Product 78BD4162-2
- Description
- Brake disc
- Axe
- Front
- No. of Pieces
- 2
- Barcode
-
8424073193421
- Url
- https://catalogonuevo.icerbrakes.com/Producto/Details?idProducto=78BD4162-2
- Weight (gr.)
- 18990
- Measures
- Ø319.8x28x43.9
-
Brake Disc Type:
Vented -
Minimum thickness [mm]:
25.4 -
Hole Arrangement/Number:
5 -
Bolt Hole Circle Ø [mm]:
114.3 -
Wheel Hub Diameter [mm]:
68
| Brand | OE Reference |
|---|---|
| RENAULT | 402060003R |
| RENAULT | 402064155R |
| RENAULT | 402065646R |
| Maker | Cross reference |
|---|---|
| BREMBO | 09.B352.10 |
| TEXTAR | 92195403 |
| Vehicle | Engine | Fuel | Date | CC | KW | CV | Traction |
|---|---|---|---|---|---|---|---|
| 1.6 RS (BHJ4, BHJ6, BHMM) |
M5M 400 M5M 401 M5M 450 |
1 | 03/2013-08/2021 | 1618 | 147 | 200 | 1 |
| 1.6 RS Trophy (BHJ4, BHJ6) |
M5M 401 |
1 | 03/2015-08/2021 | 1618 | 162 | 220 | 1 |
| Vehicle | Engine | Fuel | Date | CC | KW | CV | Traction |
|---|---|---|---|---|---|---|---|
| 1.6 TCe 200 |
M5M 450 |
1 | 02/2015-03/2023 | 1618 | 147 | 200 | 1 |
| 1.8 TCe 225 | 1 | 10/2016-03/2023 | 1798 | 165 | 225 | 1 | |
| 1.6 dCi 130 |
R9M 409 |
2 | 06/2015-03/2023 | 1598 | 96 | 130 | 1 |
| 1.6 dCi 160 |
R9M 452 |
2 | 06/2015-03/2023 | 1598 | 118 | 160 | 1 |
| Vehicle | Engine | Fuel | Date | CC | KW | CV | Traction |
|---|---|---|---|---|---|---|---|
| 2.0 dCi (JZ0L) |
M9R 610 |
2 | 04/2009-09/2016 | 1995 | 118 | 160 | 1 |
| 2.0 dCi (JZ0Y, JZ26) |
M9R 615 |
2 | 02/2009-09/2016 | 1995 | 110 | 150 | 1 |
| Vehicle | Engine | Fuel | Date | CC | KW | CV | Traction |
|---|---|---|---|---|---|---|---|
| 1.2 TCe 115 |
H5F 408 |
1 | 09/2016-03/2023 | 1198 | 85 | 115 | 1 |
| 1.2 TCe 130 |
H5F 408 |
1 | 09/2016-03/2023 | 1198 | 96 | 130 | 1 |
| 1.3 TCe 115 (R9N9) |
H5H 450 H5H 470 |
1 | 01/2018-03/2023 | 1332 | 85 | 115 | 1 |
| 1.3 TCe 140 (R9NB) |
H5H 450 H5H 470 |
1 | 01/2018-03/2023 | 1332 | 103 | 140 | 1 |
| 1.3 TCe 160 |
H5H 450 |
1 | 01/2018-03/2023 | 1332 | 120 | 163 | 1 |
| 1.5 dCi 110 (R9A3) |
K9K 646 K9K 647 |
2 | 09/2016-03/2023 | 1461 | 81 | 110 | 1 |
| 1.6 dCi 130 |
R9M 409 |
2 | 09/2016-03/2023 | 1598 | 96 | 130 | 1 |
| 1.6 dCi 160 |
R9M 452 |
2 | 09/2016-03/2023 | 1598 | 118 | 160 | 1 |
| 1.5 dCi 110 Hybrid Assist (R9AE, R9A3) |
K9K 500 K9K 502 |
14 | 04/2017-03/2023 | 1461 | 81 | 110 | 1 |
| Vehicle | Engine | Fuel | Date | CC | KW | CV | Traction |
|---|---|---|---|---|---|---|---|
| 2.0 GT |
F4R 800 |
1 | 03/2008-12/2015 | 1998 | 150 | 204 | 1 |
| 3.5 V6 (BT0C, BT0P) |
V4Y 713 |
1 | 04/2008-12/2015 | 3498 | 175 | 238 | 1 |
| 2.0 dCi (BT01, BT08, BT09, BT0E, BT0K, BT12, BT1C, BT1D,... |
M9R 742 M9R 744 M9R 746 M9R 748 M9R 754 M9R 802 M9R 805 M9R 808 M9R 814 M9R 845 M9R 854 M9R 858 |
2 | 10/2007-12/2015 | 1995 | 110 | 150 | 1 |
| 2.0 dCi (BT07, BT0J, BT14, BT1A, BT1S) |
M9R 742 M9R 744 M9R 802 M9R 814 M9R 854 M9R 858 |
2 | 10/2007-12/2015 | 1995 | 96 | 131 | 1 |
| 2.0 dCi (BT0M, BT0N, BT0S, BT19, BT1F) |
M9R 800 M9R 806 M9R 809 M9R 815 M9R 854 M9R 857 M9R 858 |
2 | 01/2008-12/2015 | 1995 | 127 | 173 | 1 |
| 2.0 dCi GT (BT11, BT1E, BT1N) |
M9R 816 M9R 820 M9R 828 |
2 | 03/2008-12/2015 | 1995 | 131 | 178 | 1 |
| 3.0 dCi (BT03, BT13) |
V9X 791 V9X 891 |
2 | 09/2008-12/2015 | 2998 | 173 | 235 | 1 |
| Vehicle | Engine | Fuel | Date | CC | KW | CV | Traction |
|---|---|---|---|---|---|---|---|
| 2.0 GT |
F4R 800 |
1 | 03/2008-12/2015 | 1998 | 150 | 204 | 1 |
| 3.5 V6 (KT0C, KT0P) |
V4Y 713 |
1 | 04/2008-12/2015 | 3498 | 175 | 238 | 1 |
| 2.0 dCi (KT01, KT08, KT09, KT0K, KT12, KT1D, KT1W) |
M9R 742 M9R 744 M9R 802 M9R 805 M9R 808 M9R 814 M9R 845 M9R 854 M9R 858 |
2 | 10/2007-12/2015 | 1995 | 110 | 150 | 1 |
| 2.0 dCi (KT07, KT0J, KT14, KT1A, KT1S) |
M9R 742 M9R 744 M9R 802 M9R 814 M9R 854 M9R 858 |
2 | 10/2007-12/2015 | 1995 | 96 | 131 | 1 |
| 2.0 dCi (KT0M, KT0N, KT0S, KT19, KT1F) |
M9R 800 M9R 806 M9R 809 M9R 815 M9R 849 M9R 854 M9R 857 M9R 858 |
2 | 01/2008-12/2015 | 1995 | 127 | 173 | 1 |
| 2.0 dCi GT (KT11, KT1E, KT1N) |
M9R 816 M9R 820 M9R 828 |
2 | 03/2008-12/2015 | 1995 | 131 | 178 | 1 |
| 3.0 dCi (KT03, KT13) |
V9X 791 V9X 891 |
2 | 09/2008-12/2015 | 2998 | 173 | 235 | 1 |
| Vehicle | Engine | Fuel | Date | CC | KW | CV | Traction |
|---|---|---|---|---|---|---|---|
| 2.0 16V Turbo |
F4R 811 F4RT 811 |
1 | 09/2008-12/2015 | 1998 | 125 | 170 | 1 |
| 2.0 GT |
F4R 800 |
1 | 09/2008-12/2015 | 1998 | 150 | 204 | 1 |
| 3.5 V6 (DT0P) |
V4Y 713 |
1 | 09/2008-12/2015 | 3498 | 175 | 238 | 1 |
| 2.0 dCi (DT01, DT08, DT09, DT0K, DT12, DT1C, DT1D, DT1M,... |
M9R 744 M9R 748 M9R 754 M9R 802 M9R 805 M9R 808 M9R 814 M9R 845 M9R 854 M9R 858 |
2 | 09/2008-12/2015 | 1995 | 110 | 150 | 1 |
| 2.0 dCi (DT0M, DT0N, DT0S, DT19, DT1F) |
M9R 800 M9R 806 M9R 809 M9R 815 M9R 849 M9R 854 M9R 857 |
2 | 09/2008-12/2015 | 1995 | 127 | 173 | 1 |
| 2.0 dCi GT (DT11, DT1E, DT1N) |
M9R 816 M9R 820 M9R 828 |
2 | 09/2008-12/2015 | 1995 | 131 | 178 | 1 |
| 3.0 dCi |
V9X 891 |
2 | 01/2012-12/2015 | 2998 | 177 | 241 | 1 |
| 3.0 dCi (DT03) |
V9X 791 V9X 891 |
2 | 09/2008-12/2015 | 2998 | 173 | 235 | 1 |
| Vehicle | Engine | Fuel | Date | CC | KW | CV | Traction |
|---|---|---|---|---|---|---|---|
| 3.5 V6 (L700, L701, L706, L708) | 1 | 01/2011- | 3498 | 169 | 230 | 1 | |
| 3.0 dCi 240 (L70G) |
V9X 891 |
2 | 02/2011- | 2998 | 177 | 241 | 1 |
| Vehicle | Engine | Fuel | Date | CC | KW | CV | Traction |
|---|---|---|---|---|---|---|---|
| 2.0 TCe |
F4R 874 |
1 | 09/2012-01/2016 | 1998 | 162 | 220 | 1 |
| Vehicle | Engine | Fuel | Date | CC | KW | CV | Traction |
|---|---|---|---|---|---|---|---|
| 1.6 16V |
H4M 738 H4M 748 H4M 749 H4M 750 H4M 751 |
1 | 11/2015- | 1598 | 84 | 115 | 1 |
| 1.6 TCe 165 |
M5M 450 |
1 | 07/2017- | 1618 | 121 | 165 | 1 |
| 1.6 TCe 205 (B9MV) |
M5M 450 |
1 | 11/2015- | 1618 | 151 | 205 | 1 |
| 1.6 dCi 130 (B9A4) |
R9M 409 |
2 | 11/2015- | 1598 | 96 | 130 | 1 |
| 1.6 dCi 165 |
R9M 452 |
2 | 11/2015- | 1598 | 120 | 163 | 1 |
| Vehicle | Engine | Fuel | Date | CC | KW | CV | Traction |
|---|---|---|---|---|---|---|---|
| 1.6 TCe 165 |
M5M 450 |
1 | 07/2017- | 1618 | 121 | 165 | 1 |
| 1.6 TCe 205 |
M5M 450 |
1 | 04/2016- | 1618 | 151 | 205 | 1 |
| 1.6 dCi 165 |
R9M 452 |
2 | 04/2016- | 1598 | 120 | 163 | 1 |
| Vehicle | Engine | Fuel | Date | CC | KW | CV | Traction |
|---|---|---|---|---|---|---|---|
| 1.2 TCe 115 |
H5F 408 |
1 | 09/2016-07/2022 | 1198 | 85 | 115 | 1 |
| 1.2 TCe 130 |
H5F 408 |
1 | 09/2016-07/2022 | 1197 | 96 | 130 | 1 |
| 1.3 TCe 140 |
H5H 450 H5H 470 |
1 | 01/2018-07/2022 | 1332 | 103 | 140 | 1 |
| 1.5 dCi 110 |
K9K 646 K9K 647 |
2 | 09/2016-07/2022 | 1461 | 81 | 110 | 1 |
| 1.5 dCi 95 |
K9K 646 K9K 846 |
2 | 09/2016-07/2022 | 1461 | 70 | 95 | 1 |
| 1.6 dCi 130 |
R9M 409 |
2 | 09/2016-07/2022 | 1598 | 96 | 130 | 1 |
| 1.6 dCi 160 |
R9M 452 |
2 | 09/2016-07/2022 | 1598 | 118 | 160 | 1 |
| 1.5 dCi 110 Hybrid Assist (R9AE, R9A3) |
K9K 500 K9K 502 |
14 | 04/2017-07/2022 | 1461 | 81 | 110 | 1 |
| Vehicle | Engine | Fuel | Date | CC | KW | CV | Traction |
|---|---|---|---|---|---|---|---|
| 1.6 TCe 150 |
M5M 450 |
1 | 11/2015-03/2022 | 1618 | 110 | 150 | 1 |
| 1.6 TCe 190 |
M5M 450 |
1 | 11/2015-03/2022 | 1618 | 140 | 190 | 1 |
| 1.6 TCe 200 |
M5M 450 |
1 | 11/2015-03/2022 | 1618 | 147 | 200 | 1 |
| 2.0 |
M4R 735 M4R 739 |
1 | 11/2015-03/2022 | 1997 | 103 | 140 | 1 |
| 1.5 dCi 110 (LPA3) |
K9K 646 K9K 647 |
2 | 11/2015-03/2022 | 1461 | 81 | 110 | 1 |
| 1.6 dCi 130 |
R9M 409 |
2 | 11/2015-03/2022 | 1598 | 96 | 130 | 1 |
| 1.6 dCi 160 |
R9M 452 R9M 453 |
2 | 06/2015-03/2022 | 1598 | 118 | 160 | 1 |
| Vehicle | Engine | Fuel | Date | CC | KW | CV | Traction |
|---|---|---|---|---|---|---|---|
| 1.6 TCe 150 |
M5M 450 |
1 | 03/2016-03/2022 | 1618 | 110 | 150 | 1 |
| 1.6 TCe 200 |
M5M 450 |
1 | 03/2016-03/2022 | 1618 | 147 | 200 | 1 |
| 1.5 dCi 110 |
K9K 646 K9K 647 K9K 648 K9K 649 |
2 | 03/2016-03/2022 | 1461 | 81 | 110 | 1 |
| 1.6 dCi 160 |
R9M 452 R9M 453 |
2 | 03/2016-03/2022 | 1598 | 118 | 160 | 1 |
