR-FE |
1 | 05/2015- | 2694 | 118 | 160 | 3 |
| 2.7 4WD (TGN126_) |
2TR-FE |
1 | 05/2015- | 2694 | 121 | 165 | 3 |
| 4.0 V6 VVTi 4WD (GGN125, GGN135) |
1GR-FE |
1 | 07/2015- | 3956 | 175 | 238 | 3 |
| 2.4 D (GUN112_, GUN122_, GUN135_, GUN120_, GUN135R,... |
2GD-FTV |
2 | 05/2015- | 2393 | 108 | 147 | 2 |
| 2.4 D (GUN112_, GUN122_, GUN135_, GUN120_, GUN135R,... |
2GD-FTV |
2 | 05/2015- | 2393 | 110 | 150 | 2 |
| 2.4 D (GUN135) |
2GD-FTV |
2 | 10/2018- | 2393 | 125 | 170 | 2 |
| 2.4 D 4WD (GUN125_, GUN125R) |
2GD-FTV |
2 | 05/2015- | 2393 | 110 | 150 | 3 |
| 2.4 D 4WD (GUN125_) |
2GD-FTV |
2 | 05/2015- | 2393 | 108 | 147 | 3 |
| 2.4 D 4WD (GUN125) |
2GD-FTV |
2 | 10/2018- | 2393 | 125 | 170 | 3 |
| 2.5 D (KUN112_, KUN122_, KUN135_) |
2KD-FTV |
2 | 05/2015-03/2019 | 2494 | 74 | 101 | 2 |
| 2.5 D (KUN135) |
2KD-FTV |
2 | 05/2015- | 2494 | 106 | 144 | 2 |
| 2.5 D 4WD (KUN125_) | 2 | 08/2015- | 2494 | 75 | 102 | 3 | |
| 2.5 D 4WD (KUN125_) | 2 | 05/2015-08/2017 | 2494 | 106 | 144 | 3 | |
| 2.8 D 4WD (GUN126_) | 2 | 05/2015- | 2755 | 128 | 174 | 3 | |
| 2.8 D-4D (GUN123_, GUN136_, GUN136) | 2 | 07/2015- | 2755 | 125 | 170 | 2 | |
| 2.8 D-4D (GUN123_, GUN136_, GUN136) |
1GD-FTV |
2 | 05/2015- | 2755 | 130 | 177 | 2 |
| 2.8 D-4D 4WD (GUN126_, GUN126R) |
1GD-FTV |
2 | 05/2015- | 2755 | 130 | 177 | 3 |
| 2.8 TD 4WD (GUN126) |
1GD-FTV |
2 | 06/2020- | 2755 | 150 | 204 | 3 |
| 3.0 D 4WD (KUN126, KUN136) | 2 | 08/2015- | 2982 | 120 | 163 | 3 | |
| 3.0 D 4WD (LAN125_) | 2 | 05/2015- | 2986 | 70 | 95 | 3 |
| Vehicle | Engine | Fuel | Date | CC | KW | CV | Traction |
|---|---|---|---|---|---|---|---|
| 2.4 D (GUN112_, GUN122_, GUN135_, GUN120_, GUN135R,... | 2 | 07/2015- | 2393 | 110 | 150 | 2 | |
| 2.4 D 4WD (GUN125_, GUN125R) |
2GD-FTV |
2 | 07/2015- | 2393 | 110 | 150 | 3 |
| 2.8 D-4D (GUN123_, GUN136_, GUN136) | 2 | 07/2015- | 2755 | 125 | 170 | 2 | |
| 2.8 D-4D 4WD (GUN126_, GUN126R) | 2 | 07/2015- | 2755 | 130 | 177 | 3 | |
| 2.8 D-4D 4WD (GUN126) | 2 | 05/2020- | 2755 | 150 | 204 | 3 |
| Vehicle | Engine | Fuel | Date | CC | KW | CV | Traction |
|---|---|---|---|---|---|---|---|
| 3.0 D (KZJ120, KDJ125, KDJ121) |
1KZ-TE |
2 | 09/2002-07/2009 | 2982 | 92 | 125 | 3 |
| 3.0 D-4D (KDJ120, KDJ125, KDJ121) |
1KD-FTV |
2 | 09/2002-08/2009 | 2982 | 120 | 163 | 3 |
| 3.0 D-4D (KDJ120, KDJ125, KDJ121) |
1KD-FTV |
2 | 07/2004-08/2009 | 2982 | 122 | 166 | 3 |
| 3.0 D-4D (KDJ120, KDJ125, KDJ121) |
1KD-FTV |
2 | 09/2002-12/2010 | 2982 | 127 | 173 | 3 |
| Vehicle | Engine | Fuel | Date | CC | KW | CV | Traction |
|---|---|---|---|---|---|---|---|
| 4.0 (GRN225_, GRN265_, GRN270_) |
1GR-FE |
1 | 09/2004-12/2015 | 3956 | 174 | 237 | 2 |
| 4.0 4WD (GRN245_, GRN250_, GRN270_, GLN245L, GLN250L,... |
1GR-FE |
1 | 09/2004-12/2015 | 3956 | 174 | 237 | 3 |
| 4.0 4WD (GRN245) |
1GR-FE |
1 | 09/2004-07/2015 | 3956 | 175 | 238 | 3 |
| Vehicle | Engine | Fuel | Date | CC | KW | CV | Traction |
|---|---|---|---|---|---|---|---|
| 2.7 (TRN245_, TRN265_) | 1 | 08/2015- | 2694 | 118 | 160 | 2 | |
| 2.7 4WD (TRN245) | 1 | 08/2015- | 2694 | 118 | 160 | 3 | |
| 3.5 (GRN325_, GRN330_) | 1 | 08/2015- | 3456 | 207 | 282 | 2 | |
| 3.5 4WD (GRN305_) | 1 | 08/2015- | 3456 | 207 | 282 | 3 |
